Aquaporin A2O Pure User manual

A2O Pure, UTS-800 Use and installation manual
2

A2O Pure, UTS-800 Use and installation manual
3
For the most updated installation manuals in
more languages, go to Aquaporin.com/installation or
contact the store where you bought your machine.
A2O Pure
Use and installation manual
Control via app 4
About A2O Pure 5
Dimensions and weight 9
List of included components 10
Installation scheme 11
How to install 12
Operating instructions 21
Replacement of cartridges 24
Maintenance 27

A2O Pure, UTS-800 Use and installation manual
4
Control
via app
Aquaporin
Connect with your purifier
Connect your A2O purifier with your
smartphone to manage and track your water
usage in real time.
Receive updates
Receive recommendations to ease the use of
your A2O purifier and get a reminder when
it’s time to change filters.
Track usage
Creates transparency between you and your
A2O purifier by allowing tracking of your
water usage. Monitor filter lifetime, next
maintenance, and the effectiveness of the
purification of the purifier.
Access information
Access manuals, installation guides, and
useful information about water.

A2O Pure, UTS-800 Use and installation manual
5
About
A2O Pure
The A2O Pure is a direct flow water filtration
system with Aquaporin Inside® technology.
The system can be used wherever traditional
reverse osmosis (RO) systems or other types
of water filtration system reach their limits.
The Aquaporin Inside® Drinking Water
Membrane (DWRO®) uses unique “made by
nature” proprietary membrane technology to
remove PFAS, heavy metals, microplastics,
bacteria, viruses, hormones, nitrates,
limescale and other harmful substances.
Input water limitations
Feedwater temperature (min. / max.) 5–25°C
Inlet pressure (min. / max.) 1–6 bar
Feedwater Quality Municipal tap water
System/technical details
A2O Pure
Model Name UTS-800
Product Category Under-the-sink
Filter cartridges
Number Name Material Lifetime
1. Pre-filter PP cotton + Activated carbon 12 months or 4,500 L
2. Post-filter Activated carbon 12 months or 4,500 L
3. DWRO® Aquaporin Inside® membrane 24 months or 7,000 L

A2O Pure, UTS-800 Use and installation manual
6
Technical data
Flow rate of filtered water12.1 L/min
Water recovery rate266% (2:1)
Membrane capacity 800 GPD
Salt retention295-98%
Electrical connection 100 - 230 V
Power consumption (operation) 95 W
Power plug standard EU
Noise level 53 ±1 dB
WiFi connection + app Yes
Leak detector Yes
Membrane flushing (auto-cleaning) Yes
Feedwater, permeate and wastewater connections 3/8, 1/4, 1/4 inch
Dimensions (W×D×H) 315 × 203 × 427 mm
Weight 8.57 kg
Compliance CE, EUFCM
1The flow rate is tested at 25 °C; lower water temperatures will reduce the flow rate
2The system is influenced by feedwater conditions such as pressure, temperature, TDS levels, and hardness.
The better these incoming conditions, the better performance. Depending on local water quality and use
environment, the lifetime of the filters, flow rate, recovery rate and salt retention rate will vary.

A2O Pure, UTS-800 Use and installation manual
7
General Information
The manual contains important instructions
for safe and efficient use of the A2O Pure,
UTS-800. This manual is part of the device
and must be constantly available at the place
of operation.
Installation or maintenance done on this
system by an untrained service person
can cause major damage to equipment or
property damage.
Description of symbols listed
The manual uses the following symbols. The
warnings/instructions are introduced by
signal words to underline risks. The warnings/
instructions absolutely must be complied
with. The operator must act carefully to avoid
accidents and property damage.
Danger: Electric current or voltage!
Always consult a qualified electrician
when working on places denoted by
this symbol.
Attention: Dangerous spot! Details
or orders and prohibitions to avoid
personal injury or extensive damage
to property
Observe: Underlines useful
recommendations and information
for an efficient operation free of any
interruptions.
Warranty and disclaimer
Observe: The information and
instructions contained in the
manual were compiled based on
current standards and regulations,
the state of the technology, our
experiences, and observations.
The warranty is void in any of the following
cases:
-Failure to follow the provisions and
information in this guide
-Improper use
-Improper or faulty installation
-Improper start-up, operation, or
maintenance
-Use of non-approved components or
nonoriginal parts
-Neglecting to perform the required
service and replacement tasks
Technical modifications: damage, faults
and stoppages resulting from unauthorized
alterations
Responsibilities of the operator
-The manual must be easily accessible
and kept in the immediate vicinity of the
device.
-The device must be operated in a
technically faultless and operationally
safe condition only.
-The provisions in the manual are to be
followed absolutely.

A2O Pure, UTS-800 Use and installation manual
8
Operating and safety notes
Overview of all operational and safety aspects
that are considered important for ensuring
safe and fault-free operation. Despite all
possible precautionary measures, some
residual risk remains with any product,
especially if it is used improperly. Warranty
claims are void unless the provisions in this
manual are observed and followed.
Proper use
The system is suitable for filtration of drinking
water quality at up to max. 25 °C and an inlet
pressure of max. 6 bar.
Observe: The feedwater must not
exceed the limit values given in the
technical data sheet – page 5.
The system shall only be used for its intended
purpose as designed and as described here
in this manual. Any other use is considered
“improper”.
Warning! The system must be fed
only with cold drinking water.
Permissible operation method
Observe: To protect the drinking
water, observe the country-specific
guidelines for drinking water
installations in any work on the
system.
-The system must be disconnected prior
to performing any maintenance work on
the drinking water supply. Rinse the water
pipe sufficiently before reconnecting the
device.
Observe: Improper installation of the
system may cause damage to it.
-Observe any country-specific installation
regulations (such as DIN 1988, EN 1717),
general hygienic conditions and technical
data for protecting the drinking water.
-Unauthorized modifications to the system
and technical alterations are not permitted.
-Avoid mechanical damage to the system.
Otherwise, the warranty is void.
-Install a stop valve upstream of the system.
-All materials in contact with filtered water
must be corrosionresistant.
-The device may not be installed in the
vicinity of heat sources or open flames.
-The system may not come into contact
with chemicals, solvents, or vapors.
-The installation site must be free of frost
and protected from direct sunlight.
-The system may not be operated with
feedwater that is microbially contaminated,
whose origin or quality is unknown, or
similar.
-A water softener is strongly recommended
for water > 15 °dH. Installing a system with
hardness higher than 15 °dH will reduce
life of the system and filters.
-Avoid leaving the system in storage for
a long time to reduce the risk of idle
contamination.
Impermissible operating methods
Attention: Danger through improper
use! Claims for damages resulting
from improper use are void.
Danger: Always disconnect the
power supply of the unit by removing
the plug or fuse if hard wired during
any maintenance and electrical work.

A2O Pure, UTS-800 Use and installation manual
9
Dimensions
and weight
Net weight: 8.57 kg
427 mm
315 mm
315 mm
203 mm
203 mm

A2O Pure, UTS-800 Use and installation manual
10
Push-in
fitting
1×
Machine incl. filters
1×
PE pipe
1/4″
1×
PE pipe
3/8″
1×
List of included components
T-piece with ball
valve, G½ x G½
Local size variations may
occur - please check
with your local dealer.
1×
DRAIN CLAMP KIT
Drain clamps
1×
Screw + nut
2×
Gasket
1×
Pressure reducer
incl. check valve
1×
Tools
required for
installation
11 mm key
or flexible
spanner
Flat and
Phillips
screwdriver
Pincer Electrical drilling
machine (6 mm
and 12 mm drill)
Faucet
1×
Spacer
1×
Upper white
gasket
1×
Lower black
gasket
1×
Plastic nut
1×
2C
76
2B
5
2A
4
1
3
8A 8B 8D8C 8E

A2O Pure, UTS-800 Use and installation manual
11
Wastewater
Inlet water
Pure
water
Pure water
Water
source
Inlet water
(tap water)
The pressure reducer
including check valve
for backflow prevention
must be applied.
Faucet
Drain
pipe
Wastewater
Installation scheme

A2O Pure, UTS-800 Use and installation manual
12
How to install
Before you start, please be sure to clean your
hands thoroughly as well as any tools used
during the installation of your purifier.
The installation will take approximately one
hour.
Before installation, ensure that the cold water
valve is turned off/closed.
TURN
OFF
Note that the length of the 1/4″PE pipe is
3 meters. This length is to be used for
multiple connections so use only what you
need for each connection and save the
remaining for later installation steps.
When you cut the PE pipes be aware that the
pipe is not compressed when you insert it into
connections.
Before installation, remove the white IN and
OUT plugs as well as the DRAIN plug. Keep
the plugs as they will be reused if the device
is relocated.
How to remove the plugs
1. Use a flat device, e.g. a screwdriver to push
down the grey release collar.
2. You can now pull the plug upwards with
your fingers.
Note that there might be a release of air when
removing the plugs.
1
2

A2O Pure, UTS-800 Use and installation manual
13
1/5
Drain installation
Drill ø 6 mm
2A
2B
2C
Add the gasket between the
drain clamps and the drain
pipe.
Gasket
2/5
4
3/5 4/5
Insert the 1/4″PE pipe so that approximately
2 cm will be going into your drain pipe.
Tighten the clamp with the
Phillips screwdriver.
~ 2 cm

A2O Pure, UTS-800 Use and installation manual
14
Wastewater
5/5
Cut the 1/4″PE pipe to fit the installation and
insert it into the wastewater connection on
the machine.
4

A2O Pure, UTS-800 Use and installation manual
15
Inlet installation
1/6 2/6
3/6
Unscrew the nut from the ball valve. Insert the 3/8″pipe onto the ball valve.
Tighten the nut with a
flexible spanner.
5
4/6
Cold water
pipe
Connect the T-piece
with ball valve on your
cold water pipe.
7

A2O Pure, UTS-800 Use and installation manual
16
5/6
Cut 5 cm of the 3/8″PE pipe
with a pincer and insert it in
the pressure reducer.
Insert a new 5 cm piece of 3/8″
PE pipe at the other end of the
pressure reducer.
Note that the direction
of the pressure reducer!
The arrow should be
pointing towards the
A2O (away from the inlet
water ball valve).
Blue
Yellow
5
3
6/6
Cut the length of the 3/8″PE pipe to fit
your installation.
Insert the 3/8″mm PE pipe to “inlet water”
on A2O.
Inlet water
5

Rubber cover
A2O Pure, UTS-800 Use and installation manual
17
Faucet
installation
1/3
Drill ø 12 mm
Drill a hole adjacent to your
regular faucet.
2/3 3/3
Assemble
and tighten with
your hands (no
use of tools).
Remove the rubber cover from
the faucet.
8C
8D
8E
8A
8B

A2O Pure, UTS-800 Use and installation manual
18
Pure water
installation
Push the push-in fitting onto the
bottom end of the faucet.
Insert a new piece of the 1/4″PE pipe in the
other end of the push-in fitting.
Cut the length of the 1/4″PE pipe to fit your
installation and insert it into the pure water
connection on the machine.
1/2
2/2
6
8
4
Pure water

A2O Pure, UTS-800 Use and installation manual
19
Connect A2O Pure to your power supply
Connect
power
2/2
Turn on the water.
WARNING: Check
for leakages before
proceeding.
TURN
ON
1/2

A2O Pure, UTS-800 Use and installation manual
20
Complete the
installation
The lights on the top panel will blink and you
hear a “ding” sound, and you can hear the
water flowing into your machine.
Once the lights on the top panel stop blinking,
open your faucet and check for leakages.
After installing your A2O Pure or replacing
the cartridges, the system must be flushed
before consuming the water – note that
the first water coming out will be black.
As our DWRO® membranes are constantly
improving in quality and technology, we
advise you to find the updated flushing times
at www.aquaporin.com or contact your local
dealer.
Enjoy.
