Aquatec Equipment PondMAX ULTRA Series User manual

INSTRUCTION MANUAL
1 LED WARM POND/GARDEN LIGHT
– ULTRA SERIES –

ThankyouforpurchasingaqualityPondMAXproduct!DESCRIPTION AND FEATURES
YourPondMAX1LEDWarmPond/GardenLighthasbeenmanufacturedwithadvancedtechnologyandqualitymaterialstoideallyintegrateintoanypondandgardenscene,thankstotheircompactdesign.•ThePondMAXlighthasaglasslensandissuitableforuseinoroutofwater.•ThehighpowerenergyefcientLEDemitsanaturalwarmlightprovidingyearsofmaintenancefreesatisfaction.•The240Vtransformer(notincluded)convertsthepowersupplytoasafe12voltsforpeaceofmindinyourpondorgarden.(RecommendedTransformer:04ST026-6VA500mA,singlelightonly)INSTALLATION
•Ifrequired,haveaqualiedelectricianinstallaweatherproofpowerpointneartothepondorgarden,withinreachofthetransformerandlight.•Mountthetransformerinadryandprotectedlocationmakingsurethatitcan’tbewetbyeitherrainorreticulation.•Forpondinstallationslidetheweightedbaseintothecircularrecessontheundersideofthelightbody.PositionthelightinthedesiredlocationtakingcarenottowettheBi-pinplugattheendofthecable.•Forgardeninstallationslidethegardenspikeintothecircularrecessontheundersideofthelightbody.Holdingthelightbodyrmly,pushthelightwithattachedspikeintothedesiredlocationtakingcarenottopenetrateanyhiddenservices.•Adjustthelightuntilfacinginthegeneraldirectionofthefeatureyouwishtoilluminate.Werecommendnaladjustmentsbecarriedoutatnight.•InserttheBi-pinmaleplugontheendofthelightcableintothetransformerandtightenthelockingcollarrmly.Thetransformercannowbeturnedon.1 LED WARM
VOLTAGE(V)12POWER(W)1.8CABLELENGTH(m)51 LED WARM POND/GARDEN LIGHT
– ULTRA SERIES –

•Onceinthecorrectpositionlockthelightbytighteningthethumbscrews,takingcarenottoovertighten.•MultiplelightscanbewiredtothesametransformerusingourPondMAX3and5WayConnectors.Alargertransformerisrequired(04ST016–20.4VAforupto5lights).MAINTENANCE
ThereisminimalmaintenancerequiredonthePondMAXLEDpondlights.Thelightshouldbeinspectedonaregularbasistoensurethelightorcableisnotdamagedinanyway.Cleanthelensonthelightregularlyformaximumefciency.IMPORTANT SAFEGUARDS
Toguardagainstinjury,basicsafetyprecautionsshouldbeobservedincludingbutnotlimitedtothefollowing;•Thelightshouldonlybeusedincleanwater.Donotusethelightinanysolventorammableliquids.Donotuseinchlorinatedorsaltwater.•Donotoperatethelightifthelightoranyofthecomponentsofthelightsuchasthepowercableortransformerhavebeendamaged.•Ifthe240Vplugsupplyingthetransformergetswet,donotunplugthecord.Disconnectthecircuitbreakerthatsuppliespowertothepoweroutlet.Thenunplugandexaminetheplugandpoweroutletforpresenceofwater.Ifthepoweroutlethasbecomewet,youshouldconsultanelectricianbeforeusingtheagain.•AlwaysuseaproperlygroundedpowersupplythatisconnectedtoanRCDwitharatedresidualoperatingcurrentnotexceeding30mAasperAS/NZS3350.2.41:1997.•Alwaysunplugthelightfromthepowersupplywhennotinuseorbeforeperforminganymaintenance.Neverpullthetransformercordtodisconnecttheplugfromthepowersupply.Grasptheplugandpulltodisconnect.1.LightBody2.WeightedBase3.GardenSpike4.ThumbScews1 2
4
3
Parts View

•Donotinstallorstorethelightwhereitwillbeexposedtoextremehotorcoldtemperatures.•Keepoutofreachofchildrenorpets.Thisapplianceshouldnotbeusedbychildrenorinrmpersonswithoutsupervision.•Donotcutthecordasthiswillresultinvoidingyourwarranty.•Careshouldbetakentoarrangethepowercordsothatitcannotbeaccidentlytrippedoverorpulled.•Donotattempttorepairthelightyourself.Returntoanauthorizedservicecentreorplaceofpurchaseifafaultoccurs.•Donotuseinwaterabove35°C.WARRANTY AGAINST DEFECTS
Thisproductcomeswithawarrantyagainstdefects(Warranty).ThebenetsprovidedinthisWarrantyareinadditiontootherrightsandremediesavailabletoyouundertheAustraliaConsumerLaw.TheWarrantyisprovidedtotheoriginalpurchaseroftheproductonthefollowingterms:•TheWarrantyisgivenbyChemkayPtyLtdtradingasAquatecEquipment:PoBox2087,SevilleGrove,WA6112;contactablebyphone(1300552202)oremail([email protected]).•TomakeaclaimundertheWarrantyyoumustreturnthefaultyproducttotheplaceofpurchasewithavalidreceiptorproofofpurchase.•AWarrantyclaimmustbemadewithin2yearsofthedateofpurchase.•IfyourclaimcomplieswiththeabovetermsandtheproductisnotanExhaustibleItemandnoVoidingEventshaveoccurred,wewill(atoursolediscretion):-repairtheproduct,ifpossible;or-provideareplacementproduct;or-ifareplacementproductisnotavailable,providearefundforthepurchasepricepaid.•YouwillbearthecostassociatedwithclaimingundertheWarrantysuchasthecostoftransportationanddeliveryoftheproducttoandfromtheplaceofpurchase.•TheWarrantywillbevoidifanyofthefollowingeventsoccur,asdeterminedbyus,atoursolediscretion(VoidingEvents):-anytampering/removalofwarranty/identicationlabelsorelectricalcomponentsisevident;-thedefecthasarisendueto:anaccident,incorrectorinadequateinstallation,misuseorabuseoftheproduct(includingimpropermaintenanceandservice),excessivewearandtear,notfollowingmanufacturer’sguidelines/instructions,ortheproducthasbeenusedinamannercontrarytothepurposeorsuitabilityoftheproduct;-theproducthasbeenmodiedwithoutourauthority;-thedefectiscausedbypowersurges/spikes/brownouts.•Lossoflivestock,damagetopropertyorpersonalinjurycausedbytheimproperuseorabuseoftheproductwillnotbecoveredandthemanufacturerexcludesallliabilityforsuchevents,totheextentpermittedbylaw.InadditiontotheWarrantysetoutabove,ourgoodscomewithguaranteesthatcannotbeexcludedundertheAustralianConsumerLaw.Youareentitledtoareplacementorrefundforamajorfailureandforcompensationforanyotherreasonablyforeseeablelossordamage.Youarealsoentitledtohavethegoodsrepairedorreplacedifthegoodsfailtobeofacceptablequalityandthefailuredoesnotamounttoamajorfailure.E.&0.E.
