ARCHPOT APF Operating instructions

APF Manual Burner System
Installation and Operation Guide
Table Of Contents
Gas Requirements
Archpot Fire Burner System
Product Installation
Product Maintenance
Product Operation
Warranty
2
3
4
6
7
8
ATTENTION: Please carefully read this instructions prior to installing your APF Manual
Burner System. Failure to adhere to these instructions may result in a possible re
hazard, explosion, property damage, serious injury or loss of life. Do not discard this
installation guide, it must remain with re feature.
ATTENTION: Installation and service must be performed by a qualied gas installer,
service agency or gas supplier. Your installer must follow these instructions
carefully. Architectural Pottery and their aliates are not responsible for the actions
of the installer or misuse of products.
California Residents Prop 65 Warning: Operating, servicing and maintaining this appliance can expose you to chemicals including carbon
monoxide and brass which are known to the State of California to cause cancer, birth defects or other reproductive harm.
For more information go to www.Prop65Warnings.ca.gov

Description BTU Rating Gas Inlet Size
12” Round Duel Burner, 304 Stainless Steel Up to 90,000 1/2” Female NPT
18” Round Duel Burner, 304 Stainless Steel Up to 125,000 1/2” Female NPT
24” Round Duel Burner, 304 Stainless Steel Up to 150,000 1/2” Female NPT
30” Round Triple Burner, 304 Stainless Steel Up to 175,000 3/4” Female NPT
WARNING!
If you smell gas, immediately take the following actions:
1. Do not attempt to ignite your appliance.
2. Shut o the gas to the appliance.
3. Extinguish any open ame near the unit.
4. If odor lingers, call your gas supplier or local re department.
• Do not store or use any gasoline or other ammable vapors and/or liquids in the
vicinity of this or any other appliance.
• Never attempt to burn wood or any other ammable materials in this re feature.
2
Gas Requirements
Gas Pressure (Nominal)
Natural Gas 7” wc
Propane 11” wc

ARCHPOT FIRE BURNER SYSTEMS
THE COMPLETE MODERN SOLUTION
PRECISION DRILLED HOLES FOR BETTER PERFORMANCE
DURABLE CONSTRUCTION
HEAVY GAUGE 304 STAINLESS STEEL BURNER PLATE
ARCHPOT FIRE MANUAL BURNER SYSTEM INCLUDES:
• 304 Stainless Steel Burner • Heavy Guage 304 Stainless Steel Support Plate
• Key Valve Assembly • Flex Line x2 • Mounting Bracket (for select models)
3
ARCHPOT FIRE BURNER SYSTEMS FOR ROUND, SQUARE AND LINEAR FIRE VESSELS
2 Piece APF Mounting Bracket
(for select models)
Whistle-Free Flex Line x2

WARNING! This unit is for outdoor use only.
• Do not install near any combustibles such as wood structures, fuels, clothing, fabrics, or dry vegetation.
• Installation shall be performed by a licensed contractor. All aspects of installation must conform to local
or national codes, or in the absence of codes, with Natural Fuel Gas Code ANZI Z223.1.
• An approved gas valve or keyed valve shall be installed in the decorative bowl or upstream of the unit and
located in an accessible area that is within 5ft from the APF Manual System.
Note: All APF Manual Systems includes pre-installed key valve, unless otherwise specied.
• The approved gas valve must be located where they can be easily accessible so that the gas can be shut o
quickly in case of an emergency.
Installation
1. Install the Fire Feature as shown in Figure 1 and Figure 2.
2. 24”- 60” Geo Round, 24”- 48” Legacy Round, 24”- 36” Geo Square, 30”- 36” Legacy Square requires
installation of the APF Mounting Bracket to secure the vessel and allow for ventilation and drainage. Install
the mounting bracket as shown in Figure 1. Using appropriate anchor bolts, (not supplied), secure the APF
bottom bracket to a suitable, stable permanent surface. Place the GFRC vessel over the bottom bracket so the
all thread is accessible from top of vessel. Attach the APF top ring bracket using the supplied bolts. Do not seal
open space between mounting bracket and vessel. Warranty is voided if the mounting bracket is not installed
on required models.
Product Installation 4
Figure 1
ANCHOR BOLTS (NOT SUPPLIED)
GFRC VESSEL
NOTE: Drainage MUST be provided in the bottom of each bowl.
APF BOTTOM
MOUNTING BRACKET
APF TOP
RING BRACKET
SUPPLIED NUTS
AND WASHERS

3. The natural gas source line must be installed underground between each vessel, as shown in Figure 2.
4. The natural gas source line must be reduced to 1/2” NPT for re tables 42”+ and 3/8” NPT for re vessels 24” - 36”.
5. Using pipe sealer, attach supplied ex line to natural gas source line. Then attach the other end of the ex line to
key valve assembly. Do not kink or make a tight radius bend on the gas hose.
6. From Key Valve Assembly connect Flex Line to the Burner Assembly.
7. Check all gas connections tight, position the burner assembly so that it sits level in the bowl.
Rotate as required so that the gas hose rests in a compact position.
Figure 2 5
DRAIN
BURNER RING
SUPPORT
PLATE
LEDGE
SUPPORT PLATE
NATURAL GAS SOURCE LINE
KEY VALVE
ASSEMBLY
FLEX LINES
MOUNTING BRACKET
Key Valve Assembly
(Inside View)
Key Valve Assembly
(Outside View)
NOTE: Leak Test – it is highly recommended to perform a gas leak test at this point in the install.
Turn on the gas supply and then, using a soapy water solution spray on the gas line connections
to ensure no leaks exist.

• Clean the burner assembly and bowl with a wet cloth or cleaning solution to remove carbon build-up,
frequency of the cleaning will depend on usage.
• Inspect the gap between the base of the bowl and the mounting bracket. It should be kept free of dirt and debris
that may restrict ventilation and drainage (see Figure 3).
• Periodically inspect the underside of the burner assembly for any signs of excessive temperatures.
Check that all gas connections are tight.
• The vessel and burner assembly should be covered and protected from extreme weather conditions.
• The burner should not be operated in high wind conditions.
Note: If any problems occur, consult a licensed heating professional or call Architectural Pottery.
Product Maintenance 6
Figure 3
KEEP SPACE BETWEEN GFRC
VESSEL AND MOUNTING
BRACKET CLEAR OF DEBRIS.
DO NOT SEAL.
CAUTION! Use only approved decorative media to cover the burner assembly.
Architectural Pottery Tumbled Lava Rock and Fire Glass are accepted media. Use
caution when in the immediate area, as pieces may pop or explode when exposed to
heat or moisture.

WARNING!
This unit is for outdoor use only.
For Your Safety
• If you smell gas, shut o the gas valve immediately.
• Extinguish any open ame.
• If odor continues, immediately call your gas supplier.
• Do not store or use gasoline or other ammable vapors and/or liquids in the vicinity of this appliance.
• Do not leave ame on while unsupervised.
• Do not operate in windy or rainy conditions.
• Unit should be operated only by a responsible adult.
• When in use, an open ame is present; therefore, use with extreme care and at your own risk.
• Before any inspection of the unit, always turn o gas supply.
• If you experience problems with this unit, call Architectural Pottery or a licensed heating professional.
• All work on this unit must be performed by a licensed heating professional.
Product Operation 7
• With the unit in o position check for gas smell or leaks.
• Using the key, open valve approximately 50%
• Stand back and quickly light burner with extended BBQ lighter.
• Adjust ame as desired for safe use.
• To extinguish ame use key to turn o valve.
Operating Instructions
CAUTION! Before you turn on the APF Manual System, make sure that features are clear of
people, animals, or any objects that are combustible.

Product Warranty 8
Terms and Conditions:
1. Prices are subject to change without notice. All dimensions shown in this catalog are approximates.
2. All orders require a 50% deposit, balance paid in full before shipment, including freight and handling
charges. Once production has started, deposit is non refundable.
3. All orders are shipped FOB Midway City. Freight collect or third party billing allowed. Architectural Pottery
provides local delivery service at rates based on the size of the order and the distance.
4. Architectural Pottery assumes no risk or damage incurred in transit, except orders delivered locally by
Architectural Pottery’s delivery service. All items are shipped at purchaser’s risk. Any claims for loss or
damage sustained in transit must be filed with carrier immediately.
5. All sales are final. No refunds. Exchanges for equal value or higher with prior approval. A restocking
charge will apply.
6. All sales are made pursuant to these conditions and orders are received with the understanding that they
are placed under these conditions.
APF Manual Burner System One Year Warranty:
Architectural Pottery warrants its products, when purchased new, to be free from defects in
materials and workmanship under normal use and service for one year, from the original date
of purchase. Replacement or repair at the option of Architectural Pottery.
[phone] • archpot.com
