ARC-1464-WP Wall Plate Audio Amplifier with CSR B/T Wireless v5.0 User Manual
FEATURES
B/T v5.0 with apt-X
24W class-D high quality power amplifier
Compact size wall plate design
Easy installation
Configurable Device Name & PIN Code
SPECIFICATIONS
Audio Inputs :B/T Receiver or stereo audio line level
B/T Version: B/T v5.0 compliant with apt-X
B/T Receive Distance:30 Meters (open space)
Power Amplifier Type :Stereo Class-D
Output power:24W(rms) per channel (@ RL=4 ohm)
THD+N :0.1 % (@ RL=4 ohm, f = 1 kHz)
Minimum Load Resistance :4 ohm
Includes Speaker Protection circuit.
Power Source:24 VDC
3 min link-lost timeout function.
B/T automatically switch to pairing state if
reconnecting fail.
Audio priority: B/T > Aux In
CONNECT AND OPERATE
STEP 1: Install the unit in wall and connect power and speaker cables
STEP 2: Turn on the rotary switch to power up
STEP 3: B/T status LED quick blinking in open paring mode, connect your B/T devices to B/T Audio Amplifier
STEP 4: For Aux-In source, plug-in audio cable and play. The unit will automatically switch between B/T and Aux-In

Configure Device Name & PIN Code
STEP1: Connect the USB TTL Cable to the computer’s USB port and then connect the other end of the cable
to the Micro USB Port on the ARC-1464-WP
STEP2: Launch the A-1464WP Configuration Tool software.
STEP3: Select corresponding Com Port
STEP4: Enter New Device Name

STEP5: Write to device
STEP6: Confirm the Bluetooth Device name with Smartphone. If name is not changed. Make sure USB TTL
Cable is connected to the Micro USB Port on the A-1464WP and go back STEP1 -STEP5
STEP7: Enter New Pin Code
STEP8: Write to device
STEP9: Confirm the Bluetooth Pin Code with Smartphone. If Pin Code is not changed. Make sure USB
TTL. Cable is connected to the Micro USB Port on the A-1464WP and go back STEP7 –STEP8
