Arda range hood User manual
Page 16 - Warranty & Registraon
Page 2 - Safety Informaon
Owner’s Manual
Range Hoods
Page 4 - Wall Mount Hoods
Page 8 - Island Mount Hoods
Page 12 - Use & Care instrucons
Pour version française, visitez notre site à l’adresse www.ardaappliances.com
We do the utmost to ensure that the provided informaon is complete and accurate; however, images and
specicaons are subject to change without noce. Visit our website at www.ardaappliances.com
for the latest version of this manual.
- 2 -
TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR PERSONAL INJURY,
PLEASE OBSERVE THE FOLLOWING:
1. Installaon and electrical work must be done by a qualied TECHNICIAN in
accordance with all applicable codes and standards.
2. If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or a similarly qualied person to avoid a hazard. Any
modicaons that may be required to the home’s electrical system for the
installaon of the range hood must only be made by qualied electricians.
3. Before servicing or cleaning unit, switch power o at the service panel.
Lock panel to prevent power from being switched on accidentally.
4. Use this unit only in the manner intended by the manufacturer.
5. Sucient air is needed for combuson and exhausng of gases through the
chimney of fuel burning equipment to prevent back draing. Follow the
heang equipment manufacturer’s guidelines and safety standards such as
those published by the Naonal Fire Protecon Associaon (NFPA), and the
American Society for Heang, Refrigeraon and Air Condioning Engineers
(ASHRAE), and the local code authories.
6. When cung or drilling into wall or ceiling, be careful NOT to Damage
exisng electrical wiring and other hidden ulies.
7. Ducted fans must always be vented to the outdoors.
8. To reduce the risk of re, use only metal ductwork.
9. This unit must be grounded.
!
We do the utmost to ensure that the provided informaon is complete and accurate; however, images and
specicaons are subject to change without noce. Visit our website at www.ardaappliances.com
for the latest version of this manual.
- 3 -
TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A RANGE
TOP GREASE FIRE, OBSERVE THE FOLLOWING:
1. SMOTHER FLAMES with a close-ng lid, cookie sheet or metal tray, and
then turn o the burner. If the ames do not go out immediately, evacuate
and call the re department.
2. NEVER PICK UP A FLAMING PAN. – You may be burned.
3. DO NOT USE WATER, including wet dishcloths or towels – a violent steam
explosion may result.
4. Use an exnguisher ONLY if:
• You know you have a Class ABC exnguisher and you already know how
to operate it.
• The re is small and contained in the area where it started.
• The re department is being called.
• You can ght the re with your back to an exit.
1. To reduce the risk of re and to properly exhaust air, be sure to duct air
outside. Do not vent exhaust air into spaces within walls, ceilings or into
acs, crawl spaces or garages.
2. Take care when using cleaning agents or detergents.
3. Avoid using food products that produce ames BENEATH the range hood.
4. The range hood must only be used for the exhausng of cooking fumes in
DOMESTIC kitchens. The manufacturer disclaims all liability for any other
use of the appliance.
5. Two installers are recommended because of the large size and/or weight of
this hood.
6. Only use with 110/120V power plug provided.
7. Please read specicaon label on product for further informaon and
requirements.
!
We do the utmost to ensure that the provided informaon is complete and accurate; however, images and
specicaons are subject to change without noce. Visit our website at www.ardaappliances.com
for the latest version of this manual.
- 4 -
1. Read this manual carefully and completely.
2. ARDA range hoods conform to ETL/CSA standards. Check your local
building codes for any addional requirements.
3. The appliance has been manufactured as Class I, therefore a
ground connecon is necessary. A 110/120V power cord with plug is
provided. The range hood must be installed so that the plug is easily
accessible (Fig. 1).
4. If appliance has been designed for use in both ducted and
recirculang modes, follow the appropriate installaon method. (For
recirculaon mode a kit is required – not included. Contact
Integrated Appliances, Ltd. to determine if a kit is available for your
hood.)
1. Measure:
a. The oor to ceiling height (A - Fig. 2).
b. Find the centre point of your opening. Mark a plumb line (B) through this point from ceiling to
your range/cook-top.
c. Check your range/cook-top user manual for the specied minimum and maximum distance
above your cooking surface. Mark the minimum clearance (C) on the centre line.
2. Decide where the ductwork will run between the hood and the outside. Short, straight duct
runs will provide the most air ow.
3. Installing a cross brace within the wall at the mounng height is recommended (see Step D -
Mounng Height Calculaon & Cross-Bracing Installaon).
4. Decide where to install the 110/120V receptacle within the dimensions of the decorave
chimney.
5. Calculate the required height of the decorave chimney. ARDA range hoods will usually t on
walls between 7½’ and 8 ½’ depending on the mounng height of the range hood. For a shorter
installaon you may need to have the provided chimney cut. For a taller installaon you may need
to fabricate an extension piece.
A - Floor to Ceiling height
B - Ceiling to Cooking Surface (center/plumb line) height
C- Cooking surface to boom of hood height
Outlet Cover
Grounding Pin
Grounded Outlet Plug
Fig. 1
A
C
B
Fig. 2
We do the utmost to ensure that the provided informaon is complete and accurate; however, images and
specicaons are subject to change without noce. Visit our website at www.ardaappliances.com
for the latest version of this manual.
- 5 -
1. Arda hoods exhaust vercally up through the ceiling to the roof
(Fig. 3). They can be ducted to the rear behind the decorave
chimney duct through an outside wall.
2. Plan where the ductwork will run between the hood and the
outside.
3. A short straight duct run will produce the most air ow. Longer
lengths and elbow ducts will reduce the eciency of the blower.
4. Install a roof or wall cap outside your home. Connect a 6” round
metal duct to the cap and work backwards towards the hood. Ensure
connecons are completely sealed with duct tape.
5.
1. Decide on the mounng height of the hood (C - Fig. 2). You will need to consider the following:
In general the minimum mounng height above an electric
range is 24” and above a gas range is 30”. Check your range’s
installaon manual for the correct minimum mounng height
for your installaon.
Mounng the hood at a height where the
controls are at eye level is usually most convenient.
actors such as symmetry and alignment within your
backsplash and/or cabinetry.
of the decorave chimney.
2. Mark the mounng height (C) on the plumb line (B).
3. The mounng holes on the hood are used for aaching the
hood to the wall. Measure the distance between the boom of the hood and the top of the
mounng holes on the hood (D - Fig. 5). Draw a line perpendicular to the center/plumb line (B)
at this height. Measure the distance between the
mounng holes on the hood (E). Center and mark this
measurement on line D. Ensure that this measurement
is centered on either side of the center (plumb) line.
This is where the mounng holes are to be posioned.
4. Behind the drywall and any backsplash material, in-
stall cross-bracing between the wall joists at the level
of the mounng screw holes (Fig. 4)
5. Insert the mounng screws through the marked
mounng holes, leaving about 1/4” of the thread
exposed. Ensure you use the appropriate type of
screws for your wall/crossbracing.
!
Hood
Roof Cap
Wall Cap
Duct
Fig. 3
Fig. 4
Center line
Mounng Holes
Drywall
Framing
Wood
cross-
bracing
Fig. 5
Mounng Holes
E
Oset
Height
D
Center (Plumb)
Line
B
Mounng Height
(to cooktop)
C
We do the utmost to ensure that the provided informaon is complete and accurate; however, images and
specicaons are subject to change without noce. Visit our website at www.ardaappliances.com
for the latest version of this manual.
- 6 -
1. Install a 110/120V electric receptacle on the wall within the dimensions of the decorave
chimney (Fig. 6). Note that removal of the plug will void the
warranty of the range hood.
1. We recommend that two people mount the hood.
2.
3. Damper installaon :
Inside the hood, under the grease lters, you will nd the:
Damper (Fig. 7); Gasket (Fig. 8); Gasket screws (x 4); Wall bracket for the chimney (Fig. 9).
Set the bracket aside for use in Step G. Place the gasket on top of the hood. Place the damper
on top of the gasket. Using the screws provided, ax the damper to the hood.
When unpacking models HAM52A and HAM52B,
please note that the gasket and associated hardware
are packed inside the hood.
4. Before mounng the hood, plug the unit in and test all funcons for proper operaon:
5. Remove the grease lters from the boom of the hood to prevent damage during the
installaon.
6. With assistance from at least one other person, hold the hood temporarily in posion ensuring
the boom is above the minimum clearance for the cooking surface.
!
Fig.6
Center/plumb
Line B
Grounded
Outlet
Fig.7
Fig.8
Fig.9
We do the utmost to ensure that the provided informaon is complete and accurate; however, images and
specicaons are subject to change without noce. Visit our website at www.ardaappliances.com
for the latest version of this manual.
- 7 -
7. Mount the hood on the mounng screws. When the hood has been leveled, secure unit by
ghtening screws.
8. Connect a 6” aluminum duct tube (not included) between your hood and duct path. Ensure that
the damper aps are free to open. Seal all seams using duct tape.
1. Carefully loosen but do not separate the
telescopic chimney duct pieces (A & B - Fig. 10). The
inside piece is the top and aaches to the wall at the
ceiling. The outside piece is the boom and rests on
the range hood.
2. Plug in the hood.
3. Install the recirculaon kit if required.
4. Aach the wall bracket.
: adjust the
width of the support bracket (D) to match the
upper duct width. Fix it to the wall using the
screws. Mark a line 4 mm down from the ceiling.
Fix the adaptor to the wall using the screws
provided so that it is centered in line with your hood and at a distance from the ceiling indicated.
: on the wall, at the ceiling edge, center the bracket on the plumb line.
Aach to the wall using screws appropriate to the wall material.
5. Place the two nested chimney pieces on top of the range hood. Draw the inside/top piece up to
the ceiling and ax to the wall bracket using the provided screws.
6. Remove the decorave plasc wrap from the hood.
A
B
D
C
C
A. Upper vent cover
B. Lower vent cover
C. Screws
D. Bracket
Arda
Fig.10
A. Upper vent cover
B. Lower vent cover
C. Screws
D. Bracket
We do the utmost to ensure that the provided informaon is complete and accurate; however, images and
specicaons are subject to change without noce. Visit our website at www.ardaappliances.com
for the latest version of this manual.
- 8 -
1. Read this manual carefully and completely.
2. ARDA range hoods conform to ETL/CSA standards. Please check your local building codes for any
addional requirements.
3. The appliance has been manufactured as Class I, therefore ground connecon is necessary.
A 110/120V plug is provided. The range hood must be installed so that that the plug is easily
accessible (Fig. 11).
4.If appliance has been designed for use in both ducted and recirculang modes, follow the
appropriate installaon method. (For recirculaon mode a kit is required – not included. Contact
Integrated Appliances to determine if a kit is available for your hood.)
1. Measure:
a. The oor to ceiling height (A - Fig. 12).
b. The distance from your cooking surface to your ceiling. (B)
c. Check your range/cooktop user manual for the specied min/
max hood distance (C) above your cooking surface.
2. Decide where the ductwork will run between the hood and the
outside. Short straight duct runs will provide the most air ow.
3. Find the centre point of your range/cooktop. Drop a plumb line
from your ceiling to this point on your cooking surface.
Mark the ceiling where the plumb line starts.
4. Calculate the required height of the mounng cage and
decorave chimney. ARDA range hoods will usually t on walls between 8 ½’ and 9 ½’ depending
on the mounng height of the range hood. For a shorter installaon you may need to have the
provided chimney and/or mounng cage cut. For a taller installaon you may need to fabricate an
extension piece.
A - Floor to Ceiling height
B - Ceiling to Cooking Surface (center/plumb line height
C - Cooking surface to boom of hood height
Outlet Cover
Grounding Pin
Grounded Outlet Plug
Fig.11
C
B
A
Fig.12
We do the utmost to ensure that the provided informaon is complete and accurate; however, images and
specicaons are subject to change without noce. Visit our website at www.ardaappliances.com
for the latest version of this manual.
- 9 -
1. Arda hoods exhaust vercally up through the ceiling to the roof
(Fig. 13). They can be ducted to the rear behind the decorave
chimney duct through an outside wall.
2. Plan where the ductwork will run between the hood and the
outside.
3. A short straight duct run will produce the most air ow. Longer
lengths and elbow ducts will reduce the eciency of the blower.
4. Install a roof or wall cap outside your home. Connect a 6” round
metal duct to the cap and work backwards towards the hood.
Ensure connecons are completely sealed with duct tape.
5.
1. In the ceiling, install cross-braces between the ceiling joists (Figs. 14a and 14b).
the boom of the cross-bracing must be level to ensure that the island hood hangs
level.
1. Install a 110/120V receptacle on the ceiling within the dimensions of the decorave chimney
(Fig. 14a). that the removal of the plug will void the warranty of the range hood.
Fig. 14b
Fig. 14a
!
Hood
Roof Cap
Wall Cap
Duct
Fig. 13
We do the utmost to ensure that the provided informaon is complete and accurate; however, images and
specicaons are subject to change without noce. Visit our website at www.ardaappliances.com
for the latest version of this manual.
- 10 -
1. For an island hood installaon, you will need
to consider the following when calculang the
mounng height (C - Fig. 12 on p.8):
In general the
minimum mounng height above an electric
range is 24” and above a gas range is 30”.
Check your range’s installaon manual for the
correct minimum mounng height for your
installaon.
On an island hood, mounng
the hood at a height where the controls are at
eye level is usually most convenient.
Factors such as symmetry and alignment within your backsplash or cabinetry.
of the decorave chimney.
2. Calculate the available height from the ceiling to the boom of the hood (X - Fig. 15). Calculate
the height of the hood (Y), then calculate the extended height for the mounng cage (Z).
3. Expand the telescopic cage to the calculated size (Z). Use the screws provided to x the
telescopic cage in place. If the calculated height of the mounng cage is smaller than the actual
height of the cage, you will need to have both the cage and the decorave chimneys cut to t
your installaon. We recommend that a stainless steel fabricator do this to ensure a straight even
cut. If the calculated height of the mounng cage is larger than the actual height of the cage,
you will need to fabricate an extension piece. Please call our oce at 1-800-268-4086 or info@
ardaappliances.com for assistance if required.
1. Centre the upper cage on the ceiling around the exhaust duct
opening. Ensure that:
a. The markings coincide with the cross-bracings between the
ceiling joints.
b. The cage is square with the cooking surface below.
c. The side of the cage that has the arrow on it faces the front.
When installed, this is the side of the hood that will have the
controls.
2. Mark the upper screw holes on the ceiling (Fig. 16).
3. Parally screw the four mounng screws provided into the
ceiling at these markings.
4. Ensure that the unit is square and level then completely ghten the screws. The cage should
now be rmly aached to the ceiling.
5. If you have not done so previously, insert the lower cage over the upper cage. Adjust the height
to the necessary distance using screws supplied.
Fig.15
X
Y
Z
Telescopic
!
Fig.16
We do the utmost to ensure that the provided informaon is complete and accurate; however, images and
specicaons are subject to change without noce. Visit our website at www.ardaappliances.com
for the latest version of this manual.
- 11 -
1. Aach 6” aluminum duct (not included) to the prepared duct
work in the ceiling. Seal all seams. If using the recirculaon kit
(not provided), the air deector is installed at this step. Please
see instrucons provided with kit.
2. Carefully separate the telescopic chimney duct pieces.
3. Aach the inner piece of the decorave chimney to the top of
the cage with screws provided (Fig. 17).
4. Slide the outer piece of the decorave chimney on to the cage
over the inner chimney and temporarily hold in place with two
screws.
1. Before mounng the hood, plug the unit in and test all
funcons for proper operaon:
a. Blower works at all speeds.
b. Lights turn on and o.
c. When blower is on, the damper aps open.
2. Remove grease lters from range hood.
3. With the assistance of two other people liing the hood from
below, raise the unit unl the lower cage sits inside the range
hood lower cage. Be sure the unit is installed with the controls
facing front. Screw hood to cage (Fig. 18).
4. Aach 6” aluminum duct to the hood duct connector. Ensure
that the damper aps are free to open. Seal all seams.
5. Plug in the unit.
6. Remove temporary screws holding the lower decorave chimney piece in place.
7. Re-install the grease lters and remove protecve plasc wrap from the hood.
Fig.17
Fig.18
We do the utmost to ensure that the provided informaon is complete and accurate; however, images and
specicaons are subject to change without noce. Visit our website at www.ardaappliances.com
for the latest version of this manual.
- 12 -
A=Power/O
B=Speed 1
C= Speed 2
D=Speed 3
E= Light
A-Delay Timer/15 minutes
B- Speed 1
C= Speed 2
D=Speed 3
E= Light
A=Delay Timer/15 minutes
B= Speed Adjust “-”
C=LED Display
D= Speed Adjust “+”
E= Light
A= Change Filter
B= Delay Timer
C= Speed Adjust “-”
D= Digital Clock
E1= Timer
E2= Delay Timer
F = Speed Adjust “+”
G= Timer
H= Light
A=Power/O
B=Speed 1
C= Speed 2
D=Power Burst
E= Light
A=Timer
B= Speed Adjust “-”
C=LED Display
D= Speed Adjust “+”
E= Light
A B C D E
A B C D E
ABC D E
ABCDE
A B C D E
A B C D E1
E2
F G H
:
88
1. Arda hoods come with a variey of controls depending on the model choice (see below).
2. Delay mers, when included, turn o the hood in a set amount of me.
3. Use the lights only when cooking.
We do the utmost to ensure that the provided informaon is complete and accurate; however, images and
specicaons are subject to change without noce. Visit our website at www.ardaappliances.com
for the latest version of this manual.
- 13 -
1. For opmum performance in removing cooking odours, it is recommended that you turn
ON your range hood prior to cooking and you leave it operang for 15 minutes aer cooking.
2. Clean the surfaces of the range hood regularly using a non-abrasive detergent.
3. The grease lters capture the grease parcles suspended in the air. They will accumulate
grease and dirt depending on the frequency of the use of your range/cooktop.
4. In order to prevent a re hazard, it is recommended that you clean the lters at least every
2 months.
: This appliance is not intended for use by young children without
supervision.
There should be adequate venlaon in the room when the range hood is used
simultaneously with other fuel burning appliances.
1. Remove the lters from the range hood and wash
them in a soluon of water and liquid detergent,
leaving to soak if necessary. Rinse thoroughly with
warm water and leave to dry.
2. The lters may also be washed in the dishwasher.
3. The aluminum panels may alter in color aer
several washes. This is normal and does not alter the
performance of the hood.
4. Replacement lters are available at
www.ardaappliances.com
Depending on your model of ARDA hood, there are two
possible types of lighng: incandescent and halogen.
The hood lights are designed for use during cooking and
not for prolonged general illuminaon of your kitchen.
Prolonged use of the lights may reduce the life me of
the bulbs.
Underside of Hood
!
!
We do the utmost to ensure that the provided informaon is complete and accurate; however, images and
specicaons are subject to change without noce. Visit our website at www.ardaappliances.com
for the latest version of this manual.
- 14 -
1. Allow the bulb to cool for 10 minutes; remove the grease lter for easy access.
2. Carefully unscrew the bulb to avoid glass breakage. Ensure that the replacement bulb has the
same voltage and waage specicaon as the old bulb. Install new bulb in the light xture by
screwing it into the xture socket.
3. Replace the grease lter.
1. Disconnect the power source from the hood by unplugging the power cord or turning o the
circuit breaker. Allow the bulb to cool for 10 minutes before removing it from the light xture.
2. Place a small athead screwdriver under the outer lip of the xture (A). With some models it is
also possible to remove the grease lter and press the light xture out of its mounng bracket from
inside the hood (B). Avoid touching the wires when pressing the xture out. Holding both ends of
the plug (do not hold wires) press down the locking lever (to unlatch the locking pin) and gently pull
the two secons apart.
3. Remove the cover on the xture, by placing a small athead screwdriver between the inner and
outer ring of the xture in the area marked “OPEN,” and pry loose the inner ring (C).
Using a dry paper towel, pull out the old bulb and discard. Hold the new halogen bulb with a dry
paper towel between your ngers. The paper towel prevents oils from your skin from adhering to
the glass of the bulb. Align the pins of the bulb with the holes in the xture and gently push the
bulb straight in unl fully inserted.
4. Replace the cover on the xture by aligning the three slots on the cover with the matching slots
on the xture and pressing rmly on the outer metal ring of the cover. To avoid breakage, do not
press on the glass.
5. To reconnect the plug line up the
ends (square hole with square peg) and
gently press together unl they lock.
Snap the light xture back into its socket
by pressing the outer ring of the xture.
Do not press on the glass.
6. Reconnect the power to the hood.
AB
C
We do the utmost to ensure that the provided informaon is complete and accurate; however, images and
specicaons are subject to change without noce. Visit our website at www.ardaappliances.com
for the latest version of this manual.
- 15 -
Hood doesn’t turn on No electrical supply
Ensure the plug is connected
Ensure the main switch is
turned ON
Power cord is damaged Call ARDA service
Poor airow
Aluminum grease lters
clogged
Clean the lters and replace
when dry
Charcoal lters clogged
(recirculang mode only) Replace the charcoal lters
Hood is vibrang Hood is not secured in place Check the installaon of hood
Tighten mounng screws
Motor running but no airow,
or air comes back into room Damper blocked
Check outside cap to ensure
that it is clear. Check damper
opens when unit is turned
on. Call installer to check for
blockages or narrowing of the
duct.
Motor stops aer a few
minutes
The hood is installed too near
the cooking surface
The hood must be at least
61cm (24” ) from the stove
Strong cooking smell
Fan speed too low Use one of the higher sengs
Charcoal lters not installed In recirculang mode, charcoal
lters must be installed
Oil dripping onto stove Aluminum grease lter
saturated
Wash the aluminum grease
lters
Whirring sound Something in contact with fan
blade Call ARDA service
Fan does not work Call ARDA service
Lights do not work,
but fan does Bulbs have burnt out Replace bulbs
All hood lights go out at once Transformer blown Call ARDA service
We do the utmost to ensure that the provided informaon is complete and accurate; however, images and
specicaons are subject to change without noce. Visit our website at www.ardaappliances.com
for the latest version of this manual.
- 16 -
This warranty applies only to the original purchaser and may not be transferred. This warranty is
applicable within North America only, to hoods installed for normal, non-commercial use in PRIVATE
SINGLE FAMILY HOUSEHOLDS.
Arda Appliances North America (hereaer “Arda”) warrants its products to be free from defects in
materials or workmanship for a period of ONE YEAR from the date of original purchase. It further
warrants the motor (part only) for an addional ONE YEAR. During the warranty period,
Arda will, at its opon, repair or replace, without charges, any product or part which is found to be
defecve under normal use and service. This warranty covers parts and labor at approved company
rates, of $95 per hour, up to a maximum of one (1) hour. Proof of payment to service repair
company is required.
THERE ARE NO OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO,
IMPLIED WARRANTIES OR MERCHANT ABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Proof of
purchase/original invoice and serial number is required for warranty claims. Keep a photocopy
easily accessible.
This warranty will be void if the serial plate has been removed or disgured.
EXCLUSIONS - This Arda limited warranty will not cover:
• Aluminum lters, lights or glass canopies, blower wheel damage
• Regular maintenance and service (except by an authorized Arda repair centre)
• Damage resulng from accident, alteraon, misuse, abuse, re, ood, acts of God, improper
installaon, installaon not in accordance with electrical codes, or use of consumables or cleaning
products not approved by Arda
• Repair of an appliance used in other than normal, single-family household, or in a manner that is
contrary to operaon and/or installaon instrucons
• Cosmec damage or freight damage caused by 3rd party freight company
• Service to product that is not easily accessible due to unusual, exceponal, or dicult installaon
that requires removal of xtures, other than the Arda product, for repair
• Service calls to instruct you how to use the appliance (i.e. user product educaon)
• Expenses for travel and transportaon if your appliance is located in a remote area where service
by an authorized Arda servicer is not available
The cost of repair or replacement under these exclusions shall be borne by the customer and
agreed to before a servicer is dispatched.
ARDA SHALL NOT BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES ARISING OUT
OF OR IN CONNECTION WITH PRODUCT USE OR PERFORMANCE.
For an ARDA authorized repair centre please contact Arda at:
1-800-387-3924 (U.S.), 1-800-268-4086 (CAN), or service@ardaappliances.com.
We do the utmost to ensure that the provided informaon is complete and accurate; however, images and
specicaons are subject to change without noce. Visit our website at www.ardaappliances.com
for the latest version of this manual.
- 17 -
Place photocopy of proof of purchase
here
Distributed by
501 Oakdale Road, Toronto, Ontario M3N 1W7
Tel: 416-646-2500 Fax: 416-646-2505
1-800-387-3924 or 1-800-268-4086
HM-20140820
Table of contents
Other Arda Ventilation Hood manuals
