Arfit TTP User manual

1
Quality Management System certified under Norm ISO 9001:2015 by TÜV Rheinland Portugal
Air Handling Units
Instructions Manual [EN]

2
Table of Contents
DESCRIPTION ............................................................................................................................................................. 1
UNIT IDENTIFICATION ............................................................................................................................................... 1
UNIT SHIPMENT ......................................................................................................................................................... 1
INSTALLATION ............................................................................................................................................................ 2
LIFTING AND POSITIONING ...................................................................................................................................... 2
JOINING THE SECTIONS ........................................................................................................................................... 3
MAINTENANCE ........................................................................................................................................................... 4
MAINTENANCE ........................................................................................................................................................... 5
EQUIPMENTS WARRANTY ........................................................................................................................................ 6
PROBLEM SOLVING ................................................................................................................................................... 7
CE DECLARATION CONFORMITY ............................................................................................................................ 8
CONDENSATION TRAY .............................................................................................................................................. 9
ELECTRICAL DIAGRAMS - EC FANS ...................................................................................................................... 10
ELECTRICAL DIAGRAMS – AC FANS ..................................................................................................................... 18
ACCESSORIES - CUT-OFF SWITCH ....................................................................................................................... 19
ACCESSORIES - PRESSURE SWITCH ................................................................................................................... 19
ACCESSORIES - CONSTANT FLOW (AC MOTORS) ............................................................................................. 20
ACCESSORIES - CONSTANT FLOW (EC MOTORS) ............................................................................................. 22
WATER COIL ............................................................................................................................................................. 24
DIRECT EXPANSION COIL ...................................................................................................................................... 24
ELECTRIC BATTERY ................................................................................................................................................ 24
ELECTRIC BATTERY ................................................................................................................................................ 25
ELECTRIC BATTERY ................................................................................................................................................ 26
HUMIDIFIER .............................................................................................................................................................. 27
HEAT EXCHANGER .................................................................................................................................................. 27

1
DESCRIPTION
The components and size of the air handling units TTP are fully customizable and can be adapted to the needs
of the building. All of these features, together with the Eurovent certification which has been granted to this unit
ascertain its high-quality level and energy efficiency. These units can be set In Line, Double Deck or Side-by-
Side.
UNIT IDENTIFICATION
The units are identified by their rating label, in which the serial number, as well as its main technical features are
stated.
UNIT SHIPMENT
The units are sent wrapped in plastic film and with wooden supports in each corner of the many sections that
belong to the unit.
When receiving the unit, please check if it has not been damaged during shipment and if it is complete. In case
you find any damage, you must register the issue in the shipment document.
Return Fan
features

2
INSTALLATION
Like any other equipment, the TTP air handling units must be correctly installed and subjected to preventive
maintained routines in order to ensure they are properly functioning from the moment they are first used and
throughout the equipment’s duration period. In order to achieve this, the recommendations bellow must be
followed if they are valid for the equipment in question:
Warnings
 Please read all information within this manual before you use the equipment.
 The power network to which this device will be connected, must comply with the current standards.
 The device must be connected correctly to an efficient electric circuit connected to the ground, as required by
current electric safety standards. In case of doubt, please ask qualified professionals to access the network.
 The device should only be installed and used according to the current norms and to the purpose for which it
was manufactured. It may be dangerous to install it and use it for a different purpose or with different parts.
 The manufacturer cannot be held responsible for damages caused by faulty installation, use or maintenance
of the device and/or for repairs made by unqualified individuals.
 Never use this unit as a support for other equipment.
 Before you open the unit door, please make sure all electric parts have been disconnected. Take special care
to assure that the fan is turned off and cannot be inadvertently turned on.
 Be careful sharp edges that may be found inside the unit.
 Never climb nor walk on top of the unit.
 The installation of a cut-off switch is mandatory.
 Movable parts - Before you proceed with any intervention, please make sure the fan is completely still.
 The connection of the accessories presented as an attachment may already be finished, depending on the
options selected at the time the order of the equipment was placed.
 Electrical resistances must be connected to control devices that don’t allow them to work when the fan is still,
that prevent them from working when safety thermostats are activated and that allow a post-ventilation period
after they are turned off, in order to allow them to cool down.
 The heating batteries and steam humidifiers may cause burn injuries. Make sure they are still/turned off and
at a temperature that allows their handling.
 Heating and/or cooling batteries have a finned surface that may cause cuts. Take due caution when handling
these elements.
Starting the equipment
 Check if there are no foreign bodies inside the module.
 Check if the turbine is spinning freely, with no contact with the fan scroll or other elements.
 Check if the electric power features are right for the engine in question and make sure the equipment is
connected to an efficient ground connection.
 Provide electrical power to the engine according to the instructions given in this manual, in chapter "Electric
Diagrams - Fan”, and check if the turbine is spinning in the correct direction.
 With the access lids closed, check if the electric consumption of the engine is in accordance with the value
indicated in its data plate. Note: the electric current requirement must never be higher than the value indicated
in the motor’s data plate.
 Check if there are no vibrations or strange noises.
 The unit is provided with plastic film in the panels for protection purposes during the manufacturing, shipping
and installation processes. Once the installation is finished, the plastic film should be removed.
LIFTING AND POSITIONING
TTP air handling are meant to be lifted from their base. The base of the units has got holes for lifting purposes in
the corners of the base and throughout its perimeter. In order to lift the machine correctly, the holes along the
perimeter should be used. If there aren’t any, then the holes in the corners of the unit should be used. The weight

3
of each module and their centre of gravity should be considered during the lifting process. Lift the unit slightly in
order to check its position.
The unit should be placed on top of a plane, levelled surface that supports its weight. The location where the unit
will be placed should have enough space to allow the doors of its several sections to open correctly and allow
access to installation and maintenance procedures in the unit.
It is advisable to use anti-vibration mounts at the base of the unit.
JOINING THE SECTIONS
Units are often provided in several sections and the person responsible for the installation should join these
sections at the installation spot.
This operation should be conducted using the materials provided. These can be found inside the unit.
 Apply the adhesive gasket (tape) to the aluminium profile of the sections you wish to join.
 Press the parts at the joining of the sections that are in the interior corners of the sections.
 Press the parts that are along the interior of the sections (if there any) that need to be joined.
Note: in some cases, it may be necessary to remove some panels from the units, in order to access the joining
parts in the sections. To do this, take the lids off and unscrew the screws in order to easily remove the panel.
Because of their size, some energy recovering sections may be sent partially disassembled. In such cases, special
care should be taken to avoid damaging these delicate components.
Check if the gaskets and sealing silicones do not allow air to bypass these elements. In the case of heat
exchangers with integrated bypass damper, make sure that the register works correctly.

4
MAINTENANCE
Air treatment equipment requires periodic maintenance to properly perform the function for which they are
designed. The frequency with which the maintenance is performed depends on the environmental characteristics
in which the equipment is inserted and the number of hours of operation, so that the following indications is to be
considered as a guide.
Fan
Operations to be carried out:
 Check if there are no strange parts inside the module.
 Check the tightness of the electric wiring.
 Check if the turbine rotates freely.
 Check the tightness of all the screws to avoid undesirable vibrations.
 General interior cleaning
Frequency of maintenance: Biannual.
Filters
Operations to be carried out:
 Check if there are no strange parts inside the module.
 Check the tightness of all the screws to avoid undesirable vibrations.
 Check if the filter cloth is not cut.
 Check the condition of filter fills (replace if necessary).
 General interior cleaning.
Frequency of maintenance: Monthly
Heat exchanger unit
Operations to be carried out:
 Check if there are no strange parts inside the module.
 Check the tightness of all the screws to avoid undesirable vibrations.
 Check the condition, fix, and clean of the heat exchanger.
 Check condensate sewage, clean and sanitize the condensate tray.
 General interior cleaning.
Frequency of maintenance: Biannual
Water and direct expansion coils
Operations to be carried out:
 Check if there are no strange parts inside the module.
 Check the tightness of all the screws to avoid undesirable vibrations.
 Check the connections to the coil
 Check and clean (if necessary, taking care not to damage) the fins of the batteries.
 If there are deformed fins, replace them in the correct position with a suitable "comb".
 General interior cleaning.
 Check, when applicable, the condensate sewage, clean and sanitize the condensate tray.
Frequency of maintenance: Quarterly

5
MAINTENANCE
Electric resistance battery
Operations to be carried out:
 Check if there are no strange parts inside the module.
 Check the tightness of all the screws to avoid undesirable vibrations.
 Check connection status, replacing cables and redoing connections if necessary.
 Check the safety thermostat.
 General interior cleaning.
Frequency of maintenance: Biannual
Evaporative humidifier
Operations to be carried out:
 Check if there are no strange parts inside the module.
 Check the tightness of all the screws to avoid undesirable vibrations.
 Check the conditions of the humidifier.
 Clean the water filter.
 Clean and sanitize the water tank tray.
 Check filter valve and water level.
 General interior cleaning.
Frequency of maintenance: Quarterly
Steam humidifier
Operations to be carried out:
 Check the tightness of all the screws to avoid undesirable vibrations.
 Check the overall performance of the humidifier.
 Check the condition and performance of the humidifier cylinder by checking the condition of the electrodes or
resistances and check if there are no strange parts inside it (replace if necessary).
 Check and retighten all electrical connections.
 Check the conditions of the steam tubes.
 Check the performance of the water inlet and outlet valves.
 Check if there are no strange parts inside the module.
 Check the condensate sewage, clean and sanitize the condensate tray.
 Check the steam lance.
Frequency of maintenance: Quarterly
Acoustic attenuators
Operations to be carried out:
 Check if there are no strange parts inside the module.
 Check the tightness of all the screws to avoid undesirable vibrations.
 Check the condition and setting of the acoustic baffles.
 General interior cleaning
Frequency of maintenance: Annual

6
Equipment’s warranty
The ARFIT warrants this product against all manufacturing defects for a period of 2 (TWO) years after the date of
purchase.
Technical assistance under warranty will only be provided upon presentation of the purchase document, which
proves that the equipment is within the warranty period.
If, during the warranty period, the product is experiencing problems resulting from manufacturing defects, ARFIT
or its Authorized Technical Services will, free of charge for repair at their premises or (at ARFIT’s discretion)
replace the product or place components to replace the defective parts in accordance with the following
conditions.
ARFIT reserves the right, by its own discretion, to replace defective product components or small value products,
either by new components or products, or by components or recycled products. The present warranty covers only
the equipment and no costs and losses that may be incurred as a result of equipment stoppage are considered
and are therefore expressly excluded.
Disclaimers of warranties
 Natural wear parts.
 Parts that are subject to deterioration or breakage, for example, belts, filters, fuses, etc.
 Malfunctions caused by misuse, abuse, neglect, negligence, lightnings, floods, humidity, falls, collisions,
accident and transportation.
 Malfunctions caused by the use of the equipment for not intended purposes.
 Malfunctions caused as a result of handling, modifying or repairing the equipment, by unauthorized persons
or technical services or by the application of improper parts or accessories.
 Malfunctions caused as a result of an improper or illegal installation (voltage, water pressure or others),
anomalies in the power, disrespect for the instructions.
 Wear or aesthetic deterioration, produced by use, changes in tone, oxidation or corrosion of the apparatus or
its components.
 Any eventual repair does not have the effect of prolonging the warranty, nor does it confer the right to any
compensation.
The warranty shall not be valid if:
 The equipment nameplate has been manipulated or tampered.
 False data has been provided.
 The equipment is not accompanied by the purchase document.
 The equipment has been handled, modified or repaired by unauthorized people or technical services.
 Verification/maintenance operations are not carried out or are carried out by unauthorized technicians.

7
PROBLEM SOLVING
Problem Possible cause Check Possible solution
Engine in very high
consumption
Operating point different than
expected;
Check the flow rate
and the pressure drop;
Increase a pressure drop in
the installation;
Excess flow; Fan speed; Reduce the rotation speed;
Air flow in excess Air distribution system,
pressure drop overrated;
Check the flow rate
and the pressure drop;
Increase a pressure drop in
the installation;
Fan speed; Reduce the rotation speed;
Insufficient air flow
Air distribution system,
pressure drop overrated;
Check the flow rate
and the pressure drop; Increase the speed of
rotation (according to
available motor power and
maximum fan speed);
Fan speed;
Clogged filter; Filter embedding; Replace filter;
Excessive noise
Flow too high, air speed too
high; Check the flow rate
and the pressure drop;
Decrease the flow;
Pressure drop too high; Avoid areas of unstable
performance of the fan;
Damaged bearings, damaged
metal components;
Bearings, condition of
the components;
Replace bearings or
damaged components;
Unbalanced moving
components; Strange vibrations; Calibrate/Replace fan;
Unit does not work Power failure;
Power supply;
Circuit breaker;
Restore power supply;
Rearm circuit breaker;
Low battery
performance
Reduction of working fluid
flow; Check flow rate; Regular flow rate;
Low air flow; Filter embedding; Replace filter;
Low efficiency of the
recuperator
Dirtiness of the recovery
element;
Cleaning condition of
the recuperator Clean recuperator
Low air flow; Filter embedding; Replace filter;
Excessive wear on
the belt
Incorrect belt tension; Check tension on the
belts; Adjust belt tension;
Incorrect pulley alignment; Check pulley
alignment; Align pulley;
Note:
Please note that air handling units are integrated into a general system. For this reason, failures may be caused
by other system components, improper interaction between the unit and the system, or environmental conditions
other than those specified for the unit project.

8
CE DECLARATION OF CONFORMITY
Declaração de Conformidade CE (PT)
A Arfit Climatização S.A. c/ sede na Rua Domingos Ferreira da Costa, 280, Zona Industrial da Maia I, sector VIII,
4475-297 Maia, Portugal, declara que o produto Unidades de Tratamento de Ar TTP está em conformidade
com as seguintes diretivas e normas em vigor aplicáveis.
A Arfit Climatização S.A. salienta que o domínio da declaração da conformidade é extensível apenas e só ao
produto acima referido e desde que sejam respeitados os requisitos inerentes á instalação e utilização do bem
em causa. A Arfit Climatização S.A. não se responsabiliza pela junção/integração deste produto com outro
equipamento, ou máquina que não tenha sido referenciado/previsto nas instruções. A pessoa responsável pela
compilação do processo técnico é: Pedro Miguel Guimarães de Sousa e Silva, na morada acima indicada
Declaration of Conformity CE (EN)
Arfit Climatização S.A. with headquarters in Rua Domingos Ferreira da Costa, 280, Zona Industrial da Maia I,
sector VIII, 4475-297 Maia, Portugal, declares that the product Air Handling Units TTP is fully in conformity with
the following directives and standards.
Arfit Climatização S.A. declares that the declaration of conformity is regarding the above mentioned product as
long as the installation and user rules are respected. Arfit Climatização S.A. cannot be responsible when this
product is integrated or connected to any other equipment not mentioned of the instruction manual. The person
responsible for compiling the technical file is: Pedro Miguel Guimarães de Sousa e Silva, at the address above.
Declaración de Conformidad CE (ES)
Arfit Climatização S.A. establecida en Rua Domingos Ferreira da Costa, 280, Zona Industrial da Maia I, sector
VIII, 4475-297 Maia, Portugal, declara que el producto Unidades de Tratamiento de Aire TTP esta en
conformidad con las siguientes directivas y normas en vigor aplicables.
Arfit Climatização S.A. establece que el dominio de la declaración de conformidad es extensible sólo y
únicamente para el producto mencionado anteriormente sujetos al cumplimiento de las exigencias inherentes a
la instalación y el uso de los bienes en cuestión. El Arfit Climatização S.A. no se hace responsable de fusión /
integración de este producto con otros equipos o maquinaria que no ha sido referenciada / provista con las
instrucciones. La persona responsable de la elaboración del expediente técnico es: Pedro Miguel Guimarães de
Sousa e Silva, a la dirección precitada
Déclaration de Conformité CE (FR)
Arfit Climatização S.A. basée a Rua Domingos Ferreira da Costa, 280, Zona Industrial da Maia I, sector VIII,
4475-297 Maia, Portugal, déclare que le produit Centraux Traitement d’Air TTP est conforme aux directives et
normes en vigueur indiquées.
Arfit Climatização S.A. déclare que le domaine de la déclaration de conformité est extensible uniquement pour le
produit mentionné plus haut sous et sous réserve de conformité avec les exigences inhérentes à l'installation et
à l'utilisation des biens concernés. La Arfit Climatização S.A. n'est pas responsable de fusion / intégration de ce
produit avec d'autres appareils ou machines qui n'a pas été référencé / prévue dans les instructions. La personne
responsable de la constitution du dossier technique est: Pedro Miguel Guimarães de Sousa e Silva, à l'adresse
ci-dessus.
Diretivas/Directives/Diretivas/Directives:
Normas/Standards/Normas/Normes:
 Machine Directive 2006/42/CE
 Low Voltage Directive 2014/35/EU
 EMC Directive 2014/30/EU
 ECODESIGN Directive 2009/125/CE
 EN 60335-1:2010
 EN 60947-3:2009
 EN 60947-5-1:2004+AC:2005+A1:2009
 EN 13857:2008
 EN 12100-1:2003
 EN 12100-2:2003
 EN 60204-1:2006
Maia, April 7th 2016
Technical direction
Pedro Silva

9
CONDENSATION TRAY
The condensation tray is intended to collect condensates that may arise in the sections where they are placed.
The condensates outlets of the various sections where these are present must be equipped with siphons (Image
1) suitable for:
 Ensure the correct drainage of the condensates
 Prevent air entrance, when the section from the unit is under negative pressure
 Prevent air leaks, when the section from the unit is under positive pressure.
 Prevent entry of odours and insects
Where P represents the maximum static pressure within the section in mm c. a.
The siphon must be allowed to be cleaned for regular maintenance.
Image 1

10
ELECTRICAL DIAGRAMS – EC FANS
One of the vital components for the correct functioning of the ARFIT brand air handling units are the fans, so,
make sure that they are correctly connected according to the following diagrams (Check the fan scheme of the
equipment purchased in the diagrams shown):
- Scheme EC-1 (Image 2):
- Scheme EC-2 (Image 3):
Connection Description
10V Voltage output 10V - Imax = 10mA (Terminal 5 flow regulator ARFIT)
GND Connection for control interface (terminal 3 flow regulator ARFIT)
E1 Analogue input 1 (Control 0 - 10V) (Terminal 4 flow regulator ARFIT)
D1 Digital input 1 (Connect to terminal 2 of the ARFIT flow regulator to enable operation)
A1 Status input (normally open)
A(D-) RS485 MODBUS
B(D+)
11 Status relay, normally open,
Closes with alarm (2A, 250 VAC)
14
PE Ground
230 / 1 EN 1:50
(See characteristics on the motor plate)
N Power - Neutral
L1 Power - Phase
Number Connection Function
1 24V Voltage output 24 VDC–= 70 mA (Connect to terminal 1 of the ARFIT flow regulator to enable
operation)
2 10V Voltage output 10 VDC - Imax = 10 mA (Terminal 5 flow regulator ARFIT)
3 GND Connection for control interface (terminal 3 flow regulator ARFIT)
4 D1 Digital input 1 (Connect to terminal 2 of the ARFIT flow regulator to enable operation)
5 E1 Analogue input 1 (Control 0-10V) (Terminal 4 flow regulator ARFIT)
6 PE Ground
7 11 Status relay, normally open,
Closes with alarm (2A, 250 VAC)
8 14
9 L1 Power - Phase 230 / 1 EN 1:50
(See characteristics on the motor plate)
10 L2 Not applicable
11 L3/N Power - Neutral
Image 2
Image 3

11
ELECTRICAL DIAGRAMS – EC FANS
- Scheme EC-3 (Image 4):
- Scheme EC-4 (Image 5):
Number Connection Function
1 24V Voltage output 24 VDC–= 70 mA (Connect to terminal 1 of the ARFIT flow regulator to enable
operation)
2 10V Voltage output 10 VDC - Imax = 10 mA (Terminal 5 flow regulator ARFIT)
3 GND Connection for control interface (terminal 3 flow regulator ARFIT)
4 D1 Digital input 1 (Connect to terminal 2 of the ARFIT flow regulator to enable operation)
5 E1 Analogue input 1 (Control 0-10V) (Terminal 4 flow regulator ARFIT)
6 PE Ground
7 11 Status relay, normally open,
Closes with alarm (2A, 250 VAC)
8 14
9 L1 Power - Phase
400 / 3 EN 1:50
(See characteristics on the motor plate)
10 L2 Power - Phase
11 L3/N Power - Phase
Number Connection COR Description
CON10 L Black Power - Phase 230 / 1 EN 1:50
(See characteristics on the motor plate)
CON11 N Blue Power - Neutral
CON12 PE Green/Yellow Ground
1 GND Blue GND – Connection for control interface (terminal 3 flow regulator ARFIT)
2 0-10V/PWM Yellow Control input 0 - 10V or PWM (Terminal 4 flow regulator ARFIT)
3 +10V Red Voltage output 10V (Terminal 5 flow regulator ARFIT)
4 TACH White Tachometer output Open collector, 1 pulse per rotation
Image 5
Image 4

12
ELECTRICAL DIAGRAMS – EC FANS
- Scheme EC-5 (Image 6):
-Scheme EC - 6 (Image 7):
Line Connection COR Description
1, 1 PE Green/Yellow Ground
230 / 1 EN 1:50
(See characteristics on the motor plate)
3 N Blue Power - Neutral
5 L Black Power - Phase
6 NC White 1 Status relay, normally closed, Opens with alarm
7 COM White 2 Standard in the status relay
8 0-10V Yellow Analogue input ,Control 0-10V (Terminal 4 flow regulator ARFIT)
10 RSB Brown RS485 interface for MODBUS, RSB, SELV
11 RSA White RS485 interface for MODBUS, RSA, SELV
12 GND Blue GND, reference for control interface, SELV (terminal 3 flow regulator ARFIT)
13 10V Red Voltage output 10V (Terminal 5 flow regulator ARFIT)
Number Connection COR Description
1.2 PE Green/Yellow Ground
400 / 3 EN 1:50
(See characteristics on the motor plate)
3 L1 Black Power - Phase
4 L2 Black Power - Phase
5 L3 Black Power - Phase
6 NC White 1 Status relay normally closed, opens with alarm
7 COM White 2 Standard in the status relay (2A, 250 VAC, min 10 mA, AC1)
8 0-10V Yellow Analogue input (value definition) 0-10V, 100kΩ impedance (Terminal 4 flow regulator
ARFIT)
10 RSB Brown RS 485, interface for MODBUS
11 RSA White RS 485, interface for MODBUS
12 GND Blue Reference for interface (terminal 3 flow regulator ARFIT)
13 10V Red Power for external devices, máx. 10mA (terminal 5 flow regulator ARFIT)
Image 7
Image 6

13
ELECTRICAL DIAGRAMS – EC FANS
-Scheme EC - 7 (Image 8):
Connector Connection Description
KL1 L1 Power - Phase
230 / 1 EN 1:50
(See characteristics on the motor plate)
N Power - Neutral
PE PE Ground
KL2
NO Status relay, normally opened, closes with alarm
COM Standard in the status relay
NC Status relay normally closed, opens with alarm
KL3
RSA RS485 MODBUS RTU
RSB
GND Reference for interface (terminal 3 flow regulator ARFIT)
Ain1 U Analogue input 0-10V, 100kΩ impedance (Terminal 4 flow regulator ARFIT)
+10V Power for external devices, max. 10mA (terminal 5 flow regulator ARFIT)
Ain1 I Analogue input 4 -20mA, 100kΩ impedance (Terminal 4 flow regulator ARFIT)
Din1 Digital input 1 (Connect to terminal 2 of the ARFIT flow regulator to enable operation)
Din2 Digital input 2
Din3 Digital input 3
Ain2 U Analogue input 0-10V, 100kΩ impedance (Terminal 4 flow regulator ARFIT)
+20V Power for external devices, máx. 50mA (Connect to terminal 1 of the ARFIT flow regulator to
enable operation)
Ain2 I Analogue input (value definition), 4-20mA, 100kΩ impedance
Aout Analogue output 0-10V
Image 8

14
ELECTRICAL DIAGRAMS – EC FANS
-Scheme EC - 8 (Image 9):
-Scheme EC - 9 (Image 10):
Connector Connection Description
PE PE Ground
KL1
L1 Power - Phase 400 / 3 EN 1:50
(See characteristics on the motor plate)
L2 Power - Phase
L3 Power - Phase
KL2
C Standard in the status relay
GND Reference for interface (terminal 3 flow regulator ARFIT)
RSA RS485 MODBUS RTU
RSB
NC Status relay normally closed, opens with alarm
Din1 Digital input 1 (Connect to terminal 2 of the ARFIT flow regulator to enable operation)
10V Power for external devices, max. 10mA (terminal 5 flow regulator ARFIT)
Ain1 U Analogue input 0-10V, 100kΩ impedance (Terminal 4 flow regulator ARFIT)
Connection COR Description
L Black Power - Phase
230 / 1 EN 1:50
(See characteristics on the motor plate)
N Blue Power - Neutral
PE Green/Yellow Ground
NC White 1 Status relay normally closed, opens with alarm
COM White 2 Standard in the status relay
+10V Red Voltage output 10V (Terminal 5 flow regulator ARFIT)
0-10V/PWM Yellow Control input 0 - 10V or PWM (Terminal 4 flow regulator ARFIT)
GND Blue GND – Connection for control interface (terminal 3 flow regulator ARFIT)
KL1 KL2
Image 9
Image 10

15
ELECTRICAL DIAGRAMS – EC FANS
-Scheme EC - 10 (Image 11):
Connector Connection Description
KL1
L1 Power - Phase
400 / 3 / 50
(See characteristics on the motor plate)
L2 Power - Phase
L3 Power - Phase
PE PE Ground
KL2
NO Status relay, normally opened, closes with alarm
COM Standard in the status relay
NC Status relay normally closed, opens with alarm
KL3
RSA RS485 MODBUS RTU
RSB
GND Reference for interface (terminal 3 flow regulator ARFIT)
Ain1 U Analogue input 0-10V, 100kΩ impedance (Terminal 4 flow regulator ARFIT)
+10V Power for external devices, max. 10mA (terminal 5 flow regulator ARFIT)
Ain1 I Analogue input 4 -20mA, 100kΩ impedance (Terminal 4 flow regulator ARFIT)
Din1 Digital input 1 (Connect to terminal 2 of the ARFIT flow regulator to enable operation)
Din2 Digital input 2
Din3 Digital input 3
Ain2 U Analogue input 0-10V, 100kΩ impedance (Terminal 4 flow regulator ARFIT)
+20V Power for external devices, max. 50mA (Connect to terminal 1 of the ARFIT flow regulator to
enable operation)
Ain2 I Analogue input (value definition), 4-20mA, 100kΩ impedance
Aout Analogue output 0-10V
Image 11

16
ELECTRICAL DIAGRAMS – EC FANS
-Scheme EC - 11 (Image 12):
Connector Connection Description
KL1
L1 Power - Phase
400 / 3 / 50
(See characteristics on the motor plate)
L2 Power - Phase
L3 Power - Phase
PE Ground
KL2
NO Status relay, normally opened, closes with alarm
COM Standard in the status relay
NC Status relay normally closed, opens with alarm
KL3
RSA RS485 MODBUS RTU
RSB
GND Reference for interface (terminal 3 flow regulator ARFIT)
0-10V/PWM Control input 0 - 10V or PWM (Terminal 4 flow regulator ARFIT)
4-20mA Control input 4 - 20mA
+20V Power for external devices, max. 20mA (Connect to terminal 1 of the ARFIT flow regulator to
enable operation)
+10V Power for external devices, max. 10mA (terminal 5 flow regulator ARFIT)
OUT Status output of the fan 0-10V, max. 3mA
Image 12

17
ELECTRICAL DIAGRAMS – EC FANS
-Scheme EC - 12 (Image 13):
Connector Connection Description
KL1
L1 Power - Phase 230 / 1 / 50
(See characteristics on the motor plate)
N Power - Neutral
PE Ground
KL2
NO Status relay, normally opened, closes with alarm
COM Standard in the status relay
NC Status relay normally closed, opens with alarm
KL3
RSA RS485 MODBUS RTU
RSB
GND Reference for interface (terminal 3 flow regulator ARFIT)
0-10V/PWM Control input 0 - 10V or PWM (Terminal 4 flow regulator ARFIT)
4-20mA Control input 4 - 20mA
+20V Power for external devices, max. 20mA (Connect to terminal 1 of the ARFIT flow regulator to
enable operation)
+10V Power for external devices, max. 10mA (terminal 5 flow regulator ARFIT)
OUT Status output of the fan 0-10V, max. 3mA
Image 13

18
ELECTRICAL DIAGRAMS - AC FANS
One of the vital components for the correct functioning of the ARFIT brand air handling units are the fans, so,
make sure that they are correctly connected according to the following diagrams:
- Three-phase motors 400V (star connection – image 14) and 230V (delta connection – image 15)
- Three-phase motors 400/690V (Image 16):
Note: For AC fans of two or more speeds consult the manufacturer's manual.
Image 14 Image 15
Image 4
Image 16
