Introduction
The SC13XX multi-angle camera is specifically designed to provide a close-up view of
sewer pipe walls by utilizing a rotating camera head. The camera head can be outfitted
with lightheads that illuminate the sewer walls as the camera head moves. The SC13XX
can be used in sanitary sewers and storm drains that are between 6 and 120 inches in
diameter.
The camera rotates and pans back and forth, thus increasing efficiency of lateral
connection inspections. When the operator at the control station pushes the “Home” button
on the CCU, the camera head assembly returns to front-center, looking down the pipe.
The camera was designed to be used with a self-propelled mobile transporter. The electric
power and control signals for the camera, its light, and the transporter are transmitted
through a 1/4-inch O.D. single-conductor armored coaxial cable.
Camera Pressurization
The body of the Single Conductor Model SC13XX camera is pressurized at the factory.
This is done with nitrogen to prevent moisture from entering the body and damaging the
internal electronics and/or interfering with their proper operation. The internal pressure is
constantly monitored and can be displayed on the video screen. Whenever the camera
body is opened or its seal is in any way broken, the body must be re-pressurized. Field
pressurization is accomplished using the Nitrogen Pressure Assembly, P/N 150062, which
is included in the Nitrogen Pressurization Kit, P/N 950011 (not included).
For further pressurization information, along with the detailed and complete pressurization
procedure, reference Aries Pressurization manual, P/N 970075.

970137_B www.ariesindustries.com Page 6
Lightheads
The Single Conductor SC13XX has the ability to be used with several lightheads. The
choice of these lightheads depends on which pipe size is to be inspected.
The two standard lightheads were the LH932444 and LH9340. The current lighthead is
the LH9350 (9 Rebel LED Ring).
LH932444 -4 Bulb Hi Power 40W (previous model)
LH932446 - 4 Bulb Hi Power 60W (previous model –
not available)
LH932448 - 4 Bulb Hi Power 80W (previous model –
not available)
LH9340 - 96 LED Ring (previous model –not
available)
LH9350 - Lighthead, 9 Rebel LED Ring
(Current model lighthead)

970137_B www.ariesindustries.com Page 7
Changing Lightheads
Each lighthead has two or three gold plated contact pins which attach to the front external
circumference of the camera lens body. Each gold plated contact pin has a silicone “wiper” O-ring
to create a watertight seal. Each lighthead has four Allen set screws to allow for easy installation
and removal from the camera lens body.
LH932444, LH932446 &
LH932448 Contact Pins
LH9340 / LH9350
Contact Pins

970137_B www.ariesindustries.com Page 8
Spare Parts Kit, Single Conductor Camera (P/N 950032)
P/N
Description
Qty
UOM
100148
Screw, 10-24 x 1/4 Cap SOC SS
4
EA
100149
Screw, 10-24 x 1/8 Long Pan Head Seal, SS w/ O-Ring
1
EA
107202
Screw, 6-32 x 3/8 Cap SOC SS
8
EA
130058
O-Ring, #041 Buna-N 70 Duro
2
EA
130075
O-Ring, #143 Buna-N 70 Duro
1
EA
130107
O-Ring, #010, 0.070 C.S. x 0.239 I.D., Buna-N 70 Durometer
2
EA
150420
Retainer, Lens, LED Pan & Tilt
1
EA
150436
Washer, Lens, LED Pan & Tilt
1
EA
150558
Cover, Side Drive Yoke
1
EA
150559
Cover, Side Pivot Yoke
1
EA
210153
Lens, Glass Protective Front Cover
1
EA
670347
Jack, Banana Miniature Red w/ Pin
3
EA

970137_B www.ariesindustries.com Page 9
RETURNING EQUIPMENT AND PARTS:
Please DO NOT return any equipment until you contact Aries for a Return Material Authorization
(RMA) #. Call the nearest Aries Customer Service department listed on the front cover of this
manual to obtain your RMA # and information on packaging and shipping the equipment to Aries.
Equipment can be damaged if not properly packaged.
PLEASE RETURN CAMERA/EQUIPMENT IN ITS ORIGINAL CASE.
Contact Aries Customer Service department for instructions and/or questions.
NOTE: Equipment needs to be cleaned before returning to Aries.
IMPORTANT: Prior to returning your equipment, a P.O. # and RMA # will be required!
ORDERING EQUIPMENT AND PARTS:
When calling Aries, please be ready to provide the following information for faster, more
accurate part order processing:
1. Name, Company/Municipality, Telephone Number, Fax Number
2. Product/Item, Description, Part Number, Quantity
3. Contact Name at Aries Industries, Inc. (if applicable)
4. Bill to and Ship to Address
5. Preferred Method of Shipment and an alternate method of shipment
6. Purchase Order Number
