Ariesys AMK Series Assembly instructions

AMK DP User Reference Manual

２
Thank you for purchasing AMK LCD console drawer. AMK LCD console drawer can save
your MONEY, TIME, SPACE, EQUIPMENT and POWER.
PCs or Servers can be controlled from One Keyboard, Mouse and LCD Monitor. AMK
LCD console drawer is loaded with features such as 19” Rack Mount Size, Daisy Chain up
to eight units, On Screen Display Menu, Password security, Searching PC server name,
Hot key Control, Front Panel Push Button and Auto Scan Control. It has complete
keyboard and mouse emulation for simultaneous PCs boot-up process.
Meets EIA310c & IEC-3 specifications
1U, built-in 17.3”, 17” or 19” LCD Monitor, 4 port DP KVM switch to 19” rack mount
cabinet.
1U Single Rail: AMK504, AMK804 or 1U Dual Rails: AMK704
Built-in 17.3”, 1920x 1080, 17” or 19” 1280x 1024
Option: 17.3”, 3840x 2160 (4K) LCD monitor
Industrial keyboard with touchpad
Built-in rail self-locking device
Tempered glass protects LCD screen
Support DOS, Win3.X, Win95/98/98SE/2000/ME/XP, WinNT, Netware, SCO Unix, HP
Unix, Linux
Hot Plug - Add PCs or Remove Connected PCs for Maintenance no need to power
down the KVM switch or PCs.
No Software Required - easy PC selection via front push buttons and Hot Keys
Auto scan mode. Easy to monitor server operation
Introduction
Features

３
Model No.: AMK504/ AMK704/ AMK804
Package Content QTY
AMK 1 port 1
User’s manual 1
Power Cord 1
Bracket 2
DP to DP Cable 4
USB to USB cable 4
audio-microphone cable 4
Foam with Box 1
Screw Pack 1
Note: AMK models with DC power supply do not include power cord.
Package Contents

４
Model No. AMK704 AMK804 AMK504
Construction Heav
y
-dut
y
Steel
Drawer Desi
g
n Dual slide rail 1U, sin
g
le slide rail LCD KB drawer
LCD Display 17”, 1280x 1024 resolution
Option: 19”, 1280x 1024 resolution
17.3”, 1920x 1080
Option: 1600x 900
Protection Tempered
g
lass protect LCD screen
Ph
y
sical securit
y
Ke
y
lockin
g
mechanism 2 thumb screws
KVM switch 4 port Displa
y
Port KVM switch
Port connection 4* Displa
y
Port, 4* audio, 4* Microphone, 4* USB
Port selection 4x Front push buttons, Hotke
y
LED indication USB LED indicates a computer is connecting
DP LED indicates the port has been selectin
g
Keyboard Industrial keyboard with touchpad
Option KB: CH, FR, GR, IT, JP, KR, PT, RU, SP, UK, US
Power supply Built-in 60W, 90~264VAC Auto Switch, Operating Temp.: -20~70°C
Option: 80W, 24~48 VDC power suppl
y
Ph
y
sical Securit
y
Ke
y
lockin
g
Mechanism
Power Consumption 3 watts stand-b
y
, 25 watts in-use
Operation Temperature 0~50℃
(
32 ~ 122°F
)
Storage Temperature -20 ~ 60℃
(
-4 ~ 140°F
)
Humidit
y
0~90%, Non-Condensin
g
Wei
g
ht
(
k
g)
12 k
g
11 k
g
Dimension
(
cm
)
442.4x 44x 590mm 442.4x 44x 521.6mm
Compliance CE, FCC Class
A
, RoHS
KVM cable 4* DP/ USB/ audio-microphone cables
AMK5 series: 2 thumb screws to secure LCD monitor
4-port DisplayPort KVM switch:
Number of Ports 4
Number of Console 1
Number of KVM cable 4
PC Keyboard/Mouse Connectors 4 x USB Type B Female
PC Video Connectors 4 x DisplayPort Female
PC Audio/Mic 8 x 3.5mm Audio/Mic Jack Female
PC Selection Push Buttons / Hotkeys
Beeper Yes
PC Port LEDs 4 (Green)
Hub Port LEDs 4(Red)
Digital Display Resolution 4096 x 2180@60HZ
Keyboard & Mouse Emulation Yes (TTU)
Autoscan Delay Time 10
~
60 sec
Technical Specifications

５
1.8m DisplayPort (M) to DisplayPort (M) cable
1.8m USB cable Type A male to Type B male
1.8m 2-in-1 audio & mic cable
Rear Panel of AMK704/ AMK804/ AMK504:
Cable Diagrams
Console audio jack
Console mic. jack
PC/Server DisplayPort
PC/Server mic jack
PC/Server audio jack
PC/Server USB Port

６
Rackmount Installation
1. Find the property position to screw these two extension brackets with the
ears and both side onto the server rackmount first.
2. Lift & push the AMK inside the rackmount, and screw between bracket and
AMK with 4 screws.
3. Mount the front ears of AMK main body onto the server rackmount.

７
Before installation, please make sure all of peripherals and computers have been turned off.
Step 1
Insert the RACK LCD Console Drawer into the 19” rack cabinet in the desired position.
Attach the 2x rear support brackets and extending into the proper length of the cabinet depth. And
secure the 2x brackets on each side with the supplied screw.
Secure the rear and front rack mounting to properly mount and fix its position into the cabinet
Step 2
Connecting the Displayport, USB type B, 2-in-1 audio & mic cables was connected to the rear of
drawer, and Displayport, USB type A, 2-in-1 audio & mic cables was connected to PC or server.
Step 3
Connecting external speaker and microphone to console audio & microphone jack.
Step 4
Double-check all of the connections. You can check the color of audio and mic connector to make
sure the audio and mic cables go to the correct ports.
Step 5
Connect the AC power cable into rear of the drawer unit.
Turn on the drawer unit main power on the back of the chassis
Step 6
Turn on all the computers and then boot them one by one. Switch on your monitor make sure
every monitors can be display and then set the computer’s Monitor power always on. In order to
keep the connection form KVM to the Computers.
Installation/Operation

８
You may have two methods to control this KVM switch, please refer to the descriptions below.
1. Front push buttons
The front button allows you a direct control over KVM switching operation. Simply press the button
to toggle to the other PC port (together with hub port control and/or audio/mic port, if binding is
enabled). By default, PC port switching, hub port control and audio/ mic port switching are bound
together, unless you specify the audio to be fixed a specific port.
2. Keyboard Hotkeys
A keyboard hotkey sequence consists of at least three specific keystrokes: See Quick Reference
Sheet
Hotkey sequence = [ScrLk]* + [ScrLk] * + Command key(s) *
User-definable = SCROLL LOCK, CAPS, ESC, F12 or NUM LOCK
Hotkey preceding sequence configuration: For users who want to use a preceding sequence other
than two consecutive Scroll Locks, there is also one convenient way to configure it.
(1) Hit ScrollLock + ScrollLock + H, then two beeps will signal readiness for new preceding
sequence selection [or Press and hold down the last front-panel button (Button 2 or Button 4)
until you hear two beeps, then release the button.]
(2) Select and press the key you would like to use as your preceding sequence (SCROLL LOCK,
CAPS, ESC, F12 or NUM LOCK keys are available for selection) and you’ll hear a beep for
selection confirmation. Now you can use the new preceding sequence to execute your hotkey
commands.
Note: Each keystroke within a hotkey sequence should be pressed within 2 seconds. Otherwise,
the hotkey sequence will not be validated.
Operation

９
QUICK REFERENCE SHEET
Command Hotkeys Description
Select PC Port ScrLk + ScrLk + (x)
x = 1~2/ 1~4 for PC port number
Select the active PC port
(Jointly select PC port / hub port control / audio mic, if
binding is enabled)
Select Hub Port
Control
ScrLk + ScrLk + (Fx)
Fx = F1~F2/ F1~F4 (Fx is a function key)
x = 1~2/ 1~4 for hub port numbe
r
Select the PC port that control all USB hub ports
(Jointly select PC & hub port control, if PC/ hub port control
binding is enabled)
Select Audio&Mic Port ScrLk + ScrLk + (Fy)
Fy = F5~F6/ F5~F8 (Fy is a function key)
y = 5~6/ 5~8 for audio&mic port numbe
r
Select the active audio&mic port
(Jointly select PC & audio&mic port, if binding is enabled)
Bind PC and Hub Port
Control Switching
ScrLk + ScrLk + Z Enable the binding of PC port and hub port control switching.
(Once this feature is enabled, any pc and/or hub port control
switching is bound together) (factory default)
Unbind PC and Hub
Port Control Switching
ScrLk + ScrLk + X Disable the binding of PC port and hub port control switching
Bind PC and
Audio&Mic Switching
ScrLk + ScrLk + Q Enable the binding of PC port and audio&mic switching.
(Once this feature is enabled, any pc and/or audio&mic
switching is bound together) (factory default)
Unbind PC and
Audio&Mic Switching
ScrLk + ScrLk + W Disable the binding of PC port and audio&mic switching
Previous PC port
ScrLk + ScrLk + ↑(arrow up)
Select the previous connected PC port
(Jointly select PC/ hub port control, if binding is enabled)
Next PC port ScrLk + ScrLk + ↓(arrow down) Select the next connected PC port
(Jointly select PC/ hub port control, if binding is enabled)
P
r
evious PC port
ScrLk + ScrLk + (Backspace)
Toggle between the previous port and current port
Beep Sound On/Off ScrLk + ScrLk + B Toggle on/off the beep sound while autoscanning
Define Hotkey
Preceding Sequence
ScrLk + ScrLk + H + (y)
y = SCROLL LOCK, CAPS, ESC, F12 or
NUM LOCK
Select the hotkey preceding sequence among 5 alternative
keys
Autoscan ScrLk + ScrLk + S Autoscan through every connected port for quick screen
browsing of each port (scan delay = 5 sec.).
Autoscan with
Programmable Delay
Time
ScrLk + ScrLk + S + (z)
z = 0~9
Autoscan with a user-defined delay time within a range of 10
~ 100 seconds
Stop Autoscan Press any button Terminate autoscan activity
Notes:
1. The USB keyboard hotkeys allows you a faster and broader control for your KVM switching operation in addition to the front-panel
button. If you have configured a hotkey preceding sequence other than two consecutive scroll locks, here you should change your
hotkey sequence accordingly. (For preceding sequence key configuration, please refer to ”Operation” in above table.)
2. When the binding of PC & USB hub port control switching is enabled by the hotkey sequence: ScrLk + ScrLk + Z, any PC and hub
port control switching are bound together. To remove this binding, use the hotkey sequence: ScrLk + ScrLk + X.
3. When the binding of PC and audio&mic switching is enabled by the hotkey sequence: ScrLk + ScrLk + Q, any PC and audio&mic
switching are bound together. To remove this binding, use the hotkey sequence: ScrLk + ScrLk + W.

１０
Troubleshooting
1. Ensure that all cables are well seated. Label all of cables with the number for each
respective computer to avoid confusion.
2. The recommended DP cable distance is 3 meters maximum without ghosting and
degradation. Normally, the cable length is based on driver capacity of your VGA card.
If you need longer VGA cable, please use VGA extender to accomplish your
applications.
3. The recommended USB cable distance is 3 meters maximum. Normally, the cable
length is based on driver capacity of your motherboard USB port. If you need longer
USB cable, please use USB extender to accomplish your applications.
4. The Power Jack polarity is center positive and the power adapter need be DC12V, 1A .
5. Don’t press any keys on the keyboard while the selected computer is booting up.
Otherwise, it might cause the keyboard error or keyboard is not detected at PC side.
6. The computer boot up fine, but keyboard doesn’t work
Make sure the keyboard works when directly plugged into the computer.
Try a different keyboard.
7. The Mouse is not detected during PC boot up.
Make sure the mouse works when directly plugged into the computer.
Make sure the mouse is a true USB mouse. A combo mouse will work just as long as
it is set for USB mode with the correct adapter. Try a different mouse.
Avoiding moving the mouse or pressing the mouse buttons when switching ports.
Avoiding switching ports during shutting down the PC process.
When you switch one PC port to another PC port, the best scan time setting need to
be set to 5 sec. or more. Normally, the DP monitor change one resolution mode to
another will take 3~5 seconds. So, the scan time is not recommended to below 5
seconds.
