Armitron YP13614 User manual

YP13614
INSTRUCTIONS MANUAL
FEATURES
SELECTING FEATURES
SETTING THE TIME AND CALENDAR
EL LIGHT FEATURE
12/24 HOUR (MILITARY) TIME
STOPWATCH
• Time Telling Mode (Hours, Minutes, Seconds, Month, Date, and Day
of the Week)
• 100 Year Calendar
• (5) 24 Hour Alarms
• Hourly Chime: One ‘Beep’ sound every full Hour
• Chronograph Mode: Hours, Minutes, Seconds, and 1/100 of a sec-
ond with Lap Operation
• Countdown Timer
• Second Time Zone
• Pacer
• 12/24 Hour (Military Time)
• Water Resistant as indicated on the watch
• INSTALITE - Electro Luminescent Display
1. Time Telling Mode displays Hours, Mlnutes, Seconds, Month, Date, and
Day of the Week.
2. From Time Telling Mode, press ‘B’ once. Chronograph appears. Press
‘B’ five times to return to Time Telling Mode.
3. From Time Telling Mode, press ‘B’ twice. Countdown Timer Mode ap-
pears. Press ‘B’ four times to return to Time Telling Mode.
4. From Time Telling Mode, press ‘B’ three times. Alarm Mode appears.
Press ‘B’ three times to return to Time Telling Mode.
5. From Time Telling Mode, press ‘B’ four times. Second Time Zone Mode
appears. Press ‘B’ once to return to Time Telling Mode.
ANALOG
1. Carefully pull the Crown (‘E’) out all the way and tum in either direction
until the desired time Is displayed.
2. Carefully push the Crown back in all the way to resume time keeping.
DIGITAL
1. From Time Telling Mode, press and hold ‘A’. Seconds flash. Press ‘C’ to
zero out the seconds.
NOTE: Zeroing out 30 or more seconds automatically adds one minute to
time.
2. Press ‘B’. Hours flash. Press ‘C’ to advance the Hours.
NOTE: Pressing and holding ‘C’ will advance digits rapidly. When 12 Hour
Format is selected, ‘PM’ indicates ‘p.m.’ times; there is no indicator for
‘a.m.’ times.
3. Press ‘B’. Minutes flash. Press ‘C’ to advance the Minutes.
4. Press ‘B’. The Year flashes. Press ‘C’ to advance the Year.
5. Press ‘B’. Months Flash. Press ‘C’ to advance the Month.
6. Press ‘B’. The Day flashes. Press ‘C’ to advance the Day.
7. Press ‘A’ to end set sequence and return to Time Telling Mode.
1. Press ‘D’ in any mode to illuminate the watch face. The backlight will
remain lit for 3 seconds.
NOTE: Excessive use of the light will shorten battery life.
From Time Telling Mode, press ‘C’ to set either 12 Hour Time or 24 Hour
(Military) time.
1. From Time Telling Mode, press ‘B’ once to enter the Stopwatch Mode.
2. Press ‘C’ to start timing.
3. Press ‘C’ again to stop timing.
4. Press ‘A’ to reset to zero.
5. Press ‘B’ to return to Time Telling Mode.
SPLIT TIME
PACER
COUNTDOWN TIMER
SETTING THE 24 HOUR ALARMS
1. While in the Stopwatch Mode, press ‘C’ to start timing
2. Press ‘A’ to measure and display the Split Times.
3. Press ‘C’ to stop timing at the end of the event.
4. Press ‘A’ to reveal the final Split Time.
5. Press ‘A’ again to reset to zero.
6. Press ‘B’ to return to Time Telling Mode.
1. From Time Telling Mode, press ‘B’ four times. Pacer Mode appears.
2. Press ‘A’ to select the tempo in tile following sequence: 10-20-30-40-60
-80-120-160 -240-320.
3. Press ‘C’ to start the Pacer.
4. Press ‘C’ again to stop the Pacer.
5. Press ‘B’ to return to Time Telling Mode.
1. From Time Telling Mode, press ‘B’ twice to enter the Timer Mode.
2. Press and hold ‘A’. Hours flash. Press ‘C’ to adjust the Hour.
3. Press ‘B’. Minutes flash. Press ‘C’ to adjust the Minutes.
4. Press ‘B’. Seconds flash. Press ‘C’ to adjust the Seconds.
5. When the Countdown Timer is set, press ‘A’ to end set sequence and
return to Timer Mode.
6. Press ‘C’ to start the Countdown Timer.
7. If desired, press ‘C’ to stop the Countdown Timer. Press ‘C’ again to
resume the Countdown Timer.
NOTE: The Countdown timing will continue in any mode until ‘C’ is
pressed. When the Timer has expired, the alarm will sound for about 60
seconds or until any button is pressed.
8. Press ‘C’ to stop the Timer.
9. Press ‘B’ to return to Time Telling Mode.
1. From Time Telling Mode, press ‘B’ three times to enter the Alarm Mode
2. Press ‘C’ to select the Alarm number: Alarm 1 through Alarm 5.
NOTE: The process to set Alarms 1 through 5 is the same.
3. Press ‘A’. Alarm Hours flash. Press ‘C’1o advance the Alarm Hour.
4. Press ‘B’. Alarm Minutes flash. Press ‘C’ to advance the Alarm Minute.
5. Press ‘A’ to end set sequence.
6. Press ‘B’ to return to Time Telling Mode.
ACTIVATING ALARM + HOURLY CHIME
1. While in Alarm Mode, press ‘C’ to activate the Hourly Chime. The Hourly
Chime Symbol appears to indicate that the Hourly Chime will sound every
hour on the hour.
2. Press ‘C’ again to deactivate the Hourly Chime.
3. Press ‘D’ again to deactivate the Alarm (1-5).
4. Press ‘C’ to activate the selected Alarm. The Alarm Symbol appears to
indicate the Alarm will sound at the preset Alarm Time for about 60 sec-
onds or until any button Is pressed.
5. Press ‘C’ again to deactivate the Alarm.
6. Press ‘B’ three times to return to Time Telling Mode.

WATER RESISTANCE
RETURN YOUR WATCH FOR SERVICING
USE OUR NATIONWIDE SERVICE CENTERS. YOU
CANNOT RETURN WATCH FOR SERVICE WHERE
IT WAS PURCHASED.
This is a WATER RESISTANT watch. Do not operate push buttons below
the surface of the water. Should water or condensation appear in the
watch, immediately have the watch checked. Water can corrode electron-
ic parts inside the case.
Please call [phone] for a listing of all approved and authorized
service centers and locations, or visit our website at:
WWW.ARMITRON.COM
YOUR WATCH SHOULD NOT BE RETURNED TO THE PLACE OF
PURCHASE. Carefully pack your watch in a sturdy box (do not send in a
gift box for same will not be returned) and mail to the nearest approved
authorized service station. Because of possible loss, we recommend that
you insure the watch, return receipt requested, when using the mail. If you
do not receive a receipt within a reasonable time, start a tracer through
the originating post office. Never include a special watch band or any
other article of personal value in your shipment.
If your watch requires cleaning, lubrication, battery changing, or needs
a crystal replaced, Armitron Adventure approved Service Centers are
available in your area. These repair facilities use Armitron Adventure parts
and components to assure quality and future performance. Free estimates
are available in advance, should you need servicing or repairs not covered
under the warranty. Repairs covered under the warranty may require proof
of purchase, so retain the purchase receipt.
INSTRUCTIONS MANUAL
CHANGING THE BATTERY
Change the battery when the watch becomes slow, the readout darkens or
does not appear, or the backlight fails. Before removing the old battery, be
sure to denote its polarity so that the new battery is installed in exactly the
same way. Replace with the same kind or equivalent only. This watch
contains precise electronic components and should only be opened by
a qualified watch technician. However, it is not necessary to return your
watch to the manufacturer for battery replacement. It is recommended that
you bring your timepiece to a local jeweler.
YP13614
SECOND TIME ZONE
1. From Time Telling Mode, press ‘B’ four times to enter the Second Time
Zone Mode.
2. Press and hold ‘A’. Hours flash. Press ‘C’ to adjust the Hour.
3. Press ‘B’. Minutes flash. Press ‘C’ to adjust the Minutes.
4. Press ‘A’ to end set sequence.
5. Press ‘B’ to return to Time Telling Mode.
NOTE: The Second Time Zone (Dual Time) Clock may be used to keep
track of a foreign time.
