Armitron 20/1277-79-81 User manual

20/1277-79-81, 20/1437GRN, 20/1555, 20/1683BLU, 20/1685GRN, 20/1811BLU
Armitron®
tron®
M
O
I
2
-
I
4
9
:
0
0
0
0
L
P
9
:
0
0
9
:
0
0
0
0
T
2
9
:
0
0
I
I
:
0
0
0
0
A
I
9
:
0
0
I
2
:
0
0
A
2
9
:
0
0
5
:
0
0
T
R
9
:
0
0
0
:
0
0
0
0
N
W
S
W
S
E
▼
M
O
I
2
-
I
4
l
l
l
l
l
l
l
l
l
l
l
l
S
E
T
A
D
J
.
M
O
D
E
L
I
G
H
T
W
A
T
E
R
1
6
5
R
E
S
I
S
T
9
:
0
0
0
0
6
0
4
5
Armitron
3
0
A
l
l
-
S
P
O
R
T
AC
E
BD
M
O
I
2
-
I
4
l
l
l
l
l
l
l
l
l
l
l
l
S
E
T
A
D
J
.
M
O
D
E
L
I
G
H
T
W
A
T
E
R
1
6
5
R
E
S
I
S
T
Armitron
I
N
S
T
A
L
I
T
E
9:0000
C
H
I
M
E
A
L
M
2
4
5
T
I
M
E
R
A
L
M
1
1
5
8 LAPS
CHRONO
0
M
O
I
2
-
I
4
l
l
l
l
l
l
l
l
l
l
l
l
S
E
T
A
D
J
.
M
O
D
E
L
I
G
H
T
9
:
0
0
0
0
M
O
I
2
-
I
4
9
:
0
0
00
00
I
2
M
O
I
2
-
I
4
99
:
0
0
0
0
M
O
I
2
-
I
4
9
:
00
00
0
0
M
O
II
22
-
I
4
9
:
0
0
0
0
9
M
O
M
O
I
2
-
II
44
9
:
0
0
0
0
MM
OO
I
2
-
I
4
9
:
0
0
0
0
I
4
H
R
II
22
H
R
22
44
FEATURES
• Time Telling Mode (Hours, Minutes, Seconds, Month,
•Date and Day of the Week)
• 12/24 Hour (Military Time)
• Chronograph Mode: Hours, Minutes, Seconds and
•1/100th of a Second with 8 Lap/Split Operations
• Timer: Hours, Minutes and Seconds
• Second Time Zone
• (2) 24 Hour Alarms: Sound for 20 Seconds at preset
•Alarm Time until any button is pressed
• Hourly Chime: Two ‘Beeps’ sound every full Hour
• Water Resistant as indicated on the watch
• INSTALITE – Electro Luminescent Display with three
•seconds automatic light up
SELECTING FEATURES
 1.Time Telling Mode displays Hour, Minutes,
 Seconds, Month, Date, and Day of the
 Week.
 2. From Time Telling Mode, press ‘B’ once.
  Chronograph Mode appears. Press ‘B’ five
  times to return to Time Telling Mode.
 3. From Time Telling Mode, press ‘B’ twice.
Timer Mode appears. Press ‘B’ four times
to return to Time Telling Mode.
 4. From Time Telling Mode, press ‘B’ three
times. Second Time Zone appears. Press ‘B’
three times to return to Time Telling Mode.
5. From Time Telling Mode, press ‘B’ four
 times. Alarm 1Mode appears. Press ‘B’
 twice to return to Time Telling Mode.
 6. From Time Telling Mode, press ‘B’ five
 times. Alarm 2Mode appears. Press ‘B’
 once to return to Time Telling Mode.
INSTALITE - NIGHT VISION DISPLAY
1. Press ‘D’ in any mode to illuminate the watch face.
NOTE: Excessive use of backlight will shorten battery life.
WATER RESISTANCE
This is a WATER RESISTANT watch. Do not operate the
push buttons below the surface of the water. Should water
or condensation appear in the watch, immediately have
the watch checked. Water can corrode electronic parts
inside the case.
12/24 HOUR (MILITARY) TIME
 1.From Time Telling Mode, press ‘A’ once.
  Seconds flash. Press ‘B’ six times. 24 Hour
  Format flashes. Press ‘C’ to select either
  12 Hour Time or 24 Hour (Military Time).
 2.Press ‘A’ to return to Time Telling Mode.
SECOND TIME ZONE
1. From Time Telling Mode, press ‘B’ three times to enter
Second Time Zone Mode.
2. Press ‘A’. Hours flash. Press ‘C’ to advance Hours.
3. Press ‘B’. Minutes flash. Press ‘C’ to advance Minutes.
4. Press ‘A’ to end set sequence.
5. Press ‘B’ to return to Time Telling Mode.
AC
E
BD
SETTING THE TIME AND CALENDAR
 Analog
 1. Pull the Crown, ‘E’, out. The
 second hand stops. Rotate the
 Crown in either direction until the
 desired time is obtained. Push
 the Crown back in to re-engage
 time keeping.
Digital
1.From Time Telling Mode press ‘A’ once.
 Seconds flash. Press ‘C’ to zero out
 seconds.
 NOTE: Zeroing out 30 or more seconds
 automatically adds one minute to time.
2. Press ‘B’. Hours flash. Press ‘C’ to advance
the Hour.
NOTE: Pressing and holding ‘C’ will
advance digits rapidly.
When 12 Hour Format is selected, ‘PM’ indicates ‘p.m.’
times; there is no indicator for ‘a.m.’ times.
3. Press ‘B’. Minutes flash. Press ‘C’ to
advance the Minutes.
4. Press ‘B’. Months flash. Press ‘C’ to
advance the Month.
5. Press ‘B’. Date flashes. Press ‘C’ to advance
the Date.
6. Press ‘B’. Day of Week flashes. Press ‘C’ to
advance the Day of the Week.
7. Press ‘A’ to end set sequence and return
to Time Telling Mode.
CHRONOGRAPH
1. From Time Telling Mode, press ‘B’ once to enter the
Chronograph Mode.
2. Press ‘C’ to start timing.
3. Press ‘C’ again to stop timing.
4. Press ‘A’ to reset to zero.
SPLIT OR LAP TIME
1. Press ‘A’ to select either SPLIT or LAP Chronograph.
SP indicates the SPLIT Chronograph is selected.
LP indicates the LAP Chronograph is selected.
SPLIT Chronograph allows the user to view the total
accumulate time at a particular interval, while the internal
stopwatch continues to accumulate total time.
LAP Chronograph allows the user to view the elapsed
time for a particular interval, then resets to zero to
measure the discrete time of the next interval.
1. In either SPLIT or LAP Chronograph, press ‘C’ to start
timing.
2. Press ‘D’ to measure splits or laps.
3. Press ‘C’ to stop timing at the end of the event.
4. Press ‘A’ to reset to zero.
5. Press ‘B’ to return to Time Telling Mode.
NOTE: To recall the time of either splits or laps, press ‘D’
before you reset the Chronograph to zero. The memory
capacity is 8 splits or laps.
SETTING ALARMS 1 & 2
1. From Time Telling Mode, press ‘B’ four times for
Alarm 1Mode or five times for Alarm 2Mode.
NOTE: Both Alarm 1and Alarm 2 can be set. When Alarm
is activated, the alarm (‘Beep Beep’) will sound at the
preset time for 20 seconds or until any button is pressed.
2. Press ‘A’. Hours flash. Press ‘C’ to advance Hours.
3. Press ‘B’. Minutes flash. Press ‘C’ to advance Minutes.
4. Press ‘B’. Second Time Zone Alarm flashes. Press ‘C’ to
select either Normal Time Zone or Second Time Zone.
Findicates the Second Time Zone is selected.
5. Press ‘A’ to end set sequence. Press ‘B’ to return to
Time Telling Mode.
ACTIVATING THE ALARM AND HOURLY CHIME
1. While in Alarm Mode, press ‘C’ to select ALARM 1,
ALARM 2 and/or HOURLY CHIME.
‘ALM1’ or the symbol on the right side of the
display, depending on your particular watch
style, indicates the ALARM 1 is activated.
‘ALM2’ or the symbol on the right side of the
display, depending on your particular watch
style, indicates the ALARM 2 is activated.
The word ‘CHIME’ or the symbol on the left
side of the display, depending on your particular
watch style, indicates the HOURLY CHIME is
activated and the alarm (‘Beep’) will sound every hour
on the hour (only available in ALARM 1 Mode).
2. Press ‘C’ again to deactivate ALARM 1, ALARM 2
and/or HOURLY CHIME.
TIMER
1. From Time Telling Mode, press ‘B’ twice to enter the
Timer Mode.
2. Press ‘A’. Hours flash. Press ‘C’ to advance Hours.
3. Press ‘B’. Minutes flash. Press ‘C’ to advance Minutes.
4. Press ‘B’. Seconds flash. Press ‘C’ to advance Seconds.
5. When Countdown Time is set, press ‘A’ to return to
Timer Mode.
6. Press ‘C’ to start Countdown timing. ‘TIMER’ will flash
on the display during Countdown.
7. If desired, press ‘C’ again to stop Countdown timing.
Press ‘C’ again to resume Countdown timing.
8. If desired, press ‘D’ to reset the Countdown time to the
preset value and to restart Countdown.
NOTE: When the Timer counts down below three
minutes, an alarm (‘Beep Beep’) will sound when the
Seconds Digit is ‘0’ or ‘30’. When the Timer counts down
below ten seconds, an alarm (‘Beep’) will sound every
second. When the Timer has expired, the alarm (‘Beep
Beep Beep’) will sound for ten seconds or until any
button is pressed. If no button is pressed during the ten
second interval, the Timer will count up for five minutes.
Press ‘C’ to stop the ‘Count up Timer.’ Press ‘C’ again
to resume ‘Count up Timer.’
9. Press ‘C’ to stop Timer. Press ‘B’ to return to Time
Telling Mode.
CHANGING THE BATTERY
Change the battery when the watch becomes slow, the
readout darkens or does not appear, or the backlight fails.
Replace with one (1) CR2025 or equivalent only.
This watch contains precise electronic components and
should only be opened by a qualified watch technician.
How-ever, it is not necessary to return your watch to the
manufacturer for battery replacement. It is recommended
that you bring your timepiece to a local watch repair
facility.
Dear Customer:
Help your watch/jewelry retailer protect our environment
by properly recycling the button cell battery in your watch.
Professional jewelers and watch retailers are best
equipped to replace the battery in your watch without
damage to the watch case and movement inside. They
have the specialized tools and experience to do the job
right. Inexperienced people can scar the case and damage
the water resistant seal – voiding your warranty.
  It is important to recycle your watch battery in an
environmentally safe way. Watch batteries contain very
small amounts of mercury, which is required to prevent
corrosion of the battery and damage to your watch. There
is no danger to you or your watch from the mercury
because it is in the sealed battery. But you need to recycle
your watch battery properly. Your professional watch/
jewelry retailer is the best person to do this for you. These
professionals collect used batteries and recycle them
through licensed waste management companies.
  Do our environment and your watch a favor. Ask your
watch/jewelry professional to replace your battery when it
expires.
A
L
M
2
A
L
M
1
1
5
A
L
M
2
A
L
M
1
1
5
C
H
I
M
E
4
5
T
I
M
E
R
WATCH INSTRUCTIONS
