ARTDEV AS-1310 User manual

AS-1310 image barcode scanner quick guide
Note
Parts of the scanner
①
Beeper
②
LED
③
Exit window
④
Trigger
⑤
Cable interface port
⑥
Release-hole of the cable
Installing the cable
1. Switch off the host;
2. Refer to the below pictures, connect the host with the scanner based on different cables;
3. Ensure that all connections are secure.
4. Switch on the host system. If the installation is successful, the beeper will beep and LED
will light.
USB cable RS232 cable
Removing the cable
1. Find the release-hole.
2. Insert a thin wire into the hole and pull out the cable gently.
Reading techniques
1. Press and hold the trigger, an aiming beam is projected which is suggested to be centered
over the barcode.
2. In general, the optimal reading range is limited to 5-7cm regardless of the size of the
minimal element of the barcode.
3. On a successful reading, the scanner will beep once, and the illumination and aiming
patterns die out. Then the scanner transmits barcode message to the host.
Return default parameters and version information
Default value initialization
Firmware version list
Note: If the reader USB input too fast causing the host can not normally receive data, please
scan the barcode below:

A standard packing includes a scanner, a USB cable and a CD (or a user manual).

Accessories include a stand, a RS232 cable, and a 5V adaptor.

Use a piece of dry and soft cloth when cleaning the scanner is in need.
Note: 1. More details refer to User Manual. 2. For better readability, please print this document with laser printer. 3. Version: AS-1310_QG_EN_V1.2.

Programming instruction and example
Two programming modes have been provided as bellows:
Single-scan setting
Scan the appropriate
Single-scan setting
Example: to set Flow control to be XON/XOFF.
Multiple-scan setting
Scan “Option bar code”
Scan “the 1st character of option”
Scan “the 2nd character of option”
Scan “END”
Example: to set Flow control to be XON/XOFF.
Quick setting to enable/disable Auto-detection
Note: The stand is an optional accessory.
Scan the barcode “EN-AutoDete” on the stand to enable Auto-detection.
Scan the barcode “DIS-AutoDete” on the stand to disable Auto-detection. Note: The
Scanning mode will switch to momentary.
Assembling the stand
Note: The stand is an optional accessory.
1. See the figure above, tighten the screws.
2. Bend the neck to the desired position for scanning.
3. Screw mounting: Screw one #10 wood screw into each screw-mount-hole until the base of
the stand is secured.
4. Tape mounting: ①Peel the paper liner off one side of each piece of tape and place the
sticky surface over each of the three rectangular tape holders. ②Peel the paper liner off
the exposed sides of each piece of tape and press the stand on a flat surface until it is
secure.
DIS-AutoDete
EN-AutoDete
Note: 1. More details refer to User Manual. 2. For better readability, please print this document with laser printer. 3. Version: AS-1310_QG_EN_V1.2.
