Articulateshade Aspen Installation instructions

Aspen

Assembly Instructions 1. Components
Included Items for Assembly
(A) - Upper Umbrella Assembly (Includes Upper Pole)
(B) - Lower Pole Assembly
(C) - (2) 1/4” - 20 x 1.75” Socket Head Cap Screws
(D) - (2) 1/4” - 20 Socket Insert Nuts
(E) - 3/16” Allen Wrench
x 2
x 2
2
A
B
C
D
E
ARTiculatedshade

Assembly Instructions 2.
Secure to Base
Lower Pole
Assembly (B)
2” Diameter
Opening
Socket Nut
2. Securing to a Base
i. Insert lower pole assembly (B) into base casing (F).
ii. If placing umbrella in table, ensure table opening is clear and ground base is
properly situated below.
iii. Insert lower pole assembly through table opening and into ground base casing.
iv. Tighten available knobs (G) until pole is secure.
Warning: Wind can cause the umbrella to fall over or y away, resulting in
property damage and personal injury. Always secure the umbrella to a base having
enough weight and resistance to anchor the umbrella. Always close the umbrella in
moderate to high winds and when not attended. 3
ARTiculatedshade
Base Casing (F)
Tightening
Knobs (G)

3. Securing the Splice
i. Ensure lower pole section (B) is securely anchored in base. (See step 2)
ii. Lift upper umbrella assembly (A) and settle onto reduced end of
lower pole assembly (B).
iii. Rotate upper pole (A) to align holes in upper pole with holes in lower pole (the cleats
will be on the same side as the lower pole’s pre-secured socket nut).
iv. Install both socket screws (C) from opposite side of the upper pole as the cleat.
v. Attach both socket nuts (D) to ends of socket screws(C).
vi. Tighten both socket screws with provided allen wrench (E) to secure upper and lower
pole (Only the serrated portion of the nut will be visible and the head of the screw will
t snug against the inner pole section, leaving only an eighth of an inch visible on the
pole. See lower pole section).
Assembly Instructions 3.
Secure Splice
Upper Pole
& Umbrella
Assembly (A)
Lower Pole
Assembly (B)
Socket Screws (C)
Socket Nuts (D)
4.
6.
5.
Jaw Cleats
4
ARTiculatedshade

Operating Instructions 4.
Opening & Closing
Release cord by
pulling up and out
of jaws of cleat
Anchor cord by
pulling down and
into jaws of cleat
Jaw Cleats
4a. Opening Instructions
i. Prior to opening, always ensure the umbrella is properly secured to an adequate anchor.
ii. Release cord from jaws of cleats by pulling upward.
iii. Open umbrella by pulling cord away from cleats (remain seated or walk backward to
avoid ribs as they expand).
iv. Secure cord by pulling downward into jaws of cleats.
v. Hang extra cord from hook at bottom of cleats.
4b. Closing Instructions
i. Release cord from jaws of cleats by pulling upward.
ii. Close umbrella slowly by releasing cord, straightening cord as necessary to prevent
twists. Be careful not to lose grip of cord at any time. (Remain seated or walk forward to
avoid contracting ribs).
Caution:
Hang on tight to cord at
all times while opening or
closing umbrella to avoid
sudden and unexpected
closing of frame, which
could result in property
damage or personal injury.
Warning: The cord on this umbrella can present a strangulation hazard. Keep children away. 5
ARTiculatedshade

Operating Instructions 5.
Lock Pin & Canopy Tie
5a. Securing the Optional Pin
i. Once the umbrella is fully
open, insert the hanging lock pin (d)
into the provided hole.
ii. To close, hold tight to cord and pull forcefully
on ring, removing lock pin (d) from column.
5b. Using the Tie Cord
The canopy design allows for drainage and air
ventilation when closed. Tie the cord low around
the canopy to prevent apping and allow water
to drain through the upper portion of the canopy
when not being used.
6
ARTiculatedshade
5c. Storing the Umbrella
Before storing the umbrella, ensure the pleats and
folds have been smoothed.
i. Pull the draping pockets (b) out to a 90 degree corner.
ii. Smooth skirt hems (c) so that fabric hangs at and is absent of wrinkles.
iii. If using a cover, tie provided cord around pockets (b) so that they are
pressed in place against the umbrella, then secure cover.
iv. Store horizontal with the pole at on the ground or hung from a ceiling
using the functional nial (a).
v. Never seal umbrella; always allow for air ow to prevent moisture buildup.
(a)
(b)
(c)
Hanging
Lock Pin (d)

Care & Maintenance
Your satisfaction is our number one priority. ARTiculatedshade umbrellas are designed to be
structurally sound, deliberately functional, and aesthetically unique. We source all materials from
US companies focusing on durability and weather resistance. Proper use and care is critical to
prolonging the longevity and functionality of all ARTiculatedshade products. We strongly
recommend the following:
* Prior to use, always ensure the umbrella is properly secured to an adequate anchor.
* Never force the umbrella to open.
* Hang on tight to cord at all times while opening or closing umbrella to avoid sudden and
unexpected closing of frame.
* If it is too windy for you to enjoy your patio, it is too windy for your umbrella to be open.
The Apsen has been successsfully tested to 40 mph wind loads, however base
size and local conditions may not merit the same results. As such, please adhere
to the following guidelines:
* As winds strengthen or gusts increase, close the umbrella.
* Always close the umbrella when unattended.
* In anticipation of and during severe weather conditions, store the umbrella out of
harm’s way to prevent damage.
* Articulatedshade recommends routine inspection of frame and hardware. Loose
fasteners should be tightened and any broken elements replaced immediately to
prevent further damage to the umbrella.
* If operating in marine or industrial environments, the canopy and frame should be rinsed
o with fresh water monthly to remove salt and particle accumulation.
* Canopy should be cleaned regularly. Hand wash with mild soap, lukewarm water, and a
soft bristle brush. Always allow to air dry. For stubborn stains or a more thorough
machine washing, follow Glen Raven’s guide for Sunbrella fabrics:
www.sunbrella.com/en-us/how-to-clean/clean-sunbrella-shade-fabrics.
* Do not use a pressure washer to clean canopies.
* The caonpy was designed with self draining vents to avoid a build up of water when not
in use. Regularly check the folds to ensure proper venitlation and drainage.
* Check base and base hardware routinely, and tighten as necessary.
* Do not operate rolling bases on stairways or steep inclines.
* See base manufacturer’s instructions for care
and use.
ARTiculatedshade
7
ARTiculatedshade

Warranty
1. Limited Warranty; Warranty Period. Subject to the exclusions and other limitations set forth below, ARTiculatedshade,
LLC. (“We” or “Us”) warrants to the original end-user (“You”) that (a) the canopy (the “Canopy”) of the ARTiculatedshade, LLC
Compact Patio Umbrella manufactured by Us will be free from material defects in both material and workmanship (the “Canopy
Limited Warranty”) for a period of ve years after Your purchase of the Canopy (the “Canopy Warranty Period”) and (b) the frame
(including the mast, ribs, plastic hubs and connectors, pulleys, cleats and fasteners) (the “Frame” and together with the Canopy,
the “Product”) of the ARTiculatedshade, LLC Compact Patio Umbrella manufactured by Us will be free from material defects in
both material and workmanship (the “Frame Limited Warranty” and together with the Canopy Limited Warranty, the “Limited
Warranty”) for a period of three years after Your purchase of the Frame (the“Frame Warranty Period” and together with the Canopy
Warranty Period, the“Warranty Periods”). THE LIMITED WARRANTY IS MADE IN LIEU OF ALL OTHER GUARANTEES AND/OR
WARRANTIES, EXPRESS OR STATUTORY AND IS GIVEN ONLY TO YOU AND IS NOT TRANSFERABLE TO ANY THIRD PARTY. ALL IMPLIED
WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
APPLICABLE TO (i) THE CANOPY ARE LIMITED IN DURATION TO THE CANOPY WARRANTY PERIOD OR (ii) THE FRAME ARE LIMITED IN
DURATION TO THE FRAME WARRANTY PERIOD. This Limited Warranty gives You specic legal rights, and You may also have other
rights that vary from State to State.
2. Limitations on the Warranty. The Limited Warranty DOES NOT cover (a) any cosmetic damage, including exposed parts
of the Product that are scratched or damaged, fading, or variations in color, (b) non-material damage that does not directly
inuence shade production of the Product or safety, or (c) any defects caused by (i) normal wear and tear; (ii) abuse, neglect,
tampering, or misuse of the Product; (iii) any accident, act of God (including wind), or other event occurring beyond Our
reasonable control or after Your purchase of the Product (including but not limited to corrosion and other eects of natural
contaminants at a location where the Product has been located); (iv) misapplication, overloading, or improper installation; (v)
improper operation, maintenance, repair, handling, transport, storage, or environmental conditions; (vi) Product alteration in any
manner by anyone other than Us; (vii) shipping; or (viii) falling over of the Product due to any of the foregoing (i) - (vii). The
presence of such limitations shall be determined by Us in Our sole discretion.
3. Remedies and Limitations. If the Product does not comply with the Limited Warranty during the applicable Warranty
Period, (a) You shall submit to Us within 10 days after Your discovery of such non-compliance a written claim meeting the
requirements set forth below (a“Warranty Claim), and (b) Your sole and exclusive remedy is that We will, at Our option, either (i)
replace the applicable Product or the defective part of the applicable Product or (ii) repair the applicable Product or the defective
part of the applicable Product, in each case, within a reasonable time after Your submission of the Warranty Claim. We shall, at
Our option, use new or refurbished parts for replacement. YOUR SOLE AND EXCLUSIVE REMEDY, AND OUR SOLE AND EXCLUSIVE
LIABILITY, FOR NON-COMPLIANCE WITH THE LIMITED WARRANTY IS AS SET FORTH IN THIS PARAGRAPH. WE SHALL NOT BE LIABLE
FOR ANY LOSS OF USE, LOSS OF PROFITS, OR LOSS OR DAMAGE TO YOUR PROPERTY, OR FOR ANY OTHER INCIDENTAL,
CONSEQUENTIAL, OR EXEMPLARY DAMAGES THAT MAY ARISE, AND THE TOTAL LIABILITY OF US SHALL NOT EXCEED THE PRICE
PAID BY YOU FOR THE PRODUCT. Some States do not allow the exclusion or limitation of incidental or consequential damages, so
the above limitations or exclusions may not apply to You.
4. Obligations of Purchaser. To make a Warranty Claim, contact Us by mail or courier at Our principal address of 1089 Gil-
bert Street, Boulder, Colorado 80302, and in Your Warranty Claim, (a) identify Your name and contact information (including Your
phone number, email address, and address where the Product is located), (b) identify the Product by model and serial number, (c)
describe with reasonable specicity the alleged non-compliance, (d) identify the date of Your discovery of the non-compliance,
and (e) enclose a copy of Your purchase receipt to verify date of purchase and that You are the original end-user. After We contact
You regarding Your Warranty Claim, You shall follow the instructions We provide for returning the non-complying Product. At Our
request, You shall return any Product or part that is replaced by Us to the location designated by Us, and such Product or part shall
become Our property upon such request. You are responsible for all of the following if incurred by Us as a result of Your Warranty
Claim: (i) any labor charges that apply to (A) Our cutting or sewing of the Canopy or (B) the installation of any part, and (ii) any
shipping and freight charges, and You shall pay all such amounts within 30 days after our delivery of an invoice therefor. If You
would like to speak with Us regarding this Limited Warranty, Our customer service team is available at 303-817-4606 and can be
emailed at [e-mail] from 9:00 a.m. to 5:00 p.m. Mountain Prevailing Time, Monday through Friday except
holidays.
5. Assumption of Risk. Your use of the Product for any purpose other than the specied uses stated in the Product
instructions is at Your own risk.
6. Governing Law. The Limited Warranty gives You specic legal rights, and You also may have other rights which vary from
state to state. The Limited Warranty and the rights and obligations herein are governed by the laws of the State of Colorado,
without regard to rules pertaining to conicts of law. The state courts located in Boulder County, Colorado shall have exclusive
jurisdiction for any disputes relating to the Limited Warranty.
8
ARTiculatedshade

Notes
Warning: Wind can cause the umbrella to fall over or y away, resulting in
property damage and personal injury. Always secure the umbrella to a base having enough
weight and resistance to anchor the umbrella. Always close the umbrella in moderate to
high winds and when not attended.
Warning: The cord on this umbrella can present a strangulation hazard. Keep
children away.
Caution: Hang on tight to cord at all times while opening or closing umbrella to
avoid sudden and unexpected closing of frame, which could result in property damage or
personal injury.
9
ARTiculatedshade
ARTiculatedshade, LLC
1089 Gilbert Street
Boulder, Colorado 80302
303.817.4606
For questions, email [e-mail].
For warranty claims, email [e-mail].
