Artusi AGH32XFFD User manual

APPLIANCES
FOR LIVING
OPERATION MANUAL
GAS COOKTOPS
MODELS
AGH32XFFD, AGH30XFFD, AGH61XFFD,
AGH75XFFD, AGH96XFFD, AGH92XFFD,
AGH65X, AGH65MB, AGH70XFFD, AGH71XFFD,
AGH90XFFD, AGH91XFFD, AGH91MB.

2
Rev.13052022
WELCOME TO THE ART OF LIVING
Congratulations, you are now the proud owner of an ARTUSI cooking appliance. Thank you for purchasing ARTUSI and
welcome to the ARTUSI Family.
This instruction manual has been specially created to inform you of the full range of features your ARTUSI appliance has
to offer and serves as an introduction to getting the very best out of your ARTUSI appliance.
We present detailed information on each of the features your ARTUSI appliance consists of. Once you have read this
section you will be able to choose the most appropriate settings for your appliance when cooking different types of food.
KEEP THE DOCUMENTATION OF THIS PRODUCT FOR FUTURE REFERENCE.
REGISTER YOUR WARRANTY ONLINE NOW AT WWW.EUROLINX.SUPPORT
Note: This user manual is prepared for more than one model.
Some of the features specied in this Manual may not be available on your appliance.
All our appliances are only for domestic use, not for commercial use.
Products marked with (*) are optional.
“THIS APPLIANCE SHALL BE INSTALLED IN ACCORDANCE WITH THE
REGULA TIONS FORCE AND ONLY USED IN A WELL VENTILATED SPACE.
READ THE INSTRUCTIONS BEFORE INSTALLING OR USING THIS APPLIANCE”
THIS APPLIANCE IS CONCEIVED FOR DOMESTIC USE ONLY. THE MANUFACTURER SHALL NOT IN ANY WAY BE
HELD RESPONSIBLE FOR WHATEVER INJURIES OR DAMAGES ARE CAUSED BY INCORRECT INSTALLATION OR
BY UNSUITABLE, WRONG OR ABSURD USE.
THIS APPLIANCE IS NOT INTENDED FOR USE BY PERSONS (INCLUDING CHILDREN) WITH REDUCED
PHYSICAL, SENSORY OR MENTAL CAPABILITIES, OR LACK OF EXPERIENCE AND KNOWLEDGE UNLESS
THEY HAVE BEEN GIVEN , SUPERVISION OR INSTRUCTION CONCERNING USE OF THE APPLIANCE BY A
PERSON RESPONSIBLE FOR THEIR SAFETY . CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT THEY
DO NOT PLAY WITH THE APPLIANCE .
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualied person in
order to avoid a hazard.
WHERE THIS APPLIANCE IS INSTALLED IN MARINE CRAFT OR IN CARAVANS, IT SHALL NOT BE USED AS A SPACE
HEATER. DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN OPERATION. DO NOT USE OR
STORE FLAMMABLE MATERIALS NEAR THIS APPLIANCE. DO NOT MODIFY THIS APPLIANCE.
TO REGISTER
YOUR WARRANTY

3
Rev.13052022
Instructions for use 4
Installation 4
Abnormal Operation 4
Gas 5
Installation Diagrams 6
Use of Electric Elements 14
Maintenance 14
Instructions for the installer 15
Gas Connection 16
Electrical connection 16
User characteristics 17
Warranty 18
CONTENTS

4
Rev.13052022
INSTRUCTIONS FOR USE
INSTALLATION
All the operations concerned with the installation (electrical and gas connections, adaptation to type of gas, necessary
adjustments, etc.) must be carried out by authorised personnel, in terms with the standards in force. Kindly read the part titled,
Instructions for the installer.
USE
Gas burners (Fig. 1-3). The ignition of the gas burner is carried out by upper part holes of the burner, pressing and rotating
the corresponding knob in an anti-clockwise manner, until the maximum position has coincided with the marker. Then the gas
burner can be turned according to need. The minimum position is found at the end of the anti.clockwise rotation direction.
In models with automatic ignition, push the control knob down to initiate the ignition spark, then turn the knob to maximum
flame. After ignition, immediately release the push-button and adjust the ame accordingly. For models with a thermoelectric
safety system, the burner is ignited as above, keeping the knob fully pressed on the maximum position for approximately 3 to
5 seconds.
After releasing the knob, make sure the burner is actually lit. Repeat ignition if necessary.
N.B. - We recommend the use of pots and pans with a diameter matching that of the burner, thus preventing the ame from
escaping from the bottom part and surrounding the pot.
• Do not leave any empty pots of pans on the cooktop
• Do not use any tools for grill-cooking on ceramic or glass hobs
IMPORTANT
• Use of the appliance produces heat and moisture in the room where it is installed. Make sure the kitchen is sufciently
ventilated; keep natural ventilation holes open or install mechanical ventilation devices (such as a hood).
• Prolonged use of the appliance may require additional ventilation, such as opening a window.
• On hobs with thermoelectric protection do not keep the ignite button pushed for more than 15 seconds. If the burner has
not ignited after 15 seconds, open the door of the room and wait at least one minute before making a further attempt.
• On hobs without protection should the burner ame go out, close the corresponding gas cock and wait at least on minute
before making any attempt to ignite it.
ABNORMAL OPERATION
Any of the following are considered to be abnormal operation and may require servicing: Yellow tipping of the hob burner
ame. Sooting up of cooking utensils. Burners not igniting properly. Burners failing to remain alight. Burners extinguished by
cupboard doors. Gas valves, which are difcult to turn. In case the appliance fails to operate correctly, contact the authorised
personnel in your area.
Electrical plates / vitro ceramic heating element (Fig. 2-2a-3). Rotate the knob towards the position required for cooking and
bear in mind that the higher the number, the higher the heat output. See table “use of electrical plates”/ heating elements vitro
ceramic. The pilot light signals that the plate is “on”. Some types of pilot lights will maintain some slight luminescence even
after disconnection. That is quite normal.
N.B. - When using electrical plates / heating elements vitro ceramic, we recommend at bottom recipients with a diameter equal or
slightly larger than that of the plate itself. Avoid liquid overow; after boiling or heating liquids, reduce the heat output. Do not leave
the electrical plates on with empty pots and pans; when cooking is nished, rotate the knob back off position. In the event of even a
slight fracture on the cooking vitro ceramic surface, disconnect the electric power supply immediately.
DO NOT STARE AT THE HALOGEN LAMP

5
Rev.13052022
COOKING
USE OF COOKWEAR
Warning: To ensure a safe working distance is maintained between the control knobs and the pot, it is recommended that
large pots are not used on the central, front burner of the 6 burner model. Always centralise pots over the burners and
check that the pot is not too close to the control knobs.
Fig. 1
Wok Ø 20-32cm
Rapid Ø 20-26cm
Semi-rapid Ø 14-20cm
Auxiliary Ø 10-14cm
MODELS WITH DUAL WOK BURNER
Some models have a Dual Wok
burner. The centre ame (F1) can be
lit by pressing the knob and turning it
clockwise or the entire burner (F2) can be lit as
shown the gure below.
WARNING: To ensure a safe working distance
is maintained between the control knobs and
the pot, it is recommended that large pots are
not used on the central, front burner of the 6
burner model. Always centralise pots over the
burners and check that the pot is not too close
to the control knobs.
The warnings apply to gas cooktop
models with glass construction
Do not use any heat
diffusers
Do not apply any cookware directly
onto the burner. Do not cook
without the trivet or pan support
tted to the burner
Do not apply excessive weight
to the cooking surface

6
Rev.13052022
12
x
*
* Distance is the minimum clearance from the top
of the benchtop to any overhead surface.
** The height of the top of the pan support with
respect to the bench top surface is 48mm
** minimum distance to combustible splashback
A
170**
20
* all measurements are in millimetres
Fig. 3

7
Rev.13052022
B
1234 5
1234 5
1 234

8
Rev.13052022
*
B
* Distance is the minimum clearance from the
top of the benchtop to any overhead surface.
** minimum distance to combustible splashback
170**
20
Fig. 3
** The height of the top of the pan support with
respect to the bench top surface is 48mm

9
Rev.13052022
1234 5
1234
C

10
Rev.13052022
*
C
* Distance is the minimum clearance from the
top of the benchtop to any overhead surface.
** minimum distance to combustible splashback
170**
20
** The height of the top of the pan support with
respect to the bench top surface is 48mm

11
Rev.13052022
650
40 mm.
30 mm.
*
D
12
12
** minimum distance to combustible splashback
170**
20
* Distance is the minimum clearance from the top
of the benchtop to any overhead surface.
** The height of the top of the pan support with
respect to the bench top surface is 48mm

12
Rev.13052022
E
654321
54321
5
5
6
3
4
2
1
3
4
2
1
Fig. 3

13
Rev.13052022
R
1234 56
1234 56
*
** minimum distance to combustible splashback * Distance is the minimum clearance from the
top of the benchtop to any overhead surface.
170**
20
** The height of the top of the pan support with
respect to the bench top surface is 48mm

14
Rev.13052022
1 1 - 2 slight melting of fats etc.; heat small quantities of liquid
2 3 - 4 mild heating of medium quantities of liquid; puddings, long-cooking sauces
3 5 - 6 slow defrosting - heat large quantities of liquid; cooking below boiling temperature
4 7 - 8 medium tender roasts; cooking at boiling temperature
5 9 - 10 high roasts - boiled food; pan-frying of meats
6 10 - 11 burning heat bring large quantities of liquid to boil; fry
USE OF ELECTRICAL PLATES/VITRO CERAMIC HEATING ELEMENTS
COMMUTATOR ENERGY HEAT COOKING METHODS REGULATOR
INTENSITY
MAINTENANCE GAS/ELECTRICAL
Prior to any operation, disconnect the appliance from the electrical system. For long-life to the equipment, a general cleaning
operation must take place periodically, bearing in mind the following:
• the glass, steel and/or enamelled parts must be cleaned with suitable non-abrasive or corrosive products (found on the
market). Avoid chlorine-base products (bleach, etc.);
• avoid leaving acid or alkaline substances on the working area (vinegar, salt, lemon juice, etc.).
• the wall bafe and the small covers (mobile parts of the burner) must be washed frequently with boiling water and detergent,
taking care to remove every possible encrustation. Dry carefully and check that none of the burner holes is fully or partially
clogged;
• the electrical parts are cleaned with a damp cloth and are lightly greased with lubricating oil when still warm.
• the stainless steel grids of the working area, after having been heated, take on a bluish tint which does not deteriorate the
quality. To bring colour back to its original state, use a slightly abrasive product.
MAINTENANCE VITRO-CERAMIC SURFACE
(Fig.-4a)
First of all remove stray food bits and grease drops from the cooking surface with the special scraper (g. 4). Then clean the hot
area as best as possible with Bar Keepers Friend or other similar products with a paper-towel, then rinse again with water and
dry with a clean cloth. Pieces of aluminium foil and plastic material which have inadvertently melted or sugar remains or highly
high sugar content food have to be removed immediately from the hot cooking area with the special scraper (Fig. 4).-This is to
avoid any possible damage to the surface of the top. Under no circumstances should abrasive sponges or irritating chemical
detergents be used such as oven sprays or spot removers.
DO NOT USE STEAM CLEANERS

15
Rev.13052022
INSTRUCTIONS FOR THE INSTALLER
This appliance shall be installed only by authorised persons and in accordance
with the manufacturers installation instructions, local gas tting regulations, municipal building codes, electrical wiring regulations,
local water supply regulations, AS 5601 - Gas Installations and any other statutory regulations. Not for use in marine craft,
caravans or mobile homes unless each burner is tted with ame failure safeguard.
INSTALLATION
This appliance is not provided with a combustion discharge. It is recommended that be installed in sufciently aerated places,
in terms of the laws in force. The quantity of air which is necessary for combustion must not be below 2.0m3/h for each kW of
installed power. See table of burner power.
Note: the device is in installation class 3. The appliance’s adjustment parameters are shown on the plate attached to its housing.
POSITIONING
(Fig. 4). The appliance can be tted into a working area as illustrated on the corresponding gure. Before positioning the hob,
t the seal ‘x’ around the entire periphery of the hole cut in the worktop/bench-top.
WHEN THE APPLIANCE IS INSTALLED SO THAT THE BASE CAN BE TOUCHED, A PROTECTING SHIELD MUST
BE FITTED. THIS SHIELD MUST BE AT LEAST 20MM FROM THE LOWEST PART OF THE APPLIANCE AND BE
CAPABLE OF WITHSTANDING THE APPLIANCE TEMPERATURES.

16
Rev.13052022
GAS CONNECTION (Fig. 5)
Connect the appliance to the gas cylinder or to the installation according to the prescribed standards in force, and ensure beforehand,
that the appliance matches the type of gas available. Otherwise, see “Adaptation to various types of gas”. Furthermore, check that the
feed pressure falls within the values described on the table “User characteristics”. Rigid/semi rigid metal connection.
Carry out the connection pipes) so as to obtain counter stress the inner parts of the appliance.
N.B. - When the installation has been carried out, check the perfect sealing of the entire connection system, by using a soapy solution.
FOR CONNECTION WITH A FLEXIBLE HOSE
The cooktop can be connected with a Flexible Hose, which complies withAS/NZS 1869 (Australian Approved), 10mm ID, class B or
D, no more than 1.2m long and in accordance with AS5601. Ensure that the Hose does not contact the hot surfaces of the hotplate,
oven, dishwasher or other appliance that may be installed underneath or next to the hotplate.
WARNING: Ensure that the hose assembly is restrained from accidental contact with should not be subjected to abrasion, kinking
or permanent deformation and should be able to be inspected along its entire length. Unions compatible with the hose ttings must
be used and connections tested for gas leaks. The supply connection point shall be accessible with the appliance installed. Before
Leaving Check all connections for gas leaks with soap and water. DO NOT use a naked flame for detecting leaks. Ignite all burners
both individually and concurrently to ensure correct operation of gas valves, burners and ignition. Turn gas taps to low flame position
and observe stability of the flame for each burner individually and concurrently. When satised with the hotplate, please instruct the
user on the correct method of operation. In case
the appliance fails to operate correctly after all checks have been carried out, refer to the authorised service provider in your area.
ELECTRICAL CONNECTION (Fig. 6) Prior to carrying out the electrical connection, please ensure that the plant characteristics
are such as to follow what is indicated on the data label placed at the bottom of the working area; C of the ambient temperature.
If connecting directly to the mains power supply, fit a multi-pole switch of a suitable size for the rated capacity with a clearance
distance which completely disconnects the power line under over voltage category III conditions, consistently with the rules of
installation (the yellow/green earth wire must not be interrupted). The plug or omni polar switch must be easily reached on the installed
equipment. To avoid all risk, if the power cable becomes damaged, it must only be replaced by the manufacturer, by an authorised
service centre, or by a qualied electrician.
DATA LABEL
The Data Label is located on the bottom cover of the appliance. Where the bottom cover is not visible in the installed position, a
duplicate Data Label is supplied to adhere in an accessible area adjacent to the appliance. Ensure that the available gas supply
matches the gas types listed on the Data Label.
ADAPTATION TO VARIOUS TYPES OF GAS
(Fig.7) Should the appliance be pre-set for a different type of gas that that available, proceed as follows:
- replace the injectors (Fig. 7) with the corresponding type of gas to be used (see table “uses characteristics”)
- to adjust to the minimum, use a screwdriver on the screw placed on the tap (Fig.7) after turning the tap to its minimum position.
For ULPG (butane/ propane) screw tight.
ISO 7/1
ISO 228/1 (FR)
WOK ONLY WOK TCD ONLY
Fig. 5 Fig. 7

17
Rev.13052022
USER CHARACTERISTICS
GAS BURNERS
GAS TYPE PRESSURE (kPa) BURNER Ø INJECTORS 1/100 mm NOMINAL GAS
CONSUMPTION (MJ/h)
Natural Gas 1.00 Auxiliary 0.92 4.1
Semi-Rapid 1.17 6.9
Rapid 1.55 11.7
Mini Wok 1.50 10.7
Wok 1.63 12.5
Universal LPG 2.75 Auxiliary 0.56 4.1
Semi-Rapid 0.70 6.5
Rapid 0.94 0.90
Mini Wok 0.90 11.0
Wok 0.94 12.0
ELECTRIC PLATE
FEED TYPE W ADJUSTMENT
NORMAL Ø145 1000 COMMUTATOR (0÷6)
ENERGY REGULATOR (0÷11) -
FAST Ø145 1500 COMMUTATOR (0÷6)
ENERGY REGULATOR (0÷11) -
~ 230 V

18
Rev.13052022
Warranty Card
Worldwide Appliances Pty Limited
A.B.N. 45868077422
Distributed by Eurolinx pty Ltd
Ofce:
48-50 Moore Street, Leichhardt N.S.W 2040
Post:
Locked Bag 3000, Annandale, N.S.W 2038
P: 1300 694 583
WARRANTY REGISTRATION
Your ongoing satisfaction with your artusi
product is important to us. We ask that you
complete the enclosed Warranty Registration
Card and return it to us so that we have a record
of the artusi product purchased by you.
PRIVACY
Worldwide Appliances respects your
privacy and is committed to handling your
personal information in accordance with the
National Privacy Principles and the Privacy
Act 1988 (Cth). A copy of the Worldwide
Appliances Privacy Policy is available at
www.artusi.com.au. Worldwide Appliances will
not disclose any personal information set out
in the Warranty Registration Card (“Personal
Information”) without your consent unless
required by:
1. law;
2. any Worldwide Appliances related company;
3. any service provider which provide services
to artusi or assist artusi in providing services
(including repair and warranty services) to
customers. Our purpose in collecting the
Personal Information is
to keep a record of the artusi product purchased
by you, in order to provide a better warranty
service to you in the unlikely event that there is
a problem with your artusi product. Worldwide
Appliances may contact you at any one or more
of the address, email address or telephone
numbers set out in the Warranty Registration
Card. Please contact artusi on 1300 694
583 should you not wish to be contacted by
Worldwide Appliances.
WARRANTY
1. Warranty
Worldwide Appliances warrants that each artusi
product will remain, for a period of either 12
months or 24 months of warranty. All Warranties
are valid from the original date of purchase, And
warranty claims must be accompanied by the
proof of purchase.
24 months warranty products:
All Built-in Appliances – Limited to Ovens,
Gas, Induction and Electric Cooktops, and All
Rangehoods. Freestanding Cookers - Gas and
Electric Models (900mm Width).
artusi.com.au
Dishwashers - Freestanding, Fully Integrated,
Semi Integrated and built-in. All Wine coolers. All
Dryers. Freestanding Cookers - Gas and Electric
Models in 50cm, 54cm and 60cm Widths
Portable Appliances* – Benchtop Models and
Portable Gas Models
2. What is not Covered by the Warranty.
The Warranty does not apply if an artusi product
is defective by a factor other than a defect arising
in the manufacture of the artusi product, including
but not limited to:
(a) damage through misuse (including failure
to maintain, service or use with proper care),
neglect, accident or ordinary wear and tear
(including deterioration of parts and accessories
and glass breakage);
(b) use for purpose for which the artusi product
was not sold or designed;
(c) use or installation which is not in accordance
with any specied instructions for use or
installation;
(d) use or operation after a defect has occurred or
been discovered;
(e) damage through freight, transportation or
handling in transit (other than when Worldwide
Appliances is responsible);
(f) damage through exposure to chemicals, dusts,
residues, excessive voltage, heat, atmospheric
conditions or other forces or environmental
factors outside the control or Worldwide
Appliances;
(g) repair, modication or tampering by the
purchaser or any person other than Worldwide
Appliances, an employee of Worldwide
Appliances or an authorised artusi service
contractor*;
(h) use of parts, components or accessories
which have not been supplied or specically
approved by artusi.
(i) damage to surface coatings caused by cleaning
or maintenance using products not recommended
in the artusi product handbook provided to the
purchaser upon purchase of the artusi product;
(j) damage to the base of an electric oven due to
items having been placed on the base of the oven
cavity or covering the base, such as aluminium
foil (this impedes the transfer of heat from the
element to the oven cavity and can result in
irreparable damage); or
(k) damages, dents or other cosmetic
imperfections not aecting the performance of the
artusi in respect of an artusi product purchased
as a “factory second” or from display
The Warranty does not extend to light globes
used in artusi products.
3. Domestic Use
Each artusi product is made for domestic use.
This Warranty may not extend to artusi products
used for commercial purposes.
Continued over...

19
Rev.13052022
DON’T FORGET TO REGISTER
YOUR WARRANTY ONLINE
NOW AT www.eurolinx.support
TO REGISTER
YOUR WARRANTY
artusi.com.au
4. Time for Claim under the Warranty
You must make any claim under this Warranty
within twenty eight (28) days after the occurrence
of an event which gives rise to a claim pursuant
to the Warranty, by booking a service call on the
telephone number below.
5. Proof of Purchase
Customers must retain proof of purchase in order
to be eligible to make a warranty claim in respect
of an artusi product.
6. Claiming under the Warranty
Customers will bear the cost of claiming under
this Warranty unless Worldwide Appliances
determines the expenses are reasonable, in which
case the customer must claim those expenses
by providing written evidence of each expense
to Worldwide Appliances at the address on the
Warranty Registration Card.
7. Statutory Rights
(a) These terms and conditions do not a ect your
statutory rights.
(b) The limitations on the Warranty set out in this
document do not exclude or limit the application
of the consumer guarantees set out in the Act or
any other equivalent or corresponding legislation
in the relevant jurisdiction where to do so would:
(i) contravene the law of the relevant jurisdiction;
or
(ii) cause any part of the Warranty to be void.
(c) Worldwide Appliances excludes indirect or
consequential loss of any kind (including, without
limitation, loss of use of the artusi product) and
(other than expressly provided for in these terms
and conditions) subject to all terms,
conditions and warranties implied by custom, the
general law, the Act or other statute.
(d) The liability of Worldwide Appliances to you
for a breach of any express or non-excludable
implied term, condition or warranty is limited at
the option of Worldwide Appliances to:
(i) replacing or repairing the defective part of the
artusi product;
(ii) paying the cost of replacing or repairing the
defective part of the artusi product;
(iii) replacing the artusi product; or
(iv) paying the cost of replacing the artusi
product.
(e) Our goods come with guarantees that cannot
be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund
for a major failure and for compensation for any
other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a
major failure.
8. Defects
Any part of an artusi product deemed to be
defective and replaced by Worldwide Appliances
is the property of Worldwide Appliances.
Worldwide Appliances reserves the right to
inspect and test artusi products in order to
determine the extent of any defect and the
validity of a claim under the Warranty.
All warranty service calls must be booked via
the customer care department. The team can
be contacted on 1 300 85 64 11 option 1 or
[e-mail]
01082016
Warranty Card continued
Warranty Card tear off

VIC
2r/131 Church St,
Hawthorn
Cod. 1.00A.77.0.2'ed.
