Please read & save this guide
Thank you for choosing Electrolux, the new premium
brand in home appliances. This Use & Care Guide is
part of our commitment to customer satisfaction and
product quality throughout the service life of your
new appliance.
We view your purchase as the beginning of a
relationship. Toensure our ability to continue serving
you, please use this page to record important product
information.
Keep a record for quick
reference
Purchase date
Electrolux model number
Electrolux serial number
Serial plate location
Questions?
For toll-free telephone support in the U.S. and
Canada:
I=877-4ELECTROLUX (1=877-435=3287)
For online support and Internet production information
visit http://www.electroluxappliances.com
@2011 Etectrolux Home Products, Inc. AIt rights reserved. Printed in Canada.

important Safety instructions
__
Recognize safety symbols, words and plastic bags after unpacking the appliance.
labels
Safety items throughout this manual are labeled with
a WARNING or CAUTION based on the risk type as
described below:
WARNING
This symbol alerts you to situations that may cause
serious body harm, death or property damage.
CAUTION
This symbol alerts you to situations that may cause
bodily injury or property damage.
Read all of the following safety instructions
before using this appliance:
• This unit has been tested and found to comply
with the limits for a class B digital device,
pursuant to Part 18 of the FCC rules. These
limits are designed to provide reasonable protection
against harmful interference in a residential
installation. This unit generates, uses and can
radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may
cause harmful interference to radio communications.
However there is no guarantee that interference
will not occur in a particular installation. If this
unit does cause harmful interference to radio or
television reception, which can be determined by
turning the unit off and on, the user is encouraged
to try to correct the interference by one or more of
the following measures:
>> Reorient or relocate the receiving antennae.
>> Increase the distance between the unit and
receiver.
>> Connect the unit into an outlet or a circuit
different from that to which the receiver is
connected.
Never allow children to play with packaging
material. iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii
Proper Installation. Be sure your appliance is
properly installed and grounded by a qualified
technician in accordance with the National
Electrical Code ANSI/NFPA No. 70 - latest
edition in the United States, or CSA Standard
C22.1, Canadian Electrical Code, Part 1, in
Canada, and local code requirements. Install
only per installation instructions provided in the
literature package for this appliance.
Ask your dealer to recommend a qualified technician
and an authorized repair service, Know how to
disconnect the electrical power to the appliance
at the circuit breaker or fuse box in case of an
emergency.
• User Servicing. Do not repair or replace any
part of the appliance unless specifically
recommended in the manuals, All other servicing
should be done only by a qualified technician to
reduce the risk of personal injury and damage to
the appliance.
•Never modify or alter the construction of an
appliance such as removal of panels, wire
covers or any other permanent part of the
product.
• Storage on Appliance. Flammable materials
should not be stored near or on the cooking
surface. This includes paper, plastic and cloth
items, such as cookbooks, plasticware and
towels, as well as flammable liquids. Do not store
explosives, such as aerosol cans, on or near the
appliance. Flammable materials may explode and
result in fire or property damage.
•Do not leave children alone. Children should not
be left alone or unattended in the area where an
appliance is in use. They should never be allowed
to sit or stand on any part of the appliance.
• Wear Proper Apparel. Loose-fitting or hanging
garments should never be worn while using the
appliance. Do not let clothing or other flammable
materials contact hot surfaces.
•Remove all tape and packaging wrap before
using the appliance. Destroy the carton and .........................................................................................................................................................................................................................................................................................................................

important Safety instructions
• DoNotUseWaterorF=ouronGreaseFires.
_______________________________________________________________________________________________________________________________________________________________Smotherthefirewith a pan lid, cruse baking soda,
:::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::::adrychemica orfoam-typeextinguisher
iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii
_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_• When heating fat or grease, watch it closely.
Fatorgreasemaycatchfireira,owedtobecome
too hot.
•Use Only Dry Pot holders. Moist or damp pot
holders on hot surfaces may result in burns from
steam. Do not let the pot holders touch hot surface
units. Do not use a towel or other bulky cloth
instead of a pot holder.
• Do Not Heat Unopened Food Containers.
Buildup of pressure may cause the container to
burst and result in injury.
Know which touch key pads controls each
surface of the Cooking Zones.
Clean the appliance regularly to keep all parts
free of grease that could catch fire. Exhaust fan
ventilation hoods and grease filters should be kept
clean. Do not allow grease to accumulate on hood
or filter. Greasy deposits in the fan could catch
fire. When flaming food under the hood, turn fan
on. Refer to hood manufacturer's instructions for
cleaning.
• Use Proper Pan Size, This appliance is equipped
with one or more Cooking Zones of different sizes.
Select utensils having flat bottoms large enough
to cover the Cooking Zones. The pan detection
sensors will not allow the affected Cooking Zones
to operate without a pan present.
•Utensil Handles Should Be Turned Inward and
Should Not Extend Over Adjacent Cooking
Zones. To reduce the risk of burns, ignition
of flammable materials, and spillage due to
unintentional contact with the utensil.
* Never Leave Prepared Food on the Cooking
Zones. Boilovers cause smoking and greasy
spillovers that may ignite, or a pan that has boiled
dry may melt or become damaged.
* Protective Liners. Do not use aluminum foil to
line any part of the cooktop. Only use aluminum
foil as recommended after cooking process, if
used as a cover to be placed over the food. Any
other use of aluminum foil may result in the risk of
electric shock, fire or short circuit.
* Glazed Cooking Utensils. Only certain types
of glass, glass/ceramic, ceramic, earthenware,
or other glazed utensils are suitable for range
top service without breaking due to the sudden
change in temperature. Check the manufacturer's
recommendations for cooktop use.
* Ventilating hood. The ventilating hood above
your cooking surface should be cleaned frequently,
so the grease from cooking vapors does not
accumulate on the hood or filter.
* Do Not Clean or Operate a Broken Cooktop.
If cooktop should break, cleaning solutions and
spillovers may penetrate the broken cooktop and
create a risk of electric shock. Contact a qualified
technician immediately.
* Clean Cooktop with Caution. If a wet sponge or
cloth is used to wipe spills on a hot cooking area,
be careful to avoid a steam burn. Some cleaners
can produce harmful fumes if applied to a hot
surface.
*Do Not Place Hot Cookware on Cold Cooktop
Glass. This could cause glass to break.
*Do Not Slide Pan Across the Cooktop Surface.
They may scratch the cooktop surface.
Do Not Let Pans Boil Dry. This may cause
permanent damage in the form of breakage,
fusion, or marking that can affect the ceramic-
glass cooktop. (This type of damage is not
covered by your warranty).
SAVE THESE
INSTRUCTIONS FOR
FUTURE REFERENCES

Features
induction Cooktop features
1. Left Rear Cooking Zone. 7. Left Rear Cooking Zone Control Pads.
2. Center Rear Cooking Zone (36" model only), 8. Center Rear Cooking Zone Control Pads
3. Right Rear Cooking Zone.
4. Left Front Cooking Zone Double Element
(36" model only).
5. Right Front Cooking Zone,
6. Left Front Cooking Zone (30" model only),
(36" model only).
9. Right Rear Cooking Zone Control Pads.
10. Left Front Cooking Zone Control Pads.
11. Right Front Cooking Zone Control Pads,
12. Main Cooktop Controls,
Figure 1 =30" Model
Figure 2-36" Model
___________i:i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i
_:_iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii_

Features
induction Cooktop features
13. Cooktop Power Key Pad.
14. Controls Lock Key Pad.
15. Minute Timer ON/OFF Key Pad.
16. Minute Timer Setting .... Pad.
17. Minute Timer Setting "+" Pad.
18. Minute Timer Display
(displays up to 99 minutes).
Cooktop Power Indicator Light.
Controls Lockout Indicator Light.
Cooking Zone .... Pad
(for each Cooking Zone).
Cooking Zone ON/OFF Key Pad
(for each Cooking Zone).
Cooking Zone "+ " Key Pad
(for each Cooking Zone).
Keep Warm Setting Key Pad
(for each Cooking Zone).
25. Glide-2-Set TM Rotary Touch Slider Zone
Control (for each Cooking Zone).
26. Cooking Zone Power Level Display
(for each Cooking Zone).
iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii
_iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii
_iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii

Gettin Started
ACOOLER COOKTOP - A unique feature of the
Induction Cooktop is whether turned ON or OFF,
the cooktop surface remains cooler than standard
ceramic cooktops.
The cookware used with the Induction Cooktop iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii::
should have flat bottoms that make good contact iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii__i
with the entire surface of the Cooking Zone. Check iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii:_:
for flatness by rotating a ruler across the bottom of
the cookware (See Fig. 2). Be sure to follow all the
recommendations for using cookware.
MAGNETIC DETECTOR -The coil sensor
automatically detects whether the pan is magnetic
and eliminates accidental "turn-ONs."
PAN SIZE DETECTION - The pan recognition sensor
automatically detects and adapts the Cooking Zones
to the pan sizes in use.
EFFiCiENT - Induction cooking heats faster while
using less energy. Induction power levels are quick
to boil and delicate when simmering.
Use the correct cookware type
The magnetic Cooking Zone sensors located below
the cooktop surface require the use of cookware
made with magnetic material in order to start the
heating process on any of the Cooking Zones.
When purchasing pans, look for cookware specifically
identified by the manufacturer for use with induction
cooktops. If you are not sure, use a magnet to test
whether the cookware type will work. If a magnet
sticks to the bottom of the cookware, the material type
is correct for induction cooking (See Fig. 1).
It is recommended to always use heavier high quality
stainless steel cookware on your Induction Cooktop
surface. This will greatly reduce the possibility of
developing scratches on the ceramic surface.
Even quality cookware can scratch the cooktop
surface, especially if cookware is slide over the
ceramic cooktop surface without being lifted up. Over
time sliding ANY type of cookware over the ceramic
cooktop will likely alter the overall appearance of the
cooktop. Eventually the buildup of scratches will make
cleaning the surface difficult and degrade the overall
appearance of the cooktop.
Fig. 1
_:_iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii_
Fig. 2
Also remember to:
• Use cookware made with the correct material type
for Induction Cooking.
• Use quality cookware with heavier bottoms for
better heat distribution allowing for more even
cooking results.
• The pan size should match the amount of food
being prepared.
Do not let pans boil dry. This may
cause permanent damage in the form of
breakage, fusion, or marring that can
affect the ceramic cooktop. (This type of
damage is not covered by your warranty).
Do not use dirty pans with grease buildup. Always
use pans that are easy to clean after cooking.
Priorto using yourcooktopforthe firsttime, apply iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii
the recommended cooktop cleaning creme to the iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii
ceramic surface. Buff with a non=abrasive cloth or iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii
pad. Thiswillmakecleaningeasierwhensoiledfrom iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii
cooking.Thespecialcooktopcleaningcreamleavesa iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii
protectivefinishon theglasstohelp preventscratches
and abrasions.

_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_!_
iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii_i!iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii_
_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_i_!b;#;#;#;#_
Getting Started
Cookware recommendations
Be sure to follow the following recommendations
for using cookware as shown:
INCORRECT
Cookware not centered
on Cooking Zone
surface.
_ -._ ............... J
Curved or warped pan
bottoms or sides.
Min. size
Pan does not meet the
minimum size required
for the Cooking Zone
used.
Pan bottom rests on
cooktop trim or does not
rest completely on the
cooktop surface.
Heavy handle tilts pan.
CORRECT
Cookware centered
correctly on Cooking
Zone surface.
Flat pan bottom &
straight sides.
W
N-- Min. size
Pan size meets
or exceeds the
recommended minimum
size for the Cooking Zone.
.............J
Pan rests completely on
the cooktop surface.
Pan is properly
balanced.
Fig. 1
Use the correct cookware size
The Cooking Zones available on the Induction
Cooktop require a MINIMUM pan size to be used at
each location. The cross (+) of each Cooking Zone
is your guide to the correct MINIMUM pan size. The
pan bottom must FULLY cover the cross for proper
cooking to occur.
The outer dots at each Cooking Zone is helpful to
determine the pan MAXIMUM size. After centering the
cookware on the cooktop, make sure the cookware
does not extend more than 1/2" beyond these dots on
the Cooking Zone. The pan must make FULL contact
on the glass surface without the bottom of the pan
touching the metal cooktop trims.
Fig. 2
The Left Front Cooking Zone got a MINIMUM pan
size much smaller than the other cooking zones to
accommodate many pan sizes,
Fig. 3

ain Cooktop Controls
Using the touch controls Controls lock pad iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii_:i
iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii_:i
The recommended The Induction Cooktop _ _ __iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii!:i
way to use the touch may be locked in order iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii_i
padson thecooktop to prevent the cooktop iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii:
is with your finger from accidentally being
placed in the centerof turned ON.
To turn ON the Controls i
the touch pad. If the
fithengercenteris notofplaceda pad,°n
the cooktop may not
respond to the selection made.
Lightly contact the pad with the flat part of your entire
fingertip. Do not just use the narrow end of your
fingertip.
Cooktop main power pad
The Cooktop POWER
key pad enables the
entire Cooktop.
To power the cooktop,
touch and hold the
POWER key pad for
1/2 second.Abeep will Fig. 1 Fig. 2
sound and the Power
LED will glow (See Fig. 2). The cooktop will be in a
ready mode for 10 seconds. If no other key pads are
touched the Cooktop Main POWER will turn OFF
automatically.
Toturn the Main Power OFF touch Main POWER key.
A beep will sound and the Power Indicator Light will
turn OFF (See Fig. 1).
Lock feature, make sure Fig. 3Fig. 4
the unit is powered OFF
(See above, Figure 1) and that the timer is not active.
Touch and hold the LOCK key pad for 3 seconds. A
beep will sound and the Lock indicator light will glow
(Fig. 4). Once locked, no other displays will glow and
no Cooking Zones or timer will activate.
To turn the Controls Lock OFF, touch and hold the
LOCK key pad for 3 seconds. A beep will sound,
the Lock indicator light will turn OFF (Fig. 3) and the
cooktop may be used normally. Remember to power
ON the cooktop if it is needed right away.
Minute timer pad
The Minute Timer feature may be useful
in the kitchen ifa recipe calls for keeping
track of time. This feature will keep
track of time from 1 to 99 minutes. The
timer display will begin to count down
minutes once set.
To Set the Minute Fig. 5
Timer feature, touch
the "TIMER" key (Fig.
5). Make sure the LOCK
feature is not active, the
Minute Timer will not Fig. 6
operate if the cooktop is locked.
Touching and releasing the ,,1-,or the m key pads
(Fig. 6) will increase or decrease the Minute Timer
setting by 1 minute with each key press (up to 99
minutes).
Once the Timer LED displays the desired amount of
time, release the "i" or the m Arrow key pads (Fig.
6). The Minute Timer will begin the countdown with
remaining minutes. Once the Minute Timer reaches 1
minute, the timer will start counting down by seconds
until gOis reached. Once the Minute Timer reaches
DOa long beep will sound indicating that the time is
up and the Timer display will flash DO.
To cancel or turn OFF the Minute Timer, touch the
"TIMER" key (Fig. 5).

Settin Surface Controls
Using the GLIDE-2-SET TMzone
control
The Glide-2-Set TM zone control is a new and
innovative way to set your cooking zone power. Heat
_scontrolled by just the touch of a finger, resulting in
a clean look uncluttered by knobs or dials.
These controls are intuitive, precise and very
stylish. Three methods of setting these controls are
available for a better ease of use.
Powering ON/OFF
Press the ON/OFF pad to activate
the Glide-2-Set TM zone control.
Fig. 1
Setting WARM
Press the WARM pad to keep
the cooking utensil at serving
temperature.
Fig. 2
Zone Control Power Levels
Over25 power levels are available
with the Glide-2-Set TM controls.
Here are the exact positions for
those precise settings.
Fig. 3
Method 1
Slide a finger in the Glide-2-Set TM
ring touch area.
Fig. 4
Method 2
Directly touch any position in the
Glide-2-Set TM ring touch area,
Fig. 5
Method 3
Touch "-" and/or "+" pads for
precise power value setting. At
startup, pressing "-" will set the
control at Lo and pressing "÷" will
set it at Power Boost.
