Asiatelco AGP-V800R User manual

Asiatelco Technologies Co.
AGP-V800R GSM Fixed Wireless Phone
User Manual
#289 Bisheng Road, Building-8, 3F,
Zhangjiang Hi-Tech Park, Pudong,
Shanghai –201 204. China
TEL: [phone]
FAX: [phone]

#289 Bisheng Road, Building-8, 3F,
Zhangjiang Hi-Tech Park, Pudong,
Shanghai –201 204. China
TEL: [phone]
FAX: [phone]
Index
1GENERAL INTRODUCTION...................................................................................................................1
2IMPORTANT INFORMATION................................................................................................................2
3PRODUCT OVERVIEW............................................................................................................................3
3.1 PACKING LIST........................................................................................................................................3
3.2PRODUCT INTRODUCTION ......................................................................................................................3
3.2.1 Appearance.......................................................................................................................................3
3.2.2 Key Definition...................................................................................................................................4
3.2.3 Display Icon......................................................................................................................................5
4BASIC OPERATIONS................................................................................................................................5
4.1 POWER ON/OFF .....................................................................................................................................5
4.2 MAKE A CALL........................................................................................................................................5
4.3 ANSWER A CALL....................................................................................................................................5
4.4 END A CALL...........................................................................................................................................5
5MAIN MENU...............................................................................................................................................6
6CONTACTS.................................................................................................................................................6
6.1 SEARCH FOR A CONTACT .......................................................................................................................6
6.2 ADD A NEW CONTACT...........................................................................................................................7
6.2.1 Add a New Contact from the Menu...................................................................................................7
6.2.2 Add a New Contact in Standby Mode ...............................................................................................7
6.3 VIEW A CONTACT ..................................................................................................................................7
6.4 DELETE A CONTACT...............................................................................................................................7
6.5 EDIT A CONTACT ...................................................................................................................................7
6.6 GROUP ...................................................................................................................................................7
6.6.1 Add a Contact to the Group..............................................................................................................7
6.6.2 Delete a Contact from the Group......................................................................................................7
6.6.3 Rename a Group...............................................................................................................................8
6.6.4 Set a Ring tone to a Group................................................................................................................8
7MESSAGES..................................................................................................................................................8
7.1 SEND A MESSAGE ..................................................................................................................................8
7.2 RECEIVE A MESSAGE .............................................................................................................................8
7.3 VIEW SENT MESSAGES ..........................................................................................................................8
7.4 SEND A MESSAGE BY USING TEMPLATES...............................................................................................9
7.5 MESSAGE SETTINGS...............................................................................................................................9
7.6 VOICE MESSAGE AND BROADCAST MESSAGE .......................................................................................9
8RECENT CALLS ........................................................................................................................................9
8.1 MISSED CALLS.......................................................................................................................................9
8.2 DIALED CALLS.......................................................................................................................................9
8.3 RECEIVED CALLS...................................................................................................................................9
8.4 ERASE LISTS ..........................................................................................................................................9
8.5 CALL DURATION....................................................................................................................................9
9SETTINGS ...................................................................................................................................................9
9.1 SET TIME AND DATE..............................................................................................................................9
9.2 SET LANGUAGE ...................................................................................................................................10
9.3 SET PREFERRED INPUT METHODS........................................................................................................10
9.4 SET LCD CONTRAST............................................................................................................................10
9.5 SET LCD BACKLIGHT..........................................................................................................................10
9.6 SET DIAL DELAY .................................................................................................................................10
9.7 SPEED DIAL .........................................................................................................................................10
9.8 NETWORK SETUP .................................................................................................................................10
9.9 SECURITY SETUP..................................................................................................................................10
9.9.1 SIM Lock.........................................................................................................................................10
9.9.2 Phone Lock .....................................................................................................................................10

#289 Bisheng Road, Building-8, 3F,
Zhangjiang Hi-Tech Park, Pudong,
Shanghai –201 204. China
TEL: [phone]
FAX: [phone]
9.9.3 Auto Keypad Lock...........................................................................................................................11
9.9.4 Fixed Dial.......................................................................................................................................11
9.9.5 Barred Dial.....................................................................................................................................11
9.9.6 Change Password...........................................................................................................................11
9.10 SET ALARM..........................................................................................................................................11
9.11 RESTORE FACTORY SETTINGS..............................................................................................................11
10 SOUND .......................................................................................................................................................11
10.1 RINGER ................................................................................................................................................11
10.2 VOLUME ..............................................................................................................................................11
10.3 RING TYPE...........................................................................................................................................11
10.4 ALERT..................................................................................................................................................11
11 CALL SERVICES .....................................................................................................................................12
11.1 CALLER ID...........................................................................................................................................12
11.2 CALL WAITING ....................................................................................................................................12
11.3 CALL DIVERT.......................................................................................................................................12
11.4 CALL BARRING....................................................................................................................................12
11.5 CALL TIME REMINDER.........................................................................................................................12
11.6 AUTO REDIAL ......................................................................................................................................12
11.7 BLACK LIST .........................................................................................................................................12

1
1 General Introduction
Thank you for choosing OneCentury G-series GE-01 GSM Desktop Phone. To use your phone well, please read
this user manual carefully before you use.
The phone has been designed to operate with the latest digital communication technology - GSM. The phone
provides the following advanced features:
Large LCD with backlight, easy to read
Status Indicators
Two-way SMS, voice mail and caller ID
Call Forwarding, Call Waiting, Three-Way Calling
Emergency call
Menu driven interface for easy operation and configuration
Store 500 contacts
Save 500 SMS
Last call redials
Choice of 22 ring tones and power On/Off music
Adjustable ring and voice volume
AC power supply
Indoor antenna
Speaker phone for hand-free operation
User friendly keypad
Long battery stand-by and talk time
Easy to service and repair
GPRS

2
#289 Bisheng Road, Building-8, 3F,
Zhangjiang Hi-Tech Park, Pudong,
Shanghai –201 204. China
TEL: [phone]
FAX: [phone]
2 Important Information
The product can only be installed indoors.
Do not place the phone near high temperature objects, under direct sunlight, near source of water, near fire
or near inflammable and explosive materials. Avoid using the phone in high temperature or humidity.
The phone may interfere with heart pacemaker, hearing aid and other electronic medical devices. Therefore
please follow the instructions given by your equipment suppliers or consult your doctor. Turn your phone
OFF in health care centers if any regulations posted in the area instruct you to do so. Hospitals or health
care centers may be using equipment that may be sensitive to external RF energy.
Place the phone away from other electronic devices like TV and Radio to avoid interference.
Keep the product away from magnetic field and static electricity.
Place the phone out of the reach of small children.
Do not attempt to reassemble the phone by yourself. Only authorized personnel could service the phone
and its accessories. Faulty installation or service can be dangerous and may invalidate the warranty.
Do not clean the phone while in operation. Before attempting to clean the phone, turn the phone off,
disconnect the external power adapter and take out the battery. Use a dry, soft cloth for cleaning. Do not
use liquid or aerosol cleaners.
Do not drop, knock or shake the phone. Rough handling may break the phone body and internal circuit
boards.
Do not use the phone if the antenna is damaged. Replace the damaged antenna immediately by a qualified
technician. Use only a manufacturer approved antenna. Non-approved antennas, modifications or
attachments may impair call quality and damage the phone.
Do not hold the antenna during operation. This may affect call quality and cause the phone to operate at
unintended power levels.
Keep the antenna free from obstructions and position the antenna straight up. This will ensure best call
quality.
Only use the battery and the power adapter approved by the manufacturer. If not, it may cause an explosion
or result in a short circuit.
It is highly recommended to fully charge the battery before initial use. The battery might have been
discharged during storage and delivery.
Do not throw battery. Batteries are not to be disposed off by putting them in fire. It may explode or catch
fire.
The power adapter must be used within the specified AC voltage range.
Take out the battery if you won’t use your phone for a long time and keep the battery well.
During lightning, do not touch the power plug. It may result in an electric shock or death.
Do not touch the plug with wet hands. Always grasp and pull the plug, not the cord. Do not put heavy
things on the power cord or bend it too much.
During daily use, do not pull out the power adapter. The battery is used for backup power, which will not
cause the increasing consumption of electricity. When power adaptor is not plugged in, device can be
operated with battery only.
Don’t use the power adapter if the power cable is damaged. Contact the maintenance center immediately
and replace the adapter.

3
#289 Bisheng Road, Building-8, 3F,
Zhangjiang Hi-Tech Park, Pudong,
Shanghai –201 204. China
TEL: [phone]
FAX: [phone]
3 Product Overview
3.1 Packing List
Once you open the product package, please check the packing list to make sure there is no part missing. If any
part is missing or broken, please contact the customer service. The packing list is as follow:
No.
Name
Qty.
Remark
1
Phone Body
1
2
Handset
1
3
Antenna
1
4
Ni-MH Rechargeable Battery
1
Bonding Battery 3pcs in 1pcs
5
User Manual
1
6
Charger
1
Table 1 Packing List
3.2 Product Introduction
3.2.1 Appearance
Figure 1 AGP-V800R GSM Fixed Wireless Phone Appearance

4
#289 Bisheng Road, Building-8, 3F,
Zhangjiang Hi-Tech Park, Pudong,
Shanghai –201 204. China
TEL: [phone]
FAX: [phone]
3.2.2 Key Definition
Figure 2 Key Layout
1
Direction Keys
Move the cursor or scroll the menu.
also be Left Soft Key and Right Soft Key.
2
OK Key
Confirm your selection
In Standby mode, press OK key to enter Dialed Calls
3
Cancel
Cancel your selection
4
END Key
Reject an incoming call, end a call, return to idle mode
5
MUTE Key
Switch to silent profile
6
CALL/REDIAL Key
Make or redial a call
7
SPEAKER Key
Hand free Key, active speaker phone mode
8
0~9 Alpha Numeric
Keys and * # Key
To input numbers and characters, In text input mode, press 0 Key to input
space

5
#289 Bisheng Road, Building-8, 3F,
Zhangjiang Hi-Tech Park, Pudong,
Shanghai –201 204. China
TEL: [phone]
FAX: [phone]
3.2.3 Display Icon
The following icon may appear on the display of the phone:
No.
Icon
Description
1
Current signal strength. The more bars there are, the stronger the signal is.
2
No signal.
3
Battery capacity indicator. The more bars there are, the more capacity the battery has.
4
Supplied by charger
5
Alarm on
6
Call forwarding
7
Phone lock
8
Missed call
9
Unread message
10
Speakerphone actives
Figure 3 Display Icon
4 Basic Operations
4.1 Power On/Off
Hook up handset to your phone and put the handset to hang up position, then connect DC power supply to the
“DC IN” port at the rear of the phone or insert the battery to the battery chamber. Switch the “Power” switch (on
the rear of the Phone) to ON, then press the Power On/Off Key on the panel for 3 seconds to power on the
phone, your phone should go to idle screen and is ready to use.
You can turn the phone off directly by switching the “Power ON/OFF” switch (on the rear of the phone) to OFF
position. If the phone will not be used for long time, please turn this switch to OFF. Or you can press the Power
On/Off Key for 3 seconds to power off the Phone.
The phone can be operated without AC, this means it can work with battery only.
4.2 Make a Call
While your phone is power on and at idle screen, enter a destination number you wish to call and then press
SEND Key. (Note: To modify digits you enter, you can press BACK/CLR Key to delete wrong digits first and
then enter new digits). Once the call is connected, the phone’s screen will display the number you have dialed,
and the time duration the call has lasted.
The phone also has a speaker. To use the speaker to make a call, press SPEAKER Key, enter a phone number,
and press SEND Key.
The battery capacity of 1200 mAh is sufficient to place any calls without external AC/DC adaptor.
4.3 Answer a Call
When there is an incoming call, the phone will ring and display the Phone number of the incoming call (if the
number is available). You can pick up the handset or press SPEAKER Key to answer the incoming call. The
ring tone and ring-tone volume can be changed in the setting menu.
4.4 End a Call
You can end a call by pressing END Key. If you are using the handset for a phone call, hanging up the handset
will end the call automatically.

6
#289 Bisheng Road, Building-8, 3F,
Zhangjiang Hi-Tech Park, Pudong,
Shanghai –201 204. China
TEL: [phone]
FAX: [phone]
5 Main Menu
Press L.KEY to enter the main menu from the idle screen. The main menu includes: Contacts, Messages, Recent
Calls, Tools, and Settings. The menu tree is as follow:
Menu
Contacts
Search
New
Copy
Erase All
Groups
Owner Number
Memory Status
Messages
Write Message
Inbox
Sent Messages
Templates
Message Settings
Voice Mail
Broadcast Message
Recent Calls
Missed
Dialed
Answered
Erase Lists
Call Duration
Settings
Display
Network Setup
Security Setup
Alarm
Restore Factory Settings
Sounds
Ringer
Volume
Ring Type
Alert
Call Services
Caller ID
Call Waiting
Call Divert
Call Barring
Call Time Reminder
Auto Redial
Black List
Figure 4 Menu Tree
6 Contacts
Contacts can be used to store contact’s name and contact’s phone numbers, home number, email address, office
number and associate sound. You can store up to 500 entries to phone memory.
6.1 Search for a Contact
You can search a contact by name,
1) Select Menu → Contacts → Search,
2) Input the name for inquiry,
3) Press L.KEY to search or change input method, press OK to start search.

7
#289 Bisheng Road, Building-8, 3F,
Zhangjiang Hi-Tech Park, Pudong,
Shanghai –201 204. China
TEL: [phone]
FAX: [phone]
6.2 Add a New Contact
6.2.1 Add a New Contact from the Menu
1) Select Menu → Contacts → New, then you can choose the contact store to SIM or to Phone,
2) Scroll to Name, press L.KEY to input the name, and then press L.KEY → Done,
3) Scroll to Number, input the phone number, and then press L.KEY,
4) Scroll to the item you need to add to input or edit.
5) Then Press L.KEY to finish adding a contact, select Yes to save the contact.
6.2.2 Add a New Contact in Standby Mode
1) In idle mode, after inputting the phone number, press L.KEY to save the number directly.
2) Save the number to SIM card or to Phone.
6.3 View a Contact
There are 3 ways to view a contact.
1) Press R.KEY to view the contact list in idle mode, scroll to the desired contact, press L.KEY, scroll to
View, and then press L.KEY to view the contact information;
2) Select Menu → Contacts → Search, input nothing, press Select → Search → OK to view the
contact list. Scroll to the desired contact, press L.KEY, scroll to View, and then press L.KEY to view the
contact information;
3) Select Menu → Contacts → Groups, select the group that desired contact belongs, scroll to Member
List, then scroll to the desired contact, press L.KEY, scroll to View, and then press L.KEY to view the
contact information.
6.4 Delete a Contact
1) Press L.KEY to view the contact list in idle mode, scroll to the desired contact, press L.KEY, scroll to
Delete, and then press L.KEY,
2) You will be prompted “? Delete”, choose Yes to delete the contact.
6.5 Edit a Contact
1) Press L.KEY to view the contact list in idle mode, scroll to the desired contact, press L.KEY, scroll to Edit,
and then press L.KEY,
2) Scroll to the item you need to edit, edit directly or press L.KEY to edit.
6.6 Group
6.6.1 Add a Contact to the Group
1) Select Menu → Contacts → Groups, scroll to the group that the desired contact belongs,
2) Scroll to Member List, press L.KEY to enter the Member List, press L.KEY,
3) Scroll to Add, press L.KEY, scroll to the desired contact, press L.KEY twice to add the contact to the
group.
6.6.2 Delete a Contact from the Group
1) Select Menu → Contacts → Groups, scroll to the group that the desired contact belongs,
2) Scroll to Member List, press L.KEY to enter the Member List, press L.KEY,
