Asko D5454 User manual

Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfill your needs for many years to come.
Scandinavian design combines clean lines, everyday functionality, and high quality.
These are key characteristics of all our products and the reason they are greatly
appreciated throughout the world.
To get the most out of your new dishwasher, we recommend that you read the
operating instructions before using it. The operating instructions also include
information on how you can help protect the environment.
Do you need this Use&Care Guide in Spanish? Log on to
www.askousa.com/customer-care to download.
¿Necesita esta Instrucciones de uso y cuidado en español? Entre en
www.askousa.com/customer-care y descárguesela.
Operating Instructions
Dishwasher
ASKO D5454XL S

CONTENTS
2FRONT PANEL
3IMPORTANT SAFETY INSTRUCTIONS
4BEFORE WASHING FOR THE FIRST TIME
4LOADING THE DISHWASHER
7USING THE DISHWASHER
10SETTINGS
12
CARE AND MAINTENANCE
INSTRUCTIONS
14TROUBLESHOOTING
17TECHNICAL INFORMATION
18SERVICE
19PROGRAM CHART
FRONT PANEL
The panel is fitted with touch buttons with audible feedback (see the chapter Settings).
P R O G
START
STO P
2
1
8
910
3
45
6
12
13
14
11
15
16
7
1 Program selector
2 Daily wash
3 Heavy wash
4 Normal wash
5 Eco wash
6 Time program
7 Rinse & Hold
8 Time set (for the Time program)
9 High temperature
10 Long dry
11 Upper/lower basket
12 Start/Stop
13 Display
14 Delayed start
15 Child lock (button lock)
16 Rinse aid indicator
Customer Care Center 1-800-898-1879
www.askousa.com
2

IMPORTANT SAFETY
INSTRUCTIONS
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARNING!
This manual does not cover all possible conditions and situations
that may occur. Common sense and caution should always be
used when installing, operating, and maintaining any appliance.
•Read all instructions before using the dishwasher.
•Dishwashers must be electrically grounded. Read the
Installation Instructions for details.
•Use the dishwasher only for its intended purpose.
•Do not run the dishwasher while you are out of the home.
•Use only automatic dishwasher detergents and rinse agents.
•To reduce the risk of injury, keep detergents and rinse aids
out of the reach of children.
•Do not load sharp items near the door; you could damage
the door seal.
•Do not wash plastic items unless they are marked “dishwasher
safe”or the equivalent. For items not marked, check the
manufacturer’s recommendations. Items not dishwasher safe
could become deformed or melt and create a potential fire
hazard.
•Do not operate the dishwasher unless all enclosure panels
are properly in place (i.e., guard plate, access panel, toe kick,
etc.).
•Do not tamper with controls by removing or changing.
•Do not abuse, sit on, or stand on the dishwasher door or
baskets.
•To reduce the risk of injury, do not allow children to play in
or on a dishwasher.
•Under certain conditions, hydrogen gas may be produced in
a hot water system that has not been used for two weeks or
more. HYDROGEN GAS IS EXPLOSIVE. If the hot water
system has not been used for two weeks, before using the
dishwasher turn on all hot water faucets and let the water
flow from each for several minutes. This will release any
accumulated hydrogen gas. As the gas is flammable, do not
smoke or use an open flame during this time.
•When removing an old dishwasher from service or discarding
it, remove the door to the washing compartment.
•Do not store or use combustible materials, gasoline, or other
flammable vapors and liquids in the vicinity of this or any
other appliance.
•Disconnect electrical power to dishwasher before servicing.
•Repairs should be done by a qualified technician.
•Read the grounding instructions in the installation instructions.
CHILD SAFETY
TIP!
Dishwasher detergents and rinse aids are corrosive, so always
keep them out of reach of children.
•Should a child swallow dishwasher detergent or rinse aid, give
plenty to drink immediately, i.e., one or two glasses of milk or
water. Do not try to induce vomiting. Seek medical advice
immediately: Call the National Capital Poison Center at
1-800-222-1222.
•Always close the door and start the dishwasher as soon as you
put in the detergent.
•Always keep small children away from the machine when it is
open. There may be some detergent residue left inside the
machine.
•If dishwasher detergent gets in someone’s eyes, rinse them
with plenty of water for at least 15 minutes.
•Do not allow children to use or play in or on the dishwasher.
•Load all long and sharp items in the utensil basket in the middle
rack. If this is not possible, load sharp objects with the pointed
end facing the back of the dishwasher.
Activate child lock (Kid Safe™)
You can activate the child lock (button lock) to prevent children
from starting the dishwasher (see the section Settings).
WINTER STORAGE/TRANSPORT
•Store the dishwasher where the temperature remains above
freezing.
•Avoid long transport distances in very cold weather.
•Transport the dishwasher upright or laying on its back.
OVERFLOW GUARD FUNCTION
The overflow protection starts pumping out the machine and turns
off the water supply if the water level in the dishwasher exceeds
the normal level. If the overflow protection is triggered, turn off
the water supply and call the Customer Care Center.
CARE AND MAINTENANCE INSTRUCTIONS
When cleaning the edge around the door, use only a slightly damp
cloth. Do not spray water around the edge! Moisture can make
its way into the lock, which contains electrical components.
PACKING MATERIAL
Please sort waste materials in accordance with local guidelines.
DISPOSAL
•When the machine has reached the end of its service life and
is to be disposed of, it should immediately be made unusable.
Pull out the power cable and cut it as short as possible.
•The dishwasher is manufactured and labeled for recycling.
•Contact your municipality for information about where and
how your dishwasher can be recycled correctly.
Customer Care Center 1-800-898-1879
www.askousa.com 3

BEFORE WASHING FOR THE FIRST
TIME
WATER SUPPLY
The machine can be connected to either a hot (max. 160 °F, 70
°C) or cold water supply. We recommend a cold water supply.
The water pressure should be 4.2-140 psi. See also the section
Economic dishwashing in the chapter Loading the dishwasher.
CHECKING WATER HARDNESS
Contact the local water utility to check the water hardness in your
area. This is important to determine how much detergent and
rinse aid to use.
TOP UP WITH RINSE AID
Drying is faster if you use rinse aid.
1 Open the rinse aid compartment lid.
2 Carefully top up with rinse aid. Only add rinse aid to the level
marked max.
3 Wipe up any spilled rinse aid around the compartment.
4 Close the lid firmly.
SELECTING THE RINSE AID DOSAGE
The rinse aid dispenser can be adjusted between (Off) and
(High dosage).
Increase the rinse aid dosage:
•If the dishes have water marks.
Reduce the rinse aid dosage:
•If the dishes have a sticky white/blue film.
•If the dishes are streaked.
•Heavy foaming. If you have very soft water, the rinse aid can
be diluted 50:50 with water.
SETTING THE RINSE AID DOSAGE
The section Settings describes how to set the rinse aid dosage.
REFILL RINSE AID INDICATOR
When the rinse aid needs topping up, the above symbol lights on
the display.
NOTE!
After topping up, it may take a while before the symbol goes
out.
LOADING THE DISHWASHER
ECONOMIC DISHWASHING
Run programs only with a full load
Wait until the dishwasher is fully loaded before running a program,
this way you save energy. Use the Rinse & Hold program to rinse
the dishes if there are any unpleasant odors while you wait for the
dishwasher to become fully loaded.
Run programs at a lower temperature
If the dishes are only lightly soiled, you can select a lower
temperature with certain programs. See also the section Selecting
Options in the chapter Using the dishwasher.
Select a program with Short dry
To save energy, use Short dry. The drying result will be better if,
once the program is finished, you leave the door slightly open.
Do not rinse under running water
Simply scrape off large food particles before loading the
dishwasher.
Choose a green detergent
Read the environmental declaration on the packaging!
Connect to cold water...
If you use oil or electricity to heat your home.
Connect to hot water (max. 160 °F (70 °C))...
If you use district heating, solar power, or geothermal power to
heat your home. Choosing a hot water connection cuts program
times and reduces the dishwasher's electricity consumption.
FRAGILE DISHES
Some cookware is not dishwasher safe. This can be for several
reasons. Some materials cannot withstand high temperatures,
others can be damaged by dishwasher detergent.
Fragile decoration
Porcelain with decoration on top of the glazing (the items feel
rough) should not be washed in a dishwasher.
Crystal/Glass
Position items so that they do not touch each other during the
wash. Use the lowest possible wash temperature and the shortest
possible program. Select Short dry. Antique and very fragile items
should not be washed in a dishwasher.
Glass washed in a dishwasher at high temperatures can gradually
develop a gray film that cannot be removed. Wash fragile glasses
at a low temperature and with a small amount of detergent.
Silver
Silver and stainless steel items should not come into contact, as
the silver can become discolored.
Cutlery with glued handles
Some types of glue are not dishwasher safe. In such cases, the
handles may loosen.
Customer Care Center 1-800-898-1879
www.askousa.com
4

Wood
Wooden items should only be washed in a dishwasher if marked
dishwasher safe.
Aluminum
Aluminum can lose its shine if washed in a dishwasher. However,
good quality aluminum pans can be washed in a dishwasher, even
if some of the shine will be lost.
Plastic items
Avoid washing plastic items that cannot withstand high
temperatures.
TYPICAL LOAD FOR 10 PLACE SETTINGS
Upper basket with 10 place settings AHAM DW-1
Lower basket with 10 place settings AHAM DW-1
1
2
5
6
34
3
Middle basket with 10 place settings AHAM DW-1
1 Teaspoons
2 Forks
3 Serving cutlery –spoons
4 Serving cutlery –fork
5 Knives
6 Soupspoons
UPPER BASKET
Place glasses, cups, bowls, side plates, and saucers in the upper
basket. Wine glasses are placed on the wine glass shelf and knives
are placed in the knife stand on the right (if equipped).
NOTE!
All dirty surfaces should face in and down!
MIDDLE BASKET
The middle basket's utensil basket has space for ladles, whisks,
serving cutlery, and similar items.
Customer Care Center 1-800-898-1879
www.askousa.com 5

The two baskets in the middle basket can be removed, or the
entire middle basket can be removed, to create more space
between the upper and lower baskets if larger items are being
washed.
LOWER BASKET
Place plates, side plates, serving dishes, and pots in the lower basket.
Place pots and pans in the rear of the lower basket to best utilize
dishwashing performance from the two rear spray nozzles (Double
Power Zone™Pots & Pans), which are intended for these types
of dishes.
Fold-down plate supports
Lower the fold-down plate supports when washing pots.
1
2
Forward mount for plate support
Used for plates with a diameter greater than 9 3/4" (25 cm).
1
2
3
4
Customer Care Center 1-800-898-1879
www.askousa.com
6

USING THE DISHWASHER
ADD DETERGENT
1 Prewash detergent compartment
2 Main wash detergent compartment
We recommend that you use only unscented, granular automatic
dishwashing detergent. Using the wrong detergent could cause
flooding and/or damage your dishwasher. Do not use detergent
that has been wet and is clumped. Also, check the expiration date
on the container.
The amount of detergent needed can vary due to differences in
water hardness. To determine the water hardness in your area,
contact your local water utility or area water softening company.
The harder the water, the more detergent you may need. Refer
to the chart below for the recommended detergent amounts
based on water hardness. Remember, you should adjust the
amount of detergent you use by small amounts until you find the
correct amount. Twelve grains and higher is extremely hard water
and detergent alone may not be enough. You may need to use a
water softener to maximize the performance of your dishwasher.
Also, in areas with hard water (9+) you may need to wash at lower
temperatures to prevent hard water deposits from forming in
tank and wash system. In hard water areas, both the dishes and
the machine can develop a white or gray film after a while. If this
happens, run the Heavy wash program with high temperature and
two tablespoons of citric acid or commercially available dishwasher
cleaner in the detergent compartment (with no dishes in the
machine).
NOTE!
If you use a dishwashing detergent with a rinse aid additive, you
should not fill the rinse aid dispenser. This could cause a film on
your dishes.
Recommended detergent amounts based on water
hardness
Detergent amountsWater hardness
Prewash 1 teaspoon
Main wash 1 to 1-1/2 tablespoons
Soft
(0-3 grains per gallon)
Prewash 1 teaspoon
Main wash 1 to 2 tablespoons
Medium
(4-8 grains per gallon)
Prewash 1 teaspoon
Main wash 2 to 3 tablespoons
Hard
(9+ grains*)
*12 grains and higher is extremely hard water.
WARNING!
Children must be supervised –dishwasher detergent is corrosive!
NOTE!
Use only dishwasher detergent! Liquid hand-washing detergent
must not be used as the foam that forms prevents the
dishwasher from operating effectively.
Dishwasher tablets
Halve the tablet if it is difficult to close the dispenser lid. There is
a risk that the detergent will not be released properly if the lid is
tight and cannot open correctly.
NOTE!
Dishwasher tablets are not recommended for short programs
(less than 75 minutes). Use powder or liquid dishwasher
detergent instead.
3-in-1/All-in-one detergent
Read through the directions for these products carefully. If anything
is unclear, contact the detergent manufacturer.
PROGRAM SELECTION
Press the Program selector one or more times until the desired
program symbol lights.
Daily wash
A program suitable for day-to-day dishwashing. This program can
also clean dried leftovers, but is not intended for burnt food, such
as on oven dishes.
Heavy wash
Program for very dirty dishes, such as pans, casserole dishes, and
oven dishes. If these dishes do not completely fill the dishwasher,
you can add plates and other dishes that can withstand a Heavy
wash to fill out the load.
Customer Care Center 1-800-898-1879
www.askousa.com 7

Normal wash
Use to wash normally soiled dishes, and even dishes with dried
leftovers, such as plates, serving dishes, cups, glasses, and so on.
Eco wash
Use when you want to save energy. For normally soiled dishes.
Time program
The program adapts to the specified running time or finish time.
With this program, it is important to choose a time suited to how
dirty the dishes are.
Lightly soiled dishes0:30-1:15
Normally soiled dishes1:30-2:00
Heavily soiled dishes2:15-3:00
To set the program time, see the section Selecting Options.
Rinse & Hold
Use to rinse dishes while you wait for the dishwasher to become
fully loaded.
SELECTING OPTIONS
To select an option, press one of the option buttons. The field
next to the button lights when the option is activated. The available
options depend on the selected program. Once you have started
the program, the options you selected are saved for the next time
you use the same program. Exceptions are the Delayed start and
Upper/lower basket options.
Time set
Press the option button several times –or hold it in –to set the
desired program time for Time program. You can choose a
program time between 30 minutes and 3 hours.
High temperature
Activate this option for improved dishwashing results. The machine
then uses a higher temperature for the main wash.
If you want to use the lower temperature, press until the field
next to the button turns off.
You can vary the temperature as shown below:
140 °F (60 °C) / 160 °F (70 °C)Heavy wash:
115 °F (45 °C) / 150 °F (65 °C)Normal wash:
140 °F (60 °C) / 150 °F (65 °C)Daily wash:
120 °F (50 °C) / 140 °F (60 °C)Eco wash:
Long dry
A higher temperature in the final rinse and a longer drying phase
improves the drying result if you activate the Long dry option. This
causes a slight increase in energy consumption. This option can be
used with all programs except Time program.
If you want a program with Short dry, press so that the field next
to the button turns off.
Upper/lower basket
By pressing the Upper/lower basket option button, you can choose
to wash only the upper basket , the lower basket , or both
baskets .
Delayed start
When you select Delayed start, the dishwasher will start 1-24
hours after you press the Start/Stop button.
1 Press the button once to activate Delayed start. Press the
button several times –or hold it in –to set the desired number
of hours.
2 Press Start/Stop and the dishwasher counts down 1 hour at a
time and starts after the selected delay.
Press and hold Start/Stop for five seconds if you want to cancel
the Delayed start option.
NOTE!
Remember to press the Start/Stop button to start the program.
START THE DISHWASHER
Press and hold Start/Stop until the display flashes three times with
the remaining time. This indicates that the program has started.
Close the door properly, otherwise the dishwasher will not start.
The display indicates if the door is open.
NOTE!
If the machine does not start within 2 minutes of the last button
press, the display returns to showing the last program run.
TIME REMAINING
Once you have selected a program and options, the display
indicates how long the program took the last time it was used.
Once you have started the dishwasher, the display indicates how
much program time remains. The remaining time is updated after
the water for the final rinse has been heated.
This may differ somewhat from time to time depending on the
temperature of the water supply, the amount of dishes, the
ambient temperature, and other factors.
While the program is running, the time counts down and the
remaining program time is shown on the display. The remaining
Customer Care Center 1-800-898-1879
www.askousa.com
8

time is shown, for example, as 1:15, which means the program will
run for another 1 hour and 15 minutes.
NOTE!
During the first run of each program, the remaining time
displayed can be slightly misleading, as the dishwasher is estimating
the time. When you run the program a second time, the
dishwasher will calculate the remaining time based on the
previous duration of the program.
STOPPING OR CHANGING A PROGRAM
If you want to change programs after starting the dishwasher, open
the door then press and hold Start/Stop for five seconds. Add
more detergent if the lid of the detergent dispenser has opened.
Then choose a new program, press Start/Stop, and close the door.
DO YOU WANT TO ADD MORE DISHES?
Open the door. The dishwasher stops automatically. Add the
dishes, close the door, and the dishwasher resumes the program.
IF THE DISHWASHER IS TURNED OFF USING
THE MAIN POWER SWITCH OR DUE TO A
POWER FAILURE
If the program was not finished, the interrupted program resumes
when power is restored.
NOTE!
During drying, the program is interrupted if the power is cut or
the door is open for more than 2 minutes.
ONCE THE PROGRAM HAS FINISHED
Once the program has finished, "End" appears on the display.
A buzzer also sounds at the end of the program. See the section
Settings, which describes how to change this function.
Once the dishwasher has finished, it uses only standby power. Turn
off the dishwasher using the main power switch if you want to
completely cut the power. Turn off the water supply valve after
each use.
Customer Care Center 1-800-898-1879
www.askousa.com 9

SETTINGS
DO AS FOLLOWS TO OPEN THE SETTINGS MENU:
Turn off the dishwasher using the main power switch. Wait about five seconds.1.
Then press the main power switch again. Wait until the numbers appear in the right-hand display before continuing
to the next step.
2.
Within five seconds, press and hold the Program selector (wait for the audible signal confirming the button press)
and then immediately press the Long dry button without releasing the Program selector.
3.
+
Keep the buttons pressed until the symbols for the Daily wash and Rinse & Hold programs start to flash.4.
TIP!
Be sure to press right on the symbols, so as not to inadvertently activate any other button. Try again if you fail to
open the settings menu the first time.
P R O G
START
ST OP
Press to save the setting value and continue
to the next setting.
Current setting.
Current setting value.
Press to browse between setting values.
Display
YOU CAN NOW ADJUST THE FOLLOWING SETTINGS:
DescriptionSettingsOptionsButton press
You can activate the child lock (button lock) option
to prevent children from starting the dishwasher.
Child lock
(Kid Safe™)
(Off)
(On) Press the High temperature and Long dry buttons si-
multaneously to temporarily deactivate the button
lock when you want to start the dishwasher. The
button lock is automatically reactivated after 2 min-
utes.
Press Start/Stop to save the setting value and continue to the next setting.
If you do not want to change any other settings, keep pressing Start/Stop to step through the entire settings menu.
The dishwasher uses a buzzer to indicate when a
program is finished or when a fault has occurred.
Buzzer volume
(Off)
(Low)
(High)
Press Start/Stop to save the setting value and continue to the next setting.
Customer Care Center 1-800-898-1879
www.askousa.com
10

DescriptionSettingsOptionsButton press
This sound is used to confirm each button press.Operation volume
(Off)
(Low)
(High)
Press Start/Stop to save the setting value and continue to the next setting.
For adjusting the contrast of the display.LCD contrast
(Low)
(High)
Press Start/Stop to save the setting value and continue to the next setting.
Rinse aid dosage setting.Rinse aid
(Off)
(Low dosage)
(High dosage)
Press Start/Stop to exit the settings menu.
Customer Care Center 1-800-898-1879
www.askousa.com 11

CARE AND MAINTENANCE
INSTRUCTIONS
COARSE FILTER
The coarse filter traps larger food particles, which cannot get past
the drain pump. Empty the coarse filter as necessary.
1 Lift the coarse filter by the handle.
2 Empty the coarse filter. Remember to replace it!
Coarse filter
FINE FILTER
Debris that collects on the fine filter is automatically rinsed away
during each wash. However, the fine filter and its pipe section
should be cleaned a couple of times a year.
1 Turn the handle counterclockwise once.
1x
Fine filter
2 Lift the pipe section straight up by the handle. Free the coarse
filter to clean the pipe section.
3 Remove and clean the fine filter.
4 Replace in reverse order. Check that the edges seal properly
when replacing the fine filter.
Pipe section
5 Lock the filter in place by turning the handle clockwise to the
stop position. The handle should point straight out from the
dishwasher.
1x
NOTE!
The dishwasher must not be used without the filter in place!
Dishwashing efficiency can be affected if the coarse filter is
incorrectly fitted.
DRAIN PUMP
The pump can be accessed from inside the dishwasher.
1 Cut the power to the dishwasher by unplugging the unit from
the power outlet.
2 Remove the coarse filter and pipe section.
3 Remove the small yellow drain pump access cover at the left
of the bottom drain (see illustration below).
4 By inserting your finger into the hole, you can turn the pump
blades to release anything blocking the pump.
5 Reinstall the access cover and filters.
6 Plug the machine in again.
If the dishwasher still does not start and a whirring sound is
heard, the overflow protection has been triggered.
•Shut off the water.
•Unplug the unit from the power outlet.
•Call the Customer Care Center.
NOTE!
Do not forget to reinstall the drain pump access cover.
LOWER SPRAY ARM
Holes and bearings can sometimes become blocked.
1 Pull the lower spray arm straight up to release it.
Customer Care Center 1-800-898-1879
www.askousa.com
12

2 Remove any debris using a needle, toothpick, or some other
similar pointed device. The spray arms also have holes
underneath.
UPPER SPRAY ARM
1 Pull out the basket.
2 Unscrew the spray arm bearings as illustrated to remove the
spray arm from the upper basket.
Spray arm bearings
3 Clean the upper spray arm in the same manner as the lower
spray arm.
4 Replace the spray arm and screw the spray arm bearings firmly
back into place.
DOOR
When cleaning the edge around the door, use only a slightly damp
cloth (with a little cleaner if necessary).
WARNING!
Do not use a spray bottle or the like around the door lock. This
is to ensure that water does not penetrate the door catch and
come into contact with the electrical components.
LIMESCALE DEPOSITS
The dishwasher tub is made of stainless steel and is kept clean
through normal use. However, if you have hard water, limescale
deposits may form in the dishwasher. If this happens, run the Heavy
wash program with high temperature and two tablespoons of citric
acid or commercially available dishwasher cleaner in the detergent
compartment (with no dishes in the machine).
FRONT PANEL
Keep the touch buttons clean and free from grease. Wipe them
clean with a dry or slightly damp cloth. Never use cleaners –they
can scratch the surface. Use the main power switch to turn off
the dishwasher before cleaning the touch buttons to avoid
activating any buttons unintentionally.
Customer Care Center 1-800-898-1879
www.askousa.com 13

TROUBLESHOOTING
ActionType of faultDisplay
Call the Customer Care Center.Overfilling
See "Water remains in the dishwasher above the filters"
in the table below.
Water outlet fault
Check that the water supply valve is on.Water inlet fault
Turn off the water supply valve and call the Customer
Care Center.
Inlet valve leakage
Turn off the machine with the main power switch and then turn it on again to clear the error message from the display.
ActionPossible causesProblem
Remove the arms and clean them.The spray arms do not rotate.The dishes are not clean.
Check that the dishes are not blocking the
spray arms.
Avoid large packages.Detergent is too old. Detergent is a perishable
product.
Dose according to water hardness. Far too
much or far too little detergent can result in
poor dishwashing results.
Incorrect detergent dosage.
Select a higher temperature or a more pow-
erful program.
Dishwashing program too weak.
Do not cover dishes with large bowls or lids.
Avoid placing very tall glasses in the corners
of the baskets.
Dishes loaded incorrectly.
Load the dishes securely.Glasses and cups have toppled over during
the program.
Screw the filter firmly into place. See the sec-
tion Care and maintenance instructions.
The filter is not correctly fitted.
See the sections Before washing for the first
time and Settings.
Incorrect rinse aid dosage setting.Spots or films on the dishes.
Wash crystal at a low temperature and with
a conservative amount of detergent. Contact
the detergent manufacturer.
Too high temperature and/or too much deter-
gent can cause etching on crystal. Unfortunate-
ly, this cannot be repaired, only prevented.
Reduce the amount. See the sections Before
washing for the first time and Settings. If you
have very soft water, you may want to dilute
the rinse aid 50:50 with water.
Rinse aid dosage setting too high.The dishes have a sticky white/blue film.
Rinse off these types of food if not starting
the dishwasher immediately. Or why not run
the Rinse & Hold program?
Some types of food, such as mustard, mayon-
naise, lemon, vinegar, salt, and dressings, can
cause spots on stainless steel if left for too
long.
Spots on stainless steel or silver.
Silver and stainless steel items should not
come into contact during dishwashing.
All stainless steel can cause spots on silver if
they come into contact during dishwashing.
Aluminum can also cause spots on dishes.
Use a detergent with a bleaching agent.Lipstick and tea can be difficult to wash off.Spots left after washing.
Check that the dishes are placed securely. Spin
the spray arms to make sure they can rotate.
The dishes are not correctly placed or the
spray arms are not rotating.
Rattling sound when dishwashing.
Customer Care Center 1-800-898-1879
www.askousa.com
14

ActionPossible causesProblem
Press and hold Start/Stop until the display
flashes three times with the remaining time.
The Start/Stop start button has been pressed
for too short a time.
The dishwasher does not start.
Check.The door is not properly closed.
Check.A fuse/circuit breaker has been tripped.
Check.The plug is not plugged into the power outlet.
Check.The water supply valve is turned off.
Check.Overflow/leaks.
Turn off the water supply valve. Pull out the
plug and call the Customer Care Center.
A whirring sound (the drain pump) is heard
from the dishwasher and does not stop when
the main power switch is turned off.
Press and hold Start/Stop for five seconds if
you want to cancel the Delayed start option.
Check that the Delayed start option has not
been selected.
None. Next time the program is run, the
corrected time will be displayed.
The program is taking longer than estimated.1 minute appears on the display.
Loosen the drain hose from where it termi-
nates. Check that no debris has clogged the
hose. Is the cone-shaped part of the drain
boot cut to the maximum size of the fitting
where it attaches?
Blocked drain hose.Water remains in the dishwasher above the
filters.
Check that the hose is free from kinks and
sharp bends.
Kink in drain hose.
Clean the coarse and fine filters.The filters are blocked.
Clean the drain pump. See the section Care
and maintenance instructions.
Debris in the drain pump.
Clean with dish brush and low foaming clean-
er.
Dirt around the seals and in corners.Bad odor in dishwasher.
Run a program with a higher temperature
about once a month.
Low temperature programs have been select-
ed for a prolonged period.
Activate the Long dry option.Drying power too low.The dishes are not dry enough.
Fully load the dishwasher.The dishwasher is not fully loaded.
Top up with rinse add or increase the rinse
aid dosage. See the sections Before washing
for the first time and Settings.
Rinse aid needs topping up or dosage is set
too low.
Open the door a little once the program has
finished.
Check that the baskets are correctly posi-
tioned horizontally, and that the middle bas-
ket's water connector is in line with its spray
pipe.
The baskets are not correctly positioned.Cannot close door.
Check that the dishes are not blocking the
baskets from sliding properly into place.
Customer Care Center 1-800-898-1879
www.askousa.com 15

ActionPossible causesProblem
Wait a moment then try again.You have pressed the touch buttons too soon
after opening the door.
The touch buttons do not react when pressed.
Clean with a dry or slightly damp cloth.Dirt on the touch buttons.
See the section Settings.Child lock (button lock) activated.
Customer Care Center 1-800-898-1879
www.askousa.com
16

TECHNICAL INFORMATION
TECHNICAL DATA
32-1/4'' - 34'' (819-864 mm)Height:
24" (610 mm)Width:
22-7/8" (581 mm)Depth:
108 lb (49 kg)1) Weight:
4.2–140 psiWater pressure:
See serial number tag and rating plate.Electrical connection:
See serial number tag and rating plate.Rated power:
1) Weight can vary due to different specifications.
Customer Care Center 1-800-898-1879
www.askousa.com 17

SERVICE
It is important to register your product warranty by logging onto "http://www.askousa.com/customer-care/register-my-appliance/" and filling
out all required fields within 90 days from the date of purchase. After doing so, you will be e-mailed a certificate that will extend the
original warranty for one additional year. If you do not have access to the internet, complete the warranty card included with the product
and mail it to the address on the warranty card within 90 days from the date of purchase. Cosmetic damage must be reported to your
dealer within five days from the date of purchase. After unpacking the washer, thoroughly check the unit for cosmetic damage.
ASKO Appliances Inc. will pay for:For residential installations only
ASKO replacement parts and/or repair labor to correct defect in mate-
rials or workmanship. Service must be provided by an authorized ASKO
service agent.
Length of warranty Two-Year Full
From date of purchase.
ASKO replacement parts and/or repair labor to correct defect in mate-
rials or workmanship. Service must be performed by an authorized
ASKO service agent.
Third Year Full
Complete your product warranty registration online at
"http://www.askousa.com/customer-care/register-my-appliance/"
within 90 days from the date of purchase to extend the original
warranty one additional year. If you do not have access to the
internet, complete the warranty card included with the product
and mail it to the address on the warranty card within 90 days
from the date of purchase.
ASKO replacement parts (labor cost not included) for the stainless steel
tank if it exhibits a manufacturing defect such as cracking or rusting
through. Service must be provided by an authorized ASKO service agent.
Lifetime
ASKO replacement parts and/or repair labor to correct defect in mate-
rials or workmanship. Service must be provided by an authorized ASKO
service agent.
For non-residential installations One-year Full Warranty
From date of purchase.
WARRANTY
ASKO Appliances Inc. will not pay for:
1 Service calls to:
•Correct the installation of the appliance.
•Repair damage due to shipment, delivery, installation, misuse
or abuse.
•Instruct how to use the appliance.
•Replace house fuses or correct house wiring.
•Correct house plumbing, including drainage problems related
to improper installation.
•Clean or service air device in drain line.
2 Repair and/or replacement parts for failure of product if
appliance is used for other than home/residential use.
3 Damage resulting from accident, fire, floods, acts of God,
alteration, misuse, abuse, improper installation, or installation
not in accordance with local electrical or plumbing codes.
4Any shipping costs for parts during the limited warranty period.
5 Replacement parts or repair labor costs for units operated
outside the continental United States.
6Pickup and delivery. ASKO washers are designed to be repaired
in the home.
In no event shall ASKO Appliances Inc. be responsible for any
incidental or consequential damages.
Some states will not allow the exclusion or limitation of incidental
or consequential damages, so this exclusion or limitation may not
apply to you. This warranty gives you specific legal rights and you
may also have other rights which vary from state to state.
For warranty service, contact our Customer Care Center at
the number listed below.
Before calling for service or contacting ASKO Appliances Inc.
regarding a warranty issue, make a note of the model, type name,
and serial number.
HOW TO CONTACT ASKO APPLIANCES INC.
Write to us at:
ASKO Appliances Inc.
P.O. Box 940609
Plano, TX 75094-0609
www.askousa.com
Or contact our
Customer Care Center at
1-800-898-1879
www.askousa.com
Customer Care Center 1-800-898-1879
www.askousa.com
18

PROGRAM CHART
Consumption values1)
Final rinse tempera- ture (°F)
Number of rinses
Main wash (°F)Prewash-
es
OptionsProgram
Water consump-
tion (gallon)
Hot water3)
Cold water2)
Energy (approx. kWh)
Wash time (approx. hours:minutes)
Energy (approx. kWh)
Wash time (approx. hours:minutes)
3.60.81:401.42:0015021401-Daily wash 4.90.73:101.53:5014031402-Heavy wash 4.20.52:001.02:3012031151-
Normal wash4)
4.80.92:051.52:3015031502Normal wash 3.50.52:200.92:3012021201-Eco wash 3.0-5.10.4-1.20:30-3:000.6-1.60:30-3:00max. 1502-3max. 1500-2-Time program 0.90.010:060.010:06-1-0-Rinse & Hold
1) Consumption values vary depending on the water supply temperature, the ambient temperature, the size of the load, the selected options, and more. 2) Connection to cold water, approx. 50 °F (10 °C). 3) Connection to hot water, approx. 120 °F (50 °C). 4) The energy label performance figures are based on this program.
Customer Care Center 1-800-898-1879
www.askousa.com 19

QUICK GUIDE
LOAD THE BASKETS (SEE PAGE 4)
1. Do not rinse dishes under running water before loading them in the dishwasher.
Simply scrape off large food particles before loading the dishwasher.
CHECK THAT THE SPRAY ARMS CAN ROTATE FREELY
2. Check also that the water supply valve is on.
ADD DETERGENT (SEE PAGE 7)
3. The detergent compartment has one smaller compartment for the prewash and
one for the main wash.
PRESS THE MAIN POWER SWITCH AND CLOSE THE
DOOR.
4.
SELECT A PROGRAM AND ANY OPTIONS (SEE PAGE 7)
5.
PRESS START/STOP (SEE PAGE 8)
6.
Item No.: 8093969. Rev. 02. We reserve the right to make changes.
www.asko.com
