We know you’re excited about owning an ASKO washing machine and you’re anxious to get started, so here is a brief summary of the
operating procedures. To get the most of the features of your machine, we recommend that you read your Use and Care Guide.
THE CONTROL PANELTHE CONTROL PANEL
Door Open Button
Press to open the glass door. Please note that the
Program Control knob must be at the end of a
program (at a red mark) to open the glass door.
Super Rinse Button
Press to program
two additional rinses.
Economy Button
Press to extend the wash time by 22
minutes. (Suggested for use only with
the low wash temperatures.)
Washer Quick Start Guide W620
Power Button
Press to turn on power to
the machine.
Program Control
Turn clockwise to select a
program.
Power Indicator Light
Glows when the power is
turned on.
Temperature Control
Turn clockwise to set the
wash temperature.
Delay Start Button
Press to delay starting the
program for five hours.
Spin Speed Control
Turn clockwise to select the
spin speed for the final spin.
DefinitionOption
Spin Speed Control
In addition to the 600 rpm to 1200 rpm spin speed options, the Spin Speed Control has a No Spin/No Drain option ( ) and a No Spin ( )
option. These are for delicate fabrics that should not be spun dry.
Super Rinse – Provides two additional rinses. Recommended for persons with sensitive skin or allergies.
E2Economy – Extends the main wash time by 22 minutes. When used with low wash temperatures (85°–100° F), this program
conserves energy but gives the same high level of cleaning. Note: You can only use this option with programs 1, 2 and 3.
5h Delay Start – Automatically delays starting the program for five hours.
Power ButtonPower Button
The Power button turns the power to the machine on and off. When the power is on, the power indicator light glows red. The power
must be on before you can open the glass door, set the programs or start the machine.
Door Open ButtonDoor Open Button
The power must be on and you must press this button to open the glass door. There will be a few seconds delay before the door opens.
Please note that the Program Control knob must be at the end of a program (at a red mark) to open the glass door. See also,
“Interrupting or Changing a Program” on the next page.)
For instructions on how to open the door manually in case of power failure, refer to your Use and Care Guide.
PROGRAMS AND OPTIONSPROGRAMS AND OPTIONS
Your ASKO washer has several programs and options specifically designed to give you the cleanest laundry possible. The tables below define
each program and option. The C and S on the Program Control are fault codes, which are explained on the next page.
Program Recommended
Number Program Types of Laundry Temp. Range (° F)
1White cotton w/prewash For heavily soiled cotton 140–205
2White cotton w/short prewash For normally soiled cotton 140–205
3Normal For lightly soiled cottons and colorfast fabrics 105–140
4Rinse
5Long spin
6Permanent Press/Synthetics For acrylic, polyester 105–140
7Super quick wash For lightly soiled fabrics 85–105
8Short spin
9Wool/Hand wash For silk, nylon, washable wool 85–105
10 Drain
CAUTION! Some fabrics may not be able to withstand extremely hot temperatures. Refer to the Recommended
Wash Temperatures chart in the Use and Care Guide.

QUICK START PROCEDURESQUICK START PROCEDURES
THE DETERGENT DRAWERTHE DETERGENT DRAWER
The detergent drawer on ASKO washers automatically dispenses the detergent and
fabric softener at the appropriate times. The drawer is located to the left of the control
panel. Simply pull the drawer out and pour the measured amounts of detergent and
softener into the proper compartments (as illustrated) and close the drawer.
DETERGENT AND FABRIC SOFTENER AMOUNTSDETERGENT AND FABRIC SOFTENER AMOUNTS
Because ASKO washers use less water than conventional top-loading washers, you need less detergent and fabric softener. We recommend
that you use a low-sudsing powder detergent only, preferably a high-efficiency (HE) detergent designed specifically for front-loading washers.
(Liquid detergents tend to suds more, which make them more difficult to rinse out.)
Detergent – The amount of detergent needed varies, depending on the detergent you use. For high-efficiency detergent specifically for
front-loading washers, you should use the amounts recommended by the manufacturer. For regular laundry detergent, 1 to 3 tablespoons of
detergent is all you need for a normal wash load. More heavily soiled items, however, may need slightly more detergent. Also, the amount
of detergent needed can vary due to differences in water hardness. (Refer to the Use and Care Guide for more details.) If you choose to use
a liquid detergent, start out with a very small amount, such as one or two tablespoons.
Fabric Softener – We recommend that you use only 2 tablespoons of fabric softener.If more softening is desired, try using slightly more
with the next load.
Prewash detergent
Main wash
detergent
Fabric
softener
We recommend that you don’t use bleach in your ASKO washer.
Thetumblingwashaction,temperaturecontroloptionsandextended
wash times are sufficient to remove most stains.
NOTE: The detergent drawer is equipped with an optional child
safety catch. (See your Use and Care Guide.)
(For more troubleshooting issues, refer to the “Troubleshooting” section in your Use and Care Guide.)
COMMONLY ASKED QUESTIONSCOMMONLY ASKED QUESTIONS
1) Where do I put the fabric softener?
2) Why does the machine run longer than my old
top-loader?
3) The machine won’t start.
4) The machine won’t spin.
5) The door won’t open.
ANSWERSANSWERS
1) See illustration above.
2) One reason ASKO washers clean better than others is because they
have longer wash cycles and extra rinses. Also, if the water entering
the machine is exceptionally cold, it will take longer to heat, therefore
increasing the cycle time.
3) a) Make sure the unit is securely plugged into the wall outlet.
b) Be sure the Power button is pushed in and the indicator light is red.
c) The door must be closed securely (but don’t slam it).
d) The Program Control knob may not be in the proper
position for the beginning of a program.
e) Check the house breaker and fuses.
4) Check the pin trap for an obstruction blocking the pump or outlet hose.
5) See “Door Open” on the previous page and Answer 3 above.
FAULT CODESFAULT CODES
The Program Control knob has two fault codes: C and S. If the knob stops on one of these, the machine detected a problem.
C– This indicates a problem that can probably be taken care of without calling a service technician.
S– This usually indicates a mechanical problem and a service call will be required.
Refer to the “Troubleshooting” section in your Use and Care Guide for more detailed information.
1.
2.
3.
4.
5.
6.
7.
8.
9.
Press the Power button ( ) to turn on the machine.
Press the Door Open button ( ) to open the door and load the wash. (The door will open in a few seconds.)
Check that the door is clear of laundry then close it firmly. (It won’t shut if it’s slammed.)
Pour the detergent and fabric softener into the proper compartments in the detergent drawer, as illustrated below. (Don’t
put detergent in the prewash compartment unless you plan to prewash.)
Close the drawer securely. (Do not slam it closed.)
Turn the Temperature Control knob to the desired wash temperature.
Set the Spin Speed Control knob to the desired rpm (optional).
Select program options, such as No Spin or Super rinse.
Turn the Program Control knob to the desired wash program. The machine will start.
INTERRUPTING OR CHANGING A PROGRAMINTERRUPTING OR CHANGING A PROGRAM
If you need to stop or interrupt a program after you start the machine, turn the Program Control knob to 10 (Drain). Any water in the machine
will be pumped out. Press the Door Open button to open the door. (It won’t open until the water is out.) To restart the washer, close the door,
add detergent (if needed), and turn the controls to the desired settings.
