Asko W6984 FI User manual

Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfil your needs for many years to
come. Scandinavian design combines clean lines, everyday functionality and high
quality. These are key characteristics of all our products and the reason they are
greatly appreciated throughout the world.
To get the most out of your new machine, we recommend that you read the
operating instructions before using the machine. The operating instructions also
include information on how you can help protect the environment.
Operating Instructions
Washing Machine
ASKO W6984 FI
WARNING: Read the instructions before using the machine.

4
Before using your machine for the
first time
4
Transport protection
4
Packing material
4
Washer door
4
Language selection
4
Time display options
4
Set the clock
4
Checking water hardness
5Safety instructions
5
General
5
Installation
5
Overflow guard function
5
Transport/Winter storage
5
Recycling
6Child safety
6
Keep an eye on children!
7Description of the washing machine
8Detergent compartment
9Advice and tips before washing
9
Sorting your laundry
9
Clothing
9
Laundry labels
9
Laundry label symbols
9
Coloured cotton
9
Unbleached linen
10
Wool
10
Rayon fibres and synthetic fibres
10
Stain removal
10
Reducing allergic reactions
10
Save time and energy
10
High water level
10
Economy and efficiency
10
Detergents
11
Dyeing fabrics
12Washing
12
Sort your laundry.
12
Turn on the main power switch
12
Open the washer door and load the
washing
12
Add detergent and fabric softener,
as required
13
Select the program
15
Select options
17
Close the washer door and press the
Start/Stop button
17
Once the program has finished
18Settings
18
You can change the following
settings:
18
Child-safe
18
Door opening
18
Temperature
18
Extra rinses
19
Pre-soak
19
Anti-crease function
19
Clock
19
Audible Volume
19
Spin option
20
Select language
20
Return
21Care and cleaning
21
Cleaning the trap and the drainage
pump
21
Cleaning the detergent compartment
21
Cleaning the outside of the machine
21
Cleaning the inside of the machine
to avoid unpleasant smells
22
Rinse holes under the agitator
22
If you have hard water
2
Contents

23Troubleshooting
23
The washer door will not open
23
The machine will not start
23
Wet washing still in the machine
24
Error messages
25Technical information
25
Information for test institute
27
Technical data
28Transport protection
29Installation
29
Positioning the washing machine
29
Adjusting the feet
29
Connection to water supply
29
Drainage connection
30
Electrical installation
31Door hanging
32
Follow these instructions:
33Fitting the wooden door
34Service
34
Before contacting the service division
36Quick guide
3
Contents

Transport protection
Remove any transport protection devices before
installing the machine. See the "Transport protection"
chapter.
Packing material
Sort waste materials in accordance with local
guidelines.
Washer door
• The washer door will not open until the machine
is connected to the electricity supply.
• To open the door manually, see "The washer door
will not open" in the "Troubleshooting" chapter.
• The machine cannot be started when the door is
open.
• To open the washer door while a program is
running, see "Close the door and press the
Start/Stop button" in the "Washing" chapter.
Language selection
You will be prompted to select the display language
when you have connected your machine and start it
for the first time. Do as follows:
1. Press the up or down arrow button and choose
from: US English, English, Svenska, Dansk,
Norsk, Suomi, Français, Deutsch, Italiano,
Espanol, Русский, Nederlands.
2. Press the button in the middle of the program
selector or Start/Stop to save and to move on to
the clock and time display settings.
Time display options
The time is shown on the display.
1. Press the up or down arrow button to choose 12h,
24h, or display remaining time. Press the program
selector or Start/Stop to confirm.
Once you have made a selection, the menu for
setting the clock will open.
Set the clock
1. Press the up or down arrow button until the correct
hour figure is displayed. Press the program
selector to confirm.
2. Press the up or down arrow button until the correct
minute figure is displayed. Press the program
selector or Start/Stop to save.
Once you have made a selection, the program menu
will open.
Checking water hardness
The quantity of detergent needed depends, amongst
other things, on how hard the water is. See the
detergent pack for details. Phone your local water
company to check the water hardness in your area.
NOTE!
Each machine is tested before leaving the factory.
A small amount of water may remain in the drain
pump, though this does not affect quality or damage
the machine.
See Quick guide on the last page
4
Before using your machine for the first time

General
• Read the operating instructions and keep them
in a safe place.
• Installation should be carried out by qualified
ASKO technicians.
• The machine should only be used for washing
items as described in these instructions. It is not
intended for dry cleaning.
•Use only detergent intended for machine washing!
• Remove any transport protection devices before
using the machine. See the "Transport protection"
chapter.
• Repairs and maintenance must be carried out by
a qualified professional.
• Damaged mains cables must only be replaced
by a qualified electrician.
• The machine is not designed to be used by
persons (even children) that are physically or
mentally handicapped or lack experience and
knowledge. Such persons must receive instruction
in how to use the machine or be supervised by a
person responsible for their safety.
• Children must be watched to ensure they do not
play with the machine.
• In the enclosed plastic bag you will find a tool for
opening the washer door in emergencies.
Installation
See the "Installation" chapter.
Overflow guard function
If the machine’s water level rises above the normal
level, the overflow guard function begins to pump
water out and shuts off the water intake. If the water
level has not dropped within 60 seconds, the program
is terminated.
Transport/Winter storage
If the machine is to be transported or stored in
unheated premises where the temperature can fall
below freezing, do as follows:
• Empty the filter and the drainage pump. See the
"Care and cleaning" chapter.
•Shut off the water to the washing machine, loosen
the supply hose to the intake valve and let the
water run out from the valve and hose.
• After emptying the pump, a small amount of water
may remain in the machine. This does not affect
quality or damage the machine.
Recycling
This machine is manufactured and labelled for
recycling. In order to prevent injuries, the machine
must be made unusable once the decision has been
taken to dispose of it. Contact your local authority
for information about where and how your machine
can be recycled correctly.
5
Safety instructions

Keep an eye on children!
• Always close the door and start the programme
immediately once you have added detergent.
• The appliance is not intended for use by young
children or infirm persons without supervision.
• Young children should be supervised to ensure
that they do not play with the appliance.
• Store detergent and fabric softener out of the
reach of children!
• In order to prevent children from starting a
program or changing one that has already started,
you can activate a Child-safe start
CAUTION!
If this appliance is supplied from a cord extensions
set or electrical portable outlet device, the cord
extension ser or electrical portable outlet device
must be positioned so that it is not subject to
splashing or ingress of moisture.
Activate child safety catch (for detergent
compartment)
On the inside of the detergent compartment is a child
safety catch.
Inactivated child safety
catch
Activated child safety
catch
When the child safety catch is activated you must
press the release button to pull out the detergent
compartment.
6
Child safety

1234
5,6
1. Main power switch
2. Detergent compartment
3. Program panel
4. Serial number plate (on inside of washer door)
5. Drainage pump cover
6. Drainage pump (behind cover)
7
Description of the washing machine

23
4
5
6
1
Pre-wash1.
Main wash with liquid detergent.
Use the separator.
2.
Main wash with powder detergent.
Do not use the separator.
3.
Fabric softener4.
Release button5.
Child safety catch6.
8
Detergent compartment

Here are some tips that may help you before
washing.
Sorting your laundry
Sort items according to:
• how soiled they are
• colour
• material
Clothing
1. Do up zips and close Velcro straps so that they
don’t harm fabrics.
2. New coloured items may contain excess dye and
should therefore be washed separately the first
few times.
3. Turn delicate items inside out. This reduces the
risk of burling and fading.
4. Empty pockets and wash them inside out if
possible.
Laundry labels
Look at the item's laundry label. The table below
shows suitable wash programs for different materials
and wash loads. Using modern washing machines
and detergents, for example compact detergents,
you can usually wash at lower temperatures. It is a
good idea to use trial and error to find out what
produces the best results.
Laundry label symbols
Examples of washing instructions and recommended programs. Always follow the washing instructions for
each garment.
ProgramMaterialLaundry labels
Everyday wash 60 °C to 95 °CCotton, linen, white and light-coloured items.
Quick 60 °CCotton, linen, cotton/polyester. Light and dark-coloured
garments.
Easy Care 40 °CAcrylic, viscose, modal, acetate, polyester, polyamide
and elastane. Light and dark-coloured garments.
Wool/Hand 30 °C to 40 °CWool, silk and other very delicate garments
or
Coloured cotton
Coloured cotton items with the washing instruction
60 °C should be washed at 60 °C for the first time in
order to remove any excess dye. If you do not do so,
there is a risk that the colour will run. Use detergent
without bleach in order to preserve the colour of the
fabric.
Unbleached linen
Unbleached linen fabrics should be washed at 60
°C, using detergent containing no bleach or optical
whiteners. Heavily-soiled linen can occasionally be
washed at higher temperatures, but not too often
because the heat can destroy the linen’s shine and
strength.
9
Advice and tips before washing

Wool
These fabrics are labelled either machine wash or
hand wash. The Wool program is at least as gentle
as washing by hand.
Wool is especially sensitive to processes such as
washing.
If you do not wish to spin dry, you can squeeze out
the water using terry towels. In this case select No
spin.
To find out how to choose this setting, see the
"Washing" chapter. However, most garments can
withstand a short spin. Choose a short spin by
selecting a spin speed of 800 rpm or less.
Rayon fibres and synthetic fibres
Materials made of rayon fibres, such as viscose, and
some synthetic fibres are very delicate and require
much space so as not to crease. Only half fill the
drum when washing and choose a spin speed of 800
rpm or lower.
NOTE!
Viscose and acetates are fragile when wet.
Stain removal
The automatic stain program can be used for the
following types of stains: Chocolate, Blood, Red
wine, Egg, Grass, Diary products, Tea/Coffee, Fat
stains grease/oil and Blueberry. The program is
suitable for cotton, cotton/synthetics and synthetics.
NOTE!
For stain removal it is always important to treat the
stain as soon as possible. Leaving a stain and
allowing it to dry makes it more difficult to remove.
It is also important to carefully scrape off any of the
stain lying on the surface. Do not load the machine
with more than 2.5 kg of laundry.
Reducing allergic reactions
The washing machine has a Super Rinse option. Use
this for people with sensitive skin, such as those with
allergies and small children.
Save time and energy
Use the Everyday wash program to save time and
energy. This program has a shorter main wash than
Normal, but is often sufficient for lightly soiled
washing.
High water level
If you want more water for the main wash and rinses,
you can use the High water level option. This is
automatically selected in the Wool/Hand program.
Economy and efficiency
You can save energy by not using higher temperature
programs than necessary.
• Select Quick if you just need to freshen up shirts
or exercise clothes, for example. This will save
both water and energy.
•If you select a fast spin speed, this reduces energy
consumption when drying in a tumble dryer or
drying cabinet.
• Always wash with a full load when using the
Heavy, Everyday wash and Normal programs.
• Avoid pre-washing. Modern machines and
detergents clean effectively without pre-washing.
Pre-washing is only necessary for heavily soiled
washing.
Detergents
Eco-labelled detergents are less harmful to the
environment.
Detergent overdosing does not give better washing
results; it merely causes a greater impact on the
environment; can also hinder the wash performance.
Try to use less detergent, and increase only if you
are not satisfied with the results.
10
Advice and tips before washing

Dyeing fabrics
If you want to dye fabrics in the machine, select the
Everyday wash program with the Super Rinse option.
Select temperature according to the dye
manufacturer’s recommendations.
Choose a low spin speed if the fabric to be dyed is
a blended material such as
polyester/cotton.
NOTE!
Add the dye directly to the washing drum – not to
the detergent compartment. After dyeing, you
should run the machine empty using the same
program. Use the normal amount of detergent.
NOTE!
Due to environmental concerns, we discourage the
use of strong chemicals.
When using agents for bleaching or stain removal,
there is a risk of rust (corrosion) and discolouration
of the machine.
11
Advice and tips before washing

1Sort your laundry.
See the "Advice and tips before washing"
chapter.
Place underwired bras in a laundry net.
Empty pockets. Coins, nails and the like can cause
damage to the machine and fabrics. See the "Advice
and Tips" section before washing.
2Turn on the main power switch
3Open the washer door and load
the washing
If the washer door is closed, press the Door
opening button (key symbol). The door opens once
all water has drained from the machine. Load the
washing. The wash program chart shows how much
washing can be washed with each program.
4Add detergent and fabric
softener, as required
The detergent packaging will have
recommendations for how much detergent you
should use. The machine holds 7 kg of washing. If
you only have a small amount of laundry in the
machine, you can reduce the amount of detergent
used.
Powder detergent
Pour the powder into the compartment for the main
wash, and pre-wash as well if desired.
Liquid detergent
When using liquid detergent, follow the detergent
manufacturer’s recommendations. For thick
detergent we always recommend using a wash ball.
Use the separator in the main detergent
compartment. Pour the liquid detergent into the front
section of the detergent compartment.
Wash ball or net
If you use a wash ball or net, place it directly in the
drum and select a program without pre-wash.
NOTE!
Detergent overdosing does not give better washing
results; it merely causes a greater impact on the
environment; can also hinder the wash
performance.
Try using less detergent, and increase only if you
are not satisfied with the results.
Fabric softener
Pour the fabric softener into the compartment with
the symbol. Follow the recommendations on the
fabric softener packaging.
NOTE!
Do not fill above the compartment’s maximum fill
level. Otherwise fabric softener will run in too early,
and will impair washing results.
12
Washing

5Select the program
Door opening
Start/Stop
Selector Display
You select the program by pressing the up or down arrow buttons. The name of the selected program is
highlighted and the finish time of the program appears on the display. Start the program by pressing the
Start/Stop button, or press the button in the middle of the arrow buttons to go on and select options.
1. Auto
This program automatically adjusts the length of the
main wash and the number of rinses to the amount
and type of laundry loaded in the machine.
2. Stain prog
For information on stain removal see the Advice and
Tips section before washing.
• Press the program selector (the big arrow) again
to access the stain symbol. Select the appropriate
stain type by turning the program selector.
• Press the program selector (the big arrow) again
to access the fabric symbol. Select the desired
fabric type.
• Follow the dosage recommendations on the
detergent package.
• For stains of Red wine, Tea/Coffee, Blueberry
and Chocolate we recommend that you also add
half the recommended amount of detergent to the
pre-wash compartment.
• You can select the temperature freely, so use the
highest temperature recommended for each
garment.
3. Time program
This program adjusts itself to the specified time frame
or finish time. When using this program, it is however
important to select a temperature and time suited to
how soiled the laundry is. The spin speed can be
selected freely.
4. Heavy
Program for heavily soiled laundry, with dirt that
needs to be fully dissolved before the main wash. A
pre-wash is used to do this. The machine adapts the
program time and water consumption to the load
size.
5. Normal
Program for normal to heavily soiled laundry, whites
and colours. You can select the temperature freely,
so follow the washing instructions for each garment.
60 °C is a good temperature for heavily soiled cotton
garments, as well as for garments worn next to the
skin. Select 40 °C if the laundry is less soiled. The
spin speed can be selected freely. The machine
adapts the program time and water consumption to
the load size.
6. Everyday wash
A standard program for lightly to moderately soiled
laundry. The temperature can be selected freely, so
follow the washing instructions for each garment.
Garments worn next to the skin ought to be washed
at 60 °C. Very lightly soiled laundry often comes
clean already at 40 °C. The spin speed can be
selected freely.
13
Washing

7. Quick
Fast program for laundry that just needs freshening
up. The program can be run at any temperature, so
follow the washing instructions for each garment.
The lower the selected temperature, the shorter the
program time. Garments worn next to the skin ought
to be washed at 60 °C. The spin speed can be
selected freely.
8. Easy Care
Program for synthetic, mixed fibre and easy care
cotton. The program has a high water level and as
such is also suitable for cushions, quilted jackets and
the like. Read the washing instructions carefully and
remember, for example, that fabric softener must not
be used with the membranes found in some outer
garments. A washing temperature up to 60 °C and
a spin speed up to 1200 rpm can be selected.
9. Synthetics
Program for delicate garments made of synthetic
fibre, mixed fibre, rayon and easy care cotton. The
maximum temperature is 60 °C, but follow the
washing instructions for each garment. Many
synthetics will come clean at 40 °C. Garments worn
next to the skin ought to be washed at 60 °C. The
maximum spin speed is 800 rpm.
10. Wool
A gentle laundry program for wool, silk and garments
that should be washed by hand. The highest
available temperature is 40 °C. This program has a
short spin. The maximum spin speed is 800 rpm.
11. Hand
A gentle laundry program for wool, silk and garments
that should be washed by hand. The highest
temperature is 30 °C. This program has a short spin.
The maximum spin speed is 800 rpm.
12. Rinse
This program performs one cold rinse cycle + spin.
Suitable for laundry that just needs to be dampened
and for cleaning cloths and mops.
13. Spin
Used to just spin the wash.
14. Drain
Used when you only want to drain the water from the
machine.
14
Washing

Program chart
Program time
(approx. hrs and min.)
Energy consumption
(approx. kWh)
Water consump-
tion
(approx. liter)
Max. load
( kg)
Spin Speed
rpm
Number of
RinsesTemp. °C
Pre-
washProgram
1. Auto
2. Stain prog
3. Time program
2:452.28571800595X
4. Heavy 2:401.27571800560X
3:551.135071800260
5. Normal 3:400.475071800240
1:401.160718003606. Everyday wash
0:500.4353.518003407. Quick
1:400.6603.512002408. Easy Care
1:200.4402.58004409. Synthetics
0:500.5702.380033010. Wool
0:500.5702.380033011. Hand
0:200.1153.51800112. Rinse
0:150.13.5180013. Spin
0:0114. Drain
Consumption data may vary from the given values depending on variations in water pressure, water hardness, water inlet temperature, room
temperature, fluctuations in the electricity, type and volume of the laundry and any extra options.
6Select options
You can select options to adjust the wash
program to suit your own specific
requirements. The available options depend on the
selected program. If the option is available for the
selected program, the symbol is shown in the display.
The machine will remember the options you select
for each program (with one exception – Delayed
Start). You can still change the selected options the
next time you select the program in question.
Temperature
• Choose the temperature by pressing the program
selector (the big arrow) until a temperature is
highlighted.
•Press the up or down arrow button until the correct
temperature is displayed. You can select
temperatures between Cold and 95 °C. If you
select Cold, the washing temperature will be the
same as that of the water entering the machine.
For Wool you cannot choose a temperature higher
than 40 °C and for Hand not higher than 30 °C.
The maximum temperature for Time program is
60 °C.
• Press the Start/Stop button to start the program
or press the program selector (the big arrow)
again to choose more options.
Spin
• Select the spin speed by pressing the program
selector (the big arrow) until spin is highlighted.
•Press the up or down arrow button until the correct
speed is displayed. You can select speeds
between 400 and 1800 rpm, (no spin) or
15
Washing

(no drain). The maximum spin speed varies
according to the program selected. The speed is
shown in the display.
•, means that the program does not include a
spin cycle and ends by draining.
•No drain means that the program does not
include a spin cycle and ends with the water from
the final rinse still in the machine. The washing
will remain covered by the water from the final
rinse, stopping it from getting creased. If you have
selected "No drain", once the program has ended
you must select the Spin or Drain program to drain
the water from the machine before you open the
washer door.
Rinse
The number of rinses varies depending on the
program selected. Use this option if you want to
increase or decrease the number of rinses for the
selected program. Economy Rinse removes one
rinse from the program. Normal Rinse means
the program runs the original number of rinses.
Super Rinse adds two extra rinses to the program.
The maximum number of rinses is seven. Super
Rinse is recommended for persons with extremely
sensitive skin and/or in areas with very soft water.
1. Select the number of rinses by pressing the
program selector (the big arrow) until the rinse
symbol lights up in the display.
2. Press the up or down arrow button to select
number of rinses.
3. Press the Start/Stop button to start the program
or press the program selector (the big arrow)
again to choose more options.
High water level
1. High water level means that additional water is
used during the main wash and rinse cycles.
Choose High water level by pressing the program
selector (the big arrow) until High water level is
highlighted.
2. This option cannot be used with the Auto, Time
program, Wool, Hand, Rinse, Spin and Drain
programs.
3. You press the up arrow button to choose High
water level or the down arrow to choose Normal
water level.
4. Press the Start/Stop button to start the program
or press the program selector (the big arrow)
again to choose more options.
NOTE!
The machine takes in the additional water for the
high water level about 15 minutes after the main
wash has started.
Delayed start
When you select Delayed start, the machine will start
0.5–24 hours after you press the Start/Stop button.
This option cannot be used with Time program.
1. Select Delayed start by pressing the program
selector (the big arrow) until the clock symbol is
highlighted and the current start and finish times
appear on the right of the display.
2. Each time you press the arrow buttons you add
half an hour to the time up to a maximum of 24
hours.
NOTE!
Remember to press the Start/Stop button to start
the program.
NOTE!
Make sure the detergent compartment is completely
dry before you add detergent, otherwise there is a
risk that the detergent will clump before the machine
starts.
16
Washing

7Close the washer door and press
the Start/Stop button
Time remaining
The time remaining is shown in hours and minutes.
Once a program is selected, the estimated program
time is displayed. This may differ from time to time
depending on the temperature of the water entering
the machine and the size of the load. If the program
time is longer than the previous wash with the same
program, "0:01" will be displayed until the program
finishes. This is normal! The next time you use the
program under similar conditions, the estimated
program time will be more accurate.
To add or remove washing after the program
starts
If you want to add or remove items after the program
has started, you can stop the program by pressing
and holding the Door opening button (key symbol)
for three seconds. When you restart the machine,
add any extra detergent needed and close the
washer door. The machine continues automatically
from the point where the program was interrupted.
Stopping or changing a program
You can stop a program by pressing the Start/Stop
button for three seconds. "Stop" appears in the
display. To restart the machine, select a new
program, add any extra detergent needed and press
the Start/Stop button.
NOTE!
Do not open the detergent compartment while the
machine is running.
8Once the program has finished
The text "Done" is shown on the display.
The washer door opens automatically once
the program has finished. If you want to deactivate
the automatic door opening function, see the
"Selecting settings" section.
• Remove the load.
• Turn off the main power switch, this will save
energy.
If you have small children or pets at home, close the
washer door once you have removed the laundry.
Backlighting
Two minutes after the wash program finishes the
display backlighting enters energy saving mode.
Press the up or down arrow button if you want to
activate the machine.
17
Washing

You can change the following
settings:
• Child-safe
• Door opening
• Language
• Temperature
• Extra rinses
• Pre-soak
• Anti-crease function
• Clock
• Audible Volume
• Spin option
How to choose the settings:
1. Press the program selector (the big arrow) until
the program selection menu in the display on the
left is highlighted.
2. Then press the up or down arrow buttons until
Settings is highlighted.
3. Press the program selector (the big arrow).
Child-safe
Child-safe
You can activate the Child-safe start option to prevent
children from starting the machine. You can
deactivate the Child-safe start option by pressing the
Start/Stop button and the program selector (the big
arrow) at the same time. The Child-safe start option
will be temporarily deactivated for three minutes.
1. Press the up or down arrow buttons until
Child-safe Start appears in the middle of the
display.
2. Press the program selector again (the big arrow)
to access the options menu on the right of the
display.
3. Press the up or down arrow buttons to select Off
or On.
4. Press the program selector to save your setting.
5. If you do not want to select any more settings,
press the arrow button down until you reach the
program you want.
Door opening
The default setting is for the washer door to open
automatically when the program has finished. If for
any reason you do not want the door to open
automatically, you can program the machine so that
the door only opens when you press the Door
opening button (key symbol).
1. Press the arrow buttons up or down until
Automatic door opening appears in the middle of
the display.
2. Press the program selector again (the big arrow)
to access the options menu on the right of the
display.
3. Press the up or down arrow buttons to select Off
or On.
4. Press the program selector to save your setting.
5. If you do not want to select any more settings,
press the arrow button down until you reach the
program you want.
Temperature
1. Press the arrow buttons up or down until
Temperature appears in the middle of the display.
2. Press the program selector (the big arrow) once
to access the alternative menu to the right of the
display.
3. Press the up or down arrow buttons and choose
°C or °F.
4. Press the program selector (the big arrow) to save
your setting.
5. If you do not want to select any more settings,
press the arrow button down until you reach the
program you want.
Extra rinses
Upon delivery, your washing machine is set to use
three rinses in the Normal and Everyday wash
programs. If you want to increase the number of
rinses to five for these programs, do as follows:
1. Press the up or down arrow button and select
"Rinses On" for five rinses or "Rinses Off" for three
rinses.
2. Press the Door opening button once to save the
setting.
18
Settings

Pre-soak
If the washing is stained, such as with blood, we
recommend a presoak. The washing will soak in cold
water for two hours before the wash program starts.
This option cannot be used with the Time program,
Wool and Hand programs.
1. Press the arrow buttons up or down until Presoak
appears in the middle of the display.
2. Press the program selector again (the big arrow)
to access the options menu on the right of the
display.
3. Press the up or down arrow buttons to select Off
or On.
4. Press the program selector (the big arrow) to save
your setting.
5. If you do not want to select any more settings,
press the arrow button down until you reach the
program you want.
Anti-crease function
This option means that the drum will rotate for three
seconds per minute for two hours once the wash
program has finished. This function prevents the
clothes from lying in the same position and getting
creased.
This is a useful feature if you can't take the washing
out straightaway.
1. Press the arrow buttons up or down until
Anti-crease appears on the right of the display.
2. Press the program selector again (the big arrow)
to access the options menu on the right of the
display.
3. Press the up or down arrow buttons to select Off
or On.
4. Press the program selector (the big arrow) to save
your setting.
5. If you do not want to select any more settings,
press the arrow button down until you reach the
program you want.
Clock
Set the clock to 12h, 24h or to display the remaining
program time.
1. Press the arrow buttons up or down until Clock
appears in the middle of the display.
2. Press the program selector again (the big arrow)
to access the options menu on the right of the
display.
3. Press the up or down arrow buttons to choose the
12h or 24h time format or display the remaining
program time.
4. Press the program selector (the big arrow) to save
your setting.
5. If you selected 12 or 24 hour, you will now come
automatically to the clock-setting menu.
Setting the clock
1. Press the up arrow button until the correct hour
figure is shown.
2. Press the program selector (the big arrow) to save
your setting.
3. Press the up arrow button until the correct minute
figure is shown.
4. Press the program selector (the big arrow) to save
your setting.
5. If you do not want to select any more settings,
press the arrow button down until you reach the
program you want.
Audible Volume
You can choose to have the machine notify you when
a program is finished or when a fault has occurred.
1. Press the arrow buttons up or down until Audible
Volume appears in the middle of the display.
2. Press the program selector again (the big arrow)
to access the options menu on the right of the
display.
3. Use the up or down arrow buttons to adjust the
Audible volume: Off, Low, Normal or High
4. Press the program selector to save your setting.
5. If you do not want to select any more settings,
press the arrow button down until you reach the
program you want.
Spin option
If you have a problem with resonance frequencies
where your machine is positioned, you can try
changing the spin setting. Choose between four
preset options.
19
Settings

Select language
1. Press the arrow buttons up or down until
Language appears in the display.
2. Press the program selector again (the big arrow)
to access the options menu on the right of the
display.
3. Press the up or down arrow button and choose
from: US English, English, Svenska, Dansk,
Norsk, Suomi, Français, Deutsch, Italiano,
Espanol, Русский, Nederlands.
4. Press the program selector to save your setting.
5. If you do not want to select any more settings,
press the arrow button down until you reach the
program you want.
Return
To return to the program menu, press the program
selector (the big arrow).
20
Settings
