Aspire AD-8091 User manual

１
Safety Symbols This symbol indicates there is dangerous voltages within the AD-8091 housing, which may have
sufficient magnitude to constitute a risk of electric shock if not handled correctly. To avoid the
risk of electric shock, do not open the housing at any time.
This symbol identifies important operating and maintenance (servicing) instructions. Be sure to
follow instructions identified with this symbol to avoid potential damage to your unit.
Safety Precautions
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE
ENCLOSURE. DO NOT OPEN THE CABINET.
REFER SERVICING TO QUALIFIED PERSONNEL ONLY.
DO NOT STARE INTO BEAM OR BLINDNESS MAY RESULT.
This DVD Recorder a laser system. To prevent direct exposure to laser beam, do not try to open the enclosure or defeat
the interlocks. Use of controls, adjustments or the performance of procedures other than those specified may result herein
hazardous radiation exposure. To prevent direct exposure to laser beam, do not try to open the enclosure. Visible laser
radiation when open and interlocks defeated
Other Precautions
Do not put any objects in the tray other than approved video and audio discs.
Do not open the unit, touch the inner parts or insert any foreign objects into the unit.
Place the unit on a level, open surface. Do not locate the unit under direct sunshine, near heating devices or in very dusty or
dirty places. Otherwise, the unit may be damaged.
Hold the plug tight when connecting or disconnecting the AC power supply. Do not put any weight on AC cord or attempt to
service the AC cord if it becomes damaged.
Keep unit away from open windows or near anyplace where water may get into the unit and damage it.
Do not stack heavy objects on the unit.
Condensation may form in the unit when moving it from very cold to very warm or humid locations. In such cases, wait for
the unit to come to room temperature and the condensation to evaporate before using the unit.
Do not place the unit near radio receivers or other video or audio devices. Should a nearby radio receiver experience
interference while the unit is running, turn the AD-8091 unit off.
SAFETY INSTRUCTIONS

２
1.Read this Manual
After unpacking this product read
the manual carefully and follow
all the operating instructions.
2.Power Sources
This product should be operated
only from the type of power source
indicated on the unit. If you are not
sure of the type of power supply to
your home, consult your product
dealer or local power company.
3.Grounding or Polarization
This product may be equipped with a
polarized alternating current line plug
(a plug having one blade wider than the
other). This plug will fit into the power
outlet only one way. This is a safety
feature. If you are unable to insert the
plug fully into the plug, contact your
electrician to replace your obsolete outlet.
Do not try to bypass the safety purpose of the polarized plug.
4.Ventilation
Slots and openings in the cabinet
are provided for ventilation and to
ensure operation of the product and
to protect it from overheating. Do
not block or cover these openings.
5.Heat
Position the unit away from heat
sources such as radiators, heat
registers, stoves, or other products
(including amplifiers)that produce
heat.
6.Water and Moisture
Do not use this product near water
such as near a bathtub, wash bowl,
kitchen sink, or laundry tub, in a wet
basement, near a swimming pool or
the like.
7.Cleaning
Unplug this product from the A/C
outlet before cleaning. Use a damp
cloth to clean the unit. Do not use
liquid or aerosol cleaners.
8.Power Cord Protection
Power supply cords should be routed
so that they are not likely to be walked
on or pinched by items placed upon or
against them. Pay particular attention
to cords at plugs, convenience
receptacles, and the point where they exit from the product.
9.Overloading
Do not overload wall outlets or
extension cords as this can result
in a risk of fire or electric shock.
SAFETY INSTRUCTIONS

３
10.Lightning
Unplug the unit from the wall outlet during storms to prevent
damage from lightning and power surges.
11.Objects and Liquids
Never push objects into this product as that could result in a
fire or electric shock. Never spill liquids
on the product.
12.Attachments
Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
13.Accessories
Do not place this product on an unstable platform. The product
may fall, causing serious injury or serious damage to the
product.
14.Disc Tray
Keep your fingers clear of the disc tray as it is closing.
Neglecting to may cause serious personal
injury.
15.Burden
Do not place heavy objects on the
product. The object may fall causing
serious personal injury and serious
damage to the product.
16.Discs
Do not use a cracked, deformed or
repaired disc. These discs are easily
broken and may cause serious
personal injury and product
malfunction.
17.Damage Requiring Service
Unplug the unit from the A/C outlet and refer servicing to
qualified service personnel under the following conditions:
a) When the power cord or plug is damaged.
b) If liquid has been spilled into or objects have fallen into the
product.
c) If the product has been exposed to rain or water.
d) If the product does not operate normally.
e) If the product has been dropped or damaged in any way.
f) When the product exhibits a distinct change in performance.
18. Servicing
Do not attempt to service this product
yourself as this may expose you to
dangerous voltage or other hazards. Refer
all servicing to qualified service personnel.
19. Replacement Parts
Be sure the service technician has used
authorized replacement parts.
Unauthorized substitutions may result in
fire, electric shock, or other hazards.
20.Safety Check
Upon completion of any service or repairs, ask the service
technician to perform safety checks to determine that the
product is in proper operating condition
21.Splashing
The apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids,
such as vases, shall be placed on the apparatus.
SAFETY INSTRUCTIONS

４
PRODUCTS WITH PROGRESSIVE SCAN OUTPUTS (525P/625P)
NOTICE REQUIREMENTS
(from the 525p/625p Addendum to the DVD License Agreement)
Licensee will incorporate the following wording, as appropriate, together with the applicable list of
Licensee’s high definition television sets, in all product manuals or the like applicable to any DVD Recorder
with a YUV progressive scan output:
For DVD Recorders with 525p, but not 625p, progressive scan output:
‘CONSUMERS SHOULD NOTE THAT NOTALL HIGH DEFINITION TELEVISION SETS ARE
FULLY COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED
IN THE PICTURE. IN CASE OF 525 PROGRESSIVE SCAN PICTURE PROBLEMS, IT IS
RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO THE ‘STANDARD
DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS REGARDING OUR TV SET COMPATIBILITY
WITH THIS MODEL 525p DVD RECORDER, PLEASE CONTACT OUR CUSTOMER SERVICE
CENTER.’
For DVD Recorders with 625p, but not 525p, progressive scan output:
‘CONSUMERS SHOULD NOTE THAT NOTALL HIGH DEFINITION TELEVISION SETS ARE
FULLY COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED
IN THE PICTURE. IN CASE OF 625 PROGRESSIVE SCAN PICTURE PROBLEMS, IT IS
RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO THE ‘STANDARD
DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS REGARDING OUR TV SET COMPATIBILITY
WITH THIS MODEL 625p DVD RECORDER, PLEASE CONTACT OUR CUSTOMER SERVICE
CENTER.’
For DVD Recorders with both 525p and 625p progressive scan outputs:
‘CONSUMERS SHOULD NOTE THAT NOTALL HIGH DEFINITION TELEVISION SETS ARE
FULLY COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED
IN THE PICTURE. IN CASE OF 525 OR 625 PROGRESSIVE SCAN PICTURE PROBLEMS, IT IS
RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO THE ‘STANDARD
DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS REGARDING OUR TV SET COMPATIBILITY
WITH THIS MODEL 525p AND 625p DVD RECORDER, PLEASE CONTACT OUR CUSTOMER
SERVICE CENTER.’
SAFETY INSTRUCTIONS

５
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents
and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this
copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other
limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or
disassembly is prohibited.
AD-8091 andAspire Digital are trademarks of Aspire Digital LLC. All other marks are trademarks of their respective
owners.
Copyright 2004 Aspire Digital, LLC. All rights reserved
Printed in China.
* 1. Please be sure on the condition of STANDBY prior to power off.
2. To prevent improper condition, restarting within five minutes since power off shall not be advised.
3. The playing effect shall not be assured if user operates the products with bad quality DVD+RW discs.
4. If this DVD+RW has been stay under 0°temperature for more than 30minutes, Please keep it
in an warmer environment (over 15°temperature) before you plug in.
SAFETY INSTRUCTIONS
Manufactured under license from Dolby Laboratories. "Dolby", "Pro Logic", and the double-D symbol
are trademarks of Dolby Laboratories. All rights reserved.

６
INTRODUCTION
DVD+R/RW Recorder and Progressive scan Player . . . . . . . . . . . . 7
Optical disc compatibility . . . . . . . . . . . . . . . . . . . 8
Caring for optical discs . . . . . . . . . . . . . . . . . . . . . 8
GETTING STARTED
Make sure the package contents are complete. . . . . . . . . . . . . . . 9
Installing batteries in the remote control . . . . . . . . 9
Operating the remote control . . . . . . . . . . . . . . . . . . . . 9
FUNCTIONAL OVERVIEW
Remote control . . . . . . . . . . . . . . . . . . . . 10
Front panel . . . . . . . . . . . . . . . . . . . . . . .11
Right side panel . . . . . . . . . . . . . . . . . . . . . . .11
Front VFD display . . . . . . . . . . . . . . . . . . . . . . . . .12
Back panel . . . . . . . . . . . . . . . . . . . . 13
CONNECTIONS
Connecting the Video output to your TV . . . . . . . . . . . . . . . . . 14-15
Audio output connections . . . . . . . . . . . . . . . . . . 16
Antenna & TV connections . . . . . . . . . . . . . . . . . . . . . . 16
A/V input connections . . . . . . . . . . . . . . . . . . . . . 17
DVD RECORDER OPERATION
Powering on the unit . . . . . . . . . . . . . . . . . . . . . . 18
Initial Setup Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Selecting the DVD Playback Mode . . . . . . . . . . . . . . 19
Using disc menus . . . . . . . . . . . . . . . . . . . . . . . . . 19
Basic disc playback . . . . . . . . . . . . . . . . . . . . . . . 20
Advanced disc playback . . . . . . . . . . . . . . . . . . . 21
Using the zoom feature . . . . . . . . . . . . . . . . . . . 22
Changing the audio track . . . . . . . . . . . . . . . . . . . 23
Using subtitles . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Displaying playback information . . . . . . . . . . . . 23
Viewing JPG files . . . . . . . . . . . . . . . . . . . . . . . . 24
Playing MP3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
RECORDING
Introduction to recording . . . . . . . . . . . . . . . . . . . . . . . . 26
Setting recording options. . . . . . . . . . . . . . . . . . . 27
Setting the Time and Date . . . . . . . . . . . . . . . . . . 27
TV Tuner Setup . . . . . . . . . . . . . . . . . . . . . . . . . . 28
The Title screen . . . . . . . . . . . . . . . . . 29
Types of Recordings . . . . . . . . . . . . . . . . . . . . . . 29
Making a Live Recording . . . . . . . . . . . . . . . . . . 29-30
Timer Recording . . . . . . . . . . . . . . . . . . . . . . . . . 31-33
EDITING YOUR RECORDINGS
Editing Overview . . . . . . . . . . . . . . . . . . . . . . . . . . 34
EDIT MENU Functions-Title . . .. . . . . . . . . . . . . . . ..34
EDIT DISC
Erasing a DVD+RW Disc. . . . . . . . . . . . . . . . . . . . . . . 35
Format Disc . . . . . . . . . . . . . . . . . . . . . . . . 35
Erase Disc . . . . . . . . . . . . . . . . . . . . . . . . 35
Finalize Disc . . . . . . . . . . . . . . . . . . . . . . . . 35
Rename Disc . . . . . . . . . . . . . . . . . . . . . . . . 35
THE DVD RECORDER SETUP MENU
Using the Setup Menu . . . . . . . . . . . . . . . . . . . . . 36
Play/Edit . . . . . . . . . . . . . . . . . . . . . . . . 36
Play/Edit Title . . . . . . . . . . . . . . . . . . . . . . . . 36
Disc Operations . . . . . . . . . . . . . . . . . . . . . . . . 36
Record Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Timer Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
My Record List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . 37
Recording Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Record Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Auto Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Set Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
DVD control . . . . . . . . . . . . . . . . . . . . . . . 38
Angle make . . . . . . . . . . . . . . . . . . . . . . . 38
Language Preference. . . . . . . . . . . . . . . . . . . . . . . 38
Parental Control. . . . . . . . . . . . . . . . . . . . . . . 38
General . . . . . . . . . . . . . . . . . . . . . 38
Menu Language . . . . . . . . . . . . . . . . . . . . . . . 38
Screen Saver . . . . . . . . . . . . . . . . . . . . . . . 38
Factory Reset . . . . . . . . . . . . . . . . . . . . . . . 39
Video Setup . . . . . . . . . . . . . . . . . . . . . . . 39
TV Display. . . . . . . . . . . . . . . . . . . . . . . 39
TV Type . . . . . . . . . . . . . . . . . . . . . . . 39
Picture Mode . . . . . . . . . . . . . . . . . . . . . . . 39
Video Output . . . . . . . . . . . . . . . . . . . . . . . 39
Speaker Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Down MIX. . . . . . . . . . . . . . . . . . . . . . . 40
Center . . . . . . . . . . . . . . . . . . . . . . . 40
Rear. . . . . . . . . . . . . . . . . . . . . . 40
Subwoofer . . . . . . . . . . . . . . . . . . . . . . . 40
Center Delay . . . . . . . . . . . . . . . . . . . . . . . 40
Rear Delay . . . . . . . . . . . . . . . . . . . . . . . 40
Speaker Test. . . . . . . . . . . . . . . . . . . . . . . 40
Audio Setup. . . . . . . . . . . . . . . . . . . . . . . 40
Digital Output. . . . . . . . . . . . . . . . . . . . . . . 40
External Decode. . . . . . . . . . . . . . . . . . . . . . . 40
Internal Decode. . . . . . . . . . . . . . . . . . . . . . . 40
Dynamic Compress. . . . . . . . . . . . . . . . . . . . . . . 41
Pro Logic. . . . . . . . . . . . . . . . . . . . . . . 41
Channel Source. . . . . . . . . . . . . . . . . . . . . . . 41
Channel Setup. . . . . . . . . . . . . . . . . . . . . . . 41
Auto CH Scan. . . . . . . . . . . . . . . . . . . . . . . 41
Channel List. . . . . . . . . . . . . . . . . . . . . . . 41
Modify Channel. . . . . . . . . . . . . . . . . . . . . . . 41
TROUBLE SHOOTING
Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
SPECIFICATION . . . . . . . . . . . . . . . . . . . . . . . 43
WARRANTY. . . . . . . . . . . . . . . . . . . . . . . 44
REGISTRATION CARD. . . . . . . . . . . . . . . . . . . . . . . 45
CONTENTS

７
You AD-8091 is a progressive scan DVD Recorder. The recording provides you the ability to create your own DVD discs
from your home movies, favorite TV programs and more. Because of the outstanding compatibility of DVD+R/RW discs,
the discs you create will be suitable for playback in most DVD Recorders. You can record from the unit's built-in TV Tuner
or an external video source like a video camera. And when you're ready to watch your recordings or commercial DVDs,
you can enjoy them in the highest quality with the unit's Progressive Scan Video Out and Digital Audio Out.
DVD+R/RW Recorder and Progressive Scan Player
DVD+R/RW Recorder
•Record from your TV, camcorder, VCR, CD’s, DVD’s.
Live, Timer and Scheduled Recording Functions
Multiple Recording Modes, HQ, SP, LP, EP, EP+
Up to 6 Hours Recording on one DVD+R/RW Disc
On-Screen Disc Title Navigator gives you quick, easy
access to your Recordings
Built-In TV Tuner, Right Side and Rear A/V Inputs
Editing features with Auto, Add/Del, Hide Chapters
Your recordings are playable on most DVD Recorders
Progressive Scan DVD+R/RW
Progressive Scan Video with 3:2 pull down
Playback DVD+R, DVD+RW, DVD- R, DVD-RW,
DVD, CD-R, CD-RW, SVCD, CD+G, MP3, JPEG,
Kodak Picture CD.
Component Video, S-Video and Composite Video
Outputs
96 kHz / 24 bit D/A converter
Stereo Audio out, Optical and Coaxial digital outputs.
Advanced playback functions: Slow playback, repeat
playback, parental control, MP3 player, JPG player,
screen saver, Zoom In/Out, track selection, on-screen
display and more
INTRODUCTION

８
Optical disc compatibility
This unit is compatible with a wide range of available optical
discs for recording and playback.
You must us DVD+R or DVD+RW discs to record on this unit.
DVD+R: These discs can only be written to once. Existing
recordings can be hidden but not deleted. So, any disc space
already used by a recording cannot be regained. DVD+R discs
are required to be "Finalized" before they will be compatible
with standard DVD Recorders. Once a disc is finalized, no
further recordings can be made.
DVD+RW: DVD+RW discs can be written to and erased
multiple times. Existing recordings can be deleted and disc
space regained. These discs do not require a finalization
procedure. As soon as a recording is made, the disc will be
compatible with standard DVD Recorders.
Units sold in North America are coded for Region 1, and are
compatible with discs marked accordingly.
DVD-R/RW: These discs can be played back when recorded
in standard DVD Video format.
CD-Audio: An on-screen navigator is provided to select and
play tracks when using CD-Audio discs.
CD-R/RW: This unit features an on-screen navigator for
easy access to playable files stored on CD-R/RW discs, such
as JPG images and MP3 music.
1. Hold a disc by the rim or with an index finger in the
central hole. Never touch the signal surface.
2. Finger prints or stains on the surface of the disc may cause
signal loss.
3. Use a soft cloth and wipe in a radiating manner from the
center of the disc to the outer rims when cleaning the disc
surface.
4. Never add labels or adhesive tapes on the discs Be
careful not to scratch or damage the disc surface.
5. To prevent discs from becoming bent or deformed, they
should be vertically kept in the disc storage case. To
prevent damage, avoid leaving discs in your car, where
they may be subject to direct sunlight and high
temperature.
6. Do not use any disc accessory to improve the audio
quality, disc protective solutions or lens cleaner. These
products may damage the disc surface.
Discs suitable for Recording and Playback
Discs suitable for Playback Only
Carin
g
for O
p
tical Discs
INTRODUCTION

９
In addition to the DVD recorder, your package contains the following accessories.
Make sure the
p
acka
g
e contents are com
p
lete
This unit comes complete with batteries for the remote control.
When installing batteries, be sure to take note of the polarity
markings on the inside of the battery compartment and match
them up with those on the batteries.
1. If the remote control functions better when it is closer to the
unit, the batteries may be running low.
2. In case of any leakage of batteries, dispose the batteries
right away and avoid touching the chemical discharge.
Make sure to clean the remote control’s battery
compartment before installing new batteries.
3. Do not mix batteries of different types, or use old batteries.
When using the remote control, be sure to stay within a 30
degree angle of the sensor (More than 3 meter )on the
receiver. Keep in mind that any obstructions between the
remote control and the receiver will effect performance.
Installing batteries in the remote control Operating the remote control
Notes on batteries
INTRODUCTION
Batteries User’s manual
Install the batteries in
the compartment.
A/V cable (composite Video,
stereo Audio
)
Remote control
Slide off the back cover

１０
Remote Contro
l
1. OPEN / CLOSE - Opens and
closes the disc tray.
2. ZOOM - Press to magnify the
screen with DVD and JPG discs.
3. A-B REPEAT - Sets the
beginning and end points of a
section to repeat.
4. REPEAT - Selects a repeat option -
Chapter, Title or Disc.
5. GOTO - To Select your desired time,
chapter of the disc to play.
6. REC MODE - Selects the
recording quality mode - HQ, SP,
LP, EP, EP+.
7. REC - Press to begin a live
recording.2
8. SETUP - Accesses the on-screen
Setup Menu for settings
adjustment. Use direction keys
(UP/DOWN/RIGHT/LEFT) to
highlight the item you desired.3
9. ENTER - Selects options in
menus. Plays a disc, chapter or
track with some discs. For other
discs, press PLAY. 4
10. RIGHT/LEFT - to highlight the
item you desired.35
11. STEP- Step to step playback
12. F.REV/F.FWD - Scan in fast
reverse or forward on DVD and other
discs.
13. PAUSE - Begins playback of a
disc, chapter or track. Press again
during playback to pause 8
14. SLOW - Slow motion playback
mode in ½,1/4 or 1/8 speed. Press
PLAY to resume normal playback.
15. OSD - brings up the on-screen
display showing information for the
playback session.
16. INTRO - playback disc for 9
sub-pictures display.9
17. SUBTITLE - Selects available
subtitles on DVD discs.
18. ANGLE - Selects between
multiple angles with DVD Discs
that support this feature. 10
19. LANGUAGE-changing the audio
language for DVD discs
20. AUDIO - Selects an audio track on
DVD .
21. TITLE - Accesses the title screen
on DVD+R/RW discs, displaying a
graphical representation of the
recordings and providing easy
navigation.
11
22. TIMER - Accesses the timer menu
for scheduled recording setup.
23. EDIT - Accesses the edit menu for
DVD+R/RW editing options.
24. STANDBY - Turns the unit on and
sends the unit to Standby mode.
25. NUMBER KEYS - Use to enter
numeric values while setting options.
26. CLEAR – At any time, press
CLEAR to return to monitor.
27. SOURCE - Selects the input video
source for recording. Choices include
built-in TV Tuner and AV Inputs.
28. DVD/TV - Switches between
Live Recording mode and DVD
Recorder mode.
29. MENU - Accesses Menu DVD
Discs.
30. (CH+/-)/ UP/DOWN - In TV tuner
mode, use to select a channel.
31. RETURN -Resume playback for
DVD discs .
32. NEXT/PREVIOUS - Advanced to
the next track or plays previous
track on DVD and other disc.
33. PLAY- Playback or Pause the disc
34. STOP - Press once to stop
playback and hold the last position
in memory. Playback can be
resumed where it was left off by
pressing PLAY. Press twice to
clear the last playback position.
35. VOL - Use to select volume +,-
36. PROG - Program play for disc.
37. PBC - Accesses Menus
on SVCD Discs. turns the PBC
function On/Off.
38. PSCAN -Select the video out
format for progressive scan mode or
Interlace TV.
39. PAL/NTSC -Select the video
system for PAL,NTSC or multi
system.
40. VIDEO/Y - Select the video out
mode for S-VIDEO (or composite),
YUV,.
41. SLEEP - Set the AUTO power off
time mode for 30 min, 60min, 90min,
120min or off
42. DISC OPER - Format the
Disc\Erase Disc\Finalize
Disc\Rename Disc.
43. MUTE - Temporarily cancels
audio playback.
FUNCTIONAL OVERVIEW
1
22 23
32
54
7
6
8
9
10
11
12 13
14 15
16 17
18 19
20
21
24
25
26 27
28
31
29 30
32 33
34 35
36
37
39 38
41 40
42
10
30
4 3

１１
Front Pane
l
1. STANDBY - Turns the unit on and sends the
unit to standby mode. In standby mode, the unit will use a
minute amount of power to enable power-on by the remote
control.
2. DISC TRAY - Loads DVD+R/RW, DVD, CD-ROM,
SVCD, MP3, JPG and other optical discs.
3. VFD DISPLAY - The front Display shows information
about the unit’s operation, such as current chapter and
elapsed time during playback and disc tray status.
4. REMOTE RECEIVERS
5. OPEN/CLOSE - Press to open or close the disc tray.
6. RECORD - Begins a Live Recording.
7. STOP - Press once to stop playback of a disc and save
the location of the stop point. The disc can be played
back from the stop point by pressing PLAY. To erase the
stop point and reset the play location to the beginning of
the disc, press STOP a second time.
8. PLAY/PAUSE - Begins playback of a disc, chapter or
track. Press again during playback to pause, and again
to resume playback.
9. REC MODE - Selects the recording quality mode HQ,
SP, LP, EP, EP+.
10. 12. NEXT/PREVIOUS - Advanced to the next track or
plays previous track on DVD and other disc.
11. SOURCE - Selects Input Sources when the Recorder
is in Live Record mode - TV Tuner, VIDEO IN 1 / 2,
S-VIDEO IN 1 / 2. And switch DVD Recorder mode to
live recorder mode.
11
14
13
15
17
18
16
19
10
11
FUNCTIONAL OVERVIEW
1.STEREO AUDIO INPUTS - Use with S-VIDEO2 IN
or VIDEO2 IN 1for recording.
2.VIDEO2 INPUT - Composite Video input for
recording. To select this input, use the SOURCE button
and choose VIDEO IN 2.
3.S-VIDEO2 INPUT - S-VIDEO input for recording. To
select this input, use the SOURCE button and choose
S-VIDEO IN 2.
1 1 2 3
Ri
g
ht Side Pane
l

１２
Front VFD Dis
p
la
y
1. FUNCTION INDICATORS
Indicate the status of advanced disc playback functions:
ALL Repeat Chapter/Title/Track function is active.
A-B Repeat A-B Function is active.
REC Recording indicator.
ANGLE Multi-Angle Mode is active.
PROGRAM Tracks are being played in PROGRAM
order.
RANDOM Tracks are being played in RANDOM order.
PBC PBC (Playback Control) Function is enabled.
These indicators show the playback status of a DVD, CD
or other optical disc - Currently Playing: , Paused: .
2. TV TYPE INDICATORS
These indicators show the TV TYPE-PAL:P, NTSC:N
3. PROCESSOR INDICATORS
These indicators display the status of the surround sound
processors and type of sound track currently active.
CHANNEL The TV channel indicates
DOLBY the Dolby Digital processor is active.
L/R The L/R option is active.
4. AM OR PM INDICATORS
These indicators show the current time is ante meridiem or
post meridiem.
5. DISC TYPE INDICATORS
Displays the type of optical disc inserted - DVD, SVCD,
CDDA (Music CD), or MP3.
6.TITLE /CHAPTER/Track INDICATOR
Displays the number of the current Title, Chapter or Track
on DVD, Music CDs and other discs.
7.MULTI-FUNCTION DISPLAY
When playing a DVD or other optical disc, displays the
elapsed time of the playback session or track. Also
displays disc tray status, system messages and more.
When the unit is in Standby Mode, displays the system
clock.
8.WEEK DAYS
Displays the current week days.
FUNCTIONAL OVERVIEW

１３
Back Panel
1. RF IN / OUT - For Antenna or Cable TV
connection. Pass through connection to TV does not
transfer the output signal from the DVD Recorder.
*Some units do not have a Pass through connector. In this
case, use a splitter (See page 16).
2. VIDEO1 INPUT - Composite Video input for
recording. To select this input, use the SOURCE button
and choose VIDEO IN 1.
3. S-VIDEO1 INPUT - S-VIDEO input for recording. To
select this input, use the SOURCE button and choose S-
VIDEO IN 1.
4. STEREO AUDIO INPUTS - Use with S-VIDEO1 IN
1or VIDEO1 IN 1for recording.
5. COMPONENT/PROGRESSIVE SCAN VIDEO
OUTPUT - Use this output with TVs supporting
Component Video or Progressive Scan input for best
video quality. Select this output in the DVD Recorder’s
SETUP MENU.
6. COAXIAL DIGITAL AUDIO OUTPUT - Use a
special coaxial digital audio connector to send the raw
coded digital signal to devices supporting digital
decoding.
7. COMPOSITE VIDEO OUTPUT - Standard Video
Output supported by most TVs.1
8. S-VIDEO OUTPUT - Connect to TVs with S-VIDEO
in for better picture quality than standard composite
video.
3
4
5
6
9. OPTICAL DIGITAL AUDIO OUTPUT - Use to
connect to a receiver or other device with 5.1 channel
decoders. This output is the coded digital signal.
10. 5.1CH AUDIO OUTPUT - Connect to TVs or other
Audio equipment supporting 5.1CH audio in.
11.POWER CABLE
7
8
9
10
11
12
FUNCTIONAL OVERVIEW

１４
In order to use the DVD Recorder, you’ll need to make a video connection to your TV. The capabilities of your TV and the cables
you have on hand will determine the connections you can use. There are 3 possible connection types:
-Composite Video - The most widely used connection. This unit includes an A/V cable for Composite Video.
-S-Video - A higher quality connection that requires a special S-Video cable and an S-Video capable TV.
-Component Video - The highest quality video connection. Supported on high-end TVs and requires a special cable.
Composite Video (Typical connection)
This unit ships with a composite video (A/V) cable for connection to TVs with a standard video input as shown below. This is the
most widely used type of connection. On most TVs, this connector is colored yellow, and is normally accompanied by stereo
audio inputs, colored red and white for stereo channels right and left, respectively.
Connectin
g
the video out
p
ut to
y
our TV
CONNECTIONS

１５
S-Video
This is a higher quality connection than standard composite video, and requires a special S-Video cable not included. The
S-Video connector is distinguishable by its 4 pins, as shown below. If your TV has an S-Video input, it’s recommended that you
use this type of connection for better picture quality.
Component Video
The highest quality video connection, component video requires separate cables for the Y, Pb, Pr signals. To use the progressive
scan option on this unit, you’ll need to use the component video output. Using the component video output requires these steps:
CONNECTIONS
First, use the supplied A/V cable to connect to the
composite video input on your TV. Select this input.
Change the TV TYPE to YUV by press the VIDEO/Y key
on the remote control.
Changing the TV OUT MODE to the progressive scan by
press the PSCAN key. Select the correct video input on
your TV.
Resetting the video output
If you inadvertently switch the OUTPUT FORMAT setting to
PROGRESSIVE while using a standard TV not capable of PSCAN,
you will loose video. If this happens, reset the recorder
to its default video settings by pressing PSCAN on the remote.
1
2
3
Component Video
InputJacks
capability

１６
This unit features a variety of audio line outputs for connection to a receiver or other audio equipment.
-Use the included A/V cable to connect the stereo audio outputs for connection to a TV or stereo receiver.
-Optical and Coaxial digital audio outputs send an encoded digital bitstream, suitable for receivers with Dolby decoding
capability. These outputs require special cables not included.
This unit is available with and without an antenna pass through connection. For units with an Antenna input connector and with
pass through connector, as shown below to the left , use antenna or cable TV connection to connect RF input and RF out connect
a TV.
Audio Out
p
ut Connections
Antenna & TV Connections
CONNECTIONS

１７
Audio/Video inputs are provided on the right side and back of the unit for connection of outside audio/video sources such as
VCRs, camcorders, DVD Recorders, etc. External Video Sources must support S-Video, Composite Video and/or Stereo Audio to
be suitable for recording.
Back AV Inputs (VIDEO IN 1, S-VIDEO IN 1)
Side AV Inputs (VIDEO IN 2, S-VIDEO IN 2)
Connectin
g
Audio/Video recordin
g
sources to the A/V In
p
uts
CONNECTIONS
Audio/Video source such as
DVD player or VCR with
Composite Video Out

１８
Powerin
g
on the unit Initial Setu
p
Procedure
Only after all connections are complete, connect the power
cord and power on the unit.
plug the standard jack end into a wall socket or power
strip.
Press STANDBY on the remote control or front panel
to bring the system out of standby mode. The
system is now ready to use.
There are 3 power states for this unit:
1. OFF – not connect the power cord. The unit draws no
power and cannot be turned on by the remote control.
2. STANDBY - the unit has not been taken out of standby by
pressing either the STANDBY key on the remote control
or the STANDBY button on the front panel. The unit
draws a slight amount of power to enable the remote
control receiving circuit.
3. ON - the STANDBY button on the remote control or the
STANDBY button on the front panel has been pressed.
The unit is ready to use.
Using the Menus
When the unit is first powered on, you'll be prompted to set
the time and date as well as TV Tuner options. You can
always change any of the settings you choose during the
Initial Setup later in the DVD Recorder's SETUP MENU.
Use the UP/DOWN keys to increase or decrease the
value of a selected field or move to a field above or
below. Use the LEFT/RIGHT keys to move to the
previous or next fields.
Press ENTER to select an option and/or continue.
Time and Date
Setting the Time and Date correctly is important, as the Timer
recordings depend on an accurate setting. The Time format used is
24HR. This means that 1:00PM will be represented as 13:00,
2:00PM as 14:00, and so on. Use the UP/DOWN keys to increase
or decrease the Time or Date and the LEFT/RIGHT keys to move
to a different field. When you're done, move to DONE and press
ENTER.
Watch TV
Play/EditDisc
Record program
Setupmenu
Channelsource
Channelsetup
Press SETUP to exit
Recording setup
DVD control
General
Video
Speaker
Audio
PressSETUP to exit
Recording Quality
Auto chapter
Set clock
Select a field then use to edit
PressSETUP toexit
Hour Minute Year Mouth Da
y
23 11 2003 DEC 31
The Initial Setup is now complete. Remember, any settings
chosen during the Initial Setup can be changed at any time in
the DVD Recorder's SETUP MENU. Press SETUP to exit the
Initial Setup and begin using your DVD Recorder.
Notes on “Power” states
DVD RECORDER OPERATION
1
2
1
2

１９
Press the DVD/TV button on the remote control or
the receiver’s front panel to select the DVD mode.
Press the OPEN/CLOSE button on the remote or front
panel to open the disc tray.
Insert a disc.
Close the disc tray by pressing OPEN / CLOSE on the
remote or front panel.
Playing a Disc from the Menu
Most DVDs will automatically display a menu after the disc
is inserted. This first menu is the first of possibly many
layers, and is therefore known as the menu.
Use the ARROW keys on the remote control to
navigate through the menu to the appropriate
selection to start the movie.
Press ENTER to confirm your selection.
Accessing a menu after play has started
If you wish to re-enter the menu after disc play has
started, use the MENU key. MENU also exits the
menu at any time.
Select the DVD Playback Mode Using Disc Menus
Insertin
g
a Disc
DVD RECORDER OPERATION
3
1
2
1
1
1
2

２０
Starting, Pausing and Stopping Disc Play
PLAY - To begin playback of a disc, press PLAY.
PAUSE - To freeze the video on a single frame, press
the PLAY/PAUSE (Front Panel) or PAUSE (Remote
Control) key during playback. To resume normal
playback, press PLAY/PAUSE (Front Panel) or PLAY
(Remote Control).
STOP - To stop playback of a disc, press STOP. The first
time STOP is pressed the location where disc play was
halted is saved. You can begin playback where you
left off by pressing PLAY. If STOP is pressed twice, the
playback location is reset to the beginning of the disc.
Fast Forward and Fast Reverse
You can scan through DVD’s, and other discs in forward or
reverse direction at speeds up to 8X (eight times normal
speed). Fast forward/reverse scanning will only work during
disc playback, not when the disc is stopped.
To use the fast forward/reverse function with the remote
control, press the F.REV or F.RWD key repeatedly to
cycle through all speeds in the desired direction.
Available speeds are 2X, 4X, 6X, and 8X. To resume
normal playback, press the PLAY key.
Skipping to the Next or Previous Chapter /Track
You can advance or skip back through the chapters or tracks
on DVD discs, Audio CDs and other discs with the NEXT
and PREV buttons on the remote or front panel.
SKIP NEXT - To advance to the next chapter or track,
press the NEXT button on the remote control or front
panel.
SKIP PREVIOUS - Press the PREV button on the
remote control or front panel to skip back to the
previous track.
Basic Disc Pla
y
back
DVD RECORDER OPERATION
1
1
2
1
2
3
