Chapter 1 Introduction
ank you for purchasing ASRock Rack D1622D4I / D1600D4I-2L2T motherboard,
a reliable motherboard produced under ASRock Rack’s consistently stringent quality
control. It delivers excellent performance with robust design conforming to ASRock
Rack’s commitment to quality and endurance.
1.1 Package Contents
• ASRock Rack D1622D4I / D1600D4I-2L2T Motherboard
(Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.02 cm x 17.02 cm)
• 1 x Mini SAS Cable (6G) (60cm)
• 1 x I/O Shield
• 1 x Screw for M.2 Socket
If any items are missing or appear damaged, contact your authorized dealer.
Because the motherboard specications and the BIOS soware might be updated, the con-
tent of this manual will be subject to change without notice. In case any modications of
this manual occur, the updated version will be available on ASRock Rack website without
further notice. You may nd the latest memory and CPU support lists on ASRock Rack
website as well. ASRock Rack’s Website: www.ASRockRack.com
If you require technical support related to this motherboard, please visit our website for
specic information about the model you are using.
http://www.asrockrack.com/support/

2 3
English
1.2 Specications
D1622D4I / D1600D4I-2L2T
MB Physical Status
Form Factor Mini-ITX
Dimension 6.7'' x 6.7'' (17.02 cm x 17.02 cm)
Processor System
CPU Supports Intel® Xeon® D 1600 Processor
Chipset Soc
System Memory
Capacity - 4x DDR4 DIMM slots
- Supports up to 128GB DDR4 ECC RDIMM
- Supports up to 64GB DDR4 ECC UDIMM
DIMM Sizes and
Type per DIMM
- ECC UDIMM: 4GB, 8GB, 16GB
- RDIMM: 4GB, 8GB, 16GB, 32GB
Frequency - ECC UDIMM: 1600, 1866, 2133MHz
- RDIMM: 1600, 1866, 2133MHz
Voltage 1.2V
Expansion Slot
PCIe 3.0 x16 1 slot
M.2 1 slot (PCIE, support form factor: 2280)
Storage
SATA Controller 6 x SATA3 6Gb/s (4 port from mini SAS HD, 2 ports SATA
7pin, SATA_4 supports DOM)
Ethernet
Interface 10000 / 1000 /100 Mbps
LAN Controller - 2 x RJ45 GLAN by Intel® i210
- 2 x RJ45 10GLAN by Intel® X557-AT2 (D1600D4I-2L2T only)
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
Management
BMC Controller ASPEED AST2500
IPMI Dedicated
GLAN 1 x Realtek RTL8211E for dedicated management GLAN
Features
- Watch Dog
- IPMI (Intelligent Platform Management Interface) v.2.0
- Virtual media over LAN function
- KVM over LAN function
Graphics
Controller ASPEED AST2500
VRAM DDR4 16MB

D1622D4I / D1600D4I-2L2T
2 3
English
Output Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
Rear Panel I/O
VGA Port 1 x D-Sub
USB 3.2 Gen1
Port 2
LAN Port
- RJ45: 2x 10GLAN(by Intel® X557-AT2 )(D1600D4I-2L2T only) +
2x GLAN(by Intel i210)
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
UID Button/UID
LED 1
Internal Connector
Auxiliary Panel
Header 1 (includes chassis intrusion, 2 front LAN LED, System LED)
SATA DOM 1
SATA DOM
Power 1
SATA Port 2
PSU_SMB1
Header 1
TPM Header 1
Speaker Header 1
Panel Header 1
MiniSAS HD
Connector 1 (SATA_0_3)
USB 2.0 Header 1 (supports 1 USB 2.0 port)
USB 3.2 Gen1
Header 1 (supports 2 USB 3.2 Gen1 ports)
Fan Header 4
ATX Power 1 x (4-pin) + 1 x (8-pin) support 12V DC-IN
SATA SGPIO 1
SATA Power
1 (for DC-IN mode)
*Caution: Misconnection between the ATXPWR1 and the HDDPWR1 con-
nectors may permanently damage the motherboard.
ClearCMOS 1 (short pad)
FanFail LED 4
System BIOS
BIOS Ty pe 16MB AMI UEFI Legal BIOS
BIOS Features
- Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8.0 Support
- ASRock Rack Instant Flash

4 5
English
Hardware Monitor
Temperature - CPU/PCH/DDR/LAN/Storage Temperature Sensing
- MB/Card side Temperature Sensing
Fan
- Fan Tachometer
- Fan Multi-Speed Control
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
1.05V_PCH, +BAT, 3VSB, 5VSB
Support OS
OS Linux®
- Red Hat Enterprise Linux Server 7.7 (64 bit) / 8.1 (64 bit)
- CentOs 7.7 (64 bit) / 8.1 (64 bit)
- SUSE Enterprise Linux Server 12 SP4 (64 bit) / 15 SP1 (64 it)
- Fedora 30 (64 bit)
- FreeBSD 11.3 (64 bit)
- Ubuntu 19.10 (64 bit)
* Please refer to our website for the latest OS support list.
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C
* For detailed product information, please visit our website: http://www.asrockrack.com
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN1&2 can wake up S5 under OS.
If you install Intel® LAN utility, this motherboard may fail Windows® Hardware Quality
Lab (WHQL) certication tests. If you install the drivers only, it will pass the WHQL tests.

D1622D4I / D1600D4I-2L2T
4 5
English
1.3 Unique Features
ASRock Instant Flash is a BIOS ash utility embedded in Flash ROM. is conve-
nient BIOS update tool allows you to update system BIOS without entering operating
systems rst like MS-DOS or Windows®. With this utility, you can press the <F6> key
during the POST or the <F2> key to enter into the BIOS setup menu to access ASRock
Rack Instant Flash. Just launch this tool and save the new BIOS le to your USB ash
drive, oppy disk or hard drive, then you can update your BIOS only in a few clicks
without preparing an additional oppy diskette or other complicated ash utility.
Please be noted that the USB ash drive or hard drive must use FAT32/16/12 le
system.

6 7
English
1.4 Motherboard Layout
CH0_A1 (64 bit, 288-pin module, Blue)DDR4,
CH0_A2 (64 bit, 288-pin module, White)DDR4,
17.0cm (6.7 in)
17.0cm (6.7 in)
5
7
6
FAN3
TPM1
AUX_PANEL1
SATAPWR1
1
HDLED RESET
PLED PWRBTN
PANEL1
1
SATA_4
CH1_B1 (64 bit, 288-pin module, Blue)DDR4,
CH1_B2 (64 bit, 288-pin module, White)DDR4,
8
1
PSU_SMB1
9
FAN1
10
BAT1
11
USB_1
SATA_5
FAN4
NUT80
M2_1
D1622D4I
D1600D4I-2L2T
PCIE7
PECI1
1
VGA1
USB 3.2
Gen1
T: USB2
B: USB1
IPMI
LAN
UID1
LAN1 LAN2
1
12
14
13
15
16
17
18
19
20
21
22
25
27
11
SPEAKER1
1
1
CLRMOS1
USB3_3_4
11
23
AST2500
FAN2
ATX12V1
SATA_0_3
1
CHASSIS_ID0
1
ME_RECOVERY1
1
SATA_SGPIO1
X557-AT2
LAN3 LAN4
1
LED_LAN3_4
23
24
1
26
ATXPWR1
HDDPWR1
4
(D1600D4I-2L2T only)(D1600D4I-2L2T only)
(D1600D4I-2L2T only)

D1622D4I / D1600D4I-2L2T
6 7
English
No. Description
1System Fan Connector (FAN2)
2PSU SMBus (PSU_SMB1)
3SATA Power Connector (HDDPWR1)*
4ATX 12V Power Connector (ATX12V1)
5ATX 4-PIN Power Connector (ATXPWR1(ATX 24pin-to-4pin))*
6System Fan Connector (FAN3)
72 x 288-pin DDR4 DIMM Slots (CH0_A1, CH1_B1)
82 x 288-pin DDR4 DIMM Slots (CH0_A2, CH1_B2)
9System Connector (FAN1)
10 Speaker Header (SPEAKER1)
11 Clear CMOS Pad (CLRMOS1)
12 TPM Header (TPM1)
13 Front LAN LED Connector (LED_LAN3_4)
14 Auxiliary Panel Header (AUX_PANEL1)
15 SATA DOM Power Connector (SATAPWR1)
16 SATA3 DOM Connector (SATA_4)
17 SATA3 Connector (SATA_5)
18 USB 3.2 Gen1 Header (USB3_3_4)
19 System Panel Header (PANEL1)
20 USB 2.0 Header (USB_1)
21 System Fan Connector (FAN4)
22 Mini SAS HD Connector (SATA_0_3)
23 ME Recovery Jumper (ME_RECOVERY1)
24 Chassis ID Jumper (CHASSIS_ID0)
25 SATA SGPIO Connector (SATA_SGPIO1)
26 M.2 Socket (M2_1) (Type 2280)
27 CPU PECI Mode Jumper (PECI1)
*Caution: Misconnection between the ATXPWR1 and the HDDPWR1 connectors may permanently damage the
motherboard.

8 9
English
1.5 Onboard LED Indicators
CH0_A1 (64 bit, 288-pin module, Blue)DDR4,
CH0_A2 (64 bit, 288-pin module, White)DDR4,
FAN3
CH1_B1 (64 bit, 288-pin module, Blue)DDR4,
CH1_B2 (64 bit, 288-pin module, White)DDR4,
1
FAN1
BAT1
FAN4
NUT80
M2_1
11
SPEAKER1
CLRMOS1
AST2500
FAN2
1
1
1
X557-AT2
1
2
3
4
65
No. Item Status Description
1FAN_LED2 Amber FAN2 failed
2FAN_LED3 Amber FAN3 failed
3FAN_LED1 Amber FAN1 failed
4FAN_LED4 Amber FAN4 failed
5 SB_PWR1 Green STB PWR ready
6BMC_LED1 Green BMC heartbeat LED

D1622D4I / D1600D4I-2L2T
8 9
English
1.6 I/O Panel
25
3
6
4
1
7 8
No. Description No. Description
1 Dedicated IPMI LAN Port* 5 LAN RJ-45 Port (LAN1)*
2 USB 3.2 Gen1 Ports (USB3_1_2) 6 10G LAN RJ-45 Port (LAN4)**
(D1600D4I-2L2T only)
3 UID Switch/LED (UID1) 7 10G LAN RJ-45 Port (LAN3)**
(D1600D4I-2L2T only)
4 LAN RJ-45 Port (LAN2)* 8 VGA Port (VGA1)
LAN Port LED Indications
*ere are two LED next to the LAN port. Please refer to the table below for the LAN port
LED indications.
Dedicated IPMI LAN Port LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10M bps connection
Blinking Yellow Data Activity Yellow 100M bps connection
On Link Green 1G bps connection
ACT/LINK LED
SPEED LED
LAN Port

10 11
English
**ere are two LEDs on each LAN port. Please refer to the table below for the LAN port
LED indications.
1G LAN Port (LAN1, LAN2) LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps connection or
no link
Blinking Green Data Activity Yellow 100Mbps connection
On Link Green 1Gbps connection
10G LAN Port (LAN1, LAN2) LED Indications (D1600D4I-2L2T only)
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 100Mbps connection or
no link
Blinking Green Data Activity Yellow 1Gbps connection
On Link Green 10Gbps connection
ACT/LINK LED
SPEED LED
ACT/LINK LED
SPEED LED

D1622D4I / D1600D4I-2L2T
10 11
English
1.7 Block Diagram
5 5
4 4
3 3
2 2
1 1
D D C C B B A A
2*rear
LPC BUS
RGMII
PCIe x 16 Gen3
CASE OPEN
D1600D4I-2L2T
Channel B
Intel Processor
SIO
Nuvoton NCT5567
Hewitt Lake –DE NS D-16XX
PCI-E X16 SLOT7
128-bit Dual-Channel Memory x 4 Slots
DDR4 1866/2133/2400
Channel A
SOC (system on chip)
X 16
support RD IMM UDIMMs DRAM RDIMM: 128GB (32GB Per DIMM) UDIMM: 64GB (16GB Per DIMM)
NCSI
PCIE x1
Realtek PHY 8211E
M.2 (2280)
USB2.0
RJ45
CPU Fan x 1
TPM
USB3.0
1*AST2500 ; 1*ASM1074 for U3 HUB
VGA
ASPEEND
AST2500
600MB/S
DDR4 1866/2133/2400 DDR4 1866/2133/2400 DDR4 1866/2133/2400
SATA_5 SATA_4 support SATA DOM
Header
3x system Fan 2 front 1 rear
FAN x 4
D-sub
SPI
SPI FLASH
32 Mb for LAN0
600MB/S
No support NGFF card
SATA_0_3 Mini-SAS HD
TR1
X 4
INTEL LAN X557-AT2 (port3/4)
KR0
PCIe x 4 Gen3
USB3.0 1*ASM1074 for U3 HUB USB3.0 2*front U3
1*front U2
Intel I210 (port1)
PCIE x1
Intel I210 (port2)
PCIE x1
SPI
SPI FLASH
32 Mb for LAN1
BIOS SWITCH
SPI FLASH
128Mb
SPI
Size
Project Name
Rev
Date: Sheet of
Title :
Engineer:
C
298Wednesday, December 25, 2019
02-System block
R1.01
D1600D4I-2L2T
Rex-Chang
<Variant Name>
Size
Project Name
Rev
Date: Sheet of
Title :
Engineer:
C
298Wednesday, December 25, 2019
02-System block
R1.01
D1600D4I-2L2T
Rex-Chang
<Variant Name>
Size
Project Name
Rev
Date: Sheet of
Title :
Engineer:
C
298Wednesday, December 25, 2019
02-System block
R1.01
D1600D4I-2L2T
Rex-Chang
<Variant Name>

12 13
English
5 5
4 4
3 3
2 2
1 1
D D C C B B A A
2*rear
LPC BUS
RGMII
PCIe x 16 Gen3
CASE OPEN
D1622D4I
Channel B
Intel Processor
SIO
Nuvoton NCT5567
Hewitt Lake –DE NS D-16XX
PCI-E X16 SLOT7 128-bit Dual-Channel Memory x 4 Slots
DDR4 1866/2133/2400
Channel A
SOC (system on chip)
X 16
support RDIMM UDIMMs DRAM RDIMM: 128GB (32GB Per DIMM) UDIMM: 64GB (16GB Per DIMM)
NCSI
PCIE x1
Realtek PHY 8211E
M.2 (2280)
USB2.0
RJ45
CPU Fan x 1
TPM
USB3.0
1*AST2500 ; 1*ASM1074 for U3 HUB
VGA
ASPEEND
AST2500
600MB/S
DDR4 1866/2133/2400 DDR4 1866/2133/2400 DDR4 1866/2133/2400
SATA_4 support SATA DOM
Header
3x system Fan 2 front 1 rear
FAN x 4
D-sub
X1
No support NGFF card
SATA_0_3 Mini-SAS HD
X 4
PCIe x 4 Gen3
USB3.0 1*ASM1074 for U3 HUB USB3.0 2*front U3
1*front U2
Intel I210 (port2)
PCIE x1
Intel I210 (port1)
PCIE x1
SPI
SPI FLASH
32 MB
BIOS SWITCH
SPI FLASH
16MB
SPI
SATA X 1
SWITCH
SATA_5 share M2
Size
Project Name
Rev
Date: Sheet of
Title :
Engineer:
C
2 98Friday, September 04, 2020
02-System block
R1.02
D1600D4I-2L2T
Rex-Chang
<Variant Name>
Size
Project Name
Rev
Date: Sheet of
Title :
Engineer:
C
2 98Friday, September 04, 2020
02-System block
R1.02
D1600D4I-2L2T
Rex-Chang
<Variant Name>
Size
Project Name
Rev
Date: Sheet of
Title :
Engineer:
C
2 98Friday, September 04, 2020
02-System block
R1.02
D1600D4I-2L2T
Rex-Chang
<Variant Name>

D1622D4I / D1600D4I-2L2T
12 13
English
Chapter 2 Installation
This is a Mini-ITX form factor (6.7'' x 6.7'', 17.0 cm x 17.0 cm)motherboard. Before
you install the motherboard, study the conguration of your chassis to ensure that the
motherboard ts into it.
2.1 Screw Holes
Place screws into the holes indicated by circles to secure the motherboard to the chassis.
2.2 Pre-installation Precautions
Take note of the following precautions before you install motherboard components or
change any motherboard settings.
1. Unplug the power cord from the wall socket before touching any components.
2. To avoid damaging the motherboard’s components due to static electricity, NEVER
place your motherboard directly on the carpet or the like. Also remember to use a
grounded wrist strap or touch a safety grounded object before you handle the compo-
nents.
3. Hold components by the edges and do not touch the ICs.
4. Whenever you uninstall any component, place it on a grounded anti-static pad or in
the bag that comes with the component.
5. When placing screws into the screw holes to secure the motherboard to the chassis,
please do not over-tighten the screws! Doing so may damage the motherboard.
Make sure to unplug the power cord before installing or removing the motherboard. Failure
to do so may cause physical injuries to you and damages to motherboard components.
Do not over-tighten the screws! Doing so may damage the motherboard.
Before you install or remove any component, ensure that the power is switched o or the
power cord is detached from the power supply. Failure to do so may cause severe damage to
the motherboard, peripherals, and/or components.

14 15
English
2.3 Installation of Memory Modules (DIMM)
is motherboard provides four 288-pin DDR4 (Double Data Rate 4) DIMM slots, and
supports Dual Channel Memory Technology.
Dual Channel Memory Conguration
Priority CH0_A1
(Blue)
CH0_A2
(White)
CH1_B1
(Blue)
CH1_B2
(White)
1Populated Populated
2Populated Populated Populated Populated
*Since installing three memory modules is NOT supported on this motherboard, we suggest not using
this conguration.
1. For dual channel conguration, you always need to install identical (the same brand,
speed, size and chip-type) DDR4 DIMM pairs.
2. It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4 slot;
otherwise, this motherboard and DIMM may be damaged.
3. Please install the memory module on CH0_A1 for the rst priority.
4. To activate Dual Channel Memory Technology, please follow the “Dual Channel Memory
Conguration” table below.
e DIMM only ts in one correct orientation. It will cause permanent damage to the
motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.
