English
1
H610TM-ITX
Motherboard Layout
14
Audio
CODEC
HDLED RESET
PLED PWRBTN
PANEL1
1
VGA1
17
DC Jack
HDMI1
HDMI2
Super
I/O
BIOS
ROM
CPU_FAN1
9
H610TM-ITX
RoHS
19 18
DDR4_B1
DDR4_A1
SATA_1
46
1
USB2_1_2
LVDS1
BKT_PWR1
1
BLT_VOL1
1
15
1
13
SPK_OUT1
1
USB 3.2 Gen2
T: USB3_3
B: USB_TC_1
USB 2.0
T: USB_3
B: USB_4
RJ-45
Line out
Mic In
ATX_PWR1
1
HD_AUDIO1
20
11
8
SATA_2
1
1
1
CLR_MOS1
TH1
25
PNL_PWR1
1
10
Intel
H610
1
SATAPWR1
21
M.2 WiFi
M.2 SSD
M2_1_CT2
M2_1_CT1
NUT1
1
CI1
16
12
PANEL_SW1
1
DMIC1
1
3
SATAPWR2
1
USB3_1_2
7
Top Side View

English
2
M.2 SSD
Back Side View

English
3
H610TM-ITX
No. Description
1 4 pin 19V Power Connector (ATX_PWR1)
2 SATA Power Connector (SATAPWR2)
3 SATA Power Connector (SATAPWR1)
4 SATA3 Connector (SATA_1)
5 SATA3 Connector (SATA_2)
6 Clear CMOS Jumper (CLR_MOS1)
7 USB 3.2 Gen1 Header (USB3_1_2)
8 USB 2.0 Header (USB2_1_2)
9 FPD Brightness Header (BLT_VOL1)
10 Backlight Inverter Voltage Selection Header (BKT_PWR1)
11 Panel Voltage Selection Header (PNL_PWR1)
12 Panel O Header (PANEL_SW1)
13 LVDS Connector (LVDS1)
14 2 x 260-pin DDR4 SO-DIMM Slots (DDR4_A1, DDR4_B1)
15 CPU Fan Connector (CPU_FAN1)
16 Chassis Intrusion Header (CI1)
17 Digital MIC Header (DMIC1)
18 System Panel Header (PANEL1)
19 Internal Speaker Header (SPK_OUT1)
20 Front Panel Audio Header (HD_AUDIO1)
21 ermal Sensor Header (TH1)

English
4
I/O Panel
No. Description No. Description
1 DC Jack** 6 LAN RJ-45 Port*
2HDMI Port (HDMI1) 7 USB 2.0 Ports (USB_3_4)
3D-Sub Port 8Microphone (Pink)
4 USB 3.2 Gen2 Type-A Port (USB3_3) 9 Line out (Lime)
5 USB 3.2 Gen2 Type-C Port (USB_TC_1)
*ere are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps connection
Blinking Data Activity Green 100Mbps connection
On Link Green 1Gbps connection
** Please use a 19V power adapter for the DC jack. is jack accepts dual barrel plugs with an inner diameter of 2.5
mm and an outer diameter of 5.5 mm, where the inner contact is +19 (±10%) DC and the shell is (centre positive).
DELTA DELTA-ADP-150TB-150W/19V
HP HP-TBC-BA52-150W/19V
FSP FSP-FSP150-ABAN1-150W/19V
DELL FA130PE1-00-130W/19.5V
DELL LA90PE0-01-90W/19.5V
DELTA DELTA-ADP-180TB-180W/19V
FSP FSP-FSP180-ABBN3-180W/19V
is motherboard is available with support for either 4-pin ATX 19V power or DC-in power supplies. Please do
not use two kinds of power supplies at the same time! Doing so may damage the motherboard components and
devices. When you use the DC-in power adapter, please use the onboard SATA power connector to get the power
for HDDs.
ACT/LINK LED
SPEED LED
LAN Port
982 64
5
31 7
Chapter 1 Introduction
ank you for purchasing H610TM-ITX motherboard. In this documentation,
Chapter 1 and 2 contains the introduction of the motherboard and step-by-step
installation guides.
1.1 Package Contents
• H610TM-ITX Motherboard (in Mini-ITX Form Factor)
• 1 x in-Mini ITX I/O Shield (Optional)
• 1 x Mini ITX I/O Shield (Optional)
• 1 x Serial ATA (SATA) Data Cable (Optional)
• 1 x SATA Power Cable (Optional)
• 3 x Screws for M.2 Sockets (M2*2) (Optional)
• 1 x Stando for M.2 Socket (Optional)

English
5
H610TM-ITX
Chapter 1 Introduction
ank you for purchasing H610TM-ITX motherboard. In this documentation,
Chapter 1 and 2 contains the introduction of the motherboard and step-by-step
installation guides.
1.1 Package Contents
• H610TM-ITX Motherboard (in Mini-ITX Form Factor)
• 1 x in-Mini ITX I/O Shield (Optional)
• 1 x Mini ITX I/O Shield (Optional)
• 1 x Serial ATA (SATA) Data Cable (Optional)
• 1 x SATA Power Cable (Optional)
• 3 x Screws for M.2 Sockets (M2*2) (Optional)
• 1 x Stando for M.2 Socket (Optional)
Because the motherboard specications and the BIOS soware might be updated, the
content of this documentation will be subject to change without notice.

English
6
1.2 Specications
Platform • in Mini-ITX Form Factor (Compatible with Mini-ITX)
• Solid Capacitor design
CPU • Supports 13th Gen & 12th Gen Intel® CoreTM Processors
(LGA1700)
• 4 Power Phase design
• Supports Intel® Hybrid Technology
• Supports Intel® Turbo Boost Max 3.0 Technology
Chipset • Intel® H610
Memory • Dual Channel DDR4 Memory Technology
• 2 x DDR4 SO-DIMM Slots
• Supports DDR4 non-ECC, un-buered memory up to 3200*
* Please refer to Memory Support List on ASRock’s website for
more information. (http://www.asrock.com/)
• Max. capacity of system memory: 64GB
• Supports Intel® Extreme Memory Prole (XMP) 2.0
Expansion
Slot • 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module
Graphics • Intel® UHD Graphics Built-in Visuals and the VGA outputs
can be supported only with processors which are GPU
integrated.
• Intel® XeGraphics Architecture (Gen 12)
• Four graphics output options: 2 x HDMI, 1 x LVDS, 1 x D-Sub
ports
• Supports 2 x HDMI 2.1 TMDS Compatible with max.
resolution up to 4K x 2K (4096x2160) @ 60Hz
HDMI x 1 port (Rear)
HDMI x 1 port (Internal)
* (Optional) DisplayPort 1.4 with DSC (compressed) max.
resolution up to 8K (7680x4320) @ 60Hz / 5K (5120x3200) @
120Hz

English
7
H610TM-ITX
• Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
• Supports LVDS with max. resolution up to 1920x1080 @ 60Hz
• Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible and
DisplayPort 1.4 Ports
Audio • Realtek ALC269 Audio Codec
• 1 x MIC IN
• 1 x Line out
LAN • PCIE x1 Gigabit LAN 10/100/1000 Mb/s
• Realtek RTL8111H
• Supports Wake-On-LAN
• Supports Lightning/ESD Protection
• Supports Energy Ecient Ethernet 802.3az
• Supports PXE
I/O • 1 x DC Jack (Compatible with the 19V power adapter)
• 1 x D-Sub Port
* (Optional) 1 x COM Port
• 2 x HDMI Ports: HDMI1 (Rear), HDMI2 (Internal)
* (Optional) 1 x DisplayPort 1.4
• 1 x USB 3.2 Gen2 Type-A Port (Supports ESD Protection)
• 1 x USB 3.2 Gen2 Type-C Port (Supports ESD Protection)
* (Optional) 2 x USB 3.2 Gen2 Type-A Ports (Supports ESD
Protection)
• 2 x USB 2.0 Ports (Support ESD Protection)
• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
• HD Audio Jacks: Line out / Microphone
Storage • 2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot
Plug
• 1 x Blazing M.2 Socket (M2_1), supports M Key type
2260/2280 M.2 PCI Express module up to Gen5 x4
* Supports NVMe SSD as boot disks
• 1 x M.2 Socket (M2_3), supports M Key type 2280 M.2 SATA3
6.0 Gb/s module

English
8
Connector • 1 x Chassis Intrusion Header
• 1 x Panel Voltage Selection Header
• 1 x Backlight Inverter Voltage Selection Header
• 1 x FPD Brightness Header
• 1 x Panel O Header
• 1 x LVDS Connector
• 1 x CPU Fan Connector (4-pin)
* e CPU Fan Connector supports the CPU fan of maximum 1A
(12W) fan power.
• 1 x 4 pin 19V Power Connector (2-Pin)
• 1 x ermal Sensor Header
• 1 x Front Panel Audio Connector
• 1 x Internal Speaker Header (4-Pin)
• 1 x Digital MIC Header
• 2 x SATA Power Connectors
• 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD
Protection)
• 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
(Supports ESD Protection)
BIOS
Feature
• AMI UEFI Legal BIOS with GUI support
• ACPI 6.0 Compliant wake up events
• SMBIOS 2.7 Support
Hardware
Monitor
• CPU Temperature Sensing
• CPU Fan Tachometer
• CPU Quiet Fan (Auto adjust chassis fan speed by CPU
temperature)
• CPU Fan Multi-Speed Control
• CASE OPEN detection
• Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
OS • Microso® Windows® 10 64-bit / 11 64-bit
Power • 1 x DC Jack (Supports 19V DC Power Adapters)

English
9
H610TM-ITX
Certica-
tions
• FCC, CE
• ErP/EuP ready (ErP/EuP ready power supply is required)
Please realize that there is a certain risk involved with overclocking, including adjusting
the setting in the BIOS, applying Untied Overclocking Technology, or using third-party
overclocking tools. Overclocking may aect your system’s stability, or even cause damage to
the components and devices of your system. It should be done at your own risk and expense.
We are not responsible for possible damage caused by overclocking.

English
10
is is a in Mini-ITX form factor motherboard. Before you install the
motherboard, study the conguration of your chassis to ensure that the
motherboard ts into it.
Pre-installation Precautions
Take note of the following precautions before you install motherboard components
or change any motherboard settings.
• Make sure to unplug the power cord before installing or removing the motherboard.
Failure to do so may cause physical injuries to you and damages to motherboard
components.
• In order to avoid damage from static electricity to the motherboard’s components,
NEVER place your motherboard directly on a carpet. Also remember to use a grounded
wrist strap or touch a safety grounded object before you handle the components.
• Hold components by the edges and do not touch the ICs.
• Whenever you uninstall any components, place them on a grounded anti-static pad or
in the bag that comes with the components.
• When placing screws to secure the motherboard to the chassis, please do not over-
tighten the screws! Doing so may damage the motherboard.
Chapter 2 Installation

English
11
H610TM-ITX
2.1 Installing the CPU
1. Before you insert the 1200-Pin CPU into the socket, please check if the PnP cap is on the
socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not
force to insert the CPU into the socket if above situation is found. Otherwise, the CPU
will be seriously damaged.
2. Unplug all power cables before installing the CPU.
1
2
A
B

English
12
4
5
3

English
13
H610TM-ITX
Please save and replace the cover if the processor is removed. e cover must be placed if
you wish to return the motherboard for aer service.

English
14
2.2 Installing the CPU Fan and Heatsink
1 2
CPU_FAN

English
15
H610TM-ITX
2.3 Installing Memory Modules (SO-DIMM)
is motherboard provides two 260-pin DDR4 (Double Data Rate 4) SO-DIMM
slots.
It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4 slot;
otherwise, this motherboard and SO-DIMM may be damaged.
e SO-DIMM only ts in one correct orientation. It will cause permanent damage
to the motherboard and the DIMM if you force the DIMM into the slot at incorrect
orientation.

English
16
2.4 Jumpers Setup
e illustration shows how jumpers are setup. When the jumper cap is placed on
the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is
“Open”.
Clear CMOS Jumper
(CLR_MOS1)
(see p.6, No. 6)
CLR_MOS1 allows you to clear the data in CMOS. To clear and reset the system
parameters to default setup, please turn o the computer and unplug the power
cord from the power supply. Aer waiting for 15 seconds, use a jumper cap to
short the pins on CLR_MOS1 for 5 seconds. However, please do not clear the
CMOS right aer you update the BIOS. If you need to clear the CMOS when you
just nish updating the BIOS, you must boot up the system rst, and then shut it
down before you do the clear-CMOS action. Please be noted that the password,
date, time, and user default prole will be cleared only if the CMOS battery is
removed. Please remember toremove the jumper cap aer clearing the CMOS.
2-pin Jumper
If you clear the CMOS, the case open may be detected. Please adjust the BIOS option
“Clear Status” to clear the record of previous chassis intrusion status.

English
17
H610TM-ITX
Backlight Inverter Voltage
Selection Header
(3-pin BKT_PWR1)
(see p.6, No. 10)
1-2 : +19V
2-3 : +12V
Panel Voltage Selection
Header
(5-pin PNL_PWR1)
(see p.6, No. 11)
1-2 : +3V
2-3 : +5V
4-5 : +12V
1
Warning:
If selected Backlight Power or Panel Power is higher than panel's spec, it
may damage the panel.

English
18
2.5 Onboard Headers and Connectors
System Panel Header
(9-pin PANEL1)
(see p.6, No. 18)
Connect the power
button, reset button and
system status indicator on
the chassis to this header
according to the pin
assignments below. Note
the positive and negative
pins before connecting
the cables.
Internal Speaker Header
(4-pin SPK_OUT1)
(see p.6, No. 19)
Please connect the chassis
speaker to this header.
GND
RESET#
PWRBTN#
PLED-
PLED+
GND
HDLED-
HDLED+
1
GND
Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these
headers and connectors. Placing jumper caps over the headers and connectors will cause
permanent damage to the motherboard.
PWRBTN (Power Button):
Connect to the power button on the chassis front panel. You may congure the way to turn
o your system using the power button.
RESET (Reset Button):
Connect to the reset button on the chassis front panel. Press the reset button to restart the
computer if the computer freezes and fails to perform a normal restart.
PLED (System Power LED):
Connect to the power status indicator on the chassis front panel. e LED is on when the
system is operating. e LED keeps blinking when the system is in S1/S3 sleep state. e
LED is o when the system is in S4 sleep state or powered o (S5).
HDLED (Hard Drive Activity LED):
Connect to the hard drive activity LED on the chassis front panel. e LED is on when the
hard drive is reading or writing data.
e front panel design may dier by chassis. A front panel module mainly consists of power
button, reset button, power LED, hard drive activity LED, speaker and etc. When connect-
ing your chassis front panel module to this header, make sure the wire assignments and the
pin assignments are matched correctly.
R + - - +
L
1
