ASROCK IMB-1313 User manual

1
IMB-1313
IMB-X1313
User Manual
Version 1.0
Published August 2020
Copyright©2020 ASRockInd INC. All rights reserved.

2
Version 1.0
Published August 2020
Copyright©2020 ASRockInd INC. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRockInd Inc.
Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identication or explanation and to the owners’ benet, without intent to
infringe.
Disclaimer:
Specications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRockInd. ASRockInd assumes no responsibility
for any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRockInd does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or tness for a particular
purpose.
In no event shall ASRockInd, its directors, ocers, employees, or agents be liable
for any indirect, special, incidental, or consequential damages (including damages
for loss of prots, loss of business, loss of data, interruption of business and the
like), even if ASRockInd has been advised of the possibility of such damages arising
from any defect or error in the documentation or product.
is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate”
ASRockInd Website: http://www.asrockind.com

3
e terms HDMI®and HDMI High-Denition Multimedia Interface, and the HDMI
logo are trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries.
CAUTION:
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

4
Contents
1 Introduction ....................................................... 5
1.1 Package Contents ......................................................... 5
1.2 Specications................................................................. 6
1.3 Motherboard Layout....................................................... 9
1.4 I/O Panel........................................................................ 11
2 Installation ......................................................... 13
2.1 Screw Holes................................................................... 13
2.2 Pre-installation Precautions ........................................... 13
2.3 Installation of Memory Modules (DIMM) ........................ 14
2.4 Expansion Slots ............................................................ 16
2.5 Jumpers Setup............................................................... 18
2.6 Onboard Headers and Connectors................................ 21
2.7 Installation of ROM Socket ............................................ 26
3 UEFI SETUP UTILITY......................................... 27
3.1 Introduction .................................................................... 27
3.1.1 UEFI Menu Bar .................................................... 27
3.1.2 Navigation Keys ................................................... 28
3.2 Main Screen................................................................... 28
3.3 Advanced Screen........................................................... 29
3.3.1 CPU Conguration ............................................... 30
3.3.2 Chipset Conguration........................................... 31
3.3.3 Storage Conguration .......................................... 34
3.3.4 Super IO Conguration ........................................ 35
3.3.5 AMT Conguration ............................................... 36
3.3.6 ACPI Conguration............................................... 38
3.3.7 USB Conguration ............................................... 39
3.3.8 Trusted Computing............................................... 40
3.4 Hardware Health Event Monitoring Screen ................... 41
3.5 Security Screen ............................................................. 42
3.6 Boot Screen ................................................................... 43
3.7 Exit Screen .................................................................... 45
4 Software Support .............................................. 46
4.1 Install Operating System................................................ 46
4.2 Support CD Information ................................................. 46
4.2.1 Running Support CD............................................ 46
4.2.2 Drivers Menu........................................................ 46
4.2.3 Utilities Menu........................................................ 46
4.2.4 Contact Information.............................................. 46

5
Chapter 1: Introduction
Thank you for purchasing ASRockInd IMB-1313 / IMB-X1313 motherboard, a reli-
able motherboard produced under ASRockInd’s consistently stringent quality con-
trol. It delivers excellent performance with robust design conforming to ASRockInd’s
commitment to quality and endurance.
In this manual, chapter 1 and 2 contain introduction of the motherboard and step-
by-step guide to the hardware installation. Chapter 3 and 4 contain the conguration
guide to BIOS setup and information of the Support CD.
Because the motherboard specications and the BIOS software might be
updated, the content of this manual will be subject to change without no-
tice. In case any modications of this manual occur, the updated version
will be available on ASRockInd website without further notice. You may
nd the latest VGA cards and CPU support lists on ASRockInd website
as well. ASRockInd website http://www.asrockind.com
If you require technical support related to this motherboard, please visit
our website for specic information about the model you are using.
www.asrockind.com/support/index.asp
1.1 Package Contents
ASRockInd IMB-1313 / IMB-X1313 Motherboard (Micro ATX (9.6-in x 9.6-in))
ASRockInd IMB-1313 / IMB-X1313 Driver CD
ASRockInd IMB-1313 / IMB-X1313 Jumper setting instruction
1 x I/O Panel Shield

6
1.2 Specications
Form
Factor Dimensions Micro ATX (9.6-in x 9.6-in)
Processor
System
CPU Intel®10th Gen (Cometlake-S) CoreTM
Processors, up to 125 W
Chipset IMB1313: Intel®Q470E
IMB-X1313: Intel®W480E
Socket LGA1200
BIOS AMI SPI 256 Mbit
Memory
Technology
Dual Channel DDR4 2933/2666/2400 MHz
- Intel®CoreTM i9/i7 CPUs support DDR4 up to
2933 MHz
- Intel®CoreTM i5/i3 CPUs support DDR4 up to
2666 MHz
- Intel®Pentium®/Celeron®CPU support DDR4
up to 2400 MHz
Capacity
128GB*
* Intel® Core i9/i7/i5 CPUs support up to 128GB
(32GB per DIMM)
Intel®Core i3/Pentium®/Celeron®CPUs support
up to 64GB (16GB per DIMM)
Socket 4 x 288-pin Long-DIMM
Graphics
Controller Intel® UHD Graphics
HDMI HDMI 2.0a
Max resolution up to 4096x2160 @60Hz
DisplayPort DisplayPort 1.2, DP++
Max resolution up to 4096x2160@60Hz
VGA Max resolution up to 1920x1200@60Hz
LVDS Dual channel 24 bit up to 1920 x 1200@60Hz
eDP eDP 1.4 Max resolution up to 4096x2304@60Hz
DVI-D N/A
MultiDisplay Triple Display
Expansion
Slot
PCIe
2 x PCIe Gen3 Slots (PCIE1/PCIE2: single at
x16 (PCIE1); dual at x8 (PCIE1) / x8 (PCIE3))
(PCIE1: Support riser card x8/x8, x8/x4/x4)
2 x PCIe x4 (Gen3)
PCI N/A
Mini-PCIe N/A

7
M.2
1 x M.2 (Key E, 2230) with PCIe x1, USB 2.0
and CNVio for Wireless
1 x M.2 (Key B, 3042/3052) with PCIe x1/
USB 3.0/USB2.0 and SIMo for 4G/5G
SIM Socket 1 x SIM socket connected to M.2 key B
Audio Interface Realtek ALC887 HD, High Denition Audio.
Line-In/Line-Out/Mic-In
Ethernet
Controller/
Speed
LAN1: Intel®I225LM with 10/100/1000/2500
Mbps
LAN2: Intel®I219LM with 10/100/1000
Mbps, support AMT/vPro
Connector 2 x RJ-45
Rear I/O
HDMI 1 x HDMI 2.0a
DisplayPort 1 x DP1.2
VGA 1
DVI N/A
Ethernet 1 x 1 Gigabit LAN, 1 x 2.5 Gigabit LAN
USB 4 x USB 3.2 (Gen2), 2 x USB2.0
Audio 3 (Line-In, Line-Out, Mic-In)
COM 2 x COM (RS-232/422/485)
PS2 1
Internal
Connector
USB
4 x USB 3.2 Gen1 (2 x USB 3.2 Gen1
header)
2 x USB 2.0 (1 x 2.54 pitch header)
COM 4 x COM (RS-232)
Parallel 1 (shared with GPIO)
GPIO 8 x GPI, 8 x GPO (shared with LPT header)
TPM TPM 2.0 onboard
LVDS 1
eDP 1 (BOM Option support)
VGA N/A
SATA PWR
Output N/A
Speaker
Header 1

8
Storage
M.2
1 x M.2 (Key M, 2242/2260/2280) with
SATA and PCIe x4 f or SSD
* Shared with SATA3_5/SATA3_6 Ports
- When using M.2 PCIe x4 S SD, both
SATA3_5 and SATA_6 Ports are disabled
- When using M.2 SA TA SSD, only
SATA3_5 Port is disabled, and SATA3_6
Port is available
mSATA N/A
SATA 8 x SATA3 (6Gb/s)
eMMC N/A
Watchdog
Timer
Output From super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec
Power
Requirements
Input PWR ATX PWR (24+8-pin)
Power On
AT/ATX Supported
AT: Directly PWR on as Power input ready
ATX: Press Button to PWR on after Power
input ready
Environment
Operating
Temp 0ºC ~ 60ºC
Storage
Temp -40°C ~ 85°C
Operating
Humidity 5% ~ 90%
Storage
Humidity 5% ~ 90%

9
1.3 Motherboard Layout

10
1 : Panel Power Select (PNL_PWR1)
2 : Backlight Control Level (BLT_PWM1) (CON_LBKLT_CTL)
3 : LVDS Panel Connector
4 : Backlight & Amp Volume Control (BLT_VOL1)
5 : Inverter Power Control Wafer (BLT_PWR1)
6 : LVDSBL1
7 : Backlight Power Select (LCD_BLT_VCC) (BKT_PWR1)
8 : LVDSBL2
9 : LGA1200 Socket
10 : M.2 Key-M Socket (M2_M1)
11 : 4-Pin CPU FAN Connector (+12V) (CPU_FAN1)
12 : 4-Pin Chassis FAN Connector (+12V) (CHA_FAN1)
13 : 24-pin ATX Power Input Connector
14 : USB 3.2 Gen1 Header ( USB3_5_6 )
1 5 : ATX/AT Mode Jumper (SIO_AT1)
16 : Chassis Intrusion Headers (CI1, CI2)
17 : 4-Pin Chassis FAN Connector (+12V) (CHA_FAN3)
18 : M.2 Key-E Socket (M2_E1)
19 : Printer Port / GPIO Header (LPT_GPIO1)
20 : Digital Input / Output Power Select (JGPIO_SET1)
21 : MCU Connector (MCU_CON1)
22 : DACC1
23 : System Panel Header
24 : Digital Input / Output Power Select (JGPIOPWR) (JGPIO_PWR1)
25 : Clear CMOS Headers (CLRMOS1, CLRMOS2)
26 : COM Port Headers (COM3, 4, 5, 6) (RS232)
27 : PWR Loss Header (PWR_LOSS1)
28 : COM Port Pin9 PWR Setting Jumpers
PWR_COM3 (For COM Port3)
PWR_COM4 (For COM Port4)
PWR_COM5 (For COM Port5)
PWR_COM6 (For COM Port6)
29 : SATA3 Connectors (SATA3_1~8)
30 : USB 3.2 Gen1 Header ( USB3_7_8 )
31 : LPC Header (LPC1)
32 : SMBUS_TEST1
33 : USB 2.0 Header ( USB2_9_10 )
34 : Buzzer (BUZZ2)
35 : COM Port Pin9 PWR Setting Jumper
PWR_COM2 (For COM Port2)
36 : SPDIF Header
37 : Front Panel Audio Header
38 : 3W Audio Output Wafer
39 : M.2 Key-B Socket (M2_B1)
40 : 4-Pin Chassis FAN Connector (+12V) (CHA_FAN2)
41 : LAN LED Connercors (LAN_LED1, LAN_LED2)

11
1.4 I/O Panel
1 USB 2.0 Ports (USB11_12)
2 COM Port (COM2) (RS232/422/485)*
3 COM Port (COM1) (RS232/422/485)*
4 LAN RJ-45 Port (LAN1)**
5 LAN RJ-45 Port (LAN2)***
6 Line In (Light Blue)
7 Line out (Lime)
8 Microphone (Pink)
9 USB 3.2 Gen2 Ports (USB3_3_4)
10 USB 3.2 Gen2 Ports (USB3_1_2)
11 D-Sub Port (VGA1)
12 DisplayPort (DP1)
13 HDMI Port (HDMI1)
14 PS/2 Keyboard/Mouse Port
PIN RS232 RS422 RS485
1 DCD TX- RTX-
2 RXD RX+ N/A
3 TXD TX+ RTX+
4 DTR RX- N/A
5GND GND GND
6 DSR N/A N/A
7 RTS N/A N/A
8 CTS N/A N/A
9 PWR PWR PWR
* This motherboard supports RS232/422/485 on COM1, 2 ports. Please refer to below table for
the pin denition. In addition, COM1, 2 ports (RS232/422/485) can be adjusted in BIOS setup
utility > Advanced Screen > Super IO Conguration. You may refer to page 35 for details.
COM1, 2 Ports Pin Denition
** There are two LED next to the LAN port. Please refer to the table below for the LAN port LED
indications.
LAN Port LED Indications
Activity/Link LED SPEED LED
Status Description Status Description
O󰀨 No Link O󰀨 10Mbps connection
Blinking Data Activity Orange 100Mbps/1Gbps connection
On Link Green 2.5Gbps connection
ACT/LINK
LED
SPEED
LED
LAN Port

12
*** There are two LED next to the LAN port. Please refer to the table below for the LAN port LED
indications.
LAN Port LED Indications
Activity/Link LED SPEED LED
Status Description Status Description
O󰀨 No Link O󰀨 10Mbps connection
Blinking Data Activity Orange 100Mbps connection
On Link Green 1Gbps connection
ACT/LINK
LED
SPEED
LED
LAN Port

13
Chapter 2: Installation
This is a Micro ATX form factor (9.6” x 9.6”) motherboard. Before you install the
motherboard, study the conguration of your chassis to ensure that the motherboard
ts into it.
Make sure to unplug the power cord before installing or removing the
motherboard. Failure to do so may cause physical injuries to you and
damages to motherboard components.
2.1 Screw Holes
Place screws into the holes to secure the motherboard to the chassis.
Do not over-tighten the screws! Doing so may damage the motherboard.
2.2 Pre-installation Precautions
Take note of the following precautions before you install motherboard components
or change any motherboard settings.
1. Unplug the power cord from the wall socket before touching any component.
2. To avoid damaging the motherboard components due to static electricity,
NEVER place your motherboard directly on the carpet or the like. Also
remember to use a grounded wrist strap or touch a safety grounded object
before you handle components.
3. Hold components by the edges and do not touch the ICs.
4. Whenever you uninstall any component, place it on a grounded antistatic pad or
in the bag that comes with the component.
Before you install or remove any component, ensure that the power is
switched o󰀨 or the power cord is detached from the power supply.
Failure to do so may cause severe damage to the motherboard, peripherals,
and/or components.

14
2.3 Installation of Memory Modules (DIMM)
This motherboard provides four 288-pin DDR4 (Double Data Rate 4) DIMM
slots, and supports Dual Channel Memory Technology.
Dual Channel Memory Conguration
1. For dual channel conguration, you always need to install identical (the same
brand, speed, size and chip-type) DDR4 DIMM pairs.
2. It is unable to activate Dual Channel Memory Technology with only one or three
memory module installed.
3. It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4
slot; otherwise, this motherboard and DIMM may be damaged.
e DIMM only ts in one correct orientation. It will cause permanent damage to
the motherboard and the DIMM if you force the DIMM into the slot at incorrect
orientation.
Priority DDR4_A1 DDR4_A2 DDR4_B1 DDR4_B2
1Populated Populated
2Populated Populated Populated Populated

15
1
2
3

16
2.4 Expansion Slots
There are 4 PCI Express slots, 3 M.2 sockets and 1 SIM socket on this mother-
board.
PCIE slots:
PCIE1 (PCIE 3.0 x16 slot) is used for PCI Express x16 lane width cards.
PCIE2 (PCIE 3.0 x4 slot) is used for PCI Express x4 cards.
PCIE3 (PCIE 3.0 x16 slot) is used for PCI Express x8 lane width cards.
PCIE4 (PCIE 3.0 x4 slot) is used for PCI Express x4 cards.
* PCIE1/PCIE2: single at x16 (PCIE1); dual at x8 (PCIE1) / x8 (PCIE3).
* PCIE1: Support riser card x8/x8, x8/x4/x4.
SIM socket:
1 x SIM socket connected to M.2 key B.
M.2 sockets:
1 x M.2 (Key M, 2242/2260/2280) with SATA and PCIe x4 f or SSD.
* Shared with SATA3_5/SATA3_6 Ports.
* When using M.2 PCIe x4 S SD, both SATA3_5 and SATA_6 Ports are
disabled.
* When using M.2 SA TA SSD, only SATA3_5 Port is disabled, and
SATA3_6 Port is available.
1 x M.2 (Key E, 2230) with PCIe x1, USB 2.0 and CNVio for Wireless.
1 x M.2 (Key B, 3042/3052) with PCIe x1/USB 3.0/USB2.0 and SIMo for
4G/5G.

17
+3VSB
+3VSB
+3VSB
+3VSB
M.2 Key-M Socket (M2_M1): M.2 Key-E Socket (M2_E1):
M.2 Key-B Socket (M2_B1):

18
2.5 Jumpers Setup
The illustration shows how jumpers are setup.
When the jumper cap is placed on
pins, the jumper is “Short”. If no jumper cap is
placed on pins, the jumper is “Open”. The illus-
tration shows a 3-pin jumper whose pin1 and
pin2 are “Short” when jumper cap is placed on
these 2 pins.
Jumper Setting Description
Clear CMOS Jumpers CLRMOS1
:
(3-pin CLRMOS1)
1-2 : Normal
(see p.9, No. 25)
2-3 : Clear CMOS
Note: CLRMOS1 allows you to clear the data in CMOS. To clear and reset the
system parameters to default setup, please turn o󰀨 the computer and unplug the
power cord from the power supply. After waiting for 15 seconds, use a jumper cap
to short pin2 and pin3 on CLRMOS1 for 5 seconds. However, please do not clear
the CMOS right after you update the BIOS. If you need to clear the CMOS when
you just nish updating the BIOS, you must boot up the system rst, and then shut
it down before you do the clear-CMOS action. Please be noted that the password,
date, time, user default prole and MAC address will be cleared only if the CMOS
battery is removed.
(2-pin CLRMOS2)
CLRMOS2
:
(see p.9, No. 25)
Open : Normal
Short : Auto Clear CMOS (Power O󰀨)
Note: CLRMOS2 allows you to clear the data in CMOS automatically when AC power
on. The data in CMOS includes system setup information such as system pass-
word, date, time, and system setup parameters. To clear and reset the system
parameters to default setup, please turn o󰀨 the computer and unplug the power
cord, then use a jumper cap to short the pins on CLRMOS2.
Digital Input / Output Power Select (JGPIOPWR) 1-2 : +12V
(5-pin JGPIO_PWR1)
2-3 : +5V
(see p.9, No. 24)
3-4 : +5V
4-5: GND
Clear CMOSDefault
1

19
COM Port Pin9 PWR Setting Jumpers 1-2 : +5V
(3-pin PWR_COM1 (For COM Port1))
2-3 : +12V
(see p.9, No. 43)
(3-pin PWR_COM2 (For COM Port2))
(see p.9, No. 35)
(3-pin PWR_COM3 (For COM Port3))
(3-pin PWR_COM4 (For COM Port4))
(3-pin PWR_COM5 (For COM Port5))
(3-pin PWR_COM6 (For COM Port6))
(see p.9, No. 28)
ATX/AT Mode Jumper Open : ATX Mode
(2-pin SIO_AT1)
Short : AT Mode
(see p.9, No. 15)
Chassis Intrusion Headers This motherboard supports
(2-pin CI1, CI2: see p.9, No. 16) CASE OPEN detection feature
that detects if the chassis cover
has been removed. This feature
requires a chassis with chassis
intrusion detection design.
CI1 :
Close : Active Case Open
Open : Normal
CI2 :
Close : Normal
Open : Active Case Open
Digital Input / Output Power Select 1-2 : +5V
(3-pin JGPIO_SET1)
2-3 : GND
(see p.9, No. 20)
1
Panel Power Select (LCD_VCC) 1-2 : +3V
(5-pin PNL_PWR1)
2-3 : +5V
(see p.9, No. 1)
4-5 : +12V
1

20
Backlight Control Level (CON_LBKLT_CTL) 1-2 : +3V (eDP)
(3-pin BLT_PWM1)
2-3 : +5V (LVDS)
(see p.9, No. 2)
LVDSBL1, LVDSBL2
(2-pin LVDSBL1)
Open : Protect LCD_BLT_VCC
(see p.9, No. 6)
Short : No Protect LCD_BLT_VCC
(2-pin LVDSBL2)
Open : Protect LCD_VCC
(see p.9, No. 5)
Short : No Protect LCD_VCC
1
Backlight Power Select (LCD_BLT_VCC) 1-2 : LCD_BLT_VCC: +5V
(3-pin BKT_PWR1)
2-3 : LCD_BLT_VCC: +12V
(see p.9, No. 7)
1
DACC1 Open : No ACC
(2-pin DACC1)
Short : ACC
(see p.9, No. 22)
PWR Loss Header Open : No Power Loss
(2-pin PWR_LOSS1)
Short : Power Loss
(see p.9, No. 27)
1
