Detail Specification
Product Brief
CPU
Memory
Expansion Slot
Graphics
Audio
LAN
Rear Panel I/O
Connector
BIOS Feature
Support CD
Accessories
Hardware Monitor
OS
Certifications
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
Chipset
Platform
- Supports CPU up to 140W
- Supports AMD OverDrive™ with ACC feature
(Advanced Clock Calibration)
- Integrated AMD Radeon HD 4200 graphics,
DX10.1 class iGPU, Shader Model 4.1,
Max. shared memory 512MB
- Built-in 128MB DDR3 1333(OC)/1200MHz
SidePort Memory
- Supports ATITM CrossFireXTM, Hybrid
CrossFireXTM and 3-Way CrossFireXTM
- Three VGA Output options: D-Sub, DVI-D
and HDMI
- EuP Ready
- Supports ASRock Instant Boot, Instant Flash,
Smart BIOS, ASRock OC Tuner,
Intelligent Energy Saver
- ATX Form Factor: 12.0-in x 8.8-in, 30.5 cm x 22.4 cm
- All Solid Capacitor design (100% Japan-made high-quality
Conductive Polymer Capacitors)
- Support for Socket AM3 processors: AMD PhenomTM II
X4 / X3 / X2 (except 920 / 940) and Athlon II X4 / X3 / X2
processors
- Supports CPU up to 140W
- Supports AMD OverDrive™ with ACC feature (Advanced
Clock Calibration)
- AMD LIVE!TM Ready
- Supports AMD's Cool 'n' Quiet Technology
- FSB 2600 MHz (5.2 GT/s)
- Supports Untied Overclocking Technology
- Supports Hyper-Transport 3.0 (HT 3.0) Technology
- Northbridge: AMD 785G
- Southbridge: AMD SB710
- Dual Channel DDR3 memory technology
- 4 x DDR3 DIMM slots
- Supports DDR3 1600(OC)/1333/1066/800 non-ECC,
un-buffered memory
- Max. capacity of system memory: 16GB
- 3 x PCI Express 2.0 x16 slots (green @ x16 mode, blue @ x8
mode, orange @ x4 mode)
- 1 x PCI Express 2.0 x1 slot
- 2 x PCI slots
- Supports ATITM CrossFireXTM, Hybrid CrossFireXTM and 3-Way
CrossFireXTM
- 7.1 CH Windows®Vista™ Premium Level HD Audio (Realtek
ALC888 Audio Codec)
- PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111DL
- Supports Wake-On-LAN
I/O Panel
- 1 x PS/2 Keyboard Port
- 1 x VGA/D-Sub Port
- 1 x VGA/DVI-D Port
- 1 x HDMI Port
- 1 x Optical SPDIF Out Port
- 1 x IEEE 1394 Port
- 1 x eSATAII Port
- 6 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
- HD Audio Jack: Side Speaker / Rear Speaker / Central /
Bass / Line in / Front Speaker / Microphone
- 6 x Serial ATAII 3.0 Gb/s connectors, support RAID (RAID 0,
RAID 1, RAID 10 and JBOD), NCQ, AHCI and "Hot Plug"
functions
- 1 x eSATAII 3.0 Gb/s connector (shared with 1 SATAII port)
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- 1 x COM port header
- 1 x IEEE 1394 header
- 1 x HDMI_SPDIF header
- CPU/Chassis/NB/Power FAN connector
- 24 pin ATX power connector
- 8 pin 12V power connector
- SLI/XFire power connector
- CD in header
- Front panel audio connector
- 3 x USB 2.0 headers (support 6 USB 2.0 ports)
- 8Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- CPU, VCCM, NB, SB Voltage Multi-adjustment
- Supports Smart BIOS
- Drivers, Utilities, AntiVirus Software (Trial Version), AMD
OverDriveTM Utility, AMD Live! Explorer, AMD Fusion
- CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU/Chassis/NB/Power Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, Vcore
- Microsoft®Windows®XP / XP Media Center / XP 64-bit /
VistaTM / VistaTM 64-bit compliant
- FCC, CE, WHQL
- EuP Ready (EuP ready power supply is required)
- 1 x ASRock SLI/XFire Switch Card
- Quick Installation Guide, Support CD, I/O Shield
- Floppy/ATA 133 cables
- 2 x SATA data cables (optional)
AMD 785G + SB710 Chipsets
Unique Feature - ASRock OC Tuner
- Intelligent Energy Saver
- Instant Boot
- ASRock Instant Flash
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
M3A785GXH/128M
www.asrock.com
- Integrated AMD Radeon HD 4200 graphics
- DX10.1 class iGPU, Shader Model 4.1
- Max. shared memory 512MB
- Built-in 128MB DDR3 1333(OC)/1200MHz SidePort Memory
- Three VGA Output options: D-Sub, DVI-D and HDMI
- Supports HDCP function
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback
EuP
EuP
Ready

AMD 785G + SB710 Chipsets
M3A785GXH/128M
www.asrock.com
EuP
EuP
Ready
What is EuP?
EuP, stands for Energy Using Product, was a provision regulated by European Union to define the power
consumption for the completed system. With the great quantity and the popularly using of the electrical products
nowadays and the continuously increasing of the electrical products categories in the following 20 to 30 years,
European Union decided to establish an effective strategy to solve the energy consumption problem. That is,
according to EuP, the total AC power of the completed system shall be under 1.00W in off mode condition.
How to setup an EuP system?
To meet EuP standard, the EuP ready motherboard and the EuP ready power supply are required. As a mother-
board vendor with eco-awareness, ASRock is the pioneer to develop “EuP Ready” motherboards based on the
great efforts of our exceptional hardware design.
According to Intel, the EuP ready power supply must meet the standard of 5v standby power efficiency is higher
than 50% under 100 mA current consumption. For EuP ready power supply selection, please check with the
power supply manufacturer for more details.
ASRock, Worldwide First EuP Ready Motherboard Manufacturer!
ASRock hereby proudly announced that we are the Worldwide First motherboard manufacturer to release “EuP
Ready” motherboard to the market! With ASRock “EuP Ready” motherboard, you are confident to setup a system
to pass the EuP standard.
EuP Ready Motherboard EuP Ready Power Supply EuP System
ATI Radeon®HD4200
Worldwide First DirectX 10.1 Onboard Graphics
Key features of DirectX 10.1 include an updated shader model, improved anti-aliasing support,
more flexible data access, and tighter specifications for better applicationcompatibility.
Features DirectX®10 DirectX®10.1
Shader Model 4 4.1
Separate per-MRT
blend modes
Pixel Coverage
Masks
Sample Pattern
Selection
Cube Map Arrays
Gather4
VS Inputs 16 32
Blending INT8, FP16/32 INT8/16, FP16/32
Filtering FP16 FP32
No Yes
No Yes
No Yes
No Yes
No Yes
DirectX 10.1 Anti-Aliasing
DirectX 10 –Standard
MSAA:Foliage edges do
not get anti-aliased
–causes shimmering and
crawling when they move
DirectX 10.1 –Alpha Test
MSAA:Foliage edges are
smoothed and anti-aliased
–offers significant image
quality improvement

AMD 785G + SB710 Chipsets
M3A785GXH/128M
www.asrock.com
110%
CPU Frequency
Enable ACC
Disable ACC
3300MHz
3000MHz
Up to
110%
performance Boost
Configuration:
CPU : Phenom X3 8750 ( 200 x 12 =2400 Mhz)
Memory : OCZ DDR2-1200
BIOS : L0.03
AMD OverDrive™ with ACC feature
(Advanced Clock Calibration)
Enable AOD ACC, Upgrade your
CPU cores and L3 cache now!
With AMD Phenom II X2 550 BE CPU
With AMD Phenom II X3 710 / 720 BE CPU
With AMD Phenom II 805 / 810 CPU
X2 cores → X4 cores
X3 cores → X4 cores
L3 cache 4MB → 6MB
*The success rate of this enhancement depends on the individual CPU.
Side port memory 128M:
Boost performance up to 10% which is rarely seen on other 785G boards
side port memroy 128M
ASRock 785G MB with
Side Port Memory 128M
Up to 10%
Performance Boost
Without side
port memory
With side
port memory
3DMARK 06
1972
2167
Performance Boost
GPU=700MHz, Sideport runs at DDR3 1200, at performance setting
10%10%

AMD 785G + SB710 Chipsets
M3A785GXH/128M
www.asrock.com
ASRock Instant Flash is an exclusive and the most user-
friendly BIOS flash utility developed by ASRock. It is embed-
ded in Flash ROM which is used to update the system BIOS
without having to enter operating systems like MS-DOS or
Windows.
Once executing ASRock Instant Flash, the utility will automatically detect all devices such as USB, hard
disk or even floppy drive to find the exact BIOS for your system. Instead of giving you all BIOS in your
devices, the Instant Flash just list BIOS versions that apply to your motherboard model only. For
example, if you have many different BIOS of different motherboards saved in your devices, but you just
need to flash your P45 motherboard, the Instant Flash will just list the P45 BIOS versions for you. This
unique function allows you to easily select the suitable BIOS version instead of browsing through all data.
Features
ASRock Instant Flash
Instant Flash just list
BIOS versions that
apply to your
motherboard model.
Click and start
Flashing!
Simple!Simple! Quick!Quick!
ASRock Instant Boot
ASRock Instant Boot is a new feature invented exclusively by ASRock.
It can boot up system in an amazing speed,
which is 10 times faster than traditional boot up. For home users or office
PC users, ASRock Instant Boot can also
guarantee a clean Windows OS, and consumed less power! For details:
http://www.asrock.com/feature/InstantBoot/index.asp
10 Times Faster, Only 4 Secs to Boot Up to Windows!
ASRock YouTube
http://tw.youtube.com/watch?v=BucIjXZVxXo
* This function is applicable ONLY to single user that does not secure ID and Password to their
systems.
* The boot up time depends on the hardware configuration.
