Assistant AH-1073 User manual

Warranty period Гарантийный срок
Date of sale Дата продажи
Model Номер модели
Stamp Печать магазина
INSTRUCTION MANUAL
LED AM/FM RADIO CLOCK
Model AH-1073
WWW.TIWELL.COM WWW.ASSISTANT.UA
– 1 – – 2 – – 3 – – 4 –
– 5 – – 7 –
ENGLISH ENGLISH ENGLISH ENGLISH ENGLISH ENGLISH ENGLISH ENGLISH
ENGLISH ENGLISH ENGLISH ENGLISH
– 6 –
ENGLISH ENGLISH
– 8 –
ENGLISH ENGLISH
STRUCTURE
1. SNOOZE SET BUTTON
2. ALARM SET/OFF BUTTON
3. TIME SET BUTTON
4. SLEEP SET BUTTON
5. HOUR SET BUTTON
6. MINUTE SET BUTTON
7. LED DISPLAY
8. BAND SWITCH
9. POWER INDICATOR (DIAL POINTER)
10. TUNING CONTROL
11. BATTERY DOOR (Bottom)
12. VOLTAGE SELECTOR (Bottom) (OPTIONAL)
(For dual voltage version only)
13. AC POWER CORD
14. FM ANTENNA WIRE
15. ON/OFF VOLUME CONTROL (BUZZ)
16. ALARM ON INDICATOR
17. FUNCTION SWITCH (ON/OFP/AUTO)
18. SPEKAER
RADIO OPERATION
This Electronic Clock-Radio should be operated
on AC current only.
Your Clock Radio has a built-in antenna for AM
reception which is directional. If the reception is not
clear, try turning the radio to other directions.
The small flexible wire on the back of the unit is
the FM antenna. For best reception, extend this
wire to its full length.
TO PLAY RADIO
1. Slide the FUNCTION SMITCH (17) to ON
position.
2. Slide the BAND SWITCH (8) to the band to
your preference.
3. Select a station by rotating the TUNING CON-
TROL (10).
4. Adjust the VOLUME CONTROL (15) to a
desired level.
5. To turn radio off. Slide the FUNCTION SWITCH
(17) to OFF position.
TO SET THE TIME
1. Press and hold the TIME SET button (3).
2. Press the MINUTE SET button (6) until the
correct minute setting is reached.
3. Continue holding the TIME SET button (3),
press the HOUR SET BUTTON (5) until the correct
hour setting is reached.
TO SET THE WAKE-UP ALARM TIME
1. Holding the ALARM SET button (2)
2. Press the MINUTE SET button (6) until the
correct minute setting is reached.
3. Continue hold the ALARM SET button (2),
press the HOUR SET BUTTON (5) until the correct
hour setting is reached.
SLEEP FUCNTION
1. Slide the FUNCTION SWITCH (17) to OFF
position.
2. Press and hold the SLEEP SET button (4),
«59» will appear on the LED DISPLAY (7), indi-
cating that the radio will shut off automatically in
59 minutes.
3. To shorten automatic shut down time, hold the
SLEEP SET button (4) and press the MINUTE SET
button (6) together to adjust as required.
4. To increase the automatic shut down time, hold
the SLEEP SET button (4) and press the HOUR
SET button (5) together to adjust as required.
Maximum sleep time is 1 hour 59 minutes.
5. The SNOOZE button can be used to cancel
the sleep function.
WAKE TO RADIO OR ALARM
1. Slide the FUNCTION SWITCH (17) to AUTO
position.
2. When pre-set alarm time is reached, the radio
will be switched on automatically for 120 minutes
and then to be shut off automatically.
3. The unit will wake to ALARM instead of RADIO
if the VOLUME CONTROL (15) is turned to BUZZ-
ER position (a «click» sound could be heard)
SNOOZE BUTTON
1. When the alarm is ringing, press the SNOOZE
button (l), the unit will be shut OFF and switched
ON again in exactly 9 minutes. You may repeat
this operation within a period of 45 minutes after
the pre-set alarm time.
BATTERY BACK-UP FOR CLOCK
1. Open the BATTERY DOOR (11), install a 9-volt
battery into the battery compartment
2. When there is a power failure, the radio and
the LED display will no longer operate, but the 9V
battery will keep the clock going.
3.So, as soon as the power failure is over, the LED
DISPLAY (7) will show the correct time immediately
without the need for time adjusting.
MAINTENANCE
1. Do not place your clock radio in a high tempera-
ture area, such as under direct sunlight or close to a
radiator. Excessive heat will damage the unit.
2. Do not expose your clock radio to rain or mois-
ture to prevent fire or shock danger.
3. Do not use polish solvents or strong detergents
to clean the unit. The cabinet can be cleaned with
a piece of soft cloth or if necessary to be cleaned
with a piece of soft cloth soaked with little water.
The power plug should be disconnected from the
mains supply during the cleaning.
SPECIFICATIONS
Frequency Range: AM 530 – 1600 KHz
FM 88 – 108 MHz
Power Supply: AC 230V~50Hz
6F22 («Krona»)
(for time back-up)
