Astone i-P22 User manual

i-P22 FCC Regulations
FCC Declaration of Conformity Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Radio and Television Interference
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause interference to radio or television reception, which can be determined by turning the equipment off and
then on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Increase the separation between the equipment and receiver.
• Connect the equipment to a different outlet so that the equipment and receiver are on different branch
circuits.
• Consult the dealer or an experienced radio / TV technician for help.
Changes or modifications not expressly approved by Sonic Impact / Astone could void the user’s authority to
operate the equipment.
THIS CLASS B DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES-003.
Sonic Impact Technologies LLC ©Sonic Impact Technologies LLC
2555 State Street i-P22 is a trademark of Sonic Impact Technologies LLC & Astone Holdings Pty Ltd.
San Diego, California 92101 iPod® is trademark of Apple Computer, Inc., registered in the U.S. and other countries
USA www.si-technologies.com www.astone.com.au
Astone Holdings Pty Ltd
Unit 5/5 Dunlop St Strathfield South
NSW 2136, Sydney
Australia
Important operating and maintenance (servicing) instructions.
1

CAUTION: TO PREVENT ELECTRONIC SHOCK DO NOT USE THIS (POLARIZED) PLUG WITH AN EXTENSION
CORD.RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS i-P22 TO RAIN OR MOISTURE
IMPORTANT i-P22 SAFETY INSTRUCTIONS
1. Read instructions --All Safety and operating instructions should be read before the i-P22 is used.
2. Retain instructions--The operating instructions should be retained for future reference.
3. Heed warnings--All warnings in the operating instructions should be read and adhered to.
4. Follow instructions--All operating instructions should be followed.
5. WARNING: Avoid water and moisture--Keep away from all liquids. To reduce the risk of fire or electric shock,
do not expose the i-P22 to rain or moisture.
6. Location--The i-P22 should be placed in a stable, level location, away from external heat sources and with
adequate ventilation. Do not expose the i-P22 to temperature or humidity extremes. Protect from exposure
to dirt, sand, and dust. Note that the speakers are magnetically shielded to prevent distortion of TVs and
computer monitors, but keep magnetic storage media at least four inches from the i-P22 to avoid data loss.
7. Power supply--When not powering off the internal rechargeable battery, the i-P22 should only be connected
to the power supply provided with your unit or as described in the operating instructions and as marked on
the i-P22.
8. Power cord use and care--Power cords should be located so that they are not likely to be walked on or
crushed by placing other objects on top of them. Check all attachments regularly. Do not bypass the proper
grounding or polarization of the power plug. If your i-P22 is not to be used for an extended period of time,
unplug and stow the power cord.
9. TO PREVENT THE RISK OF ELECTRIC SHOCK AND DAMAGE TO THE UNIT, DO NOT REMOVE THE SPEAKER GRILLES
OR OPEN THE UNIT FOR SERVICING EXCEPT TO REPLACE THE RECHARGEABLE LITHIUM ION AS INSTRUCTED IN
THIS MANUAL. PLEASE REFER SERVICING TO QUALIFIED SONIC IMPACT / ASTONE PERSONNEL.
10. Cleaning--Use only a soft dry cloth. Do not use cleaning chemicals of any kind.
11. Lightning Storms--Unplug the apparatus during lightning storms to prevent accidental damage.
12. Accessories--Only use attachment accessories specified by Sonic Impact Technologies/ Astone.
13. Damage Requiring Service--The i-P22 should be serviced by qualified service person when:
2

· The power-supply cord or the plug has been damaged.
· Objects have fallen onto or liquid has been spilled into the i-P22.
· The i-P22 has been exposed to rain.
· The i-P22 does not appear to operate normally or exhibits a marked change in performance.
· The i-P22 has been dropped or the enclosure has been damaged.
14. Servicing--The user should not attempt to service the i-P22 themselves. Servicing should be referred to a
qualified service person or returned to the dealer. For questions about warranty and service contact Sonic
Impact Technologies, LLC at [email protected] or Astone Holdings Pty Ltd at
[email protected]om.au
ONE-YEAR LIMITED WARRANTY
Sonic Impact Technologies / Astone Holdings warranties that all of its products are free from defects in
material and workmanship in the course of normal and reasonable use for a term of one year from the date of
purchase.
This warranty is the exclusive and only warranty in effect relative to Sonic Impact Technologies / Astone
Holdings powered i-P22 speaker system and any other warranties, either expressed or implied, are invalid. Neither
Sonic Impact Technologies, LLC / Astone Holdings Pty Ltd nor any authorized Sonic Impact Technologies, LLC /
Astone Holdings Pty Ltd reseller are responsible for any incidental damages incurred in the use of the speakers.
(This limitation of incidental or consequential damage is not applicable where prohibited.)
Sonic Impact Technologies, LLC’s / Astone Holdings Pty Ltd obligation under this warranty does not apply to
any defect, malfunction or failure as a result of misuse, abuse, improper installation, use with faulty or improper
equipment or the use of the speaker systems with any equipment for which they were not intended.
The terms of this warranty apply only if the i-P22 speaker systems are returned to the respective authorized
Sonic Impact Technologies, LLC / Astone Holdings Pty Ltd reseller where they were purchased.
CUSTOMER SERVICE
For service or warranty of the electronics please contact:
[email protected] / [e-mail].

PACKING CONTENT
3
i-P22System ACPower Stereo iPod®Adapter Manual Quick
Adapter Cable Sleeves Connect
Instruction
·i-P22 portable speaker case
·9V 1.2A AC power adapter
·Ø3.5 stereo cable
·iPod mini、iPod 3G 10GB 15GB 20GB/iPod 4G 20GB/iPod PHOTO 30GB、iPod 3G 30GB/ iPod 4G 40GB/ iPod PHOTO
40GB 60GB adapter sleeves
·Usermanual
·Quick connect instructions
* Note: for use with an iPod nano or iPod video, please use the adapters included with your iPod nano or iPod video
4

i-P22 Diagram：
1. Compartment Lock 7. Rubber
2. Storage Compartment 8. Belt Clip
3. Speaker Driver Unit 9. iPod® Adapter Sleeve
4. PortTube 10.iPod®30PinDockingStation
5. Battery Compartment 11. Power On/Off and LED
6. Input Jacks
5

POSITIONING YOUR i-P22 SYSTEM
It is best to position the i-P22 system on a stable, level surface within 1-2.5 meter from the listener. The i-P22
system may be placed near video displays, such as TV sets and computer monitors, without causing distortion to
the image.
ADAPTER SLEEVE USAGE
Attach the iPod adapter sleeves, provided with your i-P22, that matches the old model of your iPod . Together with
the adapter sleeves provided with new model of your iPod itself, i-P22 can be compatible to 3G iPod model
afterward, including iPod 3G, iPod 4G, iPod photo, iPod mini, iPod nano, iPod video. You can choose the adapter
sleeve according to its thickness. You can refer to the Quick connect instruction for detail operation.
CONNECTING TO YOUR i-P22
Warning: Ensure that i-P22 system is in the POWER OFF mode before making any connections and before docking
the iPod into the i-P22 system. To ensure proper operation, please carefully follow the connection sequence as
described below and in the order indicated.
An iPod model with a 30 PIN connector can be connected directly to the 30 pin docking station located on the i-P22
system. An older iPod model without a 30 PIN connector can be connected via the AUDIO IN port located at the
side of your i-P22 case and by using the 3.5 mm stereo cable, included. When you’re sure that either method of
connection has been made you are ready to play the i-P22 speakers.
4AA batteries must be inserted to the i-P22 or you may use the optional AC adapter power supply.
POWER
The i-P22 system uses a universal power supply via 9V@1.2A power adapter or as a portable system using 4 AA
batteries as its power supply.
When the iPod is connected to the i-P22 system, insert the AC adapter barrel connector into the jack marked DC IN
9V , and then insert the universal power adaptor blade end into your AC power wall jack.
AA batteries power supply
The i-P22 system also operates using 4AA batteries, (see battery replacement instructions).
6

Remarks: The output of using power adapter is twice as great as the output of using battery.
Whendocked,youriPodwillalso recharge when using the AC adapter.
START PLAYING
1. Slide power switch to the right for “AUTO ON” and note that the power indicator will illuminate.
2. Select and play your favorite music using your iPod.
VOLUME CONTROL
The buttons on the front panel are the master volume controls for the i-P22 system. Press and hold “+”
to increase the volume and then “-” to decrease the volume. The volume will start at 40% maximum volume
position every time you re-start your i-P22 system. This will avoid disturbing others when booting it up.
POWER OFF
To minimize power consumption, slide power switch to OFF when you are no longer using the device
If your i-P22 is not to be used for an extended period of time, remove the AA batteries from i-P22. Please note that
the i-P22 has an “AUTO SHUT-DOWN” (STANDBY) function which prevents excess power consumption during idle
play.
AUTO SHUT-DOWN (STANDBY)
When the power switch is set at the “AUTO ON” position, the i-P22 system will shut down automatically and goes
into standby mode if an audio signal is not detected within 5 minutes. The LED on the power switch will then turn
to green and blink. The LED will automatically stop blinking when an audio signal is detected and the
i-P22 system will automatically power on. Power consumption will be reduced in this “standby” mode, but we
suggest that you set the power switch to the “OFF” to shut down the i-P22 system completely when not in use for
an extended period of time to save battery life.
7

AA BATTERY REPLACEMENT
While using AA battery as the power supply, the indicator turns green while the battery is full. When
the indicator turns red , it is a warning that the battery is not full enough. The system will operate again
after battery replacement.
Under normal use, 4 AA battery can last at least 8 hours (depending on the volume setting and the play interval).
Please note the following illustration to replace the AA battery.
8

SPECIFICATIONS
The excellent sound quality of the i-P22 comes from our highly professional design, which includes a customized
Hi-Fi Neodymium driver, digital amp, and the latest digital equalizer circuitry.
Power Output ：1W*2 （AA battery power supply ）2W*2 （power adapter supply）
Speaker channel: 2 channel
Impedance：12Ω
Frequency response ：180Hz -- 20KHz
S/N ratio：85dB±2 (0.5M &1W)
Driver unit：neodymium-magneticdrivers 1.25”×2
9

TROUBLE SHOOTING
SYMPTOMS POSSIBLE PROBLEM SOLUTION
System is not switched on Slide the power switch to on position
Universal power cord isn’t
plugged into a wall outlet
and/or the power supply
connector is not connected to
the power supply jack on the
back of i-P22 system
Plug the universal power supply into a wall outlet
and connect the power supply connector into the
power supply jack on the back of the i-P22 system
Surge protector (if used) isn’t
powered on.
If the universal power supply cord is plugged into a
surge protector, make sure the surge protector is
switched on
Wall outlet doesn’t work Plug another device into a wall outlet (same outlet)
to confirm the outlet works
Power indicator is
not lit when the
AC adapter is
plugged in
AA battery have no charge Replace the AA batteries
Verify the universal power supply cord is plugged
into a wall outlet and he power supply jack on the
back of the i-P22 system
Verify batteries are installed if the universal power
supply isn’t being used
i-P22 system is not switched on
Verify the power switch is at the “ON” position ,
and the indicator is illuminated
Press the “+” button to increase the volumeVolume is set too low
Check volume level on alternate audio source
device and set it at mid-level
Speakers are mute
iPod is not seated into the
docking station
Remove iPod and re-seat it in the docking station
10

3.5 mm i-P22 stereo cable isn’t
connected to an audio source
Connect the 3.5 mm stereo cable to the audio
source. Make sure the signal cable is inserted firmly
into the correct jacks
3.5 mm stereo cable is
connected to incorrect output
on audio source
Make sure the 3.5 mm stereo cable is connected
and fully inserted in the “line-our” “audio out” or
the headphone jack on your sound card or other
audio source
A problem with audio source Test the speakers by using another audio source
(e.g. portable CD, cassette player or FM radio) and
by connecting the 3.5 mm stereo cable through
i-P22 system
Incorrect connection Check if iPod is properly seated in the docking
station. Check connection of the 3.5mm stereo
cable if not using the docking station. Make sure it
is connected to “Line out”, “audio out”, or the
headphone jack on your sound card or other audio
source – and NOT “speaker-out”
Cracking sound
from speakers
A problem with your audio
source
Unplug the 3.5mm stereo cable from the audio
source. Plug the cable into the headphone jack of
an alternate source (e.g. Walkman, Discman or FM
radio)
Crackling sound
from speakers
(when connected
to PC or laptop)
Volume level in operating system
is set too high
Check the operating system volume level and
decrease it if necessary
Volume level on i-P22 system is
set too high
Decrease the volumeSound is distorted
Sound source is distorted
WAV and MID files are often of poor quality;
therefore distortion and noise are easily noticed
with high-powered speakers. Try a different audio
source such as a music CD
11

Sound is distorted
(when connected
to PC or laptop)
Volume level in operating system
is set too high
Check the operating system volume level and
decrease it if necessary
Sound isn’t
continuous
AA battery is not full Replace the AA battery or use power adapter
Radio interference Too close to a radio tower Move your speakers to see if the interference goes
away
12

www.astone.com.au
