ASTRO DM-3105 User manual
HD/SD 5-inch LCD Monitor
DM-3105
Instruction Manual
Ver.1.00
HD/SD 5-inch LCD Monitor
DM-3105
Instruction Manual
2008.4
Ver.1.00
ASTRODESIGN,Inc
Contents
Introduction......................................................................................................................................................................iii
Safety Precautions ..........................................................................................................................................................iii
About This Equipment..................................................................................................................................................iii
About the Power Cord..................................................................................................................................................iii
About Foreign Particles............................................................................................................................................... iv
About the Power Supply.............................................................................................................................................. iv
About the Liquid Crystal .............................................................................................................................................. iv
About Shock of Impact ................................................................................................................................................. v
About the Installation and Operation Environment....................................................................................................... v
Chapter 1. About the DM-3105 ........................................................................................................................................ 1
DM-3105 Overview .......................................................................................................................................................... 1
Chapter 2. Names of Parts............................................................................................................................................... 3
2.1 DM-3105 Front Panel and Part Names ................................................................................................................... 3
2.2 DM-3105 Rear Panel and Part Names.................................................................................................................... 6
Chapter 3. How to Use ................................................................................................................................................... 11
3.1 How to Connect ....................................................................................................................................................... 11
3.2 How to Use .............................................................................................................................................................. 11
3.3 About the Screen .................................................................................................................................................. 12
3.3.1 Normal screens .............................................................................................................................................. 12
3.3.2 Menu Screens ................................................................................................................................................ 15
3.4 Operations Using Special Switches ...................................................................................................................... 16
3.4.1 Switching the Input Signal .............................................................................................................................. 16
3.4.2 Adjusting the Offset Level for the Brightness Signal....................................................................................... 17
3.4.3 Adjusting the Contrast of the Brightness Signal ................................................................................................ 17
3.4.4 Adjusting the Pb(Cb) Value ............................................................................................................................ 18
3.4.5 Adjusting the Pr(Cr) Value ................................................................................................................................18
3.4.6 Simultaneously Adjusting Pb(Cb)・Pr(Cr) Values............................................................................................ 19
3.4.7 Adjusting the Peaking Value........................................................................................................................... 19
3.4.8 Adjusting Hue ................................................................................................................................................. 20
3.4.9 Setting Audio Output ...................................................................................................................................... 20
3.4.10 Adjusting Gain for the Displayed Waveform or Vector .................................................................................... 21
3.4.11 Displaying the Menu Screen......................................................................................................................... 21
3.5 Oparations From Within the Menu ........................................................................................................................ 22
3.5.1 Making Detailed Settings for the Viedo Display Screen .................................................................................... 23
3.5.2 Setting the Aspect Ratio ................................................................................................................................. 26
3.5.3 Making Marker Settings .................................................................................................................................... 27
3.5.4 Making Tally Settings ........................................................................................................................................ 29
3.5.5 Making Audio Level Meter Settings................................................................................................................... 32
i
3.5.6 Making Simple Waveform Display Settings .................................................................................................... 35
3.5.7 Making Vector Display Settings ........................................................................................................................ 37
3.5.8 Making ID Settings ............................................................................................................................................ 39
3.5.9 Making Screen Display and Layout Settings..................................................................................................... 42
3.5.10 Assigning Functions to Front Switches ........................................................................................................... 46
3.5.11 Making Remote Controller Settings................................................................................................................. 48
3.5.12 Saving, Loading and Renaming Settings and Destroying Saved Settings ...................................................... 51
3.5.13 Restoring Defaults........................................................................................................................................... 53
3.5.14 Making Detailed LCD Settings ........................................................................................................................ 54
3.5.15 Making Basic Settings for the Main Unit.......................................................................................................... 56
Chapter 4. Main Specifications....................................................................................................................................... 59
4.1 Input Formats........................................................................................................................................................ 59
4.2 Input Signal Systems ............................................................................................................................................ 60
4.3 Display System ........................................................................................................................................................ 61
4.4 Headphone Output................................................................................................................................................ 62
4.5 Adjustment Values................................................................................................................................................... 62
4.6 Aspect Ratio ............................................................................................................................................................ 64
4.7 The Audio Level Meter .......................................................................................................................................... 65
4.7.1 Audio Level and Cell Coloration........................................................................................................................ 65
4.7.2 Display Format and Cell Coloration................................................................................................................... 67
4.8 Contact Type Remote Controllers............................................................................................................................ 69
4.8.1 Operation Example ........................................................................................................................................... 69
4.8.2 Setting Values During Level Operations ........................................................................................................... 71
4.9 Setting Values at Time of Initialization ..................................................................................................................... 72
4.9.1 Setting Items by Channel .................................................................................................................................. 72
4.9.2 Shared Setting Items......................................................................................................................................... 73
4.9.3 Automatically Saved Items ................................................................................................................................77
4.9.4 Resetting the Error Count and Elapsed Time.................................................................................................... 78
4.10 General Specifications........................................................................................................................................... 79
4.11 External View......................................................................................................................................................... 80
4.11.1 DM-3105 External View (Main Unit)................................................................................................................ 80
Chapter 5. Accessories and Options .............................................................................................................................. 81
5.1 Accessories ............................................................................................................................................................. 81
5.2 Options .................................................................................................................................................................... 81
Chapter 6. Maintenance, etc. ......................................................................................................................................... 83
If the unit does not function normally ............................................................................................................................. 83
The following items do not indicate a problem with or damage to the unit..................................................................... 84
If an Error or Problem Occurs........................................................................................................................................ 84
ii
Introduction
Thank you for purchasing this DM-3105 HD LCD PICTURE MONITOR.
This manual gives the information necessary for using the DM-3105 including the method of operation and
precautions.
Inappropriate handling may result in an accident. Be absolutely sure to read this manual so that you can
correctly use the DM-3105.
After reading this manual, store it safely so that it will not be lost.
Safety Precautions
警告
WARNING
About This Equipment
Do not strike or subject this equipment to strong impact. This may result in
leakage of liquid crystal, damage to equipment, bursting, overheating, or fire.
Do not use this equipment in a location where there is a risk of catching fire
or explosion.
Do not place in a food heating appliance such as a microwave oven or in a
high-pressure container. This may result in overheating of equipment,
generation of smoke, generation of fire, or destruction of circuit
components.
This equipment includes high-voltage parts inside. Do not disassemble,
repair, or modify this equipment as there is a risk of electric shock or burn
injury and doing so may result in damage to equipment.
If thunder occurs during use outdoors, immediately turn off the power,
disconnect the power cord from the main unit, and move to a safe location.
About the Power Cord
When unplugging the power cord, always grasp the plug to unplug.
Do not unduly bend or twist the power cord. This may result in fire.
Do not place heavy objects on the power cord. This may damage the cord,
resulting in fire or electric shock.
iii
About Foreign Particles
Do not spill liquid inside or drop easily flammable or metallic objects inside.
Continued use under these conditions may result in fire, electric shock, or
damage to equipment.
注 意
CAUTION
About the Power Supply
Use 8 to 18V DC for the power supplied to this equipment.
To prevent equipment damage and/or failure, we recommend the use of the
supplied AC/DC adaptor. Pay attention to the rated voltage if for some
reason you use another power supply.
After power is turned off, do not immediately turn it on again. This may result
in damage to equipment.
Note that there is a risk of adverse effects on audio if the same DC power
supply is used for the mic, amp, speakers, or other acoustic components.
About the Liquid Crystal
Due to the characteristics of liquid crystal, some pixels may be missing (or
bright or flashing).
Do not touch the liquid crystal if it leaks from the LCD panel.
If the LCD panel accidentally breaks and liquid crystal leaks out, do not put it in your mouth, breathe it,
or allow it to contact your skin. If you do somehow get liquid crystal in your mouth or eyes, wash the
affected area immediately with water. In addition, if liquid crystal gets on your skin or clothing,
immediately wipe it away with alcohol or other agent and wash away with soap and water. There may
be damage to skin or clothing if contact is allowed to continue.
Beware of broken glass of the LCD panel.
If the LCD panel breaks, take great care not to cut your hands on the glass shards.
Injury may result if you do somehow touch the broken surface.
iv
Introduction
Handle the LCD panel with care as described below as it is an extremely
high-precision instrument.
• Wiping the LCD panel with benzene, thinner, or other active agent may result in deformation.
• If water (or salt water) is allowed to stay in contact with the LCD panel, this may result in change in
color or blemishes.
• If the LCD panel is subjected to direct ultraviolet light for an extended period, there is a risk of
degradation of display quality due to lowered contrast caused by bronzing of the deflection plate.
• Irregular colors may result if moisture gets inside the LCD panel due to condensation or by other
means.
• Directly striking or bumping into the LCD panel may result in cracking or other damage to the LCD
panel.
• Do not disassemble the LCD panel as it is dangerous if leaked liquid crystal comes in contact with
skin.
Take care when handling the liquid crystal protective panel.
Gently wipe away any grease or dirt that contacts the liquid crystal protective panel using a cleaner
for office equipment. Wiping forcefully may result in scratching or damage to equipment.
About Shock of Impact
As a precision instrument, there is a risk of damage to equipment if the
equipment is subjected to shock of impact. Take sufficient care when
moving the equipment.
Do not drop the main unit.
About the Installation and Operation Environment
Installation in the following locations may result in accident or damage to
equipment.
• Locations where the ambient temperature is outside the range 0 to 40℃. (*1)
• Locations where the ambient humidity is outside the range 30 to 80%RH.
• Locations near an air conditioning unit, or where there is condensation or sudden changes in
temperature.
• Locations subject to direct sunlight. (*2)
• Locations where there is corrosive gas or excessive dust.
• Locations where there are strong magnetic fields.
• Locations where there is a risk of equipment being sprayed with airborne droplets such as water, oil,
or chemicals.
• Locations where vibrations reach equipment through the floor.
• Unstable locations.
v
To ensure normal operation of this equipment, take care that the following
conditions are met.
• Do not place heavy objects such as a monitor on top of this equipment.
• Avoid placying objects in the immediate surrounding of this equipment.
(*1) If the surface temperature of the LCD panel exceeds 60℃, there is a risk that the backlight or
other parts may be damaged.
(*2) If the LCD panel is subjected to direct ultraviolet light for an extended period, there is a risk of
degradation of display quality due to lowered contrast caused by bronzing of the deflection
plate.
vi
1
1
About the DM-3105
The DM-3105 is a compact, light-weight LCD monitor for the HD broadcast industry suitable for mobile video
monitoring when on location or reporting from the field.
This equipment supports 21 types of HDTV input signals and 2 types of SDTV video formats.
In addition to picture quality adjustments and display functions such as brightness adjustment, contrast
adjustment, chroma adjustment, and marker display, this monitor is equipped with various functions including
video level monitoring functions such as simple waveform display and simple vector display.
DM-3105 Overview
Utilizes a 5.0-inch TFT LCD panel
(Viewing angle: Left-right: 170°Up down: 170°; WVG A: 800x480)
Supports HD-SDI, SD-SDI signals and composite signal input
Supports 21 types of video formats
Supported HD-SDI specifications: Conforms for SMPTE292M and BTA S-004B standard
specifications (1.485 Gbit/s SDI input)
Supported SD-SDI specification: Conforms to SMPTE259M standard specifications (270 Mbit/s SDI
input)
Supported composite signal specifications: NTSC: SMPTE 170M
PAL: ITU-R624-4 (excluding PAL-N and PAL-M)
Automatic format tracking, automatic frame rate tracking for 1/1.000 and
1/1.001, and automatic input signal detection function
1
Equipped with SDI IN, SDI MONITOR OUT, and COMPOSITE terminals
Brightness, contrast, chroma, view, monochrome, and gamma adjustment
functions
Marker display function
(FRAME, CENTER, 95%, 93%, 88%, 80%, 4:3, 13:9, 14:9, 2.35:1, 1.85:1, 1.66:1,
Grating, BOX, USER)
Allows user-defined aspect ratio settings
(HD:V_FULL, 16:9, Actual Size, Blanking, Under Scan, SCOPE SD:4:3, 16:9,
Twice Size, Blanking, Under Scan)
Allows user-defined front switch settings
(Including aspect select, monochrome, blue only, display/hide marker, and
chroma up functions, etc.)
Allows user-defined remote controller settings
(Including tally, input signal select, marker ON/OFF select, mask ON/OFF
select, etc.)
Allows color temperature selection of 5500K, 6500K, 9300K (fine color and
gradation adjustments are also possible)
CRC/EDH error detection function for the input channel
Time code (VITC/LTC) display (DID: 260h, SDID: 260h only)
Audio level meter display
Audio level meter customization function
Simple waveform, simple vector display functions (waveform and vector
cannot be displayed simultaneously)
Panel lock, setting value save function
Allows user data to be saved and called up
Thin, lightweight, and compact (can be placed in a rack as three linked
monitors)
DC power input (8 to 18V)
2
2
2
Names of Parts
2.1 DM-3105 Front Panel and Part Names
④
⑤
⑥
⑦
⑧
⑨
⑩
②
①
LCD MONITOR DM-3105
+
⑪
③
Figure 2.1 DM-3105 Front Panel
3
Table 2.1 Front Panel Part Names
No. Name Function
①POWER Switch/LED Turns power ON/OFF. (Lights green when power is input)
②Function select switch Switches the function of front switches or locks operations.
③Liquid Crystal Display Displays video images
④INPUT switch
The video image displayed on the screen is switched in the following order:
“HD/SD_SDI IN CH_A →HD/SD_SDI IN CH_B →COMPOSITE →HD/SD_SDI
IN CH_A”.
When
FUNC is
selected
The function assigned to the switch is executed except during menu
operations.
(See Section 3.5.10)
During, this switch moves the cursor left or up, or increases the value
being adjusted.
⑤F1(+) / BRIGHT switch
When
ADJ is
selected
Enters brightness adjustment.
(See section 3.4.2)
When
FUNC is
electeds
The function assigned to the switch is executed except during menu
operations.
(See Section 3.5.10)
During menu operations, this switch moves the cursor right or down, or
decreases the value being adjusted.
⑥F2(-) / CONTRAST
switch
When
ADJ is
selected
Enters contrast adjustment.
(See Section 3.4.3)
When
FUNC is
selected
The function assigned to the switch is executed except during menu
operations.
(See Section 3.5.10)
During menu operations, this switch used the value being adjusted and
changes the level
When using YPbPr
(Color Space)
Enters chroma adjustment.
Each time this switch is pressed, the setting
changes in the following order: “Chroma →Pb
→Pr →Exit adjustment”.
(See Sections 3.4.4 to 3.4.6)
⑦F3(ENT) / CHROMA
switch
When
ADJ is
selected
When using GBR (Color
Space)
Chroma adjustment cannot be performed.
4
Chapter 2 Names of Parts
When
FUNC is
selected
The function assigned to the switch is executed except during menu
operations.
(See Section 3.5.10)
During menu operations, this switch cancels the value being changed and
exits the adjustment.
When using YPbPr
(Color Space)
Enters peak value adjustment or hue
adjustment.
The peak value can be adjusted when peaking
is ON.
Each time this switch is pressed., the setting
changes in the following order: “Peak →Hue
→Exit adjustment”.
(See Section 3.4.7 to 3.4.8)
⑧F4(ESC) / PEAK / HUE
switch
When
ADJ is
selected
When using GBR (Color
Space)
Enters peak adjustment.
Peak values can be adjusted when peaking is
ON. Hue adjustment cannot be performed.
(See Section 3.4.7)
When
FUNC is
selected
Turns the menu screen ON/OFF.
When the menu screen is ON, switches ⑨through ⑫function as −, +,
ENT, and ESC, respectively.
When the menu screen is OFF, switches ⑨through ⑫function as F1,
F2, F3, and F4, respectively.
⑨MENU / AUDIO / GAIN
switch
When
ADJ is
selected
Enters output audio volume adjustment, output channel setting, or gain
adjustment for displayed waveform/vector.
Each time this switch is pressed, the setting changes in the following order:
“Volume →L_CH →R_CH →Wave_Gain or Vector_Gain →Exit
adjustment” when a waveform or vector is displayed, and in the following
order: Volume →L_CH →R_CH →Exit adjustment” when a waveform
or vector is not displayed. (See Sections 3.4.9 through 3.4.10)
⑩+ / - switch Used to adjust setting values.
⑪Headphone jack Outputs the audio included in the input signal in stereo.
5
2.2 DM-3105 Rear Panel and Part Names
COMPOSITE
12V
1 GND
4 +12V
DC IN
MODEL ;
SER.No ;
MADE IN JAPAN
①
②
⑦
④
③
⑤
⑥
Figure 2.2 DM-3105 Rear Panel
6
Chapter 2 Names of Parts
Table 2.2 Rear Panel Part Names
No. Name Function
①Power Connector (*1) Camera connector DC power input terminal (GND 1 pin, DC IN 4 pins)
②HD/SD SDI IN A HD-SDI, SD-SDI signal input terminals
③HD/SD SDI IN B HD-SDI, SD-SDI signal input terminals
④MONITOR OUT Output terminals for performing a simple check of the SDI input signal
⑤COMPOSITE Composite signal input terminals
⑥Remote Connector (*2) D-sub 15-pin (male)
⑦Rear panel tally LED Supports TALLY1-Red and TALLY2-Green (no TALLY3 or TALLY4)
*1 Power connector (No. (1))
Pin No. Function
1 GND
2 GND *
3 DC IN(8-18V) *
4 DC IN (8-18V)
43
2 1
43
2 1
Note: Pins 2 and 3 are used when driving with a compact battery (low voltage).
Operates using NC when using the usual power supply (12V type).
7
*2 Remote connector (No. (6))
The remote controller is enabled only when ENABLE_RMT is MAKE (Low level).
For details on the remote controller, see Section 4.8.
Pin No. Signal Initial value
1 GND ―
2 Remote Control 1 Non
3 Remote Control 2 Non
4 Remote Control 3 Non
5 ENABLE_RMT ―
6 Remote Control 4 Non
7 Remote Control 5 Non
8 Remote Control 6 Non
9 Remote Control 7 Non
10 Remote Control 8 Non
11 Remote Control 9 Non
12 Remote Control 10 Non
13 Remote Control 11 Non
14 Remote Control 12 Non
15 GND ―
1
5
6
15
11
10
8
Chapter 2 Names of Parts
Remote connector receiver
Inside of DM-30**-L
Control IC
Low level threshold: 0.7V
Remote controller sw
1kΩ
Cable resistance
Vf=0.65V
itch
2 to 14 pin
1.15 pin
3.3V
10kΩ
Note: Design for a cable resistance fo 50Ωor less.
Caution
Do not connect or disconnect the Remote Connector while power is on.
9
10
