Asus PT201 series User manual

PT201 Series
LCD Monitor
User Guide

Information on the Disposal of this Equipment
Do not throw your this product in municipal waste. This product has been designed to enable proper
reuse of parts and recycling. The symbol of the crossed out wheeled bin indicates that the product
(electrical, electronic equipment and mercury-containing button cell battery) should not be placed in
municipal waste. Check local regulations for disposal of electronic products.
E9503
June 2014
First Edition

3E
IMPORTANT INFORMATION
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER.
NO USER-SERVICEABLE PARTS
INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning ash with arrowhead symbol, within
a triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufcient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within a triangle is
intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
product.
Federal Communications Commission Interference Statement
This device complies with FCC Rules Part 15. Operation is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the Federal
Communications Commission (FCC) rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
WARNING! The use of a shielded-type power cord is required in order to meet FCC emission limits and to prevent interference
to the nearby radio and television reception. It is essential that only the supplied power cord be used. Use only shielded cables
to connect I/O devices to this equipment. You are cautioned that changes or modications not expressly approved by the party
responsible for compliance could void your authority to operate the equipment.

4
E
Thank you for your purchase of an ASUS LCD product. To ensure safety and many years of trouble-free operation of your
product, please read the Safety Precautions carefully before using this product.
SAFETY PRECAUTIONS
Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly
handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can
result in electric shock and/or re. In order to prevent potential danger, please observe the following instructions when installing,
operating and cleaning the product. To ensure your safety and prolong the service life of your LCD product, please read the
following precautions carefully before using the product.
1. Read instructions — All operating instructions must be read and understood before the product is operated.
2. Keep this manual in a safe place — These safety and operating instructions must be kept in a safe place for future
reference.
3. Observe warnings — All warnings on the product and in the instructions must be observed closely.
4. Follow instructions — All operating instructions must be followed.
5. Cleaning — Unplug the power cord from the AC outlet before cleaning the product. Use a dry cloth to clean the product. Do
not use liquid cleaners or aerosol cleaners.
6. Attachments — Do not use attachments not recommended by the manufacturer. Use of inadequate attachments can result
in accidents.
7. Water and moisture — Do not use the product near water. Do not install the product in a place where water may splash onto
it. Be careful of equipment which drains water such as an air-conditioner.
8. Ventilation — The vents and other openings in the cabinet are designed for ventilation.
Do not cover or block these vents and openings since insufcient ventilation can cause overheating and/or shorten the life
of the product. Do not place the product on a sofa, rug or other similar surface, since they can block ventilation openings.
Do not place the product in an enclosed place such as a bookcase or rack, unless proper ventilation is provided or the
manufacturer’s instructions are followed.
9. Power cord protection — The power cords must be routed properly to prevent people from stepping on them or objects from
resting on them.
10. The screen used in this product is made of glass. Therefore, it can break when the product is dropped or applied with
impact. Be careful not to be injured by broken glass pieces in case the screen breaks.
11. Overloading — Do not overload AC outlets or extension cords. Overloading can cause re or electric shock.
12. Entering of objects and liquids — Never insert an object into the product through vents or openings. High voltage ows in
the product, and inserting an object can cause electric shock and/or short internal parts.
For the same reason, do not spill water or liquid on the product.
13. Servicing — Do not attempt to service the product yourself. Removing covers can expose you to high voltage and other
dangerous conditions. Request a qualied service person to perform servicing.
14. Repair — If any of the following conditions occurs, unplug the power cord from the AC outlet, and request a qualied service
person to perform repairs.
a. When the power cord or plug is damaged.
b. When a liquid was spilled on the product or when objects have fallen into the product.
c. When the product has been exposed to rain or water.
d. When the product does not operate properly as described in the operating instructions.
Do not touch the controls other than those described in the operating instructions. Improper adjustment of controls
not described in the instructions can cause damage, which often requires extensive adjustment work by a qualied
technician.
e. When the product has been dropped or damaged.
f. When the product displays an abnormal condition. Any noticeable abnormality in the product indicates that the product
needs servicing.
15. Replacement parts — In case the product needs replacement parts, make sure that the service person uses replacement
parts specied by the manufacturer, or those with the same characteristics and performance as the original parts. Use of
unauthorized parts can result in re, electric shock and/or other danger.
16. Safety checks — Upon completion of service or repair work, request the service technician to perform safety checks to
ensure that the product is in proper operating condition.
17. Wall mounting — When mounting the product on a wall, be sure to install the product according to the method
recommended by the manufacturer.
18. Heat sources — Keep the product away from heat sources such as radiators, heaters, stoves and other heat-generating
products (including ampliers).
DEAR ASUS CUSTOMER

5E
SAFETY PRECAUTIONS (Continued)
19. Usage of the monitor must not be accompanied by fatal risks or dangers that, could lead directly to death, personal injury,
severe physical damage or other loss, including nuclear reaction control in nuclear facility, medical life support system, and
missile launch control in a weapon system.
20. Do not touch the parts of the product or the AC adapter that become hot for long periods of time. Doing so may result in
low-temperature burns.
To maintain compliance with EMC regulations, use shielded cables to connect to the following terminals: HDMI input terminal
and DisplayPort input terminal.
If a monitor is not positioned in a sufciently stable location, it can be potentially hazardous due to falling. Many injuries,
particularly to children, can be avoided by taking simple precautions such as:
• Using xing devices like wall mount brackets recommended by the manufacturer.
• Only using furniture that can safely support the monitor.
• Ensuring the monitor is not overhanging the edge of the supporting furniture.
• Not placing the monitor on tall furniture (for example, cupboards or bookcases) without anchoring both the furniture and the
monitor to a suitable support.
• Not standing the monitors on cloth or other materials placed between the monitor and supporting furniture.
• Educating children about the dangers of climbing on furniture to reach the monitor or its controls.

6
E
- The TFT color LCD panel used in this monitor is made with
the application of high precision technology. However, there
may be minute points on the screen where pixels never light
or are permanently lit. Also, if the screen is viewed from
an acute angle there may be uneven colors or brightness.
Please note that these are not malfunctions but common
phenomena of LCDs and will not affect the performance of
the monitor.
- Do not display a still picture for a long period, as this could
cause a residual image.
- Never rub or tap the monitor with hard objects.
- Please understand that ASUSTeK COMPUTER Inc. bears
no responsibility for errors made during use by the customer
or a third party, nor for any other malfunctions or damage
to this product arising during use, except where indemnity
liability is recognized under law.
- This monitor and its accessories may be upgraded without
advance notice.
- Do not use the monitor where there is a lot of dust, where humidity
is high, or where the monitor may come into contact with oil or
steam. Do not use in an environment where there are corrosive
gases (sulfur dioxide, hydrogen sulde, nitrogen dioxide, chlorine,
ammonia, ozone, etc.). As this could lead to re.
- Ensure that the monitor does not come into contact with
water or other uids. Ensure that no objects such as paper
clips or pins enter the monitor as this could lead to re or
electric shock.
- Do not place the monitor on top of unstable objects or in
unsafe places. Do not allow the monitor to receive strong
shocks or to strongly vibrate. Causing the monitor to fall or
topple over may damage it.
- Do not use the monitor near heating equipment or in places
where there is likelihood of high temperature, as this may
lead to generation of excessive heat and outbreak of re.
- Do not use the monitor in places where it may be exposed
to direct sunlight.
- The AC outlet shall be installed near the equipment and
shall be easily accessible.
- Do not touch the screen when starting the LCD monitor.
If the screen is touched, the monitor may not function
correctly. In this situation, turn the LCD monitor off, wait at
least 5 seconds, and then turn on the monitor again.
- Do not use in applications where water or other uid may
adhere to the screen. If uid adheres to the screen, the
touch panel may not operate correctly.
- Do not use your nails, touch pens or digitizer pens other
than the one supplied, ASUS pencils, or other hard objects
to operate the unit.
- If the pen tip of the digitizer pen is worn or damaged,
replace the pen tip. Failure to do so may scratch the screen
or cause the digitizer pen functions to not operate correctly.
- Depending on the application you are using, the supplied
touch pen and digitizer pen may not function.
- If another USB device is connected to the computer to which
the touch panel is connected, do not operate the USB device
during touch panel input. Input may not take place correctly.
- Do not use liquid such as alcohol in cleaning the screen.
- Keep all cables off the touch panel. Not doing so may lead
to LCD monitor malfunctions.
- If used in a room (or location) with drastic temperature
differences, the display quality of the screen and the quality
of touch panel performance may decrease.
The Power Cord and AC Adapter
- Use only the power cord and AC adapter supplied with the monitor.
- When handling the AC adapter, observe the following:
Incorrect handling may result in re, electric shock, or injury.
• Do not drop the AC adapter or subject it to impact.
• Never disassemble the AC adapter. It contains high
voltage parts that are dangerous to touch.
• The AC adapter is for indoor use only. Do not use it
outside.
• Do not use the supplied AC adapter with other devices.
- Do not damage the power cord and AC adapter nor place
heavy objects on it, stretch it or over bend it. Also, do not
add extension cords. Damage to the cord may result in re
or electric shock.
- Do not use the power cord with a power tap.
Adding an extension cord may lead to re as a result of
overheating.
- Do not remove or insert the power plug with wet hands.
Doing so could result in electric shock.
- Unplug the power cord if it is not used for a long time.
- Do not attempt to repair the power cord if it is broken
or malfunctioning. Refer the servicing to the service
representative.
- Do not stay in contact with the parts of the product and the
AC adapter that become hot for long periods of time.
Doing so may result in low-temperature burns.
- For your health, observe the following:
• If using the monitor continuously, take a 10- to 15-minute
break every hour to rest your eyes.
• Do not use the monitor in high-contrast light conditions.
• Do not use the monitor in locations where the screen is
subject to direct sunlight.
Manual Scope
- This document is the operation manual for the PT201.
- Microsoft, Windows and Windows Vista are registered
trademarks of Microsoft Corporation.
- The terms HDMI and HDMI High-Denition Multimedia Interface,
and the HDMI Logo are trademarks or registered trademarks of
HDMI Licensing LLC in the United States and other countries.
- DisplayPort is a registered trademark of Video Electronics
Standards Association.
- Adobe, Acrobat, and Reader are either registered
trademarks or trademarks of Adobe Systems Incorporated
in the United States and/or other countries.
- All other brand and product names are trademarks or
registered trademarks of their respective holders.
- Language of OSD menu used in this manual is English by
way of example.
- Illustrations in this manual may not exactly represent the
actual product or display.
LED Backlight
● The LED backlight in this product has a limited lifetime.
* If the screen gets dark or does not turn on, it may be
necessary to replace the LED backlight. This LED backlight
is exclusive to this product and must be replaced by an
authorized ASUS servicing dealer or service center.
* Please contact your local ASUS servicing dealer or
service center for assistance.
TIPS AND SAFETY INSTRUCTIONS

7E
Supplied Components
If any component should be missing, please contact your dealer.
 Liquid Crystal Display Monitor: 1
 Power cord
 CD-ROM (Utility Disk): 1
 Digitizer pen: 1
 Digitizer pen cable clamper (clamper, xing screw: 1): 1
 Variable stand (stand, xing screws: 4, hexagonal wrench): 1
 AC adapter: 1
 USB cable (USB-microUSB Type B for touch panel): 1
 Setup Manual: 1
 Digitizer pen stand: 1
 Digitizer pen spare pen tips: 1
 DisplayPort cable: 1
Contents
IMPORTANT INFORMATION............................................3
Federal Communications Commission Interference
Statement.....................................................................3
DEAR ASUS CUSTOMER ................................................4
SAFETY PRECAUTIONS..................................................4
TIPS AND SAFETY INSTRUCTIONS ...............................6
Supplied Components.....................................................7
System Requirements .....................................................8
Part Names .......................................................................9
Connecting Devices ......................................................10
Connection with a PC.................................................10
Connecting USB devices ........................................... 11
Connecting the digitizer pen ...................................... 11
Binding Cables...............................................................12
Video cable and USB cable .......................................12
Digitizer pen cable......................................................12
Connecting the Monitor to a Power Source ................13
Installation......................................................................14
Installing on a stand
(Standing position) .....................................................14
Installing on a table
(Pen writing position/Horizontal position) ...................15
Turning Power On/Off....................................................16
Turning on the power .................................................16
Turning off the power .................................................16
Touch Actions ................................................................17
Touch action modes ...................................................17
Touch action ...............................................................17
Digitizer pen ...............................................................19
Other functions...........................................................20
Cautionary points .......................................................20
Monitor Settings ............................................................21
Menu operations ........................................................21
Menu functions...........................................................22
SETUP Menu Details .................................................23
Prohibiting operations (operation lock).......................24
Monitor status indicators ............................................25
Troubleshooting.............................................................26
Specications ...............................................................27

8
E
System Requirements
nTouch panel
To use the touch panel, the monitor must be connected to a computer using a USB cable.
Touch panel operating conditions are as described below.
Computer PC/AT compatible computer with a USB 1.1 port and able to output a resolution of 1920 x 1080.
OS Windows 8.1 (32-bit or 64-bit version), Windows 8 (32-bit or 64-bit version),
Windows 7 (32-bit or 64-bit version)
• Windows 7 or later is recommended for touch action.
• The digitizer pen can be used with Windows 7 or later.

9E
nFront view
1
1. Power LED (See page 16.)
Part Names
nRear view
123 3
4
5
7
8
10
9
11
6
1. VESA holes (See page 28.)
2. Anti-theft hole ( )
Allows the monitor to be secured using a commercially available anti-theft lock. The anti-theft hole is compatible with
Kensington’s MicroSaver security system.
3. Speakers
4. Power/Menu button (See page 16, page 21.)
5. Cable clamp (See page 12.)
6. USB terminal (See page 11.)
7. Digitizer pen connection terminal (See page 11.)
8. HDMI input terminal (See page 10.)
9. DisplayPort input terminal (See page 10.)
10. Touch panel terminal (See page 10.)
11. AC adapter connection terminal (See page 13.)

10
E
Connecting Devices
Caution
• Be sure to turn off the power and disconnect the plug from
the power outlet before connecting/disconnecting cables.
Also, read the manual of the equipment to be connected.
• Do not forcibly bend or apply force to cables. Doing so may
result in wire breakage or other damage.
• When connecting cables, spread a soft cloth on a stable
level surface such as a desk, and gently place the monitor
on it with the screen facing down.
• Do not use any cable that has a damaged or deformed
terminal. Using such cables may cause malfunctions.
• Connect USB devices that have the following thicknesses
around the connector area.
1/2 inch (12mm)
1-1/2 inch (38mm)
5/16 inch (8mm)
A
B
C
11/16 inch (17mm)
D
D
B
C
A
TIPS
• Images may not be displayed properly depending on the
computer (video card) to be connected.
• To use the digitizer pen, the necessary software must be
installed on the computer from the supplied CD-ROM.
• When connecting a USB device to the USB terminal, use
only USB devices with current consumption of 500mA or
lower.
Connection with a PC
Connect the monitor and a PC using the connection cable.
nInputting video and audio
HDMI input terminal
HDMI input terminal
Commercially available HDMI cable
(conforming to the HDMI standard)
To HDMI output
terminal on PC
Check the orientation of the connector and insert it horizontally
as far as it will go.
DisplayPort input terminal
DisplayPort input terminal
Commercially available DisplayPort cable
To DisplayPort output
terminal on PC
Check the orientation of the connector and insert it horizontally
as far as it will go.
TIPS
• The length of the signal cables or surrounding environment
may affect the image quality.
• The video from the terminal that has signal input is

11 E
displayed. In this state, even if a signal is input from the
other terminal, the display is not switched. To switch the
display, use [Input Select] on the menu screen. (See page
22.)
• If the LCD monitor is turned on when there are input signals
from both terminals, the video from the DisplayPort input
terminal is displayed (factory default).
nUsing the touch panel
To use the touch panel, connect the monitor to a USB port on
a PC using the supplied USB cable.
USB terminal
Touch panel terminal
Supplied USB cable
To USB port on PC
Check the orientation of the connector and insert it horizontally
as far as it will go.
Connecting USB devices
When using a commercially available mouse, keyboard, or
other device, connect the device to the USB port.
USB terminal
USB cable
Check the orientation of the connector and insert it horizontally
as far as it will go.
Connecting the digitizer pen
When using the supplied digitizer pen, connect the digitizer
pen cable.
Digitizer pen connection terminal
Digitizer pen cable
Check the orientation of the connector and insert it horizontally
as far as it will go.
Connecting Devices

12
E
Binding Cables
Caution
• When connecting cables, spread a soft cloth on a stable level surface such as a desk, and gently place the monitor on it with
the screen facing down.
Video cable and USB cable
Secure the video cable (HDMI or DisplayPort) and USB cable using the cable clamp.
1. Remove the cable clamp.
Cable clamp
2. Route the cables through the cable
restraint slot.
Cable restraint
slot
3. Push the cable clamp down into
place.
Cable clamp
Digitizer pen cable
You can secure the digitizer pen cable using the supplied clamper and xing screw.
1. Pass the digitizer pen cable through the ring of the clamper.
2. Attach the clamper using the xing screw.
Clamper
Digitizer pen cable
Fixing screw

13 E
Connecting the Monitor to a Power Source
Caution
• Use only the AC adapter and power cord supplied with the monitor.
1. Connect the monitor to the power outlet using the supplied AC adapter and power cord.
AC adapter core
Core restrainer
Back of monitor
AC adapter
connection terminal
Power cord
(Supplied)
AC adapter (Supplied)
For power
outlet
2. Push the AC adapter core into the core restrainer.

14
E
Installation
Installing on a stand
(Standing position)
Placement on the variable stand
Place the unit on the supplied variable stand.
Caution
• The variable stand is designed for placement of the unit in
the landscape orientation. It cannot be used for the portrait
orientation.
• When connecting the stand, spread a soft cloth on a stable
level surface such as a desk, and gently place the monitor
on it with the screen facing down.
• Applying excessive pressure to the LCD panel with your
hands may result in damage to the unit.
• Be careful not to get your ngers caught when adjusting the
angle. There is a risk of injury.
1. Place the variable stand on the rear of the monitor,
insert the xing screws and tighten by hand to position
the stand.
2. Securely tighten the xing screws using the supplied
hexagonal wrench.
3. Place the monitor in the standing position, and adjust
the angle of the stand.
Hold the top of the display with one hand so that it does not
fall over, hold the rear leg of the stand with your other hand,
and adjust the angle of the stand.
The legs can extend about 20 to 75 degrees in relation to
the at surface.
20°
75°

15 E
Installing on a table
(Pen writing position/Horizontal
position)
Remove the monitor from the stand and place face-down on a
table or other level surface.
Caution
• Do not exert a large amount of force on the monitor from
above. Doing so may damage the ap.
• After removing the monitor from the rack stand, store the
stand so that the screws will not be lost.
Pen writing position
Place the monitor on a table or other level surface.
1. Hold the ap by the depression on the back of the
monitor and pull the ap up.
Depression
2. Place the monitor where you want to use it.
Horizontal position
Place the monitor on a table or other level surface.
Caution
• When using the monitor horizontally, use the horizontal tab
in the upright position.
1. Lift up the two tabs on the back of the monitor.
2. Place the monitor where you want to use it.
Installation

16
E
Turning on the power
1. Press the POWER button.
Press
POWER button
Power LED
The power LED turns on.
2. Turn on the PC.
The screen appears.
Status Status of the monitor
Green lit Signal input
Orange lit No signal input
Alternately ashing red and
green Abnormal temperature
Caution
• When switching the POWER button off and back on,
always wait for an interval of at least 5 seconds. Rapid
switching may lead to errors or malfunctions.
• High temperatures inside the unit are indicated when the
Power LED is alternately ashing red and green, and may
lead to the power turning off automatically. (See page 26.)
• For a complete electrical disconnection, pull out the main
plug.
nOperation Mode
When the monitor is turned on for the rst time after being
shipped from the factory, the operation mode setting screen
will be displayed. Set it to ECO Mode or Normal Mode.
ECO Mode - If there is no operation for 4 hours or more, the
monitor automatically turns off the power.
Normal Mode - Will perform standard operation.
Even after being set, changes can be made using [Operation
Mode], located in the menu of the monitor.
Turning Power On/Off
Turning off the power
1. Turn off the PC.
2. Depress the POWER button for around 2 seconds.
Depress for around
2 seconds
POWER button
The power LED turns off.
Caution
• If the monitor will not be used for a long time, disconnect
the power plug from the power outlet.

17 E
Touch Actions
Touch action modes
There are three touch action modes: nger/pen mode, pen-
only mode, and nger-only mode. These modes can be
changed on the menu screen.
The monitor is set to nger/pen mode when shipped.
Caution
• Use the supplied pen in pen mode.
Finger/pen mode
You can perform touch actions with your ngers or pens
(digitizer pen).
Touch actions performed with a pen are given priority, and
any actions performed at the same time with your ngers
will be disabled. Pen actions have priority, even during hover
operations. (See page 19.)
Finger actions will be enabled again about 0.5 seconds after
you remove the pen from the screen.
Pen-only mode
This mode is for pen (digitizer pen) use only. You cannot touch
the screen with your nger. You can touch the menu screen
(See page 21) with your nger.
Finger-only mode
This mode is for nger use only. You cannot touch the screen
with the digitizer pen.
Touch action
Touch actions that can be used with this monitor differs from
operating system and application. The functions of touch
actions are also different. For details, check Windows Help
and the application’s support documentation.
OS
Touch action
Windows
8.1 / 8
Windows 7
Single-tap Yes Yes
Double-tap Yes Yes
Swipe Yes Yes
Swipe from edge of screen Yes No
Drag-and-drop Yes Yes
Slide to pan Yes Yes
Flicks Yes Yes
Press-and-hold Yes Yes
Zoom Yes Yes
Press-and-tap No Yes
Rotate Yes Yes
TIPS
• In Windows 7, if the checkmark has been removed from
“Enable multi-touch gestures and inking” in “Pen and touch”
in Control Panel, select the checkbox.
nActions common to ngers, digitizer
pens, and touch pens
Single-tap
Touch the screen with your nger/pen.
Double-tap
Quickly touch the screen twice with your nger/pen.
Swipe
Touch the screen with your nger/pen, move without lifting,
and then stop.
Swipe from edge of screen
After touching the edge of the screen with your nger/pen,
move horizontally without releasing your nger/pen and then
stop.

18
E
Drag-and-drop
Touch the screen with your nger/pen and move without lifting.
When you have nished the movement, lift your nger/pen.
Slide to pan
With your nger/pen touching the screen, move it up and
down to scroll the screen.
Flicks
Move your nger/pen in a icking motion.
Flick your nger
Press-and-hold
Press briey with your nger/pen, and then lift your nger/pen
from the screen.
nFinger actions
Zoom
While touching the screen with two ngers, move them closer
together and farther apart.
Pinch
Stretch
Press-and-tap
With one nger touching the screen, tap once (single tap) with
another nger.
With one nger touching
Tap once (single tap) with another nger
Rotate
While touching the monitor with one nger, move the other
nger in the direction you wish to rotate in.
With one nger touching
Move another nger in the desired direction of rotation
Touch Action

19 E
Digitizer pen
The PT201 monitor supports a digitizer pen. To use the
digitizer pen, the utility software must be installed and
congured. (See page 19.)
nDigitizer pen actions
Button operations
Function button 2
Function button 1
Pen tip
Function button 1: Pressing and holding this button and
touching the screen performs the same
action as a right-click on a mouse. (factory
default)
Function button 2: Pressing and holding this button while
moving the pen on the screen enables the
eraser function. (factory default)
You can change the functions that are assigned to the function
buttons using the digitizer pen utility.
Hover operations
The unit will recognize when the tip of the pen is hovering
within 15 mm of the screen, allowing you to position the
pointer without touching the screen.
TIPS
• The digitizer pen supports pen pressure functions. The pen
can be used with software that responds to pen pressure.
• The digitizer pen may not be recognized, depending on the
application, if you touch the display with the pen before the
hover operation is enabled. Verify that the hover operation
is enabled and then perform operations using the digitizer
pen.
• If the digitizer pen does not operate correctly, try placing
the tip of the pen vertically on the screen.
nDigitizer pen stand
Place the digitizer pen in the pen stand when it is not being
used.
Pen stand
Digitizer pen
You can wrap the digitizer pen cable around the digitizer pen
stand.
Bottom cover
Top cover
Pen tip
storage cap
Close the top cover and bottom cover as shown in the
following diagram.
Touch Action

20
E
nSpare pen tip storage
The pen stand features a pen tip storage area where you can
store spare pen tips.
TIPS
• Spare pen tips are not stored in the stand at the time of
purchase. Store the spare pen tips in the pen stand to
make sure you do not lose them.
1. Remove the spare pen tip storage cap.
Cap
Pen tip storage
2. Insert the spare pen tips into the holes in the pen tip
storage.
3. Reattach the cap.
nReplacing the digitizer pen tip
Replace the pen tip when it is worn or damaged. Using the
digitizer pen with a worn or damaged pen tip may scratch the
surface of the monitor, or may cause the digitizer pen function
to stop operating. Pen tips will wear with normal use.
Replace
when worn
down to
this level.
1. Unscrew the pen tip cover and remove it.
2. Pull out the pen tip.
3. Insert a new pen tip, and reattach the pen tip cover.
Other functions
In Windows 8.1/8, input panel functions can be used.
In Windows 7, touch pointer and input panel functions can be
used.
For information about the touch pointer and input panel
functions, see Windows Help.
Touch pointer :
A translucent image of a mouse appears near the point
touched. The left/right buttons of the image can be clicked
to perform the same actions as left/right clicking a mouse.
Input panel :
A software keyboard and an input panel with handwriting
recognition appear on the screen.
Windows 8.1/8 and Windows 7 (excluding Starter), the ink
function of Microsoft Ofce can be used.
Handwritten comments can be written, and handwriting can
be recognized using this function.
For details, see Microsoft Ofce Help.
Cautionary points
• When performing touch actions, use the ball of your nger.
• Use only the supplied digitizer pen or touch pen to perform
pen actions.
• Do not use the supplied pen for any purpose other than
touch panel operation.
• Do not press hard on the tip of the digitizer pen.
• If there is dirt or foreign matter on the tip of the digitizer
pen, remove it. Failure to do so may damage the screen.
• Even when in pen-only mode, the unit may respond to
objects other than the supplied digitizer pen.
• When performing pen actions with the supplied digitizer
pen, do not touch the screen with anything other than the
hand that is holding the pen.
Touch Action
