Asus VE205 L Series User manual

VE205xL/VE245xL/
VE246xL Series
LCD Monitor
User Guide

ii
Contents
Notices......................................................................................................... iii
Safety information ...................................................................................... iv
Care & Cleaning........................................................................................... v
1.1 Welcome! .................................................................................... 1-1
1.2 Package contents......................................................................... 1-1
1.3 Monitor introduction .................................................................... 1-2
1.3.1 Front view ....................................................................... 1-2
1.3.2 Back view........................................................................ 1-3
2.1 Assembling the monitor base..................................................... 2-1
2.2 Adjusting the monitor.................................................................. 2-1
2.3 Detaching the arm/base (for VESA wall mount)........................ 2-2
2.4 Connecting the cables................................................................. 2-3
2.5 Turning on the monitor................................................................ 2-4
3.1 OSD (On-Screen Display) menu ................................................ 3-1
3.1.1 How to reconfigure.......................................................... 3-1
3.1.2 OSD Function Introduction.............................................. 3-1
5RGEKſECVKQPUUWOOCT[............................................................. 3-4
3.3 Troubleshooting (FAQ).............................................................. 3-12
3.4 Supported operating modes ..................................................... 3-13

iii
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with manufacturer’s
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the graphics card is
required to assure compliance with FCC regulations. Changes or modifications
to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.
As an Energy Star®Partner, our company has determined that this product meets
the Energy Star®guidelines for energy efficiency.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the
Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.

iv
Safety information
• Before setting up the monitor, carefully read all the documentation that came
with the package.
• To prevent fire or shock hazard, never expose the monitor to rain or moisture.
• Never try to open the monitor cabinet. The dangerous high voltages inside the
monitor may result in serious physical injury.
• If the power supply is broken, do not try to fix it by yourself. Contact a qualified
service technician or your retailer.
• Before using the product, make sure all cables are correctly connected and the
power cables are not damaged. If you detect any damage, contact your dealer
immediately.
• Slots and openings on the back or top of the cabinet are provided for
ventilation. Do not block these slots. Never place this product near or over a
radiator or heat source unless proper ventilation is provided.
• The monitor should be operated only from the type of power source indicated
on the label. If you are not sure of the type of power supply to your home,
consult your dealer or local power company.
• Use the appropriate power plug which complies with your local power
standard.
• Do not overload power strips and extention cords. Overloading can result in
fire or electric shock.
• Avoid dust, humidity, and temperature extremes. Do not place the monitor in
any area where it may become wet. Place the monitor on a stable surface.
• Unplug the unit during a lightning storm or if it will not be used for a long period
of time. This will protect the monitor from damage due to power surges.
• Never push objects or spill liquid of any kind into the slots on the monitor
cabinet.
• To ensure satisfactory operation, use the monitor only with UL listed
computers which have appropriate configured receptacles marked between
100-240V AC.
• If you encounter technical problems with the monitor, contact a qualified
service technician or your retailer.
This symbol of the crossed out wheeled bin indicates that the product (electrical,
electronic equipment, and mercury-containing button cell battery) should not
be placed in municipal waste. Please check local regulations for disposal of
electronic products.

v
Care & Cleaning
• Before you lift or reposition your monitor, it is better to disconnect the cables
and power cord. Follow the correct lifting techniques when positioning the
monitor. When lifting or carrying the monitor, grasp the edges of the monitor.
Do not lift the display by the stand or the cord.
• Cleaning. Turn your monitor off and unplug the power cord. Clean the monitor
surface with a lint-free, non-abrasive cloth. Stubborn stains may be removed
with a cloth dampened with mild cleaner.
• Avoid using a cleaner containing alcohol or acetone. Use a cleaner intended
for use with the LCD. Never spray cleaner directly on the screen, as it may drip
inside the monitor and cause an electric shock.
The following symptoms are normal with the monitor:
• The screen may flicker during the initial use due to the nature of the fluorescent
light. Turn off the Power Switch and turn it on again to make sure that the
flicker disappears.
• You may find slightly uneven brightness on the screen depending on the
desktop pattern you use.
• When the same image is displayed for hours, an afterimage of the previous
screen may remain after switching the image. The screen will recover slowly or
you can turn off the Power Switch for hours.
• When the screen becomes black or flashes, or cannot work anymore, contact
your dealer or service center to fix it. Do not repair the screen by yourself!
Conventions used in this guide
WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when
trying to complete a task.
IMPORTANT: Information that you MUST follow to complete a task.
NOTE: Tips and additional information to aid in completing a task.

vi 9JGTGVQſPFOQTGKPHQTOCVKQPRefer to the following sources for additional information and for product and
software updates.
1. ASUS websites
The ASUS websites worldwide provide updated information on ASUS
hardware and software products. Refer to http://www.asus.com
2. Optional documentation
Your product package may include optional documentation that may have
been added by your dealer. These documents are not part of the standard
package.

1-1ASUS VE205xL/VE245xL/VE246xL Series LCD Monitor
1.1 Welcome!
Thank you for purchasing the ASUS®LCD monitor!
The latest widescreen LCD monitor from ASUS provides a crisper, broader, and
brighter display, plus a host of features that enhance your viewing experience.
With these features, you can enjoy the convenience and delightful visual
experience that the monitor brings you!
1.2 Package contents
Check your package for the following items:
LCD monitor
Monitor base and screw
Warranty card
Quick start guide
1 x Power cord
1 x VGA cable
1 x DVI cable
1 x Audio cable
If any of the above items is damaged or missing, contact your retailer
immediately.

1-2 Chapter 1: Product introduction
1.3 Monitor introduction
1.3.1 Front view
VE245HL/
VE246HL
VE245TL/
VE205TL/
VE205SL
VE245NL/
VE205NL/
VE205DL
1
S/A Volume/Down Menu Brightness/Up Input Select Power Key
S Volume/Down Menu Brightness/Up A Power Key
SContrast/Down Menu Brightness/Up APower Key
2 643 5 1
1. , , Button:
Use this hotkey to switch from five video preset modes (Standard Mode,
Theater Mode, Game Mode, Night View Mode, Scenery Mode) with
SPLENDID™ Video Enhancement Technology. ( , )
Exit the OSD menu or go back to the previous menu as the OSD menu
is active. ( , )
Automatically adjust the image to its optimized position, clock, and phase by
pressing this button for 2-4 seconds (for VGA mode only.) ( , )
2. , Button:
Press this button to decrease the value of the function selected or move
left/down to the previous function.
This is also a hotkey for Volume adjustment. ( )
This is also a hotkey for Contrast adjustment. ( )
3. MENU Button:
Turns on the OSD menu.
•
•
•
•
•
•
•

1-3ASUS VE205xL/VE245xL/VE246xL Series LCD Monitor
Press this button to enter/select the icon (function) highlighted while the
OSD is activated.
4. Button:
Press this button to increase the value of the function selected or move
right/up to the next function.
This is also a hotkey for Brightness adjustment.
5. Button:
Press this button to cycle through the available input sources.
Press (Input Select button) to display HDMI signals after you connect
HDMI cable with the monitor.
6. Power button/power indicator
Press this button to turn the monitor on/off
The color definition of the power indicator is as the below table.
Status Description
Blue ON
Amber Standby mode
OFF OFF
1.3.2 Back view
VE245TL
VE245NL
VE245HL/
VE246HL
VE205
2 1 3 4 5 6 11 2 5 6
•
•
•
•
•
•
Sc re w ho le s for
VESA wall mount
Rear connectors
Kensi ngto n lock
slot

1-4 Chapter 1: Product introduction
Rear connectors 2NGCUGTGHGTVQ5RGEKſECVKQPUUWOOCT[HQTOQFGNU1. Audio-in port. This port connects PC audio source by the bundled audio
cable.
2. AC-IN port. This port connects the power connector from the bundled power
cord.
3. Earphone jack
4. HDMI port. This port is for connection with an HDMI device.
5. DVI port. This 24-pin port is for PC (Personal Computer) DVI-D digital signal
connection.
6. VGA port. This 15-pin port is for PC VGA connection.
The VESA wall mount kit (100 mm x 100 mm) is purchased separately.

2-1ASUS VE205xL/VE245xL/VE246xL Series LCD Monitor
2.1 Assembling the monitor base
To assemble the monitor base:
1. Have the monitor base place on a table.
2. Connect the base with the arm according to the below drawing. A click sound
shows that the base has been connected successfully.
3. Remove the fixing pin on the monitor stand.
4. To disassemble the monitor base, insert the fixing pin on the monitor stand,
press and hold the release button, and then remove the base from the
monitor.
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
2.2 Adjusting the monitor
For optimal viewing, we recommend that you look at the full face of the
monitor, then adjust the monitor to the angle that is most comfortable for you.
Hold the stand to prevent the monitor from falling when you change its angle.
<RXFDQDGMXVWWKHPRQLWRUVDQJOHIURPWRIt is normal that the monitor slightly shakes while you adjust the the viewing
angle.
•
•
•

2-2 Chapter 2: Setup
2.3 Detaching the arm/base
(for VESA wall mount)
The detachable arm/base of this LCD monitor is specially designed for VESA wall
mount.
To detach the arm/base:
1. Have the front of the monitor face down on a table.
2. Remove the rubbers in the four screw holes (Figure 1).
3. Use a screwdriver to remove the two screws on the arm (Figure 2), then slide
out the arm/base to detach it from the monitor (Figure 2).
Figure 1 Figure 2
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.

2-3ASUS VE205xL/VE245xL/VE246xL Series LCD Monitor
2.4 Connecting the cables
1. Connect the cables as the following instructions:
VGA
Earphone jack
HDMI
Audio-in Audio-inAudio-in
VE245TL
VE245NL
VE245HL/
VE246HL
VE205
VGA
To connect the audio cable: connect one end of the audio cable to the
monitor’s Audio-in port, the other end to the computer's audio-out port.
To connect the power cord: connect one end of the power cord securely to
the monitor’s AC input port, the other end to a power outlet.
To connect the VGA/DVI/HDMI cable:
Plug the VGA/DVI/HDMI connector to the LCD monitor’s VGA/DVI/HDMI
port.
Connect the other end of the VGA/DVI/HDMI cable to your computer's
VGA/DVI/HDMI.
Tighten the two screws to secure the VGA/DVI connector.
To use earphones: connect the end with plug type to the monitor’s earphone
jack.
When these cables are connected, you can choose the desired signal from the
Input Select item of the OSD functions.
2. Gather all the cables with the cable management slot.
•
•
•
a.
b.
c.
•
Cable management
slot

2-4 Chapter 2: Setup
2.5 Turning on the monitor
Gently press the power button
. See page 1-3 for the location of the power button.
The power indicator lights up in blue to show that the monitor is ON.

3-1ASUS VE205/VE245/VE246 Series LCD Monitor
3.1 OSD (On-Screen Display) menu
*QYVQTGEQPſIWTGPress the MENU button to activate the
OSD menu.
1.
Press (or ), and to navigate through the functions.
Highlight and activate the desired function by pressing the MENU button. If
the function selected has a sub-menu, press (or ), and
again to navigate through the sub-menu functions. Highlight and activate the
desired sub-menu function by pressing the MENU button.
Press (or ), and to change the settings of the selected
function.
To exit the OSD menu, press the or button. Repeat step 2 and step
3 to adjust any other function.
3.1.2 OSD Function Introduction
Spendid
This function contains five sub-functions
you can select for your preference. Each
mode has the Reset selection, allowing
you to maintain your setting or return to the
preset mode.
1.
Scenery Mode: best choice for scenery photo display with SPLENDID™
Video Enhancement.
Standard Mode: best choice for document editing with SPLENDID™
Video Enhancement.
Theater Mode: best choice for movie with SPLENDID™ Video
Enhancement.
Game Mode: best choice for game playing with SPLENDID™ Video
Enhancement.
Night View Mode: best choice for dark-scene game or movie with
SPLENDID™ Video Enhancement.
In the Standard Mode, the Saturation and Sharpness functions are not
user-configurable.
In the other modes, the sRGB function is not user-configurable.
•
•
2.
3.
4.
•
•
•
•
•

3-2 Chapter 3: General Instruction
2. Image
You can adjust brightness, contrast,
sharpness, saturation, position (VGA only),
and focus (VGA only) from this menu.
Brightness: the adjusting range is from 0 to 100. is a hotkey to
activate this function.
Contrast: the adjusting range is from 0 to 100.
ASCR: turns on/off the ASCR (ASUS Smart Contrast Ratio) function.
Sharpness: the adjusting range is from 0 to 100.
Saturation: the adjusting range is from 0 to 100.
Position: adjusts the horizontal position (H-Position) and the vertical
position (V-Position) of the image. The adjusting range is from 0 to 100.
Focus: reduces Horizonal-line noise and Vertical-line noise of the image
by adjusting (Phase) and (Clock) separately. The adjusting range is from
0 to 100.
Phase adjusts the phase of the pixel clock signal. With a wrong phase
adjustment, the screen shows horizontal disturbances.
Clock (pixel frequency) controls the number of pixels scanned by one
horizontal sweep. If the frequency is not correct, the screen shows vertical
stripes and the image is not proportional.
•
•
3. Color
Select the image color you like from this
function.
Color Temp.: contains five color modes including Cool, Normal, Warm,
sRGB, and User mode.
Skin Tone: contains three color modes including Reddish, Natural, and
Yellowish.
In the User mode, colors of R (Red), G (Green), and B (Blue) are user-
configurable; the adjusting range is from 0-100.
•
•
•
•
•
•
•
•
•

3-3ASUS VE205/VE245/VE246 Series LCD Monitor
4. Input Select
In this function, you can select your
desired input source.
5. System Setup
Allow you to adjust the system.
Volume: the adjusting range is from 0 to 100. is a hotkey to
activate this function.
Aspect Control: adjusts the aspect ratio to full or 4:3.
OSD Setup:
Adjusts the horizontal postition (H-Position)/the vertical position
(V-Position) of the OSD from 0 to 100.
Adjusts the OSD timeout from 10 to 120.
Enables or disables the DDC/CI function.
Language: there are 11 languages for your selection, including English,
German, Italian, French, Dutch, Spanish, Russian, Traditional Chinese,
Simplified Chinese, Japanese, and Korean.
Information: shows the monitor information.
All Reset: “Yes” allows you to restore the default setting.
•
•
•
*
*
*
•
•
•

3-4 Chapter 3: General Instruction
6SHFL¿FDWLRQVVXPPDU\9(+/Panel Type TFT LCD
Panel size 24" (16:9) wide screen
Max. Resolution 1920 x 1080
Pixel pitch 0.27675 mm
Brightness (Typ.) 250 cd/m2
Contrast Ratio (Typ.) 1000:1
Contrast Ratio (Max.) 50000:1 (with ASCR on)
Viewing angle(H/V) CR>10 /160Display colors 16.7 M
Response time 2 ms
SPLENDID™ Video
Enhancement
Yes
SPLENDID™ selection 5 video preset modes (by hotkey)
Auto adjustment Yes (by hotkey)
Color temperature selection 5 color temperatures
Skin-Tone selection 3 skin-tones
Digital input DVI-D with HDCP; HDMI v1.3
Analog input D-Sub
Audio-in port 3.5 mm Mini-jack
Earphone jack Yes
Colors Black
Speaker (Built-in) 1 W x 2 Stereo, RMS
Power LED Blue (On)/ Amber (Standby)
VESA wall mount 100 x 100 mm
Tilt -5~+20Kensington lock Yes
Voltage rating AC: 100~240V
Power consumption Power On : < 35 W, Standby: < 1 W, Power Off: <1 W
Temperature (Operating) 0C~40C
Temperature (Non-
operating)
-20C~+60C
Dimension (W x H x D) 570 mm x 342 mm x 214 mm (machine)
640 mm x 494 mm x 185 mm (package)
Weight (Esti.) 5.31 kg (Net) ; 7.3 kg (Gross)
Multi-languages 11 languages (English, German, Italian, French, Dutch,
Spanish, Russian, Traditional Chinese, Simplified
Chinese, Japanese, Korean)
Accessories VGA cable, DVI cable, audio cable, power cord, quick
start guide, warranty card
Regulation approvals Energy Star®, CB, CE, Gost-R, CCC, UL/cUL, FCC,
C-Tick, BSMI, VCCI, RoHS, WEEE, PSB, J-MOSS, KC,
EuP, TCO03, ISO 9241-307
5RGEKſECVKQPUCTGUWDLGEVVQEJCPIGYKVJQWVPQVKEG

3-5ASUS VE205/VE245/VE246 Series LCD Monitor
6SHFL¿FDWLRQVVXPPDU\9(+/Panel Type TFT LCD
Panel size 24" (16:9) wide screen
Max. Resolution 1920 x 1080
Pixel pitch 0.27675 mm
Brightness (Typ.) 250 cd/m2
Contrast Ratio (Typ.) 1000:1
Contrast Ratio (Max.) 50000:1 (with ASCR on)
Viewing angle(H/V) CR>10 /160Display colors 16.7 M
Response time 5 ms
SPLENDID™ Video
Enhancement
Yes
SPLENDID™ selection 5 video preset modes (by hotkey)
Auto adjustment Yes (by hotkey)
Color temperature selection 5 color temperatures
Skin-Tone selection 3 skin-tones
Digital input DVI-D with HDCP; HDMI v1.3
Analog input D-Sub
Audio-in port 3.5 mm Mini-jack
Earphone jack Yes
Colors Black
Speaker (Built-in) 1 W x 2 Stereo, RMS
Power LED Blue (On)/ Amber (Standby)
VESA wall mount 100 x 100 mm
Tilt -5~+20Kensington lock Yes
Voltage rating AC: 100~240V
Power consumption Power On : < 35 W, Standby: < 1 W, Power Off: <1 W
Temperature (Operating) 0C~40C
Temperature
(Non-operating)
-20C~+60C
Dimension (W x H x D) 570 mm x 342 mm x 214 mm (machine)
640 mm x 494 mm x 185 mm (package)
Weight (Esti.) 5.31 kg (Net) ; 7.3 kg (Gross)
Multi-languages 11 languages (English, German, Italian, French, Dutch,
Spanish, Russian, Traditional Chinese, Simplified
Chinese, Japanese, Korean)
Accessories VGA cable, DVI cable, audio cable, power cord, quick
start guide, warranty card
Regulation approvals Energy Star®, CB, CE, Gost-R, CCC, UL/cUL, FCC,
C-Tick, BSMI, VCCI, RoHS, WEEE, PSB, J-MOSS, KC,
EuP, TCO03, ISO 9241-307
5RGEKſECVKQPUCTGUWDLGEVVQEJCPIGYKVJQWVPQVKEG

3-6 Chapter 3: General Instruction
6SHFL¿FDWLRQVVXPPDU\9(7/Panel Type TFT LCD
Panel size 24" (16:9) wide screen
Max. Resolution 1920 x 1080
Pixel pitch 0.27675 mm
Brightness (Typ.) 250 cd/m2
Contrast Ratio (Typ.) 1000:1
Contrast Ratio (Max.) 50000:1 (with ASCR on)
Viewing angle(H/V) CR>10 /160Display colors 16.7 M
Response time 5 ms
SPLENDID™ Video
Enhancement
Yes
SPLENDID™ selection 5 video preset modes (by hotkey)
Auto adjustment Yes (by hotkey)
Color temperature selection 5 color temperatures
Skin-Tone selection 3 skin-tones
Digital input DVI-D with HDCP
Analog input D-Sub
Audio-in port 3.5 mm Mini-jack
Earphone jack No
Colors Black
Speaker (Built-in) 1 W x 2 Stereo, RMS
Power LED Blue (On)/ Amber (Standby)
VESA wall mount 100 x 100 mm
Tilt -5~+20Kensington lock Yes
Voltage rating AC: 100~240V
Power consumption Power On : < 35 W, Standby: < 1 W, Power Off: <1 W
Temperature (Operating) 0C~40C
Temperature
(Non-operating)
-20C~+60C
Dimension (W x H x D) 570 mm x 342 mm x 214 mm (machine)
640 mm x 494 mm x 185 mm (package)
Weight (Esti.) 5.31 kg (Net) ; 7.3 kg (Gross)
Multi-languages 11 languages (English, German, Italian, French, Dutch,
Spanish, Russian, Traditional Chinese, Simplified
Chinese, Japanese, Korean)
Accessories VGA cable, DVI cable, audio cable, power cord, quick
start guide, warranty card
Regulation approvals Energy Star®, CB, CE, Gost-R, CCC, UL/cUL, FCC,
C-Tick, BSMI, VCCI, RoHS, WEEE, PSB, J-MOSS, KC,
EuP, TCO03, ISO 9241-307
5RGEKſECVKQPUCTGUWDLGEVVQEJCPIGYKVJQWVPQVKEG
