AT&T PagePac Plus AmpliCenter Quick start guide

463-248-202
Issue 1
3/16/93
PagePacPlus AmpliCenter
Installation and Use

Copyright 1993 Harris Dracon
All Rights Reserved
Written/Printed in U.S.A.
AT&T 463-248-202
0II722051-300
Issue 1, March 1993
Notice
Every effort was made to ensure that the information in this guide was complete and accurate at the time of printing.
However, information is subject to change.
Federal Communications Commission (FCC) Interference Notice and Canadian Dept. of Communications
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15
of the FCC rules and D.O.C. regulations. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instruction guide, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to clause
harmful interference, in which case the user will have to correct the interference at his or her own expense. For
repair information, see section 4, Maintenance and Customer Support, and for additional FCC interference and
registration information, see appendix A, FCC Statement and Warranty Information, in this manual.
Trademarks
PAGEPAC, PAGEPAC PLUS and AMPLICENTER are trademarks of Harris Corporation. Centrex is a registered
trademark of AT&T.
Warranty
AT&T provides a limited warranty for this product. Refer to ''AT&T Limited Warranty and Limitation of
Liability" in appendix A.
Ordering Information
The order number for this book is 463-248-202. To order copies of this book, call 1-800-432-6600 in the U.S. and
1-800 255-1242 in Canada. For more information on how to order this and other system reference materials, see
"Reference Materials," in "About This Guide." For information on ordering replacement parts, accessories, and
other compatible equipment refer to "Ordering Information," in section 1.
Support Telephone Numbers
AT&T provides a toll-free customer Helpline 24 hours a day,
In the U.S., call the AT&T Helpline at 1-800-628-2888 if you need assistance when installing, programming, or
using your system. For service or technical assistance in Canada call one of the following Technical Assistance
Centers:
Eastern Canada and Ottawa: 1-800-363-1882
Ontario:
1-800-387-4268
Central and Western Canada 1-800-663-9817
VG—3193-2.2M

Contents
1. Overview
1-1
■
■
■
■
■
■
■
■
■
■
■
■
■
About This Guide
How to Use This Guide
Before You Start
Installation Steps
Connectivity Chart
Product Safety Labels
Terminology
Reference Materials
How to Comment on This Guide
Shipping Container Contents
Ordering Information
Features and Capabilities
Specifications
1-2
1-2
1-2
1-3
1-4
1-6
1-6
1-6
1-6
1-7
1-8
1-9
1-10
2. Hardware Configuration 2-1
■
■
■
■
■
■
Power
2-2
Circuit Protection
2-2
Mounting
2-2
Universal Approvals
2-3
Controls and Indicators, Terminals and Connectors 2-3
Auxiliary Equipment
2-5
iii

3. Installing the Hardware 3-1
■
■
■
■
■
■
■
Important Safety Information
Example System Setup
Mounting PagePac Plus AmpliCenter
Connecting Speakers
Telephone System Interface
Music Source Interface
System Testing
3-2
3-3
3-6
3-8
3-9
3-11
3-13
4. Maintenance and Customer Support 4-1
■
■
■
■
■
In Case of Difficulty
4-2
Power Failure Operation 4-3
Common Problems
4-3
Troubleshooting
4-3
Electrical Block Diagram
4-5
A. FCC Statement and Warranty Information A-1
B. Feedback Form B-1
IN. Index IN-1
iv

Tables
1. Overview
1-1
1-1. PagePac Plus Connectivity Chart
1-4
1-2. AmpliCenter Specifications
1-10
2. Hardware Configuration
2-1. Controls and Indicators, Terminals and Connectors
2-1
2-4
v

Figures
1.
Overview
1-1
1-1. Installation Steps
1-3
1-2. AmpliCenter Components
1-7
1-3. PagePac Plus AmpliCenter
1-9
2. Hardware Configuration 2-1
2-1. AmpliCenter Controls and Indicators,
Terminals and Connectors
2-3
3.
Installing the Hardware 3-1
3-1.
3-2.
3-3.
3-4.
3-5.
3-6.
3-7.
AmpliCenter Interface with PagePac Plus Controller
3-4
Series AmpliCenters, without Controller
3-5
Wall Mounted Hardware 3-6
Rack Mounted Hardware
3-7
Speaker Run Method
3-8
AmpliCenter Interconnection to Telephone System
or to Controller 3-10
Music Input Connections
3-12
4. Maintenance and Customer Support
4-1
4-1. AmpliCenter Electrical Block Diagram
4-5
vi

Overview
Contents
About This Guide
How to Use This Guide
Before You Start
Installation Steps
Connectivity Chart
Product Safety Labels
Terminology
Reference Materials
How to Comment on this Guide
Shipping Container Contents
Ordering Information
Features and Capabilities
Specifications
1-2
1-2
1-2
1-3
1-4
1-6
1-6
1-6
1-6
1-7
1-8
1-9
1-10
Overview 1-1

About This Guide
The PagePac Plus AmpliCenter Installation and Use Manual explains the
features of the AmpliCenter, how to install and configure the AmpliCenter,
and interface to a communication system and other auxiliary equipment.
It is intended that PagePac Plus be installed by a trained telephone, audio,
or electrical installer with basic electronic knowledge. PagePac Plus
conforms to common installation practices and preferences found within
the Telcom Electrical and Commercial Sound installers manual.
How to Use This Guide
■
■
■
■
Overview. This section provides an overview of AmpliCenter features
and capabilities, specifications, and a summary of installation steps for
the experienced installer.
If you are installing the PagePac Plus AmpliCenter for the first time,
you should read this entire guide before getting started to familiarize
yourself with the features.
Hardware Configuration. This section describes and illustrates the
AmpliCenter D20, D100, and D300 units.
Installing the Hardware. This section provides instructions for
mounting the PagePac Plus AmpliCenter hardware on a wall or in a
standard 19" equipment rack. Complete, detailed instructions for
connection and operation with telephone systems, music source,
speakers, and any control device inputs or outputs is provided.
Maintenance and Customer Support. This section gives some basic
troubleshooting tips if a paging zone does not operate properly after
connection to the AmpliCenter. Should a problem arise which requires
technical assistance, call AT&T technical support groups at the
numbers listed in this section.
Use the Contents and Index to locate specific items of interest.
Before You Start
Before installing your system, read and understand the safety instructions
in section 3. Be sure you have all the necessary parts— see Shipping
Container Contents, below. In addition, see Tools Required in section 3
for a few tools and test equipment that will be needed for installation.
1-2 Overview

Installation Steps
NOTE: The numbers in these
steps match the numbers in
figure 1-1.
1.
2.
3.
4.
5.
6.
7.
Mount the PagePac Plus AmpliCenter to either the wall, cabinet or a
rack.
Pull cables.
Hookup cabling to AmpliCenter and auxiliary equipment. (Refer to
Example Setups in section 3.) Use stick-on labels to identify the
AmpliCenter/zone (i.e., cafeteria - zone 1).
Set the AmpliCenter Telephone Mode Selection Switch to match the
host telephone system and make connection.
Install power cord and plug into outlet.
Test paging zone served by the AmpliCenter. (Refer to Testing the
System, in section 3.)
Adjust sound levels using AmpliCenter controls. (Refer to
Adjustments, in section 4.)
TO HOST TEL.
SYSTEM
MUSIC INPUT
Figure 1-1. Installation Steps
Overview 1-3

Connectivity Chart
The Connectivity chart gives the trunk interface requirements for the host
systems listed. This information is then used to set the telephone mode
function switch on the PagePac Plus AmpliCenter.
Table 1-1. PagePac Plus Connectivity Chart
Merlin Plus
Merlin 206/820
Merlin 1030/3070
Merlin II Merlin Legend
Mode
C.O.
Line
Page
Port
C.O.
Line
Page
Module
C.O.
Line
Service
Module
C.O.
Line
Analog
Station
C.O.
Line
Analog
Station
Loop
Start Yes
Note 1
—
—
—
Ground
Start 3
—
—
—
—
Yes
Note 1
—
—
—
—
—
—
—
Yes
Note 1
—
—
—
—
—
—
—
Yes
Note 1
—
—
—
—
—
—
—
Yes
—
—
—
—
—
—
—
Dry
Loop
(Hi Z)
Dry
Loop
(600 Ω)
Spirit 308/616 Spirit
1224/2448
Partner Partner II
Partner Plus
Mode
C.O. Line
Page Port
C.O. Line
C.O. Line
Analog
Station
C.O. Line
Analog
StationPage
Port
Loop Yes —
Yes Yes —
Yes
— —
Start
Ground
————————
Start 3
Dry
—— — ————
Loop
—
(Hi Z)
Dry
—
No
——— — —
Yes
Loop
Note 2
(600 Ω)
1-4 Overview

Table 1-1. PagePac Plus Connectivity Chart (Continuation Page 1)
System 25
System 75/G1/G3I Definity
System 85/G2
Mode
C.O. Line
Analog
Station
Aux.
PortC.O. Line
Analog
Station
Aux. Port
C.O.
Line Analog Station Aux.
Port
Loop Yes ——Yes ——
Yes
— —
Start
Ground
Yes ——Yes ——
Yes — —
Start
3
Dry
— — — — — — — ——
Loop
(HI Z)
Dry Yes Yes Yes
Loop Note 2 Note 2
Note 2
(600 Ω)
— Indicates a non applicable connection
Comkey 416, 718
1434 and 2152 HorizonDimension
Mode
C.O. Line
Intercom
C.O. Line
Analog
Station
Intercom
C.O. Line
Analog
Station
Aux.
Port
Loop
Start
Ground
Start
3
Dry
Loop
(HI Z)
Dry
Loop
(600
Ω)
Yes —
Yes
——
Yes
———
—
No
—
——
——
Yes —
—
No
Yes — —
Yes
— —
—
Yes —
— —
Yes
Note 2
NOTES:
1. Two pound keys (##) must be pressed for one pound key (#) to be sent to the AmpliCenter when dialing
from a multi-button set.
2. A 2 pair RJ-11 cord must be used to interface with the AmpliCenter.
3. Ground Start trunk for tel. system must share a common ground with AmpliCenter page input ground.
Overview 1-5

Product Safety Labels
This guide contains several product safety labels, identified by a
CAUTION - Indicates the presence of a hazard that will or can cause
minor personal injury or property damage if the hazard is not avoided.
WARNING - Indicates the presence of a hazard that can cause
severe or fatal personal injury if the hazard is not avoided.
Carefully read all WARNING labels. Opening the system modules will
expose you to hazardous voltages, which can cause severe personal
injury or death. Also, read "Important Safety Information" at the beginning
of Section 3, Installation.
Terminology
This guide uses standard telephony, audio, and electronics terminology
used in describing paging features, hardware, and telecommunication
system interface.
Reference Materials
For related product information, refer to the PagePac Plus Programming
and Operation Guide. Also, see the PagePac Plus Controller Installation
and Use Guide and Zone Expansion Unit Installation and Use Manual for
specific information on those products.
To order additional reference materials
Information Center:
In the U.S. 1-800-432-6600
In Canada: 1-800-255-1242
How to Comment on This Guide
call the AT&T Customer
A feedback form is located at the end of this guide. If the feedback form is
missing, send your comments and recommendations for changes to:
A. Sherwood
AT&T
99 Jefferson Road (Room 2A-25)
Parsippany, NJ 07054
FAX: [phone]
1-6 Overview

Shipping Container Contents
The following items should be found in the PagePac Plus AmpliCenter
shipping container.
■ AmpliCenter module
■ Rack mounting hardware (4 Phillips 10-32 screws)
■ Power Cord
■ This Installation and Use guide
AMPLICENTER D20, D100, D300
FOUR MOUNTING SCREWS
INSTALLATION MANUAL
AmpliCenter
Installation and Use
POWER CORD
Figure 1-2. AmpliCenter Components
Overview 1-7

Ordering Information
Equipment is available from many AT&T sources. Contact any of the
following for sales information and advice on the equipment that would
best meet your needs:
AT&T Catalog Sales
1-800-451-2100
AT&T Sales Office
1-800-247-7000
AT&T Phone Center Store
1-800-222-3111
AT&T Authorized Dealer
1-800-247-1212.
1-8 Overview

Features and Capabilities
The following list provides an overview of the features of the PagePac
Plus AmpliCenter.
Amplifies paging — The AmpliCenter amplifies the page in increments
of 20 watts (D20), 100 watts (D100), or 300 watts (D300) for a 70V
constant voltage distribution system.
Paging input — The AmpliCenter accepts inputs from PBX trunk ports,
dry loop page ports, or amplified microphones.
Music interface — The AmpliCenter is the unit to which the background
music source (CD, radio, tape player) is connected, for distribution to
the paging system.
Volume control — The AmpliCenter has music ducking (mute) level,
music volume level, and bass control adjustment pots on the rear
panel. Overall output level can be controlled by dialing a DTMF code.
Remote amplifier connection — The AmpliCenter provides 0 dBm
audio output for connection to a remote amplifier, which receives a
contact closure control signal from the AmpliCenter.
AmpliCenter D20, D100, D300
PEC 5328-020, -100, -300
MOUNTING
BRACKETS
Figure 1-3. PagePac Plus AmpliCenter
Overview 1-9

Specifications
Table 1-2. AmpliCenter Specifications
Capacities ■ D20: up to 20 Watts total speaker load
■ D100: up to 100 Watts
■ D300: up to 300 Watts
Dimensions and ■ All models: 3-1/2" (8.9 cm) high x 19" (48.25 cm) wide x 5" (12.7 cm) deep
Weights ■ D20: 5 lbs (11 Kg) , D100 and D300: 6 Ibs (13 Kg)
RJ-11 Jack ■ Talk battery: 24 volts, loop start or ground start, negative voltage ring lead
Specifications
■ Impedence: 600 Ω
Temperature ■ -10 to +40 deg. C. (14°F to 104°F) operational; to +50 deg. C. (122°F) with forced air
Range: ■ -20 to +70 deg. C. (28°F to 158°F) storage and shipment
Humidity Range:
■ 5% to 95% (non-condensing) storage/shipment and operation
Environmental ■ Locate in an area free of excess moisture, corrosive gases, dust, and chemicals.
Requirements
Electrical ■ 100-250 VAC, 50/60 Hz, lamp, 3-prong outlet separate ground
■ Outlet must not be controlled by an on/off switch
■ Grounding:
A. Use the power cord supplied with the unit, or an equivalent cord that meets applicable
safety codes. Do not cut or remove the third wire ground prong.
B. The attachment-plug receptacles in the vicinity of the product or system are all to be of a
grounding type, and the grounding conductors serving these receptacles are to be
connected to earth ground at the service equipment.
1-10 Overview

Hardware Configuration
2
Contents
Power
Circuit Protection
Mounting
Universal Approvals
Controls and Indicators, Terminals and Connectors
Auxiliary Equipment
2-2
2-2
2-2
2-3
2-3
2-5
Hardware Configuration 2-1

Power
The rear panel of the AmpliCenter has a green LED which lights indicating
Power On.
One DC voltage derived from the PagePac Plus D-series AmpliCenter via
the interconnect cable (provided with the Controller) is the source for all
power required by the PagePac Plus Controller and any (optional)
attached Zone Expansion Modules.
Circuit Protection
Complete thermal and short circuit protection with automatic reset.
Mounting
Capable of mounting into a EIA 19" cabinet, free standing rack, or wall
mounting. Refer to Installation section 3.
2-2 Hardware Configuration

Universal Approvals
Domestic and international approvals:
■
■
■
■
UL813
FCC, Part 15, Class A (see Appendix A)
CSA 22.2, No 950
DOC.
Controls and Indicators, Terminals and Connectors
Figure 2-1 shows the controls and indicators, terminals and connectors on
the rear panel of the AmpliCenter. Table 2-1 identifies them by function.
Refer to the PagePac Plus Installation and Use Guide for similar
information for the whole PagePac Plus system.
Figure 2-1. AmpliCenter Controls and Indicators, Terminals and Connectors
Hardware Configuration 2-3

The following items describe all control and indicator functions illustrated in
figure 2-1:
Table 2-1. Controls and Indicators, Terminals and Connectors
1.
2.
3.
4.
5.
6.
7.
8.
9.
AC Power in: 100-250VAC, 50/60 Hz, 1 amp (AmpliCenter is self-switching.)
0dBm out, an auxiliary output that differs from the main 70.7V output in that it is a low level
(0dB), 600 ohm balanced output used for driving a remote or off-premises amplifier
DC Power, and 70V audio out to Controller
Bass control screw-type adjustment pot. Attenuates low frequencies so that horns and small
speakers are not overdriven by excessive bass energy. Cut-off frequency is adjustable from 50
Hz (full CCU) to 400 Hz (full CU)
Music In: left and/or right channels with ground;
Paging In: redundant paging input (ground, C1, tip, and ring)
70V Out: Balanced output used for terminating the loudspeaker wiring
Screw-type pots: VOX sensitivity level, Music ducking (mute level for music during voice
page), Music level for various music sources
LEDs: green - power on, lights when AC line voltage is applied to AmpliCenter
red – overload, lights when the AmpliCenter output exceeds its output power rating.
This can occur when total speaker load is greater than the output rating, or
when speaker wiring is shorted
red - unbalanced output, indicates when one speaker lead is accidentally shorted to ground
green – page accessed, lights when voice paging is active
Telephone system mode switch: dry loop 600 ohms, dry loop Hi Z, ground start, and loop start
From host telephone system or Controller RJ11 connector paging audio and control
2-4 Hardware Configuration
