ATC 6254M User manual

6254M Mainboard Contents
1
CONTENTS
COMPONENT LOCATION DIAGRAM………………..…..…A
CHECK LIST OF THE PACKAGING…………..……………..B
CONNECTORS DESCRIPTION ……………………….….…..C
TABLE OF CONTENTS…………………………………….…..1
HOW TO USE THIS MANUAL……………….………….…….2
CHAPTER 1 Introduction……………………………..……..3
1-1 System Features ..........................................................................3
German.....................................................................................4
French......................................................................................5
Spanish.....................................................................................6
Italian........................................................................................7
1-2 Software Power Off Control........................................................9
1-3 Fan Off Control...........................................................................9
1-4 Running 100MHz CPU Bus (JP11).............................................10
1-5 Keyboard & PS/2 Mouse Power On (JP9)..................................11
1-6 Wake-On-LAN ........................................................................12
1-7 Thermister (optional)..................................................................12
1-8LDCM ( LANDesk Client Manager, optional)..............................13
CHAPTER 2 Installation..............................................................14
2-1 Installation Procedure ..............................................................14
2-2 CPU Installation........................................................................14
2-2-1 Core/Bus Freq. Ratio…………………………………….…….14
2-2-2 CPU Setting……………………………………………………15
2-3 System Memory Installation......................................................16
2-4 IDE Driver Installation...............................................................17
2-5 Sound Driver Installation...........................................................17
2-6 VGA Driver Installation.............................................................18
2-7 Hardware Doctor Installation.....................................................18
CHAPTER 3 Award BIOS Setup................................................19
3-1 Update BIOS Procedure............................................................20
3-1-2 Update Microcode API...........................................................21
3-2 Award System BIOS Configuration Setup ..................................22
Appendix A How to Install PentiumII/III Celeron and
Processors with SECC2 Package
Appendix B How to Setup Thermister (optional)

How To Use This Manual 6254M Mainboard
2
Appendix C Technical Support Request Form
HOW TO USE THIS MANUAL
This manualiswritteninauser-friendly style. It would be advisable
for users to read it in an orderly sequence :
1. For Hardware Information:
ReadPageA:COMPONENTLOCATIONDIAGRAM,PageB:CHECKLISTOF
THE PACKAGING and Page C: CONNECTORS DESCRIPTION.
2. For Mainboard and System Features:
Read “Chapter 1 Introduction” in detail, and you will find helpful information on
mainboard and system features. Especially, when you want to do some feature setup,
detailed instructions are provided therein to help you through.
3. For CPU, Memory and Drivers Installation:
Read “Chapter 2 Installation” for your CPU, memory and application drivers
installation. Detailed instructions are provided to guide all kinds of users.
4. For BIOS Update and Setup:
Read “Chapter 3 Award BIOS Setup” for updating your mainboard BIOS and
setting up your BIOS Configuration.
5. For Installing PentiumII/III, Celeron or Processors with SECC2 Package:
Read APPENDIX A for setting up Intel PentiumIII, PentiumII, CeleronTM, or
processors with SECC2 package.
6. For Installing Thermister:
Read APPENDIX B for thermister installation. You will find that the self-explanatory
drawings enclosed therein make the job easy and simple.
7. For other Technical Support:
Read APPENDIX C, fill and send the Request Form to your dealer for other technical
support.
It is often heard that the default setting on a mainboard is not what user expects. A
user-friendly manual would be the handiest assistant to help change the on-board
configuration or default setting. In case this manual cannot solve all your problems,
please ask your dealer for help and be sure the warranty on your system is still valid.
REMARK: Intel®is a registered trademark of Intel Corporation.

6254M Mainboard Chapter 1 Introduction
3
All other brands and product names are registered trademarks of their respective companies.

6254M Mainboard Chapter 1 Introduction
4
CHAPTER 1 INTRODUCTION
Welcome to utilize 6254M mainboard, the Intel 440BX chipset supporting
both 66MHz and 100MHz Front Side Bus PentiumII/III CPU. It also has the
built-in Yamaha YMF 724/740 3D PCI sound chip and Voodoo3 VGA chip.
The Yamaha YMF 724/740 sound chip is using PCI interface which allows
your computer to perform 3D stereo sound. And the Voodoo3 3D VGA chip
working with AGP interface technique allows users to have 2D/3D display
resolution without plug any of VGA cards.
1-1System Features
:CPU Slot supporting Intel PentiumIII CPU 450Mhz to 550MHz, PentiumII CPU
233MHz to 450MHz and Intel CeleronCPU 266MHz to 466MHz.
:Intel 440BX AGPset.
:Yamaha YMF 724/740 3D PCI Sound Chip.
:Onboard 3Dfx Voodoo3 with onboard 16MB SGRAM.
:Four 168-pin DIMM Sockets in four banks of 64-bit wide path up to 512MB
SDRAM or 1GB registered SDRAM (with parity chip ECC support).
:Built-in Switching Voltage Regulator.(VRM 8.2 SPEC.)
:Auto-detect CPU core voltage range from 1.8V to 3.5V.
:Two16-bit ISA slots and four PCI slots compliance with reversion 2.2 of the PCI
Local Bus specification.
:Dual Master IDE connectors support Ultra DMA/33 (33MB/sec), up to four
devices in two channels for connecting high capacity hard disk, CD-ROM,
LS-120MB floppy drive, tape backup etc.
:Winbond 83977 high-speed Ultra Multi-I/O chipset.
:ATX Power Connector.
:USB (Universal Serial Bus) Connector supporting up to 127 peripheral devices.
:PS/2 Keyboard Connector and PS/2 Mouse Connector.
:Infrared Transfer (IrDA TX/RX) Connector.
:One FDDPort supporting two devices available for 1.2MB, 1.44MB and 2.88MB.
:Two 16550A fast UARTs compatible Serial Ports.
:One EPP/ECP mode Parallel Printer Port.
:Software Power Off Control; Modem Ring On; SB-Link; Keyboard & PS/2 Power
On; Wake-On-LAN functions.
:Built-in Hardware Health Monitor chip. (optional)
:Intel LDCM software. (optional)
:ATX Form Factor; Hardware Dimension is 305mm x 210mm. (12" x 8.26")

6254M Mainboard Chapter 1 Introduction
5
1-1 Systemmerkmale (German)
:CPU Slot unterstützt Intel Pentium III CPU 450MHz zu 550MHz,
Pentium II CPU 233MHz zu 450MHz und Inetl Celeron
CPU 266MHz zu 466MHz .
:Intel 440BX AGPset .
:YAMAHA YMF 724/740 dreidimensional PCI Sound Chip .
:An Board dreidimesional fx Voodoo3 mit 16MB SGRAM .
:Vier 168-pin DIMM Sockets in vier Banks für 64-bit Breit
ausgedehnte Bahn hoch bis zu 512MB SDRAM oder 1GB
registriend SDram ( mit ECC Chip in Gleichheit unterstützt ).
:Built-in schaltet den Voltageregulator .( VRM 8.2 SPEC )
:Selbstnachweisend CPU Kernvoltage variiert zwischen 1.8V und
3.5V .
:Zwei 16-bit ISA Slots und vier PCI Slots sind Wünschen gemäß der Umkehrung
2.2 für PCI Lokalbus in Spezifizierung .
:Dual Master IDE Anschließstück unterstützen Ultra DMA/33
(3MB/sec ), hoch bis zu vier Vorrichtungen in zwei Kanälen ,
das Einsetzten der Hardscheibe ist in hoherAufnahmfäigkeit,
CD-Rom, LS-120MB Softwaredrive , Tapereserven etc.
:Winbond 83977 hohe-Tempi Ultra multi-I/O Chipset .
:ATX Power schließen sich an .
:USB (universale Seriennummer-Bus ) Anschlußstück wird Randverrichtung hoch
bis zu 127 untergestützt .
:PS/2 Keyboard Anschlußstück und PS/2 Mouse Anschlußstück .
:Übertragend(IrDA TX/RX) Anschlußstück .
:One FDD Schließloch unterstützt zwei verwendbare Vorrichtungen
für 1.2MB , 1.44MB und 2.88MB.
:Zwei 16550A rapide UARTs vertragende Seriennummer der
Schließlöchern .
:Ein EPP/ECP Model mit parallelem Printerschließloch .
:Abschalten zu Software ist kontrolliertbar ; Modem mit Signalklang ;
SB-Anschließen ; Keyboad und PS/2 Einschalten ;
:Wake-On-LAN Funktion .
:Konstruktion -in Hardware mit gesundheitlichem Monitor Chip.
( freigestellt)
:Intel LDCM Software .( freigestellt)
:ATX Form Faktor ; Hardware Dimension ist 305mm x 210mm.
(12" x 8.26")

Chapter 1 Introduction 6254M Mainboard
6
1-1 Caractéristiques du Système (French)
:Socle CPU supportant un CPU d'Intel Pentium®III 450Mhz à 550Mhz, un CPU
d'Intel Pentium®II 233Mhz à 450Mhz et un CPU d'Intel Celeron™ 266Mhz à
466Mhz.
:Puce Intel 440BX AGP.
:Puce sonore YMF 724/740 3D PCI de YAMAHA.
:3 Dfx Voodoo3 Sur Carte avec 16MB de SGRAM Sur Carte.
:Quatre Socles DIMM 168-broches dans quatre banques d'une piste de 64-bit sur
512MB de SDRAM ou 1GB de SDRAM enregistrée ( avec support ECC de puce
par paire ).
:Régulateur de voltage interchangeant incorporé ( VRM 8.2 SPEC ).
:Gamme du voltage détecté par le CPU de 1,8V à 3,5V.
:Deux socles ISA 16-bit et quatre socles PCI conformes avec l'inversion 2.2 des
spécifications du Bus PCI Local.
:Double connecteurs maîtres IDE avec support d'Ultra DMA/33 ( 33MB/sec.) sur
quatre périphériques dans deux chaînes pour connecter un disque dur de grande
capacité, un lecteur de CD-ROM, de disquette LS-120MB, une machine pour copie
de secours, etc.
:Jeu de puces Ultra Multi-I/O haute vitesse Winbond 83977.
:Connecteur d'alimentationATX.
:Connecteur USB ( Bus Sériel Universel ) supportant plus de 127 périphériques.
:Commecteur de clavier PS/2 et connecteur de souris PS/2.
:Connecteur de transfert d'infrarouge ( IrDA TX/RX ).
:Un port FDD supportant deux périphériques disponibles pour 1,2MB, 1,44MB et
2,88MB.
:Deux ports sériels compatibles 16550A fast UARTs.
:Un Port d'Imprimante Parllèle mode EPP/ECP.
:Logiciel de contrôle d'arrêt; Sonnerie de modem; Lien SB; Clavier & PS/2 Marche;
Fonctions LAN de Réveil.
:Puce d'état du moniteur et du matériel ( optionnelle ).
:Logiciel Intel LDCM ( optionnel ).
:Facteur de Forme ATX; dimensions du matériel: 305mm x 210mm ( 12" x 8,26" ).

6254M Mainboard Chapter 1 Introduction
7
1-1 Características del Sistema (Spanish)
:Ranura CPU soporta Intel Pentium®III CPU 450Mhz a 550Mhz, Pentium®II CPU
233Mhz a 450Mhz e Intel CeleronTM CPU 266Mhz a 466Mhz.
:Intel 440BX AGPset.
:Chip de sonido Yamaha YMF 724/740 3D PCI
:3Dfx Voodoo3 abordo con 16MB SGRAM abordo
:Cuatro Casquillos 168-pin DIMM en cuatro bancos de 64-bit camino ancho hasta
512MB SDRAM o 1GB registrado SDRAM (con soporte de chip de paridad
ECC)
:Regulador de Voltaje Incorporado (VRM 8.2 SPEC.)
:Autodetección de rango de voltaje central de CUP de 1.8V a 3.5V
:Dos ranuras 16-bit ISA y cuatro ranuras PCI conforme a la reversión 2.2 de la
especificación de PCI Local Bus
:Conectores IDE Master Duales soportan Ultra DMA/33 (33MB/seg.), hasta cuatro
dispositivos en dos canales para conectar disco rígido de alta capacidad,
CD-ROM, lector de floppy LS-120MB, respaldo de cinta, etc.
:Chipset Ultra Multi-I/O de alta velocidad Winbond 83977.
:Conector de alimentación ATX.
:Conector USB (Bus Serial Universal) que soporta hasta 127 dispositivos
periféricos.
:Contector de Teclado PS/2 y Conector de Ratón PS/2.
:Conector de Transferencia Infrarroja (IrDA TX/RX).
:Un puerto FDD que soporta dos dispositivos disponibles para 1.2MB, 1.33MB y
2.88MB.
:Dos Puertos Seriales 16550A fast UARTs compatibles.
:Un Puerto de Impresora Paralelo en modalidad EPP/ECP.
:Control de Apagado en Software; Encendido de Módem; SB-Link; Teclado &
Encendido PS/2; Despertar en LAN.
:Chip de Monitor de Salud de Hardware incorporado, (opcional)
:Software Intel LDCM, (opcional)
:Factor de Forma ATX; Dimensión de Hardware es 305mm x 210mm (12” x 8.26”)

Chapter 1 Introduction 6254M Mainboard
8
1-1 Caratteristiche del Sistema (Italian)
:La slot CPU supporta micro-processori Intel Pentium III Cpu da 450 Mhz a 550
Mhz, Pentium II CPU da 233 Mhz a 450 Mhz ed Intel Celeron CPU da 266 Mhz a
466 Mhz.
:Set Intel 440BX AGP.
:PCI Chip suono Yamaha YMF 724/740 3D.
:3Dfx Vodoo3 caricato con 16MB SGRAM caricate.
:Quattro prese DIMM a 168 pin, a disposizione quadrupla, con 64 bit di ampiezza
fino a 512MB SDRAM oppure 1GB registrato SDRAM (con chip parità supporto
ECC).
:Regolatore Voltaggio Aggiustabile internamente costruito (VRM 8.2 SPEC.)
:Auto-lettura voltaggio interno CPU con ampiezza da 1.8V a 3.5V.
:Due prese ISA da 16-bit e quattro prese PCI conformi a reversione 2.2 della
specifica di PC Local Bus.
:Connettori Dual Master IDE supportanti Ultra DMA/33 (33 MB/sec), fino a due
dispositivi in due canali per la connessione di hard disk ad alta capacità, CD-ROM,
floppy drive LS-120 MB, backup di nastro, ecc.
:Winbond 83977 alta velocità Ultra Multi-I/O chipset.
:Connettore di alimentazione ATX.
:Connettore USB (Universal Serial Bus = Bus Seriale Universale) in grado
disupportare un massimo di a 127 dispositivi periferici.
:Connettore Tastiera PS/2 e Connettore Mouse PS/2.
:Connettore Transfer Infrarossi (IrDA TX/RX).
:Un porto FDD che supporta due dispositivi disponibile per 1.2MB, 1.44MB e
2.88MB.
:Due Porti Seriali compatibili con 16550A fast UARTs
:Un porto con mode EPP/ECP Stampante Parallela.
:Dispositivo controllo spegnimento software; accensione suono Modem; SB-Link;
accensione tastiera e PS/2; funzioni Wake-On-LAN.
:Chip per controllo di condizione dell’ Hardware (Hardware Health Control -
opzionale).
:Software Intel LDCM (opzionale).
:Fattore Forma ATX; le dimensioni dell’ hardware sono 305mm x 210mm (12” x
8.26”).

6254M Mainboard Chapter 1 Introduction
9
Voodoo III –2000/3000 Features
:Fully integrated 128-bit
:VGA/2D/3D/Video accelerator
:True Multi-exturing-2 textures/ clock
:3Dfx Voodoo compatibility.
:2X AGP with sidebands.
:DVD Acceleration.
:Digital video output for NTSC, PAL and SECAM TV-out support.
:Digital LCD support (LCDfxTM)
:DirectX 6, Open GL, Glide 2.x/3.x support.
:0.25 Micron, 5-layer metal CMOS technology.
:2000: 4 million triangles/sec., 250 Megatexels/sec.
3000: >7 million triangles/sec., > 366 Megatexels/sec.
:2000: 300MHz RAMDAC, 2048x1536@65Hz.
3000: 350MHz RAMDAC, 2048x1536@75Hz.
:2000: 125MHz Core Graphics Clock
3000: 183MHz Core Graphics Clock
Audio Features
:True Full Duplex Playback and Capture with different Sampling Rate
:Maximum 32-voice XG capital Wavetable
:Synthesizer including GM compatibility
:DirectSound Hardware Acceleration
:DirectMusic Hardware Acceleration
:Downloadable Sound (DLS) level-1
:Genuine OPL3
:Hardware Sound Blaster Pro compatibility
:Joystick
:Supporting PC/PCI and Distributed DMA for legacy DMAC (8237) emulation
:Supporting Serialized IRQ
:Supporting AC-2 Interface (AC-Link)
:Single Crystal operation (24.576MHz)
:5V Power supply for I/O; 3.3V Power supply for Internal core logic

Chapter 1 Introduction 6254M Mainboard
10
1-2 Software Power Off Control
The mainboard design supports Software Power Off Control feature through the
SMM code in the BIOS under Windows 95/98, and MS-DOS operation system
environment.
First, you should connect the power switch cable to the connector “PS-ON” on
the mainboard. In the BIOS screen of POWER MANAGEMENT SETUP’, choose
“User Define” (or “Min. Power Saving” or “Max. Power Saving”) in ‘Power Manager’
and pick up “Yes” in ‘PM Control by APM’.
In Windows 95/98, if you would like to power off the system, you just need to
choose “shutdown the computer ?” in the “Shut Down Windows“ from Windows
95/98. Then the system power will be off directly, and become to the stand-by status.
If you would like to restart the system, just press the power switch button, and the
system will be powered on.
Note : If you are going to leave your system idle for several days, we suggest you
use hardware power off to shutdown your system.
Status Power LED Light Turbo LED Light
Software power off
control Blinking (JP5, pin1-2) Light off (JP5, pin2-3) Light off
APM mode Light on Light on
System running Light on Light on
* Under Software power off control, the status of Power LED Light depends on the setting of JP5.
If you set JP5 to “pin1-2” position, it is blinking. Otherwise, it is light off.
1-3 Fan Off Control
With fan-off function, the CPU cooling fan can turn off automatically even when
the system is in suspend mode. This function is able to reduce energy consumption
and system noise.
Because it is a feature of advanced BIOS, you should set this option enabled
through “Power Management Setup” from the BIOS setup screen.

6254M Mainboard Chapter 1 Introduction
11
1-4 Running 100 MHz CPU Bus (with JP11)
The mainboard provides Jumper 11 that allows you to set your CPU host clock
and perform CPU overclock function. There are two ways to set CPU host clock at
‘closed’ and ‘open’. When setting ‘closed’, the system will automatically detect the
CPU host clock, for instance 66MHz and 100MHz. Another way is to set Jumper11at
‘open’ for 66MHz CPU overclock to 100MHz.
We recommend that users should use Intel PentiumII/III 100 MHz CPU, running
at 350, 400, 450 and 500MHz internal clock speed. Moreover, the SDRAM memory
module must be 8 nano-second (Maximum Frequency 125 MHz) speed of
memory –die or less. However, based on Intel’s design, we don’t recommend users to
run over 100MHz CPU host bus.
Please note that the default setting of Jumper 11 is ‘closed’.
Jumper 11BASE CLK
ClosedAuto (default)
Open Overclock (66MHzàà100MHz)
(a) Pin Closed (b) Pin Open
Slot 1
JP11
--Ifyouwouldliketorunover100MHzCPUhostbus,like112and124MHz,please
set “CPU Clock Frequency” in “CHIPSET FEATURES SETUP” from the
BIOSsetupscreen.Ifthesystemcan’tbootupwiththeclockfrequencythatyou
setto,youcanclearthe set frequency by pressing the ‘Insert” key on keyboard.
After restarting the system, you have the system operating at the default
frequency.

Chapter 1 Introduction 6254M Mainboard
12
1-5 Keyboard & PS/2 Mouse Power On (with JP9)
With ATX Power Supply and Jumper 9 set to Pin 1-2 closed, 6254M Mainboard
is enabled to Keyboard & PS/2 Mouse Power On functions :
JP 9 KB & PS/2 Mouse Wakeup
1-2Enable
2-3Disable
(a) Enable (1-2 closed) (b) Disable (2-3 closed)
The default Power On function is “Button Only”. That means, we can only turn
our computer on and off by pressing the “Power Button”. If we want to enable KB &
PS/2 Mouse Power On function, we first have to set JP9 to Pin 1-2 closed, and then go
to “Power On Function” in “Integrated Peripherals” of Award BIOS Setup. At the line
“Power On Function”, we can press “Page Up” or Page Down” to make the following
selections:
1. Password(via Keyboard):
When user selects “Password”, it will show “Enter Password:”. After user has typed
the password, screen will show “ Confirm Password:” and user has to type the same
password to confirm it. Save selection and shut down system. Now computer will
only be powered on by entering correct password.
In case the set password is forgotten, carry out “Clear CMOS” (Page 14) to clear
password, or computer can not be powered on.
2. Hot Key (via Keyboard):
When user selects this option, screen will show another line : “Hot Key Power ON :
Ctrl-F1”. User can select from “Ctrl-F1” to “Ctrl-F12” as Hot Key by pressing
PageUp / PageDown. After fixing Hot Key, save selection and shut down system.
Now computer will only be powered on by pressing the correct Hot Key.
3. Mouse Left, Mouse Right (via PS/2 Mouse):
This function is available via PS/2 mouse only. User can select either “Mouse Left”
or “Mouse Right” from the “Power On Function” line. After picking either option,
save selection and shut down system. Now computer will only be powered on by
double-clicking the correct PS/2 Mouse button.
Do not slide the mouse when you click; or you can’t power on the system.
4. Button Only (via Power Button): “Button Only” is default setting, at which
computer can only be on/off via Power Button.
JP9
PCI slots

6254M Mainboard Chapter 1 Introduction
13
1-6 Wake-On-LAN
The remote Wake-On-LAN (WOL) mode of operation is a mechanism that uses
Advanced Micro Device Magic Packet technology to power on a sleeping workstation
on the network. This mechanism is accomplished when the LAN card receives a
specific packet of information, called a Magic Packet, addressed to the node on the
network. For additional protection, Secure ON is an optional security feature that can
be added to the Magic Packet that requires a password to power on the sleeping
workstation. When LAN card is in remote Wake-On-LAN mode, main system power
can be shut down leaving power only for the LAN card and auxiliary power
recondition.
The LAN card performs no network activities while in the remote Wake-On-LAN
mode of operation. It only monitors the network for receipt of a Magic Packet. If a
Magic Packet is addressed to the LAN card on the network, the LAN card wake up the
system. If the Secure ON feature has been enabled, the password added to the Magic
Packet is also verified prior to waking up the system.
You should select two kinds of PCI Ethernet cards with WOL function. One is
Intel and the other is with PME signal supporting. And you can set “Wake Up On
LAN” this function enabled through “ Power Management Setup” from the BIOS setup
screen.
1-7 Thermister (optional)
If Hardware Monitor is built onboard, CPU temperature can be monitored by
setting up the Thermister.
When setting up the thermister (refer to Appendix B), the BIOS will load the CPU
temperature automatically. A warning beep sound will be sent out if the user set the
option on. If the CPU is overheated, the user will get the warning. Then you should
shut down computer and check your devices. Or contact you dealer for further help if
CPU temperature persists.
Note: If you would like to enable the function of hardware monitor, to set up
thermister beforehand is necessary. RT2 is the thermister connector.

Chapter 1 Introduction 6254M Mainboard
14
1-8 LDCM 
LANDesk Client Manager (optional)
The mainboard built-in controller supports Intel LDCM. LDCM can satisfy users
who want manageable systems that can interact automatically with the user. Client
manager is the answer, enabling both administrators and clients to manage systems.
The features of LDCM are as following :
View system inventory
Client Manager enables you to view hundreds of inventoried items. Some of these
items are software related, while many others are hardware related.
View DMI-compliant component information
Client manager enables you to view component information that is compliant with the
Desktop Manager InterfaceDMI. This means you can manage third-party
DMI-compliant components which did not include Client manager.
Back up and restore system configuration files.
Client Manager enables you back up and restore system configuration files. Whenever
you plan on changing the system configuration , you can make a backup set. If the
system no longer works correctly, after you the change the system configuration ,
you can simply restore the system configuration with the backup set.
Troubleshoot
Since Client manager enables you to view the system inventory, you can easily
troubleshoot system problems.
Receive notifications for system events
Client manager enables you to receive notification of certain system events. For
example, if the system is running low on virtual memory, you are notified of the
potential problem.
Transfer files to and from client workstations
As an administrator, you have the ability to transfer files to and from client workstation.
This is helpful, for example, when you need to update a client workstation driver.
Remotely reboot client workstations
Administrator also have the ability to remotely reboot a workstation. This is helpful
when you want your system configuration changes to take effect.

Chapter 2 Installation 6254M Mainboard
15
CHAPTER 2 INSTALLATION
2-1 INSTALLATION PROCEDURE
Before installing the computer, please prepare all components such as CPU, DRAM;
peripherals such as hard disk, keyboard, CD-ROM and accessories such as cables.
Then, install the system as following:
ŒPlug CPU/ heat sink (refer to PentiumII/III & CeleronTM installation
guide, Appendix A), and DRAM modules on the mainboard.
•Set DIP switch & jumpers based on your configuration.
ŽPlug add-on cards into PCI/ISA slots, if needed.
•Connect cables to peripheral devices, especially for power supply.
•Make sure all components and devices are well connected, turn on the
power and setup System BIOS based on your configuration.
‘Install peripheral devices, add-on card drivers and test them.
’If all of above procedures are running successfully, turn the power off
and screw the chassis cover to the chassis, and then connect external
devices which are cabled to the system.
2-2 CPU INSTALLATION
The mainboard has built-in VID (Voltage Identify) function to automatically detect
CPU voltages. Thus you do not have to set the CPU voltage setting.
2-2-1 CPU Core/Bus Freq. Ratio :
SW1
1-1
1-2
1-3
1-4
3.0x ON ON OFF OFF
3.5x ON ON ON OFF
4.0x OFF OFF OFF OFF
4.5x OFF OFF ON OFF
5.0x OFF ON OFF OFF
5.5x OFF
ON ON OFF
6.0x ON OFF
OFF
ON
6.5x ON OFF
ON ON
7.0x ON ON OFF
ON
7.5x ON ON ON ON
8.0x OFF
OFF
OFF
ON

Chapter 2 Installation 6254M Mainboard
16
2-2-2 CPU Setting
a. For 233~333MHz Intel Pentium II & 266~466MHz CeleronTM CPUs.
INTERNAL CPU CLOCK SW1
233MHz (66x3.5)
266MHz (66x4.0)
300MHz (66x4.5)
333MHz (66x5.0)
366MHz (66x5.5)
400MHz (66x6.0)
433MHz (66x6.5)
466MHz (66x7.0)
b. For 350~450MHz Intel Pentium II and 450~550MHz Pentium III CPUs.
INTERNAL CPU CLOCK SW1
350MHz (100x3.5)
400MHz (100x4.0)
450MHz (100x4.5)
500MHz (100x5.0)
550MHz (100x5.5)
1 2 3 4
ON
OFF
1 2 3 4
ON
OFF
1 2 3 4
ON
OFF
1 2 3 4
ON
OFF
1 2 3 4
ON
OFF
1 2 3 4
ON
OFF
1 2 3 4
ON
OFF
1 2 3 4
ON
OFF
1 2 3 4
ON
OFF
1 2 3 4
ON
OFF
1 2 3 4
ON
OFF
1 2 3 4
ON
OFF
1 2 3 4
ON
OFF

6254M Mainboard Chapter 2 Installation
17
2-3 SYSTEM MEMORY INSTALLATION
The Mainboard provides four 168-pin DIMM sockets for system memory
expansion from 8MB to 512MB SDRAM, 1GB registered SDRAM or 1GB EDO
DRAM.(EDO DRAM is available for 66MHz processors only.) These four DIMMs
are arranged to four banks, please refer to page A.
Bank/DIMM Memory Module Total Memory
Bank0/DIMM1 8/16/32/64/128/256MB 8MB~256MB
Bank1/DIMM2 8/16/32/64/128/256MB 8MB~256MB
Bank2/DIMM3 8/16/32/64/128/256MB 8MB~256MB
Bank3/DIMM48/16/32/64/128/256MB 8MB~256MB
Total System Memory 8MB~1GB
DRAM type, size, parity supported:
6EDO DRAM: for 66MHz system frequency only
6Unbuffered, registered SDRAM with SPD
6Both parity or non-parity are available.
63.3V, Single/double-side, 8/16/32/64/128/256Mbytes
(Max. memory size: 256MB registered SDRAM or EDO DRAM)
6Both 4Mbx4 and 16Mbx4 (Each side has 16 chips.) SDRAM devices are
supported in the form of Registered DIMMs only.
uFor 66MHz host bus CPUs use 12ns or faster DIMM module;
uFor 100MHz host bus CPUs use 10ns or faster and PC-100 compliant modules .
@@ SPD (Serial Presence Detect)
This EPROM contains speed and design information of the memory module. The
mainboard may get optimal performance via accessing the data of SPD.
@@ ECC (Error Check and Correction)
This mainboard can support the ECC function while utilizing parity modules. To enable
this function, users must set “DRAM Data Integrity Mode”to “ECC”through “Chipset
Features Setup”from the BIOS setup screen. All in all, ECC’s function is to detect and
correct the errors of transfer data.

Chapter 2 Installation 6254M Mainboard
18
2-4 IDE DRIVER INSTALLATION
Setup for Windows 95/98 :
1. Start Windows 95/98.
2. Put the All-In-One CD into your CD-ROM drive.
3. Select “START”, “RUN”.
4. Type “D:\IDE\WIN95\SETUP.EXE” or “E:\IDE\WIN95\SETUP.EXE”.
(If your operating system is Win95, please type “D or E:\winp2x4.exe”
before you install IDE driver.)
5. Restart the computer, then follow the instructions on your screen to install
new IDE driver we offer in the All-In-One CD.
6. Exit Windows 95/98, turn power off; then turn power on.
2-5 YAMAHA SOUND DRIVER INSTALLATION
2-5-1Installing Yamaha 724/740 PCI Driver for WinNT
Yamaha Sound 724/740 PCI Driver for WinNT is included in the
Driver/Utility CD under the autorun main menu “Install Yamaha 724/740 PCI
Driver”. To install this driver, just take the following steps:
1. Start WinNT 4.0 and insert the Driver/Utility CD into your CD-ROM Drive.
2. The screen will automatically show the autorun main menu which includes
“Install Yamaha 724/740 PCI Driver”.
3. Click this item and “Yamaha DS-XG Setup” screen will display.
4. Click “Windows NT4.0 Driver” and driver setup will automatically start to run.
5. Follow the instructions on the autorun screen until setup is complete.
6. Restart your system to put the sound driver into effect.
2-5-2 Installing Yamaha 724/740 PCI Driver for Win95/98
1. Start your Win95/98 and insert the Driver/Utility CD into CD-ROM Drive.
2. The screen will automatically show the autorun main menu which includes
“Install Yamaha 724/740 PCI Driver”.
3. Click this item and “Yamaha DS-XG Setup” screen will display.
4. Click “Windows 95/98 Driver” and driver setup will automatically start to run.
5. Follow the instructions on the autorun screen until setup is complete.
Restart your computer to put the sound driver into effect.

6254M Mainboard Chapter 2 Installation
19
2-6 VOODOO III AGP DRIVER INSTALLATION
2-6-1Installing Voodoo III AGP Driver for Win95/98
1. Start your Win95/98 and insert the Driver/Utility CD into CD-ROM Drive.
2. The screen will automatically show the autorun main menu which includes
“Install Voodoo III AGP Driver”.
3. Click this item to begin installing the driver.
4. Click “Drivers Setup” and driver setup will automatically start to run.
5. Follow the instructions on the autorun screen until setup is complete.
2-6-2 Installing Voodoo III AGP Driver for WinNT
1. Start your WinNT and insert the Driver/Utility CD into CD-ROM Drive.
2. The screen will automatically show the autorun main menu which includes
“Install Voodoo III AGP Driver”.
3. Click this item to begin installing.
4. Click “Drivers Setup” and driver setup will automatically start to run.
5. Follow the instructions on the autorun screen.
6. Choose 3Dfx Interactive Inc. Voodoo3 2000 or 3000 depends on your chipset
type.
7. Follow the instructions on the autorun screen until setup is completed.
2-7 HARDWARE DOCTOR INSTALLATION
ØØSetup for Win95/98 or WinNT
1. Start Windows95/98 or WinNT.
2. Insert All-In-One CD into your CD-ROM drive.
3. Choose “Install Hardware Monitor” in the installation main menu.
4. Follow the instructions on the autorun screen until setup is completed.
Note:AfterfinishingHardwareDoctorinstallation,inWinNTyoumustrestartyour
computer, but in Win95/98 you don’t have to.

Chapter 3Award BIOS Setup 6254M Mainboard
20
CHAPTER 3 AWARD BIOS SETUP
Award BIOS manufacturer provides access to the system BIOS through the hardware
and software on the mainboard. The hardware consists of a Flash ROM and the
software is a group of programs that are installed in the ROMBIOS along with all the
other data the BIOS must contain.
After the BIOS is updated, if you want to clear the old setup data stored in the CMOS,
then you can clear CMOS.
NOTE : In case CMOS should be cleared, unplug the power cord, set Jumper 8 2-3
closed for at least 5 seconds, put it back to 1-2 position and plug the power cord
again.
JP8
Normal 1-2
Clear CMOS 2-3
Normal (Pin 1-2 closed) Clear CMOS (Pin 2-3 closed)
JP 8
PCI Slots
123
