ATD‐80351
SABERII15WCORDEDUNDERHOODLIGHT
USER’SMANUAL
FEATURES:
•30SuperBrightSMDLEDs
•18/2SJTOW25ftcordremainsflexibleincoldweatherandwaterresistant
•ABShandlewithdoubleinjection,impactprotectionandergonomicdesignprovidescomfortableusage
•AluminumalloyhookwithPVCcoverforprotection,softcoatedpaddedhookshelppreventscratching
ofthevehiclessurface
•Thebarextendsfrom47"to70"andeasilyattachestomostSUV'sandtrucks
•360degreeratchetinghooksprovidesafeandfirmattachment.
•CSAlisted
CaliforniaProp65WARNING:
Thisproductcontainschemicalsincludinglead,knowntotheStateofCaliforniatocausecancer,birthdefects,orother
reproductiveharm.Washhandsafterhandling.



GeneralSafetyWarnings:

WARNING:Theinstructionsandwarningscontainedinthismanualshouldbereadandunderstoodbeforeusing
oroperatingthistool.Donotallowanyonetouseoroperatethistooluntiltheyhavereadthismanualandhave
developedathoroughunderstandingofhowthistoolworks.Failuretoobserveanyofthefollowinginstructionscould
resultinseverepersonalinjurytotooluserandbystanders,orcausedamagetothetoolandproperty.Keepthismanual
forfuturereference.

Note:Thewarningsandcautionsdiscussedinthisinstructionmanualcannotcoverallpossibleconditionsand
situationsthatmayoccur.Itmustbeunderstoodbytheoperatorthatcommonsenseandcautionarefactorswhich
cannotbebuiltintothisproduct,butmustbesuppliedbytheoperator.

WARNING:Usesafetyequipment.Usersandbystandersshouldusesafetygogglesorsafetyglasseswithside
shieldswhichcomplywithcurrentnationalstandards,orwhenneeded,afaceshield.UseanANSIapproveddustmaskor
respiratorwhenworkingaroundmetal,wood,andchemicaldustsandmists.Thisappliestoallpersonsintheworkarea.
Alsousenon‐skidsafetyshoes,hardhat,gloves,dustcollectionsystems,andhearingprotectionwhenappropriate.
WARNING:Keepbystandersandchildrenoutoftheworkareawhileoperatingthistool.

WARNING:Alwayskeepyourworkareaclean,uncluttered,andwelllit.Clutteredordarkareasinviteaccidents
andinjuries.DONOTworkonfloorsurfacesthatareslippery.

WARNING:Donotoperatethistoolifyouaretiredorundertheinfluenceofalcohol,drugs,ormedicationsthat
couldaffectyourabilitytousethetoolproperly.

WARNING:Dressproperly.Donotwearlooseclothingorjeweleryastheycanbecaughtinmovingparts.Wear
restrictivehaircoveringtocontainlonghair.

WARNING:Donotreachoveroracrossrunningmachines.Keepproperfootingandbalanceatalltimes.Non‐
skidfootwearisrecommendedwhenworking.


ElectricalSafetyWarnings:

WARNING:Readallsafetywarningsandinstructions.Failuretofollowallwarningsandinstructionsmayresult
inelectricshock,fireand/orseriousinjuryordeath.

WARNING:Beforeconnectingatooltoapowersupply,alwayschecktoensurethepowersupplycorrespondsto
thevoltageonthenameplateofthetool.Apowersupplywithavoltagegreaterthanthatspecifiedforthetoolcan
resultinseriousinjurytotheuser,aswellasdamagetothetool.Usingapowersupplywithavoltagelessthanthe
nameplateratingisharmfultothemotor.Ifindoubt,donotpluginthetool.


WARNING:Groundedtoolsmustbepluggedintoanoutletproperlyinstalledandgroundedinaccordancewith
allcodesandordinances.Thistoolisequippedwitha3‐prongpluganda3‐wiregroundingsystem.Neverremovethe
groundingprongormodifythepluginanyway.Donotuseanyadapterplugs.Checkwithaqualifiedelectricianifyou
areindoubtastowhethertheoutletisproperlygrounded.

NOTE:Doubleinsulatedtoolsareequippedwithapolarizedplug(onebladeiswiderthantheother).Thisplug
willfitinapolarizedoutletonlyoneway.Iftheplugdoesnotfitfullyintheoutlet,reversetheplug.Ifitstilldoesn’tfit,
contactaqualifiedelectriciantoinstallapolarizedoutlet.Donotchangethepluginanyway.

WARNING:Toreducetheriskofelectricshock,DONOTuseindampconditions,onwetsurfaces,orexposeto
rain.Donotpluginthistooloroperateitwithwethandsorwhilestandinginwater.

WARNING:Neverusethecordforcarrying,pullingorunpluggingthepowertool.Graspplugandpullto
disconnectfromoutlet.Keepcordawayfromheat,oil,sharpedgesormovingparts.Replacedamagedcords
immediately.

WARNING:Donotcarrythepowertoolwithyourfingerontheswitch.Ensuretheswitchisintheoffposition
beforepluggingthetoolintothepoweroutlet.Intheeventofapowerfailurewhileatoolisbeingused,turntheswitch
offtopreventsurprisestartingwhenthepowerisrestored.

WARNING:Alwaysremovethepowercordfromtheelectricoutletwhenmakingadjustments,changingparts,
cleaningorworkingonthetool.

WARNING:Careshouldbetakentoarrangethecordsoitwillnotbesteppedon,trippedover,orotherwise
subjectedtodamageorstress.

WARNING:Neverattempttopluginoroperateequipmentwithdefectiveordamagedwires,powercordor
powercordplug.Haveanydefectiveordamagedpartsreplacedimmediatelybyqualifiedpersonnel.

WARNING:Avoidbodycontactwithelectricallygroundedsurfaces.Thereisanincreasedriskofelectricshockif
yourbodyisgrounded.

WARNING:IftheworkareaisnotequippedwithapermanentlyinstalledGroundFaultCircuitInterrupteroutlet
(GFCI),useaplug‐inGFCIbetweenthepowertoolorextensioncordandthepowerreceptacle.

WARNING:Ifanextensioncordisnecessary,useonly‘Listed’extensioncords.Ifusedoutdoors,theymustbe
marked“ForOutdoorUse”.Thosecordshavinga3‐pronggroundingtypeplugsandmatingreceptaclesaretobeused
withgroundedtools.

WARNING:Useofimpropersizeorgaugeofextensioncordmaycauseunsafeorinefficientoperationofyour
tool,orcausedamagetoyourtool.Besureyourextensioncordisratedtoallowsufficientcurrentflowtothemotor.If
indoubt,alwaysusealargergaugecord.Besuretocheckthevoltagerequirementsofthetooltoyourincomingpower
source.


NOTE:Thetablebelowshowsthecorrectsizetouseaccordingtocordlengthandtheamperagedrawofthetool
(specifiedonthenameplate).Whenindoubt,usethenextheaviergauge.Thesmallerthegaugenumber,theheavier
thecord.(AWG=AmericanWireGauge).

MinimumGaugeforExtensionCords(AWG)
(whenusing120voltsonly)
AmpereRatingTotalLengthofCordinFeet(meters)
MoreThanNotMoreThan25'(7.6m)50'(15m)100'(30.4m)150'(45.7m)
0618161614
61018161412
101216161412
12161412NotRecommended




ATD‐80351SpecificSafetyInstructions:

WARNING:Read all instructions before using

WARNING:For indoor use only – do not use in or around, tubs, showers, sinks, pools, hot tubs, or in a wet
environment

WARNING:Use only the recommended voltage and frequency requirements

WARNING:Do not move or turn off light by pulling the power cord
WARNING:Do not use if the cords or Clear tube are damaged
WARNING:Keep out of reach of children
WARNING:Do not operate light with wet hands.
WARNING:Keep lamp away from hot objects.

Operating Instructions:
•To use, plug the unit into any 110-120 VAC power source, such as a wall receptacle.
•Press the on/off switch (l) to turn unit on, press the other side of switch (0) to turn it off.
•The hooks can be adjusted by simply pulling out on them and affixing to whatever surface you like,
such as a car hood. (Up to 70” wide)
•Once your light is in place, it can be rotated to the desired position by simply twisting the light. You
will hear ratcheting “clicks” as you rotate it.

ATD-80351
ITEM# ORDERING PART# PART DESCRIPTION ITEM# ORDERING PART# PART DESCRIPTION
1 PRT80351-01 PULL ROD 12 PRT80351-12 BRIGHTNESS INDICATE BOARD
2 PRT80351-02 SCREW M5X9 13 PRT80351-13 POWER CORD
3 PRT80351-03 LEFT HANDLE SET 14 PRT80351-14 SWIVEL SHAFT
4 PRT80351-04 SCREW M3X5 15 PRT80351-15 POSITION BLOCK
5 PRT80351-05 PROTECTING COVER 16 PRT80351-16 LAMP HOLDER
6 PRT80351-06 LED PCB 17 PRT80351-17 PRESSURE SPRING
7 PRT80351-07 CLEAR TUBE LOWER 18 PRT80351-18 DRIVER
8 PRT80351-08 SCREW 2.9X16 19 PRT80351-19 ALUMINUM TUBE,UPPER
9 PRT80351-09 BRIGHTNESS INDICATE COVER 20 PRT80351-20 ELASTIC BAND
10 PRT80351-10 RIGHT HANDLE SET 21 PRT80351-21 BLOCK
11 PRT80351-11 ON/OFF SWITCH
Visit us at www.atdtools.com
Copyright (C) 2013 ATD Tools, Inc. All rights reserved.
