ATD Tools ATD-10836 User manual

Cordless Screwdriver
3.6V Lithium ion
ATD-10836
CAUTION: Read this operation manual before using this tool.
1. 6.35mm (1/4”) Quick Connect Chuck
2. Torque Collar
3. Battery Charge Indicator
4. Rear Rotating handle lock button
5. Forward/Reverse Slide Lever
6.Charge Indication LED
7. Charging Socket
8. ON/OFF Switch
9. LED Light On/Off Button
10.LED Light
11. Charger Plug
12. 120V Charger Adaptor
Specifications
Motor: 3.6 V
Input: 120V ~ 60Hz
No load speed: 200/min
Additional Safety Instructions For Chargers And
Batteries
Danger! If the battery pack case is cracked or damaged, do not insert into
charger. There is a danger of electric shock or electrocution.
Warning! Don’t allow any liquid to get inside charger. Electric shock may result.
To facilitate cooling of the battery pack after use, avoid placing the charger
or battery pack in a warm environment such as in a metal shed, or an
un-insulated trailer.
• Before using the charger, read all instructions and cautionary markings on
charger, battery pack and product using the battery pack.
• Do not place any object on top of the charger or place the charger on a
soft surface that may result in excessive internal heat. Place the charger in a
position away from any heat source.
•To reduce risk of damage to the electric plug and cord, pull by the plug
rather than the cord when disconnecting the charger.
• Make sure cord is located so that it will not be stepped on, tripped over, or
otherwise subjected to damage or stress.
123
8
5
9
10
7
6
4
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and
must be repaired.
c) Disconnect the plug from the power source and/or the battery pack
from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate
the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from
those intended could result in a hazardous situation.
5) Battery tool use and care
a) Recharge only with the charger specified by the manufacturer. A
charger that is suitable for one type of battery pack may create a risk of
fire when used with another battery pack.
b) Use power tools only with specifically designated battery packs. Use of
any other battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other small
metal objects, that can make a connection from one terminal to
another. Shorting the battery terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery;
avoid contact. If contact accidentally occurs, flush with water. If
liquid contacts eyes, additionally seek medical help. Liquid ejected
from the battery may cause irritation or burns.
6) Service
a) Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
b) If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is unavoidable, use a
residual current device (RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection.Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your finger on the switch or
energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on.
A wrench or a key left attached to a rotating part of the power tool may
result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used. Use
of dust collection can reduce dust-related hazards.
Save all warnings and instructions for future reference.
The term “power tool” in all of the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
WARNING! Read all safety warnings and all instructions. Failure
to follow the warnings and instructions may result in electric
shock, fire and/or serious injury.
General Power Tools Safety Warnings
Output: 6V DC 300mA
Battery: 3.6V 1300mAh
Gearbox: Single Speed
12
11

•An extension cord should not be used unless absolutely necessary. Use
of an improper extension cord could result in the risk of fire, electric
shock or electrocution.
• Do not operate charger if it has received a sharp blow, been dropped
or otherwise damaged in any way. Have it checked by an electrician or
power tool repairer.
• Do not disassemble charger. Take it to an electrician or power tool
repairer when service or repair is required. Incorrect reassembling may
result in a risk of electric shock, electrocution or fire.
•To reduce risk of electric shock, unplug charger from the outlet before
attempting any cleaning. Removing the battery pack will not reduce
this risk.
• Never attempt to connect 2 chargers together.
• DO NOT store or use the tool and battery pack in locations where the
temperature may reach or exceed 40ºC (such as outside sheds or metal
buildings in summer).
•The charger is designed to operate on standard household electrical
power (120 Volts). Do not attempt to use it on any other voltage!
The battery pack is not fully charged out of the carton. First read the
safety instructions and then follow the charging notes and procedures.
•The longest life and best performance can be obtained if the battery
pack is charged when the air temperature is between 18 - 24ºC. Do not
charge the battery pack in an air temperature below 10o C or above
40ºC. This is important and will prevent damage to the battery pack.
• Do not incinerate the battery pack even if it is seriously damaged or is
completely worn out. The battery can explode in a fire.
• Never attempt to open the battery pack for any reason. If the plastic
housing of the battery pack breaks or cracks, immediately discontinue
use and do not recharge.
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
Charging the Battery
This tool has been shipped in a low charge condition
and should be fully charged prior to use.
Plug the 120V charger adaptor (12) into an appropriate
AC power outlet and switch on.
Connect the charger plug (11) of the AC adaptor into
the charging socket (7) of the screwdriver.
The red charge indication LED (6) will illuminate.
The batteries will take 3-5 hours to charge. This may vary up to 7 hours due
to the level of charge left in the batteries and also the ambient temperature.
NOTE: The charge indicator LED (6) will always be illuminated when the
charger is plugged in and turned on!
Initial Charge
Charge your battery for 5-7 hours then use it until it runs down and only
slowly operates. Recharge for 5-7 hours again.
Once again run your tool until only a small amount of charge remains.
Repeat the above cycle about 4 or 5 times, this should set the battery
“memory”, then charge as earlier stated.
Caution: This charger does not automatically turn off when the battery is
fully charged. Please take care not to leave the tool on the charger turned
on for excessive periods of time.
Switch off the charger at mains when charging is complete.
NOTE: The charge indicator LED (6) will be illuminated when the charger is
plugged in charging the screwdriver. The charge indicator LED (6) will turn
off when the screwdriver is fully charged.
Inserting Driver Bits
Important! Always unplug the charger and make sure
the forward/reverse lever (5) is in the lock position. Refer
to Forward / Reverse Lever in the coming instructions.
The screwdriver has a quick connect chuck (1) feature,
simply slide the collar of the quick connect chuck (1)
back towards the torque collar (2) to either insert or extract the driver bits
you are using. Release the collar once you have inserted the driver bit
to lock in your bit.
Replacement Driver Bits can be purchased at any tool store.
Always ensure that you only use single ended 2 .
For driver bits shorter than 50mm, it must be used with bits holder which is
also included in this kit. Otherwise, shorter driver bits may become stuck or
hard to remove from the screwdriver.
On/Off Switch
Depress the On/Off trigger (8) to start the screwdriver and keep holding it
for continuous operation.
To stop the screwdriver, release the On/Off trigger (8).
Note: This screwdriver does not have variable speed!
Additional Safety Instructions For Chargers
And Batteries (cont.)
Operation
Forward / Reverse Lever
To select the forward or reverse on your screwdriver
simply push the forward/ reverse slide lever (5) to the
left side for reverse (R) or the right side for forward (F).
To lock the screwdriver simply ensure that the
forward/reverse lever (5) is placed in between forward
or reverse position.
Torque Settings
When using your screwdriver for various driving applications, it becomes
necessary to increase and decrease the power and torque in order to
prevent the possibility of damaging screw heads, threads, work piece, etc.
In general, power and torque should correspond to the size of the screw
and the material type that the screw is being driven into.
To Adjust Torque
• Locate the arrow on the front of torque collar (2).
• Identify the drill bit icon or non torque setting and
6 torque settings on the front of the drill.
• Rotate the torque collar (2) to the desired setting
aligning the number on the front of the screwdriver
with the arrow torque collar (2).
•To increase or decrease torque, rotate torque
collar (2). The lower the number, the lower the torque or twisting action
the screwdriver will produce. The higher the number, the higher the
torque or twisting action the screwdriver will produce.
Always check that the correct torque setting is selected by practicing on
scrap material prior to carrying out a job.
Pre Drilling your Material
It is recommended to pre drill holes in the material you are about to screw
into. Pre drilling holes will assist the screwdriver when driving screws and
enable your tool to operate efficiently.
Operation Of The Screwdriver
Only use driver/drill bits which can be securely fastened in the quick
connect chuck (1) and for which the bits have been designed.
Before using the screwdriver check whether the screw-bit is inserted cor-
rectly. Avoid over-tightening screws, otherwise the screw head may be
damaged or stripping of the threads may occur.
Screw Insertion
Set the direction of rotation of the screwdriver to the clockwise/forward
direction using the forward/reverse lever (5). Insert the required driver bit
into the head of the screw. Hold the driver bit in line with the head of the
screw, otherwise the screw or the screw head may be damaged. Always
keep constant pressure while driving in the screw to avoid damage to the
driver bit or screw head.
Depress the On/Off switch (8) to start driving the screw into your workpiece.
Always hold the screwdriver firmly and when the screw is completely
screwed in, release the On/Off switch (8), otherwise the screw or the screw
head may be damaged. If the On/Off switch (8) is not released immediately
the high torque could also damage the driver bit or the screwdriver.
Screw Removal
Set the direction of rotation of the screwdriver to the anticlockwise/reverse
direction using the forward/reverse lever (5). Insert the required driver bit
into the head of the screw. Hold the driver bit in line with the head of the
screw, otherwise the screw or the screw head may be damaged.
Always keep constant pressure while driving or removing the screw to
avoid damage to the driver bit or screw head.
Depress the On/Off switch (8) to start removing the screw from your workpiece.
Always hold the screwdriver firmly and when the screw is completely
removed, release the On/Off switch (8).
Rotating Rear Handle
This screwdriver has two different handle configurations to assist with your
job requirements. Inline will assist you in hard to reach areas where
additional reach is required. Bent or “L” shape will provide you with
additional grip for those jobs where more torque is required.
To return the handle to the original position press the rotating handle lock
button (4) and rotate the handle clockwise till the handle locks into position.
,,

Battery Charge Indicator
The screwdriver is equipped with a battery charge
indicator (3) to assist you to determine how charged
your screwdriver may currently be.
To check how much charge your screwdriver may
have simply press the button below the battery charge
indicator (3) and the LED lights will illuminate.
A red Led informs you that the screwdriver requires
charging, an orange Led indicates that the screwdriver is low in charge
andquires charging.
A green LED indicates that the screwdriver is fully charged and ready
for use.
LED Light
The screwdriver has a built in LED light (10) to
illuminate dark areas. Simply press the LED light
On/Off button (9) on and off as required. Turn
off the LED light when not needed to save battery life
by pressing the LED light On/Off button (9) again.
This will turn off the LED light (10).
Maintenance
• Keep the ventilation vents of the tool clean at all times, if possible,
prevent foreign matter from entering the vents.
•After each use, blow air through the tool housing to ensure it is free from
all dust particles which may build up. Build up of dust particles may
cause the tool to overheat and fail.
• If the enclosure of the tool requires cleaning do not use solvents but a
moist soft cloth only. Never let any liquid get inside the tool; never
immerse any part of the tool into a liquid.
Note: ATD Tool will not be responsible for any damage or injuries
caused by the repair of the tool by an unauthorised person or by
mishandling of the tool.
Operation (cont.)
Caring For The Environment
Power tools that are no longer usable should not be
disposed of with household waste but in an
environmentally friendly way. Please recycle where
facilities exist. Check with your local council authority
for recycling advice.
Recycling packaging reduces the need for landfill and
raw materials. Reuse of recycled material decreases
pollution in the environment. Please recycle packaging
where facilities exist. Check with your local council
authority for recycling advice.
Description of Symbols
Contents
1 x Cordless Screwdriver
1 x Charger
1 x 2 1/4 Bits Holder
28 x 1 CRV Bits
6 x 2 CRV Bits
1 x Instruction manual
V
~
mA
A
dc
Hz
W
no
/min
Volts
Alternating current
Milliamperes
Amperes
Direct current
Herts
Watts
No load speed
Revolutions or reciprocation per minute
Double insulated
Warning
Isolation transformer
Indoor use only
Polarity
,,
,,
,,

Parts List
1 PRT10836-01 CORLESS SCREWDRIVER
2 PRT10836-02 REPLACEMENT CHARGER
3 PRT10836-03 #3 Slotted Screwdriver Bit-1"
4 PRT10836-04 #4 Slotted Screwdriver Bit-1"
5 PRT10836-05 #5 Slotted Screwdriver Bit-1"
6 PRT10836-06 #6 Slotted Screwdriver Bit-1"
7 PRT10836-07 #7 Slotted Screwdriver Bit-1"
8 PRT10836-08 #0 Phillips Screwdriver Bit-1"
9 PRT10836-09 #1 Phillips Screwdriver Bit-1"
10 PRT10836-10 #2 Phillips Screwdriver Bit-1"
11 PRT10836-11 #3 Phillips Screwdriver Bit-1"
12 PRT10836-12 #0 Pozi Screwdriver Bit-1"
13 PRT10836-13 #1 Pozi Screwdriver Bit-1"
14 PRT10836-14 #2 Pozi Screwdriver Bit-1"
15 PRT10836-15 #3 Pozi Screwdriver Bit-1"
16 PRT10836-16 2mm Hex Bit
17 PRT10836-17 2.5mm Hex Bit
18 PRT10836-18 3mm Hex Bit
19 PRT10836-19 3.5mm Hex Bit
20 PRT10836-20 4mm Hex Bit
21 PRT10836-21 5mm Hex Bit
22 PRT10836-22 6mm Hex Bit
23 PRT10836-23 T10 Torx Bit
24 PRT10836-24 T15 Torx Bit
25 PRT10836-25 T20 Torx Bit
26 PRT10836-26 T25 Torx Bit
27 PRT10836-27 T27 Torx Bit
28 PRT10836-28 T30 Torx Bit
29 PRT10836-29 T40 Torx Bit
30 PRT10836-30 T45 Torx Bit
31 PRT10836-31 #00 Phillips Screwdriver Bit 2"
32 PRT10836-32 #0 Phillips Screwdriver Bit-2"
33 PRT10836-33 #1 Phillips Screwdriver Bit-2"
34 PRT10836-34 #2 Phillips Screwdriver Bit-2"
35 PRT10836-35 #4 Slotted Screwdriver Bit-2"
36 PRT10836-36 #6 Slotted Scewdriver Bit-2"
37 PRT10836-37 2 1/4" Bit Holder
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
No. Part no. Description Qty
