Model T70 PBM M
ODEL T70 PBM
High Performance Powered Subwoofer
Congratulations on your purchase of an Atlantic Technology T70 PBM
powered subwoofer. With proper care, your new subwoofer will
provide many years of trouble-free performance.
The T70 PBM is capable of delivering very high output levels and wide
dynamic range. When properly placed it will provide smooth in-room
bass response down to approximately 25Hz, with a peak SPL of 103dB
(1500 cubic foot space).
The built-in proprietary high-current amplifier is conservatively rated
at 125 watts RMS. This amplifier, coupled with a massive 10" long-
throw treated cellulose pulp woofer in a sealed enclosure, generates
musically accurate deep bass with a minimum of distortion.
Your Atlantic Technology powered subwoofer will smoothly integrate
with virtually all other brands of loudspeakers on the market as all its
internal electronics have been designed to maintain optimum signal integrity. From the premium
quality amplifier to the clearly marked controls, this is one of the most versatile high performance
subwoofers you can buy. An added benefit is its relatively compact size and straight forward design.
Features
Your Atlantic Technology powered subwoofer has been engineered using the latest technology and
finest components available. It features:
●
A long-throw 10" driver with vented motor structure and 2" high temperature, 4-layer voice coil
This powerful driver has a very stiff treated cellulose pulp cone that acts as an almost perfect
piston throughout its operating range. Its massive magnetic motor assembly and high
temperature component parts deliver high performance and exceptional reliability.
●
A sealed enclosure for low distortion and deep bass output
Sealed enclosure designs are inherently low in distortion and naturally deliver deep, smooth bass
response with a gradual and predictable roll-off below resonance. As with all Atlantic Technology
subwoofers, we have paid inordinate attention to giving you accurate musical bass reproduction
along with terrific special effects.
●
A linear power high current Class A/B amplifier conservatively rated at 125 watts RMS
The T70 PBM’s custom-designed discrete amplifier has been precision matched and equalized to
its 10" driver. It exerts accurate and powerful control over the driver for the best performance
possible.
●
A useful in room working frequency range of 25Hz to 150Hz
●
A continuously adjustable 24dB/octave crossover with a range of 60 Hz to 150Hz
This sophisticated crossover’s steep upper end roll-off slope of 24 dB per octave allows for
exceptional integration with most any brand or type of satellite speaker on the market. In
particular, the 24dB/octave design makes the T70 PBM ideal for use with compact, bass restricted
satellite speakers.

○○○○○○○○○○○○○○○○○○○○○○○○○○
3
○○○○○○○○○○○○○○○○○○○○○○○○○○
Atlantic Technology ®
Figure 1:
Typical amplifier
panel and controls
for Model T70 PBM.
You’re amplifier
may differ from
this illustration.
Important Note: If you are using a surround receiver/processor that includes its own filtered subwoofer
output we recommend that you set the crossover control on the T70 PBM to 150Hz.
●
Two line inputs, two line thruputs
The thruputs allow daisy chaining of multiple subwoofers, or can act as a return path back to the
processor.
●
Two high level inputs, two high-pass outputs
These let you connect the subwoofer to your amplifier using the amplifier’s speaker outputs. The
High-pass speaker outputs provide a bass-filtered signal and are intended to connect to the left
and right front satellite speakers.
STANDBY/ON
ACINPUT
WARNING: FORCONTINUEDPRO-
TECTIONAGAINSTRISKOFFIRE,
REPLACEONLYWITHSAMETYPEFUSE.
AVIS: UTILISERUNFUSIBLEDE
RECHANGEDEMEMETYPE.
POWER
115VUSEFUSET4A/250V
230VUSEFUSET2A/250V
L/MONORIGHT
BASS
LEVEL
PHASE
INVERT
CROSSOVER
FREQUENCY
ON
ON
AUTO
OFF
INPUT
RIGHT
LEFTL/MONO
MIN
60Hz
80Hz
RIGHT
OUTPUT
OUTPUT
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
SW-100D-CE DATE OF MFG
2001 01 00001
AVIS: RISQUEDECHOCELECTRIQUE/NEPASOUVRIR

○○○○○○○○○○○○○○○○○○○○○○○○○○
4
○○○○○○○○○○○○○○○○○○○○○○○○○○
Model T70 PBM
●
A Phase Invert switch (Normal/Invert)
This switch allows precise acoustic matching with speaker systems whose output may be phase
reversed. This switch also allows you to compensate for unusual room acoustics that occur when
a woofer is physically separated from the midrange/high frequency units. Be sure to try the Phase
switch in both positions when you set up the T70 PBM. Even if you just change the built-in
crossover settings it’s a good idea to try the Phase switch in both positions, since the crossover
control and the Phase switch acoustically interact with each other.
●
A rear panel mounted level control
●
Automatic standby operation
Automatic standby features automatic signal sensing turn on and a 7-12 minute turn-off delay.
●
Designed and built to meet all UL safety requirements
Connecting Your Subwoofer
The Atlantic Technology System T70 PBM Powered Subwoofer is simple to hook up, offering several
connection methods for maximum flexibility. Study the system diagrams starting on the next page.
Once you have found the example which most closely matches your system, hook up your
subwoofer(s) as shown in that diagram.
Low-Level Connection
If you have purchased the entire System T70, we suggest using the low-level (RCA jack) subwoofer line
out or preamp output if your receiver/processor has one. Simply connect your subwoofer with high
quality shielded cables as shown in the diagrams. Use the diagram that best suits your connection
requirements.
Using the Low-level Thruput
If desired, you can run a line level signal through the T70 PBM and out to another unit. This way you
can add an additional subwoofer with minimal additional wiring. The signal that comes out of the
Thruput jacks is identical to the input signal.
High-Level Connection
Alternately, you may use the high-level (speaker) inputs. We recommend that you connect your new
T70 PBM Powered Subwoofer(s) using high quality wire of 16 gauge or larger. There are many respected
manufacturers in the audio industry that specialize in speaker wire and interconnect cables suitable for
your new system. Please consult your audio/video dealer for more specific information.
High-level Output
If desired, you can run a high level signal into the T70 PBM and directly out to the left and right front
speakers. This method is primarily intended for systems without a built-in crossover or a dedicated
subwoofer output. The signal that comes from the High-level Output jacks has the bass filtered from
the input signal.
Warning: To prevent risk of electrical shock or damage to your equipment, always unplug all component AC
cords before proceeding with speaker and component connections! The last step in wiring your system should
be plugging in the AC cords!

○○○○○○○○○○○○○○○○○○○○○○○○○○
5
○○○○○○○○○○○○○○○○○○○○○○○○○○
Atlantic Technology ®
Example 1:
Subwoofer
Line Out/
Low Level In
When using this
connection
method, please
see the Important
Note on page 3.
Example 2:
Preamp Line
Out/Low
Level In for
1 Subwoofer
This arrangement
is for owners of
stereo receivers/
amplifiers with
Preamp outputs.
If your receiver/
amplifier uses
jumper links be-
tween the Pre-out
and Main In, then
you must remove
them and use
option 1 or 2. If
your receiver/
amplifier uses a
switch instead of
jumpers, then use
option 3.
Option 1
Option 3
Option 2
Single Sub Woofer
Pre Out
Main In
LR
Receiver/Amplifier/Processor
Pre Out
Main In
LR
Pre Out
Main In
LR Internal
Pre Amp
External
Pre Out
Main In
LR
INPUT
LEFT L/MONO
L/MONO
+
-
INPUT
OUTPUT
RIGHT
RIGHT RIGHT
INPUT
LEFT L/MONO
L/MONO
+
-
INPUT
OUTPUT
RIGHT
RIGHT RIGHT
INPUT
LEFT L/MONO
L/MONO
+
-
INPUT
OUTPUT
RIGHT
RIGHT RIGHT
Y-adapters
Sub Woofer Out
Single Sub Woofer Optional Second Sub Woofer
Receiver/Amplifier/Processor
INPUT
LEFT L/MONO
L/MONO
+
-
INPUT
OUTPUT
RIGHT
RIGHT RIGHT
INPUT
LEFT L/MONO
L/MONO
+
-
INPUT
OUTPUT
RIGHT
RIGHT RIGHT

○○○○○○○○○○○○○○○○○○○○○○○○○○
6
○○○○○○○○○○○○○○○○○○○○○○○○○○
Model T70 PBM
Example 3:
Preamp Line
Out/Low Level
In for
2 Subwoofers
Note that the
L/MONO input is
used on both sub-
woofers. Instead
of Y-adapters, you
may also use the
outputs to con-
nect back to the
Main Inputs as
shown in Option
2 of Example 2.
Pre Out
Main In
LR
Left Sub Woofer Right Sub Woofer
Receiver/Amplifier/Processor
INPUT
LEFT L/MONO
L/MONO
+
-
INPUT
OUTPUT
RIGHT
RIGHT RIGHT
INPUT
LEFT L/MONO
L/MONO
+
-
INPUT
OUTPUT
RIGHT
RIGHT RIGHT
Y-adapters
Example 4:
Speaker Out/
High Level In for
1 Subwoofer
This is the most
common method
for connecting a
subwoofer to a
system without a
dedicated sub-
woofer line out or
Preamp outputs.
The signal that
comes from the
High-level Output
jacks has the bass
filtered from the
input signal.
Left Right
Main Speakers
Sub WooferLeft Front Speaker Right Front Speaker
Receiver/Amplifier
INPUT
LEFT L/MONO
L/MONO
+
+
-
-OUTPUT
INPUT
OUTPUT
RIGHT
RIGHT RIGHT

○○○○○○○○○○○○○○○○○○○○○○○○○○
7
○○○○○○○○○○○○○○○○○○○○○○○○○○
Atlantic Technology ®
Example 5:
Speaker Out/
High Level In for
2 Subwoofers
This is the most
common method
for connecting 2
subwoofers to a
system without a
dedicated sub-
woofer line out or
Preamp outputs.
Note that the
L/MONO High
Level input is used
on both left and
right subwoofers.
Left Right
Main Speakers
Left Sub Woofer Right Sub WooferLeft Front Speaker Right Front Speaker
Receiver/Amplifier
INPUT
LEFT L/MONO
L/MONO
+
+
-
-
OUTPUT
INPUT
OUTPUT
RIGHT
RIGHT RIGHT
INPUT
LEFT L/MONO
L/MONO
+
+
-
-
OUTPUT
INPUT
OUTPUT
RIGHT
RIGHT RIGHT
You can connect to the High-level inputs by removing 1/2" of insulation from each wire end, twisting
the strands of wire together and placing the wire into the appropriate binding post on the rear of the
woofer as illustrated. Be careful that no stray strands of wire touch across connections.
It is important to observe polarity while making speaker connections: red (+) terminals on the ampli-
fier to red (+) on the speaker, black (–) on the amplifier to black (–) on the speaker. Look carefully at
the wires you are using and note that one of the wires in each pair will be marked by either the con-
ductor color, printing on the wire jacket, a ridge on one side of the wire jacket, or a thread intertwined
with the wire strands. By convention, the marked wire is connected to the red (+) terminal.
Power Connection
Connect the power cord to an AC outlet only after making all other connections to the subwoofer.
This will avoid any chance of accidentally activating the subwoofer while wiring. Atlantic Technology
does not recommend plugging the subwoofer into the switched outlet of an amplifier, preamplifier,
or receiver. The power demands of the subwoofer amplifier may exceed the power rating of the
switched outlet and may damage the equipment.
The T70 PBM is totally automatic in its operation. The automatic on/off circuitry will only activate the
subwoofer in the presence of an audio signal from your audio/video system. After 7-12 minutes with
no signal detected from the rest of the system, the amplifier will shut itself off and go into standby
mode. Power consumption in the standby mode is negligible. Standby operation can be completely
bypassed by placing the “Auto” switch in the “On” position. In this mode, the subwoofer will be
controlled by the position of the Main Power switch.

○○○○○○○○○○○○○○○○○○○○○○○○○○
8
○○○○○○○○○○○○○○○○○○○○○○○○○○
Model T70 PBM
Figure 2:
Typical arrange-
ment for a single
subwoofer in a
home theater.
Start here
Less Bass
More Bass
Placement and Operation
Generally speaking, the best location for your new Subwoofer will be in the front of the room, in or
close to a corner (Figure 2). Every room has its own unique sound characteristics, and flexibility in the
exact placement of the subwoofer is always desirable. The closer the subwoofer is placed to a wall and
especially a corner, the more and deeper the bass response you will hear. However, in some rooms,
corner placement can produce too much bass or a “one note” boomy effect. Under such circumstances
the subwoofer may work better away from the wall or corner. You should experiment to find the best
position in your room.
Helpful Hint: A particularly useful experiment is to place the subwoofer right at the prime listening position
(move that couch or chair out of the way and put the sub in its place). Then play something with lots of good
bass (preferably music), and walk around the room, listening to the subwoofer’s response. When you locate an
area that has ample amounts of well defined bass you have found a good potential place to locate the sub.
Dual Subwoofer Placement
When two subwoofers are used you may wish to place them asymmetrically; that is, in slightly
different positions in the room (Figure 3). This will reduce common mode room resonances that
typically occur with symmetrically placed subwoofers. Another good option is to place the subwoofers
in the same corner. Several tests have shown this to be a viable means of producing smooth bass
response in many rooms.
Subwoofer Tuning Using the Variable Level Control
Assuming that you do not have access to a Sound Pressure Level meter for system set up, start your
listening with the subwoofer crossover control set at approximately two-thirds of its range (which
corresponds to approximately 100Hz), the phase switch set to normal, and the variable level control
set to the bottom of its range (fully counterclockwise facing the back of the woofer). Play some music

○○○○○○○○○○○○○○○○○○○○○○○○○○
9
○○○○○○○○○○○○○○○○○○○○○○○○○○
Atlantic Technology ®
that you know has good bass content, and turn the level control up until you just start to hear the
subwoofer working. Now, from your normal listening position, determine whether the subwoofer is
playing loudly enough and filling in the bass frequencies of the music evenly. If adjustment is
necessary, start by changing the setting of the rear mounted level control to compensate.
If the bass seems too heavy, move the subwoofer away from the wall/corner. If the bass seems too thin,
move the subwoofer closer to the wall/corner. Small differences in positioning can make big
differences in bass response. When you find a position that seems to work well, have someone switch
the phase switch between its two settings, while you’re in the prime listening position. Pay particular
attention to both the deep bass and the transition from the subwoofer to the satellites.
Sometimes people prefer more bass impact for movies than sounds natural when reproducing music.
You may wish to determine both a video level and an audio level if you find yourself falling into this
camp. Remember however, the most common error people make when setting up their system is to
play the subwoofer (and surround speakers) too loudly. Of course, the Bass Police will not arrest you
for this act. But should you desire the most accurate overall reproduction, a well balanced sound from
bass to highest treble is the best way to get it.
Using the Crossover Control
When used with the complete T70 system, the T70 PBM crossover control should be set at two-thirds
of its range as stated above. The goal is to optimize the performance of the system by ensuring that the
subwoofer and satellites produce a cohesive and well integrated sound “picture.” The low frequency
response of the T70 satellites has been optimized to work with approximately a 100Hz crossover point.
This provides maximum performance and the smoothest integration with the subwoofer.
Higher crossover frequencies pass more bass but can sound boomy and may be more easily localized to
the subwoofer. Higher crossover frequencies may be suitable, however, when using very small satellites
that have no real low frequency performance. Settings lower than 90Hz should be employed if you are
using full range speakers that have extended bass response. This way, the subwoofer will only
reproduce the very lowest bass frequencies that are in the range where the large main speakers begin to
roll off. It’s generally undesirable to have the main speakers and the subwoofer overlap too much.
Larger speakers generally require a lower crossover frequency, smaller speakers generally a higher
Figure 3:
Assymmetrical
arrangement for
2 subwoofers in
a home theater,
for example, one
closer to a corner
than the other.

○○○○○○○○○○○○○○○○○○○○○○○○○○
10
○○○○○○○○○○○○○○○○○○○○○○○○○○
Model T70 PBM
crossover frequency. Consult the manufacturer’s specified low frequency response for your main
speakers to determine the appropriate setting on the subwoofer. In the end, however, a little time
spent experimenting will generally result in dramatically better bass response.
The Phase Invert Control
A subwoofer operating out of phase with the rest of the system won’t provide optimum low frequency
performance. Also, the correct subwoofer phase can enhance room acoustics. Since there is so much
variation in the industry regarding phase, and no standards have been established, a switch that will
reverse the phase of the subwoofer is provided on the amplifier panel. Listen to a monaural musical
source with strong bass content. (For example, you can use the mono switch on an FM tuner or
preamp, or use a Y-connector on the outputs of one of your source components to get a mono signal.)
Have someone experiment with the position of the phase switch to get the most extended bass while
you’re sitting in the prime listening position. It should be obvious which is the correct setting. In
particular, there will be a smoother more integrated transition between the satellites and the
subwoofer when they are properly phased.
A Word About Bass, Center Channel Modes, and System Set Up
Many Dolby Pro Logic surround processors and surround receivers feature a “Wide” and “Normal”
mode for the center channel speaker. Atlantic Technology recommends that the center channel be
operated in the Normal mode when using a powered subwoofer. The center channel speaker will
sound more dynamic and the intelligibility of the system will generally be improved when in the
Normal mode.
With discrete digital “5.1” channel systems (Dolby Digital AC-3, etc.) many controllers provide a Bass
Management option, which lets you set the front and rear speakers in a limited bandwidth (Small) or
full range (Large) mode. All Atlantic Technology speakers are designed to be used in the Small setting
with such a controller. However, when using high level connections, the Large setting should be used.
Care and Feeding of Your Subwoofer
The T70 PBM is constructed from 3/4" Medium Density Fiberboard. MDF is a non-resonant material
ideal for speaker system enclosures. The outside of the woofer is layered with a high quality Black Oak
finished vinyl laminate. To clean the cabinet you may use a soft cloth either dry or slightly dampened
with clean water. Be careful not to wet the cabinet or allow any water to enter the cabinet seams.
Avoid placing your speakers in direct sunlight or near a source of heat that may, over time, damage the
finish.
Important: Save Your Boxes! If you can do so, save the carton, packing pieces and plastic bags that came
with your subwoofer. They will be useful in case you move or have to ship your subwoofer for any reason. In
any case, save all packing materials until you are certain that the system has suffered no damage in
shipment. If you find such damage, either visible or internal, contact your dealer immediately for the proper
return procedure.

○○○○○○○○○○○○○○○○○○○○○○○○○○
11
○○○○○○○○○○○○○○○○○○○○○○○○○○
Atlantic Technology ®
Subwoofer Troubleshooting Guide
Once your subwoofer is set up, you should have many years of maintenance free enjoyment from your
system. However, if you should encounter a problem, refer to the following guide to help find the
solution. If the problem persists, please contact your local authorized Atlantic Technology dealer.
Problem Possible Cause Possible Solution
No bass output AC power cord unplugged or plugged into a non-working outlet. Plug into a working outlet.
Input cables not securely connected or defective. Check all connections, then try another input cable.
Audible buzz Input cable not securely connected or defective. Check all connections, then try another input cable.
or hum Single HI LEVEL input connected to the RIGHT channel only. Connect to the LEFT input channel.
Ground loop through antenna or cable TV system input. Test by disconnecting antenna and/or cable system input leads.
If hum goes away, install isolation balun(s) at that point.
Weak bass Subwoofer too far from the wall. Move the subwoofer closer to a wall or corner.
VARIABLE INPUT LEVEL set too low. Turn control up somewhat.
Weak bass: vague stereo image Input source connected to HI LEVEL inputs is wired out of phase. Check speaker wire connections and reconnect in proper phase.
Model T70 PBM Specifications
Specifications are those in effect at the time of printing. Atlantic Technology reserves the right to change specifications or designs at any time without notice. Dolby Digital, AC-3,
Dolby Stereo and Dolby Pro Logic are trademarks of Dolby Laboratories Licensing Corporation. DTS is a registered trademark of DTS Technology.
Type/Features Powered Subwoofer with Sealed Acoustic-Suspension Enclosure
24 dB/Octave variable crossover
Line-level stereo inputs and thruputs
High-level stereo inputs and high-level, high-pass bass filtered outputs
Absolute phase invert switch
Auto signal sensing on/off
Driver (1) 10" long-throw woofer, 2", 4-layer vented voice coil, vented
motor system
Amplifier Power 125 Watts RMS discrete linear Class A/B power amplifier
Amplifier Distortion <0.025%
Frequency Response 25-150 Hz␣ ±3dB (in room)
Peak output (SPL) 103dB
Dimensions 11.375in x 16.5in x 14.9in; 290mm x 420mm x 380mm
Weight 37.5lbs.; 17kg.

○○○○○○○○○○○○○○○○○○○○○○○○○○
12
○○○○○○○○○○○○○○○○○○○○○○○○○○
Model T70 PBM
The lightning flash with arrowhead, within an
equilateral triangle, is intended to alert the user
to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that
may be of sufficient magnitude to constitute a
risk of electrical shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating maintenance
(servicing) instructions in the literature
accompanying the appliance.
CAUTION: To reduce the risk of electric shock, do not remove
the cover (or back). No user serviceable parts inside. Refer to
qualified personnel.
WARNING: To reduce the risk of fire or electric shock, do not
expose this appliance to rain or moisture.
For Future Reference
Record your speaker serial number and date of purchase here:
Model Number Serial Number Date of Purchase
The serial number is found on the back of the speaker near the connecting terminals.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
010-T172A
