Atlas 2N User manual

Owners Guide
Atlas Two Passenger
03-17-23

Operators Manual ATLAS CARTS
2
Operators Manual ATLAS CARTS
Owner’s Guide
Atlas Lifted Four Passenger
Model 2N
Atlas Carts
111 County Road 214
Liberty Hill, TX 78642
US: (833) UR-ATLAS
OUTSIDE US: [phone]
For the latest and most up-to-date version of this owners manual
scan the QR code below.

Operators Manual ATLAS CARTS
3
Operators Manual ATLAS CARTS
Table of Contents
Welcome
Ownership Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Dealership Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Documentation
Model and Serial Number . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Design / Engineering Changes by Atlas Carts . . . . . . . . . . . . . . . . .6
Vehicle Modifications by Others . . . . . . . . . . . . . . . . . . . . . . . . .6
Warranty
Atlas Carts Vehicle Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . .7–9
Safety First
General Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Safety Signal Words. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Rental and Fleet Usage Safety Guidelines . . . . . . . . . . . . . . . . . . .11
Vehicle Safety Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Vehicle Safety and Compliance Decals Locations . . . . . . . . . . . . . . .12–13
Warning Buzzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Regenerative Braking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Battery Safety and Recycling. . . . . . . . . . . . . . . . . . . . . . . . . . .14
Vehicle Controls and Features
Vehicle Controls Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Dash Displays and Indicators
Battery State of Charge (SOC) . . . . . . . . . . . . . . . . . . . . . . . . . .16
Hazard Flasher Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
USB Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Front Storage Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Key Start Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Charging Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Golf Tee Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Radio Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Steering Column Display Alerts
Error Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Low Voltage Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Parking Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Turn Signal Indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
High/Low Beams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Real time State of Charge (SOC). . . . . . . . . . . . . . . . . . . . . . . . .19
Real time Speed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Forward/Reverse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Hydraulic Oil Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Motor Fault. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Total Mileage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Onboard Battery Charger Safety Warning . . . . . . . . . . . .20
S E C T I O N
1
S E C T I O N
2
S E C T I O N
3

Operators Manual ATLAS CARTS
4
Operators Manual ATLAS CARTS
Table of Contents
Vehicle Certifications and Specifications
Federal Communications Commissions . . . . . . . . . . . . . . . . . . . .21
European Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Vehicle Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Vehicle Operation
Operator Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Daily Pre-Operation Check
Safety Check Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Daily Pre-Operational Checklist . . . . . . . . . . . . . . . . . . . . . . . . .24
Vehicle Maintenance
Maintenance Safety Overview . . . . . . . . . . . . . . . . . . . . . . . . . .25
Vehicle Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Preventative Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Maintenance & Service Recommendation . . . . . . . . . . . . . . . . . . .26
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Lifting the Vehicle Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Lifting the Vehicle Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Checking Tire Pressure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Wheel Assembly Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Wheel Assembly Installation . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Onboard Battery Charger
Battery Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Onboard Charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Charger Cord Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Vehicle Towing/Transporting
Preparing the Atlas Cart to be Towed. . . . . . . . . . . . . . . . . . . . . .31
Preparing the Atlas Cart to be Transported on a Trailer . . . . . . . . . . . .31
Extended Storage
Storing the Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Restoring the Vehicle After Storage. . . . . . . . . . . . . . . . . . . . . . .32
S E C T I O N
4
S E C T I O N
5
S E C T I O N
6
S E C T I O N
7
S E C T I O N
8
S E C T I O N
9

Operators Manual ATLAS CARTS
5
S E C T I O N
1
Operators Manual ATLAS CARTS
Welcome
You are now the proud owner of a Atlas Carts personal vehicle. Please take
time to read and understand all the information provided in this owner’s
manual. Knowing how to operate and maintain your new vehicle is the best
way to protect your investment. Your new Atlas Cart has been designed to
provide you with many miles of reliable transportation.
Understanding all the operating instructions and safety precautions in this
manual will prevent the risk of personal injury or property damage.
Owners are responsible to register their vehicles immediately after purchase.
Registration of the vehicle will make sure Atlas Carts is able to communicate
any necessary information directly to owners.
To register online, vist; https://www.atlascarts.com/dealers/warranty
You can also mail your name, address, and vehicle serial number to:
Atlas Carts Warranty Department
111 County Road
Liberty Hill TX 78642
Ownership Information
Dealership Information Contact Atlas Carts customer support anytime for quick answers to your
questions and concerns. Your dealer or distributor can provide additional
information about:
Accessories
Publications
Replacement Parts
Technical Support
Warranty Information
To locate a dealership near you visit: www.atlascarts.com

Operators Manual ATLAS CARTS
6
S E C T I O N
1
Operators Manual ATLAS CARTS
Documentation
The vehicle serial number
plate is located on the
lower part of the dashboard
on the passenger side near
the right speaker. See the
dashboard illustration on
page 17.
ANY VEHICLE MODIFICATIONS OR CHANGES
THAT RESULT IN IMMINENTLY AFFECTING
OCCUPANT SAFETY, WILL RESULT IN DEATH
OR SERIOUS INJURY.
MODIFICATIONS TO THE VEHICLE MUST NOT
COMPROMISE COMPLIANCE WITH STATE OR
FEDERAL REGULATIONS.
Any modifications made to a Atlas Carts vehicle or installation of accessories
that are not approved by Atlas Carts may adversely aect the safe operation
and performance of the vehicle. Modifications may include, but are not limited
to suspension, seating changes, increased speed and cargo capacity. Atlas
Carts does not recommend any modification of this vehicle unless the modifi-
cation is specifically designed and oered by Atlas Carts.
However, if the vehicle is modified, the modifier shall:
1. arrange for the modification to be designed, tested and implemented by
an engineer with expertise in vehicles and their safety;
2. maintain a permanent record of the design, testing and implementation
of the modification;
3. make appropriate changes to the capacity, plate(s), decals, and operation
and maintenance manuals; and
4. apply a permanent and readily visible label on the vehicle stating the
vehicle has been modified with the date of the modification and the
name of the entity that made the modification.
The entity making any modification becomes the original equipment manu-
facturer of the modified vehicle, assumes liability for the vehicle, and has the
responsibilities listed above.
Refer to the warranty for specific details regarding vehicle modifications.
Model and Serial Number
Design/Engineering
Changes by Atlas Carts
Vehicle Modifications
by Others
Atlas Carts may make design changes to any Atlas Carts vehicle without
notifying owner or making the same changes to a previously purchased Atlas
Carts vehicle.
Atlas Carts is not liable for any errors or omissions in this manual or any
incidental or consequential damages that result from the use of any material
presented in this manual.
Atlas Carts, Austin, TXMfg Name:
Serial NO. 2N022319-000001
2N 02 2319-000001
2N 5
210AH 48
11/10/2022
220622069
223302930065
Model Name KW
Capacity Voltage
Date code
Motor S/N
Contr. S/N
Model
Number
Battery
Type
Production
Year/Week
Production
Position Number

Operators Manual ATLAS CARTS
7
S E C T I O N
1
Operators Manual ATLAS CARTS
Atlas Carts Vehicle Warranty
Warranty Time frame
Atlas warrants to the original purchaser or lessee, that its new vehicle or new
component purchased from Atlas or an Authorized Dealer or Distributor shall
be free from defects in material and workmanship under normal use and
service for the periods stated below, subject to the provisions, limitations
and exclusions in this limited warranty.
This limited warranty covers material, workmanship and repair labor cost for
the items specifically listed below for the periods listed. Such repair labor shall
be performed only by Atlas, its Authorized Dealers or Distributors, or a service
agency approved by Atlas. For repairs made by qualified technicians other
than Atlas factory technicians or an Authorized Dealer or Distributor, Atlas
will provide only the replacement parts or components.
Subsystem/Component Warranty
Vehicle Main Frame Lifetime For Material
And Workmanship
Suspension: Steering gearbox, Two years
steering column, shocks, leaf springs
and lifted system parts
Major Electronics: Solid state speed Two years
controller, e-brake, battery charger,
solenoid
Lithium Ion Battery and Battery Five years or 10,000 hours,
Management System (BMS) whichever comes first, retaining
a minimum of 70% of its original
capacity over that period
Pedal Group: Pedal group mechanical Two years
assembly, brake cluster assemblies
and cables
Seat System: Seat metal parts, seat armrests, Two years
rear flip seat system & all other parts of seat
except cushions
Electric Powertrain: Electric motor, Two years
transaxle and wheel
Body Group: Beauty panels (including Two years
dashboard, front and rear cowl), front
and rear underbody, structural assembly
module and bumper
Seat Cushions: Seat bottom and seat backs One year
All Other Parts and Accessories: safety belt One year
kit, lights, fender flares, limit switches, voltage
regulator, F&R switch, windshield, canopy
and support structure, side mirrors, center mirror,
options and accessories supplied by Atlas
Wear Items: Tires, fuses, decals, lubricants, No warranty
floor lining, mats, pads, brake lining pads,
bushings and items that deteriorate, fade or
fail due to exposure or ordinary wear and tear

Operators Manual ATLAS CARTS
8
S E C T I O N
1
Operators Manual ATLAS CARTS
Atlas Carts Vehicle Warranty
Exclusions Excluded from any Atlas warranty is damage to a vehicle or component resulting
from a cause other than a defect including poor maintenance, neglect, abuse,
accident and collision, maintenance adjustments, unreasonable or unintended
strain or use, improper installation of accessories, installation of parts or
accessories that are not original equipment including Atlas approved or
non- approved GPS systems, non-approved alteration, and acts of God.
Also excluded from any Atlas warranty are all fuses, filters, decals (except safety
decals), lubricants, routine wear items such as engine mounts, bed floor lining,
mats, pads, spark plugs, light bulbs, brake pads, brushes, solenoids, bushings,
drive buttons, cosmetic deterioration, and items that deteriorate, fade or fail due
to exposure or ordinary wear and tear.
The provisions of this limited warranty shall not apply to failure due
to the following conditions:
• Batteries
– Tampering with or opening of the battery case.
– Intentional overcharging or undercharging of a vehicle.
– Improper charging of a vehicle due to the use of a battery charger model
not approved by Atlas for use with the vehicle.
– Use of energy management systems that do not allow a minimum
of 4 hours of charge time to assure proper charging.
– Neglect, breakage, freezing, fire, explosion, wreckage, melted terminal
posts, the addition of any chemical, or the operation of the battery in an
uncharged condition; the installation of the batteries in reverse or
recharging in reverse, breakage of containers, covers, or terminal post,
or batteries used in applications for which they were not designed.
– A battery damaged by a defective charger or batteries in vehicles that
do not receive proper charging.
– A vehicle not having an operational charger on a circuit that has the
parameters specified in the vehicle operator’s manual (the number
of operational chargers must equal the number of operational vehicles),
or use of an unapproved algorithm.
• Operationoutsidethemanufacturer’sstatedallowableoperatingtempera-
ture of less than -15 degrees Celsius or more than 55 degrees Celsius.
Lack of proper maintenance such as preventive maintenance checks, proper
rotation of vehicles in a fleet application, maintaining proper tire pressure
and alignment and tightening loose wire connections as outlined in the
operator’s manual.
• Damagescausedbyimproperinstallationofthecomponent.
• Failedsemiconductorpartssuchdiodesandfusesthatarevulnerable
to electrical overloads (including lightning) beyond the control of Atlas.
• DamagedchargerACandDCcordsetwithplug,whichisawearitem
and subject to user abuse.
• Improperextendedstorage.
Transportation expenses for warranty services are also excluded from
this warranty.

Operators Manual ATLAS CARTS
9
S E C T I O N
1
Operators Manual ATLAS CARTS
Voiding of Warranty
Sole Remedy
Disclaimer
No Consequential
Damages
How To Make A Warranty
Claim
This warranty shall be void if the vehicle or component is damaged, involved
in an accident, abused or used in an unintended manner or shows indications
that it has been altered in any way, including, but not limited to, modification
of components, braking system, steering, transaxle, or other operating systems
of the cart to cause it to perform outside specifications. The warranty is also void
if the vehicle shows indications that reasonable or necessary maintenance as
outlined in the operator’s manual and maintenance and service manual was not
performed at the time and in the manner specified in such manuals.
Atlas’ liability under this limited warranty shall be the repair or replacement,
at Atlas’ option, of the vehicle or component that Atlas deems to be defective.
Replacement shall mean furnishing, during the applicable limited warranty peri-
od, a new vehicle or factory-reconditioned vehicle or component that is identical
or reasonably equivalent to the warranted product or component at no cost
to the purchaser. Repair shall mean remedying a defect in the vehicle or compo-
nent thereof at no cost to the purchaser during the applicable limited warranty
period. Atlas reserves the right to test and recharge any component returned
for adjustment. If Atlas elects to repair the vehicle or component, it may provide
factory-reconditioned parts or components. All parts and components replaced
under warranty shall become the property of Atlas.
This limited warranty is exclusive. Atlas makes no other warranty of any kind,
expressed or implied. The Purchaser and Atlas agree the sole remedy of the
replacement or repair of the defective vehicle or component is the sole remedy
of the Purchaser. Atlas makes no other representation or warranty of any kind,
and no representative, employee, distributor or dealer of Atlas has the authority
to make or imply any representation, promise or agreement, which in any way
varies the terms of this warranty.
In the event that another pre-printed warranty document, certificate or both
oered by or through Atlas at the time of sale of this vehicle (each an “Addition-
al Warranty Document”) is deemed to conflict with the limitations or exclusions
contained herein, the limitations and exclusions contained herein shall continue
to apply to both this limited warranty statement and, to the maximum extent
permitted by law, to each Additional Warranty Document.
In no event shall Atlas be liable for any incidental or consequential damages
including, but not limited to, loss related to property other than the vehicle,
loss of use, loss of time, inconvenience, or any other economic loss.
Some states allow neither limitation on the duration of an implied warranty nor
exclusions or limitation of incidental or consequential damages. Therefore, the
above limitations or exclusions may not apply to you. This warranty gives you spe-
cific legal rights, and you may also have other rights, which vary from state to state.
To make a warranty claim under this limited warranty, you must present the
vehicle or defective component with evidence of proof of purchase date and
number of amp hours (if applicable) to an authorized Atlas dealer.
For warranty-related communication, contact:
Atlas Carts
Attn: Warranty Department
111 County Road 214
Liberty Hill, TX 78642
Atlas Carts Vehicle Warranty

Operators Manual ATLAS CARTS
10
S E C T I O N
2
Operators Manual ATLAS CARTS
Safety First
General Information Only operate this vehicle as described in this manual. Speak with your local
dealer or distributor for changes, additions, or modifications that are necessary
to comply with local laws and regulations pertaining to the use of the vehicle.
Atlas Carts has designed this vehicle to transport two people along improved
or semi-improved byways. Typical applications include: commercial, industrial,
agriculture and personal use as permitted by local laws and regulations.
This vehicle can be used in a variety of usages outside of the manufacturer’s
intent. Atlas Carts cannot anticipate and warn for every possible usage condi-
tion. It is the responsibility of the operator to exercise good sense and judge-
ment and always operate the vehicle in an appropriate manner for the way in
which the vehicle is being used.
Signal words (DANGER, WARNING, CAUTION, and NOTICE) and safety mes-
sages are used in this manual to alert the owner to important safety messages.
Safety decals are also placed on the vehicle where applicable to notify the
owner/operator regarding safe operation and maintenance of the vehicle.
Read, understand, and obey all instructions, safety precautions, and safety
decals before vehicle operating the vehicle.
NEVER remove any safety decals. Missing, damaged, or unreadable safety
decals should be replaced immediately to prevent possible property damage,
personal injury, or death. Purchase replacement safety decals from your dealer
or distributor.
Understand and follow all laws and regulations for vehicle operation
in your area.
Speak with your dealer or distributor if you have questions about any material
contained in this manual or the vehicle.
Explanation of Safety Signal Words
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death
or serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in death
or serious injury.
CAUTION: Indicates a potentially hazardous
situation which, if not avoided, may result in minor
or moderate injury.
NOTICE: identifies a potentially hazardous situation
which could result in property damage.
Safety Signal Words

Operators Manual ATLAS CARTS
11
S E C T I O N
2
Operators Manual ATLAS CARTS
Safety First
Atlas Carts recommends that vehicles used as rentals or as part of a fleet
follow the following guidelines for safe service.
It is the responsibility of the vehicle owner to read and fully understand the ca-
pabilities and limitations of the vehicle. The vehicle owner is liable for the safe
use of this vehicle to prevent dangerous situations for the operator, passenger
and other people.
Serious personal injury or death can occur if you fail to comply with comply
with the instructions and procedures shown in this owner’s guide.
The vehicle or battery charger can cause flammable materials to ignite. Do not
operate the vehicle or battery charger near flammable materials and fumes.
The vehicle is not to be used in areas that contain explosive material.
Do not operate the vehicle in storms or when lighting is present in the area.
Get out of the vehicle immediately and find a safe shelter area.
Children must always be supervised when in or around the vehicle. Unintended
vehicle operation can cause death or serious personal injury.
Do not operate the vehicle when under the influence of alcohol, drugs, medica-
tions, or while distracted.
Electrical shorts can cause a fire or electrical shock resulting in death or
serious personal injury.
To prevent accidental electrical shorts or shocks while making any repairs,
always use insulated tools. Do not make contact between positive voltage and
the ground circuit.
Do not loiter in front of or behind the vehicle to prevent being hit by another
vehicle.
Only two persons may occupy the vehicle at any time. Do not allow people to
ride on any part of the vehicle that is not equipped with a seat. Never let a
passenger hold a child in his or her lap when the vehicle is moving.
Atlas Carts recommends that only trained technicians be allowed to service or
repair the vehicle. Technicians should have the knowledge and experience in
electrical and mechanical repair and are obliged to follow appropriate instruc-
tions when performing maintenance, service, or installing accessories.
Rental and Fleet Usage
Safety Guidelines
Vehicle Safety Guidelines
•Vehicleoperationareasmustbe
approved and all possible safety
hazards identified.
•Operatorsmustbequaliedand
approved to operate the vehicle.
•Provideinstructiontooperators
on safe vehicle operation.
•Maintainallvehiclesinsafe
operational condition.
•Besurethatallsafetydecals
are present on the vehicle.

Operators Manual ATLAS CARTS
12
S E C T I O N
2
Operators Manual ATLAS CARTS
Safety First
Vehicle Safety and
Compliance Decals
Take note of the various Safety Decals that are located in and around the
vehicle. Be sure to follow all the instructions on the safety decals to prevent
the risk of accidental death, serious personal injury, or property damage.
When cleaning the vehicle, do not use solvents, gasoline, or other chemicals to
clean the decals. Do not pressure wash decals. Instead, use a soft moist cloth
to gently remove any accumulated dirt that may obscure the information printed
on the decals.
Make sure all of the safety and operation decals are in the correct locations
as placed by the manufacturer. Do not remove any of the safety decals.
Always replace any safety and operation decals that are missing or damaged.
1
2
SERIOUS INJURY OR DEATH MAY OCCUR WITH UNINTENDED
MOVEMENT, COLLISION, ROLLOVERS OR FALLING OUT FROM VEHICLE
MAXLOAD: 2P = 500 lbs. MAX GRADE:20%
4P = 900 lbs.
•Only authorized and/or licensed personnel should operate this vehicle
•All operation should follow in compliance with local and state laws
•Unpaved surfaces, high traffic areas and driving near higher speed vehicles should be
done with cauton
•Do not obstruct traffic with operation of this vehicle
WARNING
•All occupants should be fully seated before the start and operation of this vehicle
•Maximum occupants per bench seat is two (2)
•Only driver side occupant should operate this vehicle
•Children should not be unattended with vehicle at any time
•Slower speed should be used when making turns and driving on inclined/declined surfaces
•Occupants should keep entire body secure within vehicle while vehicle is in motion
•This vehicle should not be operated under the influence of drugs or alcohol
•This vehicle should not ne operated when distracted
OPERATING INSTRUCTIONS
Users should read the vehicle manual and safety warnings to fully understand vehicle operation before use.
·Turn wheels in the direction of a clear path.
·Tu rn key to the ON position
·Only sh ift to forward or reverse when vehicle is completel y stoppe d
·Pressing on accelerator pedal will cause vehicle to move
·To increase vehicle speed, gradually press accelerator pedal
·Release accelerator pedal and press down brake pedal to “bring”
vehicle to full sto p
Severe injury or death may occur with unintended vehicle movement!
·Make sure parking brake is engaged when not in operation
·Vehicle should be place in Neutral when parking
·Turn key to the oposition and remove from key hole when not in operation
WARNING!

Operators Manual ATLAS CARTS
13
S E C T I O N
2
Operators Manual ATLAS CARTS
Safety First
3
4
5
7
6

Operators Manual ATLAS CARTS
14
S E C T I O N
2
Operators Manual ATLAS CARTS
Vehicle Safety Features
The vehicle comes equipped with a multi-purpose buzzer.
The warning buzzer makes an audible tone when:
•TheForward/Neutral/Reversecontrol(FNR)issettoR.
Regenerative Braking
Warning Buzzer
Battery Safety
and Recycling
Regenerative braking helps maintain the downhill speed of the vehicle
in relation to the accelerator pedal position.
Regenerative braking performance decreases when the battery
is fully charged.
Regenerative braking cannot maintain the vehicle speed on an excessive
grade (more than 20%). Use the brake pedal to control the vehicle speed.
When the battery is fully charged, a fault code will appear on the display
alerting the driver that regenerative braking will be reduced. Use the
brake pedal to control the vehicle speed.
Accelerator Pedal Position Vehicle Speed
Fully Regenerative braking maintains the speed
Pushed of the vehicle at the programmed top speed.
Partially Regenerative braking maintains the speed of the
Pushed vehicle at a percentage of the programmed top
speed in relation to the pedal position.
Fully Regenerative braking will slowly bring the
Released vehicle to a stop.
Note: Regenerative braking functions are controlled by
controller settings. Contact dealer for more information.
Damage including leaks and explosion can occur if a battery is flooded
or submerged. The battery must be replaced.
The battery is not serviceable. NEVER attempt to open the battery.
Attempting to open can result in electrical shock, explosion, or fire.
When a battery is no longer able to hold a charge, recycle the battery.
It is your responsibility to recycle Lithium-Ion batteries correctly. NEVER
discard lithium-ion batteries in your regular municipal trash collection.
Contact your dealer or check with your local recycling center.

Operators Manual ATLAS CARTS
15
S E C T I O N
3
Operators Manual ATLAS CARTS
Vehicle Controls & Features Overview
Steering Column Display
Center Dashboard Cluster
Hedalight & Turn Signal Lever
w/ Horn Button
Accelerator PedalBrake Pedal Serial No. Plate
ON/OFF main switch
Forward/Neutral / Reverse Switch

Operators Manual ATLAS CARTS
16
S E C T I O N
3
Operators Manual ATLAS CARTS
Dash Displays and Indicators
Battery State of Charge
(SOC) Display
This display provides a visual report of the Battery State of Charge (SOC)
and other information.
Battery Power
Indicator
The remaining power is 10%
The remaining power is 50%
The remaining power is 100%
10
10
10

Operators Manual ATLAS CARTS
17
S E C T I O N
3
Operators Manual ATLAS CARTS
Dash Displays and Indicators
Charging
Indicator
Golf Ball
Holder
•Flashinggreenlightindicatesbatteryischarging.
•Solidgreenlightindicatesfullycharged.
•Redashinglightindicatesbatteryisnotchargingproperly
and charger connections should be checked.
Hold four golf balls and can be removed if desired.
Hazard Flasher
Button
Radio
USB Interface
Front Locking
Trunk
Key Start
Switch
Push this button to turn on the hazard warning lights (four-way flashers).
This causes all four outside turn signals and both indicators in the instrument
panel to flash. Use the hazard warning lights if you need to park in a
dangerous area near heavy trac or if your vehicle is disabled.
See page 20 for radio instructions.
With the key switch in the ON position, the 12V, 2amp USB port supplies
power to electronic devices via a USB cable.
Can be locked/unlocked with the vehicle ignition key.
Key start 2-position switch.
•OFF-vehicleisdisabled.
•ON-vehiclepoweron
Hazard warning
flasher button
Radio USB Interface
Key start Charging
Indicator
Golf tee
Storage
Front locking
trunk

Operators Manual ATLAS CARTS
18
S E C T I O N
3
Operators Manual ATLAS CARTS
Radio Controls
Bluetooth Instructions
Radio Functions
To connect bluetooth devices, ensure vehicle key is in “ON” position, press the
POWMOD button on the vehicle radio. In your device’s settings, ensure your
bluetooth is turned on. Find “ATLAS” device and choose connect.
1 PWR/MOD Press this button briefly to turn system on. Press and hold for 3 seconds to power
system o. When system is on, use this button to toggle between RADIO, AUX IN,
& PHONE.
2 BND/AMS Press this button briefly to switch between the three FM and two AM sequences.
Press this button to answer incoming calls when connected to hands free calling.
4/5 VOL+/ VOL- Use VOL+ to increase stereo volume level from (0-40).
Use VOL- to reduce stereo volume level from (0-40)
6/7 TRACK/TURN BUTTONS Press left and right red arrow button to move to dierent radio frequency or play
previous or next song on bluetooth device. Hold buttons for three seconds to
initiate frequency scanning on radio mode.
8 PAU Press and hold this button on radio mode to save radio frequency in #1 position.
When pressing in BT AUDIO mode, this pause bluetooth playing.
9 INT Press and hold this button on radio mode to save radio frequency in #2 position.
The INT function is not used in this system.
10 RPT Press and hold this button on radio mode to save radio frequency in #3 position.
The RPT function is not used in this system.
11 RDM Press and hold this button on radio mode to save radio frequency in #4 position.
The RDM function is not used in this system.
12 CLK Press and hold this button on radio mode to save radio frequency in #5 position.
The CLK function is not used in this system.
13 MUTE Press and hold this button on radio mode to save radio frequency in #6 position.
Press and hold this button in the BT AUDIO mode to mute the vehicle’s
microphone.
1
2
8 9
13
106 5 11 4 7
12

Operators Manual ATLAS CARTS
19
S E C T I O N
3
Operators Manual ATLAS CARTS
Steering Column Display
The Speedometer is an important tool to understanding your vehicle operation.
When the vehicle has an electrical or mechanical malfunction, a beeping sound and
flashing maintenance icon (small service wrench) and error code will alert the driver
of the specific fault. The driver should immediately stop and arrange for the vehicle
to be serviced by their local authorized Atlas dealer.
Some versions of the display will indicate a maximum reading of 99% State of Charge.
This is due to the limitation of the display. When 99% is shown, the vehicle is actually
at 100% state of charge.
Forward and reverse
Real-time speed
Turn signal
indicator
Low beams
State of Charge
Total mileage Motor fault light
Hydraulic oil
level indicator
Error code
1
High beams
Turn signal
indicator
Parking lights
Low voltage
warning light
2
3
4
5
6
7
8
9
10
11
5
4
1 Error Code Alerts driver of a vehicle malfunction. As soon as safe to do so, park vehicle in safe
location and contact your authorized Atlas dealership.
2 Low Voltage Warning Alerts driver of a low battery voltage occurrence. Vehicle must be charged as soon
as possible to avoid damaging electrical components.
3 Parking Lights Alerts driver that parking brake is engaged.
4 Turn Signal indicators Alerts driver that turn signal is on.
5 High/Low Beams Alerts driver headlights are on. Green indicator on right side is for low beams,
blue indicator on left is for high beams.
6 Real time State of Charge (SOC) Alerts driver of the available battery state of charge percentage.
7 Real time Speed Alerts driver of current ground speed..
8 Forward/Reverse Alerts driver of position of direction selector switch.
9 Hydraulic Oil Level Alerts driver of low hydraulic oil level. As soon as safe to do so, park vehicle in safe
location and contact your authorized Atlas dealership.
10 Motor Fault Alerts driver of vehicle malfunction. As soon as safe to do so, park vehicle in safe
location and contact your authorized Atlas dealership.
11 Total Mileage Alerts driver of total vehicle miles driven.

Operators Manual ATLAS CARTS
20
S E C T I O N
3
Operators Manual ATLAS CARTS
Onboard Battery Charger Safety Warning
Failure to observe the following safety precautions when charging the
on-board battery may result in fire, property damage, serious personal
injury or death.
Connect the charger power cord to an outlet that is correctly installed
and grounded according to all local codes and regulations.
A grounded outlet is necessary to decrease the risk of electric shock – do not
use ground adapters or replace the plug.
If an extension cord is needed, only use approved male to female AC power
cord. 12/3 SJTOW Heavy Duty, 125 volt, 1875 watt, 15 Amp, AC Cord with
3 Prong Grounded Plug.
Do not touch parts of output connector or battery terminals that do not have
insulation. Inspect the power cord for damage before connecting.
Disconnect the AC plug before you make or break the connections to a
battery that is charging.
Do not pull the cord to disconnect the charger.
The on-board charger is not user serviceable. Do not open or disassemble
the on-board charger.
Do not operate the charger if the AC cord is damaged. Make sure qualified
personnel does all repair work to the charger.
Never charge batteries in a hazardous environment.
Do not charge the battery in a wet location. Keep the power cord dry.
Contact dealer for replacement cord or on-board battery charger service.
Some Atlas models are designed to not allow charging of lithium battery when
temperature of battery is below 32 degrees F (0 degrees C). This is normal
and charging will resume when battery temperature is above freezing.
Please contact your dealer for more information.
