Atlas ATM1500 User manual

1
w w w . a u t o m a t i o n d i r e c t . c o m
1 - 8 0 0 - 6 3 3 - 0 4 0 5
AATTLLAASSINDUST IAL FLAT PANEL PC MONITO
QUICK INSTALLATION GUIDE
3505 HUTCHINSON ROAD
CUMMING, GA 30040-5860, USA
TM
1. Verify Contents of the Box:
• Atlas Flat Pan l Monitor – (A “T” at th nd of th part numb r
d signat s th touch scr n option.)
• VGA vid o cabl – 10’ l ngth
• RS-232 S rial touch scr n cabl (touch scr n mod ls only) – 10’ l ngth
• USB touch scr n cabl (touch scr n mod ls only) – 10’ l ngth
• Mounting clips and scr ws (qty of 14)
• USB r t ntion brack t and mounting scr w (touch scr n mod ls only)
• Optional pow r plug prot ctiv cov r
• Docum ntation and Driv r CD
• This Quick Installation Guid
Description:
The Atlas monitor is a high performance color TFT flat panel monitor
specifically designed for harsh industrial environments including Class
I Division 2, Class II Division 2 and Class III Hazardous Locations. The
Atlas monitor accepts standard analog VGA input or digital DVI input,
and can display all VESA video modes up to 1280 x 1024 at 75 Hz with
16 million colors. An optional 5-wire analog touch screen is available
that offers both RS-232 and USB interface capability. The monitor is
housed in a heavy duty steel chassis with a powder coated machined
aluminum bezel. The monitor is certified to NEMA 4/4X/12 standards,
is UL/CUL listed, meets CE requirements and is RoHS compliant.
anel mounting is simplified using convenient mounting clips instead
of conventional studs. All monitors are shipped with a power input
wiring receptacle, 10’ VGA cable, 10’ RS-232 cable (touch panel
models only), 10’ USB Cable (touch panel models only), mounting
hardware, this Quick Installation Guide, and CD-ROM containing
Hardware User’s Guide (ATM-USER) and touch screen driver software
for Windows 98/NT/2000/X /Vista/7.
NNOOTTEE::SEE THE HARDWARE USER’SGUIDE, AT -USER,
INCLUDED ON THE SUPPLIED DOCU ENTATION & DRIVER CD FOR
ADDITIONAL DETAILS. THEUSER’SGUIDE IS IN PDF FILE FOR AT AND
REQUIRES DOWNLOADING ADOBE’S FREE ACROBAT READER TO OPEN
AND VIEW.
Atlas Industrial Monitor
Contents:
3
12
B
F
C
A
E
D
Dimensions:
Agency Approvals:
Mounting Clips
(qty. 14)
VGA Video
Cable
AAttllaass
Monitor
Pa kaging
Material
Do umentation
& Driver CD
RS-232 Cable
& hex spa ers
(“T” ver. only) USB Cable
(“T” ver. only)
Certifi ations & Standards
Name UL508 ANSI/ISA
12.12.01-2012 CE
AAttllaass
Flat Panel Monitor E157382 E200031
EN 55022-1: Class A,
EN 61000-3-2: Class A,
EN 61000-3-3,
EN 61000-6-2,
IEC 60950-1
UL
CUS
R
Mode A B C D E F
ATM1500/ATM1500T 12.80”
(325.1 mm)
15.80”
(401.3 mm)
2.65”
(67.3 mm)
3.95”
(100.3 mm)
1.17”
(29.8 mm)
2.40”
(61.0 mm)
ATM1700/ATM1700T 14.48”
(367.8 mm)
17.14”
(435.4 mm)
2.85”
(72.4 mm)
5.00”
(127 mm)
1.32”
(33.5 mm)
2.60”
(66.0 mm)
ATM1900/ATM1900T 15.70”
(398.8 mm)
18.66”
(474.0 mm)
2.95”
(74.9 mm)
6.00”
(152.4 mm)
1.50”
(38.1 mm)
2.70”
(68.6 mm)
Qui k
Installation
Guide

2
w w w . a u t o m a t i o n d i r e c t . c o m
1 - 8 0 0 - 6 3 3 - 0 4 0 5
WARNING: Damage can occur by applying excessive torque to the
mounting clips.
2. Install Monitor through Enclosure Door or Wall
• Th monitor must b install d on a flat surfac of a NEMA typ 1, 4, 4X
or 12 nclosur .
• Us dim nsions as shown in th diagram b low to provid a
r ctangular mounting cutout in an approv d NEMA 4/12 nclosur ’s
door or wall.
• Mount th monitor through th nclosur cutout, install and tight n (14)
mounting clips to a torqu of 8.0 inch-pounds as shown in th diagram
to th right.
CUTOUT
A
B
Cutout Dimensions:
CUT AWAY
VIEW
MAXIMUM ALLOWABLE
PANEL THICKNESS
Mounting Clip Installation:
Warning: Suitable for use in Class 1, Division 2 Groups A, B, C,
and D; Class 2 Division 2 Groups F and G, Class III hazardous
locations, or nonhazardous locations only.
3. Connect DVI or VGA Video Cable between Monitor & PC
• Conn ct th includ d 10’ VGA vid o cabl from th vid o conn ctor on
th monitor to th vid o output conn ctor on th host PC b ing us d
with th monitor or us a digital DVI cabl (sold s parat ly).
• If using a DVI cabl , input s l ction must b chang d to DVI by pushing
th UP button on th r ar of th monitor.
4. Connect USB or Serial Cable between Monitor & PC
• Appli s to touch scr n v rsion only.
• Us ith r th includ d 10’ RS-232 S rial touch scr n cabl or th 10’
USB touch scr n cabl from th appropriat conn ctor on th monitor
to th appropriat conn ctor on th host comput r; do not conn ct
both.
• If using th USB cabl , s cur th cabl using th includ d USB
r t ntion brack t and scr w; consult th Hardwar Us r’s Guid ,
ATM-USER, on th suppli d Docum ntation and Driv r CD for d tails.
* NOTE: USE ONE OR THE
OTHER, NOT BOTH.
TOUCH SCREEN
CABLES *
VIDEO CABLE *
DISPLAYPOWER
WARNING
Touch Screen is still
active while display
power is off
Cable Connections:
NNOOTTEE::THE 17” AND 19” ONITORS WILL PRODUCE THE BEST I AGE
QUALITY IF THE PC IS SET FOR A 1280 X1024 PIXELS @ EITHER 60,
OR 75 HZ. VIDEO ODE.
Mode A B
ATM1500/ATM1500T 12.00”
(304.8 mm)
15.00”
(381.0 mm)
ATM1700/ATM1700T 13.70”
(348.0 mm)
16.35”
(415.3 mm)
ATM1900/ATM1900T 14.90”
(378.5 mm)
17.75”
(450.9 mm)
NNOOTTEE::THE 15” ONITOR WILL PRODUCE THE BEST I AGE QUALITY IF
THE PC IS SET FOR A 1024 X768 PIXELS @ EITHER 60, 70 OR 75 HZ.
VIDEO ODE.
NNOOTTEE::WHEN USING THE USB TOUCHSCREEN CONNECTION, THE USE
OF THE USB RETENTION BRACKET IS REQUIRED FOR HAZARDOUS LOCA-
TIONS AND HIGHLY RECO ENDED FOR NONHAZARDOUS LOCATIONS.
WARNING - EXPLOSION HAZARD - Do not connect or disconnect the
USB ports unless the power has been switched off or the area is
known to be non-hazardous.
AVER ISSEMEN - RISQUE D'EXPLOSION - Ne pas brancher ou débrancher
le ports USB á moins que l'alimentation á été coupée ou si la zone
n'est pas hazardeuse.
ADVER ENCIA - PELIGRO DE EXPLOSIÓN - No conecte o desconecte los
puertos USB a menos que la computadora se encuentre apagada o
el área se considere no peligrosa.
WARNUNG - EXPLOSIONSGEFAHR - USB-Ports nur anschließen oder
trennen, wenn keine spannung anliegt oder der Bereich nicht
explosiongefährdet ist.
NNOOTTEE::TOPREVENT INADVERTANT DISCONNECTION OF VIDEO AND / OR
SERIAL TOUCHSCREEN CABLES ASSURE THAT THE THU BSCREWS ARE
SUFFICIENTLY TIGHT.
WARNING: An operating temperature of 0 to 50 °C (32 to 122 °F)
ambient termperature inside the enclosure needs to be maintained
for proper operation of the monitor.

3
w w w . a u t o m a t i o n d i r e c t . c o m
1 - 8 0 0 - 6 3 3 - 0 4 0 5
6. Apply Power to the Monitor & PC
• Pr ss th DISPLAY POWER button on th r ar of th monitor to wak th
monitor up. Pr ssing th DISPLAY POWER button again turns off th
backlight inv rt r and puts th monitor in a r duc d pow r stat but
th touch scr n r mains activ . It is important to not that this switch
do s not disconn ct pow r from th monitor. Pow r is always suppli d
to th int rnal AC/DC pow r supply, which in turn continually suppli s
pow r to th int rnal monitor l ctronics and th optional touch scr n
controll r.
7. Install the Appropriate Touch Screen Driver
• Th calibration of th touch scr n occurs by a calibration utility that
installs as part of th touch scr n driv r installation proc ss.
• Appli s to touch scr n v rsion only.
• Ins rt th Docum ntation and Driv r CD into th host PC’s CD driv .
• If th CD do s not start automatically with th window shown b low
display d, th n go to Start > Run, brows to th CD’s “atlas. x ” fil ,
op n it, and click OK.
• From th Atlas scr n, th us r can vi w th Hardwar Us r’s Guid for
th monitor b ing us d, and/or install th touch scr n driv rs for th
particular PC op rating syst m b ing us d. B for installing th driv rs,
pl as r ad th Touch Scr n Driv r Docum ntation for op rating
syst m d tails.
• R boot th PC and r start th monitor to activat th driv r.
8. Verify Video and Touch Screen Functionality
• V rify th monitor’s vid o display by running a familiar program.
• If using th touch scr n mod l, us th touch scr n to navigat by
running a familiar program.
Display Power
Button
Power
Indicator
DISPLAY POWER
WARNING
Touch Screen is still
active while display
power is off
LCD Power Button:
MAIN MENU
BRIGHTNESS/CONTRAST
1280X1024 63.9KHZ/60HZ
COLOR
POSITION
SETUP
EXIT
R G B
OSD Settings Main Menu:
9. Adjust the Monitor OSD Settings as equired
• Pr ss th S l ct (Auto Adj) control button on th r ar of th pan l to
initiat an automatic configuration of th scr n.
• Although normally not n d d, th control buttons on th r ar of pan l
can b us d to mak oth r adjustm nts to th scr n.
• Consult th Hardwar Us r’s Guid , ATM-USER, on th suppli d
Docum ntation and Driv r CD for d tail d usag of th OSD s ttings.
10. Installation Complete
WARNING: he monitor does not automatically select a video input
mode. he user must press the “UP (VGA/DVI)” button on the rear
of the monitor to select either VGA or DVI input. If a “No Video”
message appears on the screen, it is also suggested the user try using
the “UP (VGA/DVI)” button to select the active video input.
NNOOTTEE::ONCE YOU HAVE CONNECTED YOUR PC AND THE ONITOR,
SELECTED THE VIDEO SOURCE, AND POWERED BOTH UNITS, IT IS
SUGGESTED THAT THE “SELECT (AUTO ADJ)” BUTTON ON THE REAR
OF THE ONITOR BE PRESSED TO AXI IZE THE VIDEO SETTINGS.
5. Connect Power to the Monitor
• Pow r sourc n ds to b 100 - 240 VAC, 50/60 Hz.
• S pow r conn ction diagram to th right.
• S cur plug r t ntion scr ws to monitor.
• Pow r should not b appli d until all cabl s ar attach d and th
monitor is r ady to op rat .
TOP VIEW
FRONT VIEW
ADC P.N. ATM-AC-CON or
PHOENIX CONTACT P.N. 1777992
L N
Plug Retention Screws
Power
Connection
Label
PE
WARNING: Damage can occur if power is not properly connected.
Power Connections:
100 VAC - 240 VAC INPUT (1.0 Amps Min)
31 2
PIN No. Defi itio
1 AC Line Input
2 AC Neutral Return
3 Protective Earth Ground
Panel Power Draw
ATM1500 (T) 25 W
ATM1700 (T)  30 W
ATM1900 (T)  35 W
WARNING - EXPLOSION HAZARD - Do not disconnect equipment while
the circuit is live unless the area is known to be free of ignitable
concentrations.
Warning - Explosion Hazard - Substition of any components may
impair suitability for Class 1, Division 2.
Required Wire Spe ifi ation
Wire Size 18 - 12 AWG (0.8 - 3.3 mm2)
Wire Material a d
Temperature 60 °C or 60 / 75 °C Copper
Tighte i g Torque 7.0 lb·in (0.79 Nm)
WARNING – ouch screen is still active while display power is off.
A EN ION – L'écran tactile est toujours actif, méme quand l'af-
ficheur n'est pas alimenté.
ADVER ENCIA – La pantalla táctil sigue activa aún cuando el dis-
play esté apagado.
WARNUNG – ouch screen ist immer noch aktiv, während die
anzeigefläche ausgeschaltet ist.

4
w w w . a u t o m a t i o n d i r e c t . c o m
1 - 8 0 0 - 6 3 3 - 0 4 0 5
Copyright 2007-2014, Automationdirect.com In orporated/All Rights Reserved Worldwide
Accessories & eplacement Parts:
Part Number Des ription
ATM-CBL-VGA10 10 ft. 15-pin coaxial VGA cable. Connects any Atlas monitor to a standard VGA card.
ATM-CBL-VGA25 25 ft. 15-pin coaxial VGA cable. Connects any Atlas monitor to a standard VGA card.
ATM-CBL-VGA50 50 ft. 15-pin coaxial VGA cable. Connects any Atlas monitor to a standard VGA card.
ATM-CBL-DV2M 6 ft. (2 meter) DVI (type D) video cable. Connects A M1700 and A M1900 to a standard DVI-D
port. DVI cables provide a higher bandwidth video interface than the VGA cables.
ATM-CBL-DV3M 10 ft. (3 meter) DVI (type D) video cable. Connects A M1700 and A M1900 to a standard DVI-D
port. DVI cables provide a higher bandwidth video interface than the VGA cables.
ATM-CBL-10 10 ft. serial communication cable. Connects Atlas monitor to std. 9-pin RS-232 port.
(touch screen models only)
ATM-CBL-25 25 ft. serial communication cable. Connects Atlas monitor to std. 9-pin RS-232 port.
(touch screen models only)
ATM-CBL-50 50 ft. serial communication cable. Connects Atlas monitor to std. 9-pin RS-232 port.
(touch screen models only)
USB-CBL-AB3 3-ft (0.9 meter) Standard USB 2.0 cable with Standard-A plug to Standard-B plug. Suitable for all
USB devices. (touch screen models only)
USB-CBL-AB6 6-ft (1.8 meter) Standard USB 2.0 cable with Standard-A plug to Standard-B plug. Suitable for all
USB devices. (touch screen models only)
USB-CBL-AB10 10-ft (3 meter) Standard USB 2.0 cable with Standard-A plug to Standard-B plug. Suitable for all
USB devices. (touch screen models only)
USB-CBL-AB15 15-ft (4.6 meter) Standard USB 2.0 cable with Standard-A plug to Standard-B plug. Suitable for all
USB devices. (touch screen models only)
ATM-AC-CON Replacement Power Wiring Connector for AC Powered Units.
ATM-CLIP Replacement flat panel mounting clip kit. Package of 16 clips and screws.
ATM-CBL-VGA10 ATM-CBL-VGA25
ATM-CBL-VGA50 ATM-CBL-DV2M
ATM-CBL-DV3M
ATM-CBL-10 ATM-CBL-25
ATM-CBL-50 USB-CBL-AB3
USB-CBL-AB6 USB-CBL-AB10
USB-CBL-AB15 ATM-AC-CON
ATM-CLIP
WA NING
To minimize the risk of potential safety problems, you should
follow all applicable local and national codes that regulate the
installation and operation of your equipment. These codes vary from
area to area and it is your responsibility to determine which codes
should be followed, and to verify that the equipment, installation, and
operation are in compliance with the latest revision of these codes.
Equipment damage or serious injury to personnel can result from the failure
to follow all applicable codes and standards. We do not guarantee the prod-
ucts described in this publication are suitable for your particular applica-
tion, nor do we assume any responsibility for your product design,
installation, or operation.
If you have any questions concerning the installation or operation of
this equipment, or if you need additional information, please call
Technical Support at 770-844-4200.
This publication is based on information that was available at the time
it was printed. At Automationdirect.com®we constantly strive to
improve our products and services, so we reserve the right to make
changes to the products and/or publications at any time without notice
and without obligation. This publication may also discuss features that
may not be available in certain revisions of the product.
Additional Help and Support
• For product support, sp cifications, installation, and
troubl shooting, a Hardwar Us r’s Guid , ATM-
USER, is includ d on th suppli d Docum ntation
and Driv r CD, or downloadabl from th Onlin
Docum ntation ar a of th AutomationDirect W b sit .
• For additional t chnical support and qu stions, call our T chnical
Support t am @ 770-844-4200.
