Strategy Series®Surface Mount Loudspeaker
SM42T
Specifications
Power Rating 16 Watts RMS
Transformer Taps 2, 4, 8, & 16 Watts and 8ΩBypass
Frequency Response 115Hz – 16kHz (±5dB)
Sensitivity (1W / 1M) 88dB
Height 7" (177.8mm)
Width 5" (127mm)
Depth 515⁄16" (150.3mm)
Features
• Compact,Two-WayLoudspeakerSystemsforExceptional
Performance in Sound Reinforcement Systems
• Weather-ResistantConstructionForYear-roundIndoororOutdoor
Use,UV-resistantTalcImpregnatedPolypropylene,InjectionMolded,
WeatherproofEnclosure,PowderCoatedAluminumGrillesandall
BrassHardwareInserts
• 100HRSaltSprayTestPerASTMB117
• ColorMatchedHeavy-dutyZincChromatePlated&PowderCoated
“C"Bracket(Included)
• HighlyEfficient4"PolypropyleneWoofer
• 1"Ferrofluid™CooledDomeTweeter
• AtlasSoundTRXWAVEGUIDE™ –AConstantDirectivityStyleHigh
FrequencyWaveGuideSystemProvidesAccurate,EvenHigh
FrequencyCoverage
• AtlasSoundPOLYGUARD™HighFrequencyCircuitDivertsDamaging
TransientSignalstoProtecttheTweeter
• ScrewdriverAdjustable16Watt70.7V/100VTransformerfor
DistributedSoundApplications(maybebypassedfor8Ωoperation via
tapselectorswitch)
• All1⁄4"-20HardwareInsertsAllowEasyIntegrationof“OffTheShelf"
Security Hardware
• OMNIMOUNT™10SeriesCompatible
• AvailableinBlackorWhite
• Five-YearWarranty
Applications
Usesurface-mountAtlasSoundSM42Tloudspeakersystemsfor
commercial,professional,andresidentialapplicationsorwhere
high-fidelitysoundandweather-resistancearedesired.Full-range
frequencyresponsemakesthesesystemsidealforindoororoutdoor
installations,inmonauralandstereoforegroundorbackgroundmusic
systems,andforapplicationsinboutiques/shops,restaurants/cafes,
corporateAVapplicationsandhousesofworship.Multi-position,
C-shapedmountingbracketandruggedconstructionprovideoptimum
installationflexibilityandassuranceoflong-termservice.
SM42T-W

AtlasSound.com 2/2
1601 JACK MCKAY BLVD. ENNIS, TEXAS 75119 U.S.A.
TELEPHONE: [phone]
FAX [phone]
©2009 Atlas Sound LP. All rights reserved. Atlas Sound is a trademark of Atlas Sound L.P. All other trademarks are property of their respective owners. ATS003249 RevA 8/09
General Description
Environment-resistantSMSeriesloudspeakersystemsofferquality
soundreproductionandcontemporarystylinginacompactenclosure.
Systemcomponentsconsistofahighlyefficientwoofersectionand
Ferrofluid™cooledmylarhighfrequencydevice.Vocalandmusicalclar-
ityisoptimizedbythemathematicallyconceived,advanceddesignof
theAtlasSoundTRXControlWaveGuide™high frequency director. This
designprovidessmooth,evensoundcoverage(90°x90°).Thehigh
frequencysectionissymmetrical,forequalcoverageinbothvertical
andhorizontalcabinetmountingpositions.Highfrequencycomponent
protectionisprovidedbytheAtlasSoundPolyGuard™protection circuit.
Bothdriversfeaturelow-flux-leakagedesignsenablingthespeaker
tobeusedincloseproximitytovideomonitors.Forcriticalvideo
monitoringapplications,aminimumdistanceof18"fromtheedgeofthe
loudspeakertotheedgeofthescreenisrecommended.TheSM42T
includesaninternallymounted,16Watt70.7V/100Vlinematching
transformerwithscrewdriveradjustableexternaltapselectionforusein
distributedsoundapplications.
To withstand the harshest environments, the new Strategy Series®
SM42Tsurfacemountloudspeakersareconstructedofweather
resistantmaterials:UV-resistant,talcimpregnated,polypropylene
injectionmoldedcabinets;polypropylenewoofercones;powdercoated
aluminumgrillesandallbrasshardware.TheStrategySeriesspeaker
systemsincludeaversatileyetsimpleC-bracketdesignedtoprovide
easyverticalorhorizontalinstallationonjustaboutanysurface.Care
shouldbetakentoensurethatthechosenmountingsurfaceisstrong
enoughtosupporttheSM42T.Careshouldalsobetakentoensure
thattheSM42Tisnotexposedtodirectprecipitation.A5⁄8"-27threaded
holeisprovidedontheC-brackettoallowtheSMseriesspeakertobe
mountedonanyAtlasSoundmicrophonestandfornear-fieldlivesound
applications.23⁄8"OCbrassinsertsarealsoprovidedontherearofthe
SM42TtoaccommodatetheAtlasSoundSMBALLMOUNTbracketor
OMNIMOUNT™10Seriesbrackets.Allinsertsformountingknobsare
standard 1⁄4"-20toalloweasysubstitutionofstandard“offtheshelf"
vandalprooftorxheador“one-way"hardware.Inputconnectorsinclude
asealed2-poleterminalstripcapableofacceptinguptotwo#14AWG
wires.2,4,8,and16Watttapsarescrewdriverselectableviaasealed
switchlocatedneartheinputsectionontherearofthecabinet.Internal
transformermayalsobebypassedfor8-ohmoperationviatapselector
switch.Aflushcoverwithwireexitholeisprovidedtoensureinput
connectionsandtapselectorswitchareprotected.Systemsareavailable
inBlackorWhitefinishesandcanbepaintedtoaccommodateany
architecturalconsiderations.
Architect & Engineer Specifications
Theindoor/outdoormini-loudspeakersystemshallbeAtlasSoundModel
SM42T-___(BorW)orapprovedequal.Assembliesshallconsistof
two-waywooferandtweeterwithinenvironment-resistanthousings.
EnclosureshallbeconstructedofpaintableUV-resistant,talcimpreg-
nated,polypropyleneinjectionmoldedplasticfinishedinblack(SM42T-B)
orwhite(SM42T-W).Eachunitshallincludeastampedpowdercoated
aluminumgrilleandremovableC-shapedmountingbracket.Allhardware
insertsshallbebrassandthreaded1⁄4"-20.The16WattRMSsystem
shallhavea4"(102mm)woofer,constructedofreinforcedpolypropyl-
ene,anda1"(25mm)Ferrofluidtweeter.Thedividingnetworkcrossover
frequencyshallbe4kHz.Thedividingnetworkshallincludeprotection
circuitsforthehigh-frequencycomponent.Eachunitshallincludean
internallymounted16Watt70.7V/100Vlinematchingtransformerfor
useindistributedsoundapplications.Wattagetapsshallbescrewdriver
selectableviaasealedswitchlocatedneartheinputsection.Wattage
tapsshallbe2,4,8,&16Watts@70.7V.Theloudspeakersystemshall
meetthefollowingperformancecriteria:Powerhandling:16Watts
RMS.Frequencyresponse:115Hz–16kHz(±5dB).Sensitivityshallbe
88dBSPLatonewatt,85Hz–16kHzmeasuredatadistanceofone
meteronaxis.Impedanceshallbe8Ωnominal.Inputconnectorsshall
includeatwo-polebarrierstripcapableofacceptinguptotwo#14AWG
cables.Acoverwithwireexitholeshallbeprovidedtoprotecttheinput
connectors.Theloudspeakersystemshallexhibitnoperformanceor
cosmeticdegradationaftera100–hoursaltspraytestperASTMB117
Theunitshallbe7"(178mm)high,5"(127mm)wide,and515⁄16" (151mm)
deep.
SM42T
(Back Shown with Cover Removed)
