Atleisure GAZ-960126 Use and care manual
Contact our customer service department toll free at 1-855-880-7205 or email us at [email protected]
| Package Contents 2.
Gazebo
Assembly and User Manual
ITEM: GAZ-960126
NOTE: The schematics in this manual are for assembly and operation
illustration only. They may differ from the gazebo’s actual appearance.
If you have any questions, problems please do not return
to the place of purchase. Contact our customer service
department toll free at 1-855-880-7205 or email us at
customerser[email protected]
PART PICTURE QUANTITY
Tube 1 4pcs
Tube 2 4pcs
Tube 3 8pcs
Tube 4 4pcs
Tube 5 4pcs
Tube 6 4pcs
A 1pc
B 4pcs
C 4pcs
Contact our customer service department toll free at 1-855-880-7205 or email us at [email protected]
3. Package Contents |
Contact our customer service department toll free at 1-855-880-7205 or email us at [email protected]
| Assembly Instructions 4.
DESCRIPTION PICTURE QUANTITY
String 4pcs
Stake 8pcs
Cover 1pc
C
3
3
CC
CC
3
3
3
34
4
44
3
3
3
3
Step 1. To build the frame for the
gazebo, start with one corner and
attach two(2) of Tube 3 to either side
of Part C. Repeat for each corner.
Step 2. Join the four(4) corners
with the Tube 4.
Contact our customer service department toll free at 1-855-880-7205 or email us at [email protected]
5. Assembly Instructions (cont’d) | | Assembly Instructions (cont’d) 6.
Contact our customer service department toll free at 1-855-880-7205 or email us at [email protected]
C
2
1
1
1
1
2
22
A
C
CC
CC
5
5
5
5
C
C
Step 3. Join Tubes 2 and 1
and attach the set to the top
of Part C. Then attach Part A
to the ends of Tube 1.
Step 4. Attach
Tube 5 to the
bottom of Part C,
making the gazebo
frame stand on the
four(4) legs.
B
B
6
6
6
Step 5. Place Cover on
top of the frame. Attach
Tube 6 to Tube 5, then
place each leg into Part B,
the base for the Canopy.
Step 6. Attach the strings
to the top of the canopy
and use the stakes to
attach the gazebo to the
ground.
Contact our customer service department toll free at 1-855-880-7205 or email us at [email protected]
7. Warranty |
90–DAY WARRANTY
This product is covered under a manufacturer’s 90-day warranty from date of
purchase against defects in materials and workmanship. This warranty does
not cover damage due to neglect, abuse or weather related damage. For full
HOW TO FILE A CLAIM
If you are within your warranty, to file a claim you must have your receipt
and pictures of your damaged umbrella. Email information to ATLeisure at
customerser[email protected].
www.atleisure.com
ATLANTA, GEORGIA
Customer Service Toll Free 1-855-880-7205
Monday through Friday from 8:00am-5:00pm
(Eastern Time)
