aTli T-100 Operator's manual

1
USER
INSTRUCTION
MANUAL
ATLI Cam App Dashboard Control
Model No. T-100, T-100 Lite
This instruction manual covers the in-app dashboard control for firmware version
4.1.0 or higher.
Please refer to INSTALLATION AND SETUP PROCEDURE for more
information on how to install and connect the camera.

2
Content Index
Dashboard ......................................................................................................... 3
Magnifier ........................................................................................................... 4
EV ..................................................................................................................... 4
Auto/Manual/Preset ........................................................................................... 5
Preset ............................................................................................................. 5
Add Presets ....................................................................................................... 6
System Settings ................................................................................................ 7
WLAN ............................................................................................................. 7
Memory Card .................................................................................................. 9
Advanced ..................................................................................................... 10
Remote Support ........................................................................................ 10
Time Zone ................................................................................................. 10
Built-in FTP Server .................................................................................... 11
FTP Auto Sync .......................................................................................... 12
About ......................................................................................................... 12
Time Lapse Mode ........................................................................................... 13
Output .......................................................................................................... 13
Orientation .................................................................................................... 14
Power Saving ............................................................................................... 14
Grid ............................................................................................................... 15
Time Stamp .................................................................................................. 15
Schedule ...................................................................................................... 16
Occurrence: Once ..................................................................................... 16
Occurrence: Daily ...................................................................................... 17
Occurrence: Weekly .................................................................................. 18
Realtime Playback (Live Preview) ................................................................ 19
Change settings on the fly ............................................................................ 20
Time Slice ..................................................................................................... 21
Photo Mode ..................................................................................................... 22
Video Mode ..................................................................................................... 23
Album .............................................................................................................. 24

3
Dashboard
Once the camera is connected to the app, access the dashboard to manage and operate the
camera.
Icon
Description
More feature
HDR
Auto/Manual/Preset
Home
Battery Status
Charging
Memory Card Status
available storage | available frame
Rotate
Record/Take photo
System Settings
Album

4
Magnifier
EV
EV
-4~ 4
Long-press on the screen to activate
magnifier.
Drag the magnifier and move around.
EV is disabled when both ISO and Shutter
Speed are set to manual.
Tap on the lock button to lock the focus in
place.

5
Auto/Manual/Preset
Preset
The presets come with a default interval that is recommended.
*T-100 Lite does not support Infrared mode.
Preset
Interval (s)
Cloud
3
City Night
3
Flower
10
Star
10
Sun
2
Preset
Mode
Infrared
Common/Fantasy1/Fantasy2/Fantasy3/Custom
Shutter
Speed
1/20K,1/10K,1/5K,1/2.5K,
1/1000,1/500,1/250,1/125,1/60,
1/30,1/25,1/15,1/8,1/4,1/2,1,1.4
ISO
100~ 4000
White
Balance
2500~ 10000
Sharpness
-10~10
Saturation
-30~ 30
Contrast
-5~ 5
Hue
-20~ 20
• Auto [ ]: The camera will choose the
optimized settings.
• Manual [ ]: Customize the following
settings.
• Drag the magnifier and move around.
*Manual settings are unavailable
in the preset scenes.

6
Add Presets
Add custom presets with personalized settings.
• To create a custom scene with
personalized settings, click on
Add Scene [ ] to proceed.
• Enter a name and choose an icon
for the new scene.
• Custom scene can be located
under preset menu.
• Tap on the icon to edit or delete
the custom scene.

7
System Settings
Manage the following settings of the camera.
WLAN
To enable internet access for the camera, connect it to a local Wi-Fi network via WLAN.
Setup
System Settings > WLAN > Select a Wi-Fi SSID > Enter Wi-Fi Password > Wi-Fi name turns blue

8
• The default IP Setting mode is DHCP.
• This enables the camera to obtain an
IP and the corresponding network
settings from the Wi-Fi router.
• However, the camera IP and other
network settings can be assigned
manually by changing the IP Setting
mode to Static as shown in the Wi-Fi
configuration.

9
Memory Card
Memory Card shows the status of the microSD card.
Formatting memory card
Back up all important data before formatting
a microSD card.
* Formatting a micorSD card can help to
solve corrupted files issues, but it cannot fix
a damaged SD card.
If formatting does not resolve the SD card
related problems, please retry with another
SD card.
Once the memory card reaches its capacity,
the camera will stop recording and save the
files automatically.

10
Advanced
The Advanced section provides additional features or supports to the camera.
Remote Support
Enabling Remote Support will authorize the ATLI technical team to remotely access the
camera and conduct a thorough inspection of the camera status, settings, and operation.
Setup
1. Turn on Remote Support in Advanced.
2. Connect the camera to a local Wi-Fi network which has internet connection.
3. Connect the camera to a power source to make sure the camera stays online.
In order to ensure a good connection, the camera should be placed near the Wi-Fi router.
*Remote Support will be disabled automatically by restarting/rebooting the camera.
Time Zone
The time zone setting sets the camera internal clock to align with your local time zone.
It is important to set this correctly as the camera clock is used for all camera activities that
involves time, such as timestamp, schedule, file storage time, etc.
The default Time Zone is set to “Auto” which assigns the time zone automatically based on the
current location.

11
If the Time Zone is not assigned correctly, it can be set manually.
Setup
1. Tap on Time Zone > Auto [ ] to switch to Manual.
2. Select a preferred time zone for the display on the time stamp.
To reset the time zone to the default setting, tap on Manual [ ] to reset.
Built-in FTP Server
*T-100 Lite does not support Built-in FTP Server.
The camera is equipped with a built-in FTP server for direct access by a FTP client.
When this feature is enabled, the FTP login information is displayed.
When accessing via the camera Wi-Fi, enter the FTP server address in a FTP client as
the Address via Hotspot.
When accessing via your local Wi-Fi, enter the FTP server address in a FTP client as
the Address via WLAN.

12
• Firmware Version
Current camera firmware version
• Serial Number
Camera serial number
• MAC
MAC address
• Up Time
Time duration of the camera being
used
• Camera Time
Time shows on the time stamp
FTP Auto Sync
*T-100 Lite does not support FTP Auto Sync.
The camera has a built-in FTP client that enables the camera to login your FTP server and the
upload the video automatically when a shooting ends.
This function requires you to setup your own FTP server and configure your router for accessing
from internet.
*Refer to AN008 for more detailed information.
About
Find the following information under About.

13
Time Lapse Mode
The following settings apply only to the time lapse mode.
Output
Saving options of the output. Two output options for a time lapse recording are supported: video,
or video+photo.
*T-100 Lite does not support Video+Photo output.
• Video Only:
Saving only video to the
camera album after a shooting
ends.
• Video + Photo:
Saving both video and photo
sequence to the camera
album after a shooting ends.

14
Orientation
The orientation setting automatically adjusts the on-screen image display for viewing and
recording.
Select a rotation that matches the orientation of the camera.
Power Saving
The Power Saving enables the camera to enter sleep mode in order to extend the battery life. This
feature only takes effect in an active recording session or an active schedule for recording.
When the camera is in power saving, the camera can be waked up by pressing the power button
momentarily 1 second. Users can then access the camera when the status LED turns green.
There are three available options: Auto, On, Off.
• Auto (By default):
Power Saving will be deactivated
automatically when the camera is connected
to an external power source.
• On:
Power Saving will be implemented
mandatorily.
The camera will enter sleep mode even when
it’s connected to an external power source.
• Off:
Power Saving off. The camera will not enter
sleep mode while it’s running.

15
Grid
Gridlines are displayed on the screen.
Time Stamp
A time stamp is displayed at the left corner of screen.

16
Schedule
Use Schedule for pre-arranged recordings.
The occurrence of the recordings can be set to once, daily, or weekly.
Occurrence: Once
Note
The schedule will end automatically once it reaches the end time.
Occurrence-Once:
The camera is programmed to record
continuously starting from the start time to the
end time.
§ Start time:
Designated start time of the schedule.
§ End time:
Designated end time of the schedule.
§ Interval:
Designated time lapse interval.
§ Scene:
Choose a scene for the schedule.
*Do not specify (by default): The camera will
start recording according to the current
settings.

17
Occurrence: Daily
Note
To end the schedule, access the camera and terminate the schedule manually.
It is possible to configure up to 6 timeslots.
Occurrence-Daily:
The camera is programmed to record on a
daily basis.
Saving Options:
• Merge:
The recorded video from each time slot will
be consolidated into one video clip after the
schedule ends.
• Every timeslot:
The recorded video will be generated after
each time slot ends.
• Every day:
The recorded video will be consolidated into
one video clip after each day ends.
§ Time Range:
Start time and end time for each time slot.

18
Occurrence: Weekly
Occurrence-Weekly:
The camera is programmed to record on a
weekly basis. It is possible to customize the
specific days within a week.
*The days selected are displayed in blue,
otherwise they are displayed in grey.
*All days are pre-selected by default.
For description of the unmentioned
features in this section, please refer to the
previous contents (Occurrence-Once &
Occurrence-Daily).

19
Realtime Playback (Live Preview)
Preview and track the progress of the time lapse recording.
Note
*Realtime Playback is only supported in time lapse mode.
The activation of this feature will occur once
a time lapse recording has started.
Tap on [ ] to expand the widget for detailed
information.
Click on [ ] to preview the recorded video.
View, share, or download the video content
in the preview.

20
Change settings on the fly
Upon previewing the video, it is possible to pause the video and make necessary changes to the
settings without ending the recording.
Note
Changes of the following settings are allowed:
- Output
- Power Saving
- Grid
- Time Stamp
- EV, Shutter Speed, ISO, White Balance
