AT9322 R2
Multimedia USB Keyboard Hub
Technical Reference Manual
Revision2.1

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
TABLE OF CONTENTS i
Table of Contents
1.0 Introduction--------------------------------------------------------------------------------------- 1
1.1 Description----------------------------------------------------------------------------------- 1
1.2 Features--------------------------------------------------------------------------------------- 1
2.0 Application Block Diagram------------------------------------------------------------------
-
3
3.0 Pin Assignment---------------------------------------------------------------------------------
-
5
4.0 System Architecture and Reference Design-------------------------------------------
.
9
4.1 AT9322 R2 Block Diagram---------------------------------------------------------------
----
9
4.2 Sample Schematics------------------------------------------------------------------------- 10
4.3 Keyboard Hub EEPROM Sample Value----------------------------------------------
---------
11
4.4 Sample Key Matrix Layout Table------------------------------------------------------- 16
5.0 Electrical Characteristics--------------------------------------------------------------------
-
17
5.1 Absolute Maximum Rating--------------------------------------------------------------- 17
5.2 Recommended Operating Conditions-------------------------------------------------- 17
5.3 General DC Characteristics-------------------------------------------------------------- 18
5.4 DC Electrical Characteristic for 5 volts operation----------------------------------- 18
5.5 DC Electrical Characteristic for 3.3 volts operation-------------------------------- 19
5.6 Crystal Oscillator Circuit Setup for Characteristics-------------------------------- 19
5.7 USB Transceiver Characteristics-------------------------------------------------------- 20
5.8 ESD Test Results---------------------------------------------------------------------------- 24
5.9 Latch-Up Test Results--------------------------------------------------------------------- 25
6.0 Mechanical Information----------------------------------------------------------------------- 27

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
INTRODUCTION 1
1.0 Introduction
Description
The AT9322 R2 is an integrated USB keyboard and 2 port hub controller chip. The AT9322
R2 has a built-in default keyboard matrix, so that it can be directly connected to an 18 x 8
keyboard matrix. The keyboard matrix can be customized via an optional external 1024-byte
serial EEPROM. Downstream ports canbe used to connect various USB peripheral devices,
such as USB printers, modems, scanners, cameras, mice, and joysticks to the system without
adding external glue logic. It also supports multimedia volume control, CD/DVD Play/Pause,
Stop, Eject, Mute and general purpose shortcut keys such as Internet, email and help.
This single chip integration makes the AT9322 R2 the most cost effective hub/keyboard
solution available in the market.
Features
?? Fully compliant with the Universal Serial Bus Specification,version 1.1
?? USB hub design is compliant with Universal Serial Bus Hub Specification, revision 1.1
?? USB keyboard design is compliant with USB Device Class Definition for Human
Interface Devices (HID), Firmware Specification, version 1.1
?? Single chip integration of USB keyboard, hub, ACPI and multimedia control functions
?? Integrated USB hub supports two bus-powered downstream ports
?? Patent-pending, table-driven SCANTABLE?technology for easy customization to
different keyboard matrix up to 18x8.
?? Support rotary encoder for multimedia volume control
?? Support CD/DVD Play/Pause, Fast Forward, Rewind, Stop, Eject, Mute (up to 24 keys)
?? Additional general purpose keys for internet, email, help…shortcuts, up to 16 keys.
?? Additional 2 general purpose LEDs
?? Support ACPI compliant suspend/shutdown key
?? Built-in 3.3v voltage regulator allows single +5V operating voltage drawing directly from
USB bus. This results in reduced overall system cost.
?? Optional gang-powered control pin for downstream port.
?? Runs at 12Mhz frequency
?? Available in 64-pin LQFP package.

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
APPLICATION BLOCK DIAGRAM 3
2.0 Application Block Diagram
The AT9322 R2 is a single chip which integrates USB keyboard and hub functionality. The
upstream port is connected to the USB system. The downstream ports can be used for a mouse
and joystick. The multimedia function keys are designed to support volume control, CD/DVD
Play/Pause, Stop, Eject, Mute and general purpose shortcut keys for one key internet, email
and help.

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
PIN ASSIGNMENT 5
3.0 PinAssignment
The AT9322 R2 is packed in a 64-pin Quad Flat Package (LQFP). The following figure
shows the signal names for each of the pins on the chip of a LQFP package. The table on the
following page describes each of the pin signals.
SCAN_C2
SCAN_C7
SCAN_C6 SCAN_C5 SCAN_C4
SCAN_C3
SCAN_C1 SCAN_R8 SCAN_R7 SCAN_R6 SCAN_R5 SCAN_R4
SCAN_R3
SCAN_R10 SCAN_R9
SCAN_C8
RSTN
XTAL_1 XTAL_2
GNDAP
VCCAP
USB_DP
USB_DM
USB1_DP USB1_DM USB2_DP
MUTEKEYN
SLEEPKEYN
MODEKEYN
DESCSELET2
USB2_DM
SCROLL_LOCK
16
14
15
10
11
12
7
8
9
5
6
2
3
4
1
13
61 60 59 58 57 56 55 54 53 52 51 50 496264 63
DESCSELET0
CAPSLOCK
NUM_LOCK
LED2
LED1
DP1OVCR
DP2PWRUP
DP2OVRCR
GANGPWRN
AIN
GNDK
VCC3K
BIN
DESCSELET1
SCAN_R1
SCAN_R2
33
35
34
39
38
37
42
41
40
44
43
47
46
45
48
36
20 21 22 23 24 25 26 27 28 29 30 31 321917 18
VHV
V33
WAKUPKYN
SHUTDKYN
SCAN_M2
SCAN_M1
SCAN_M0
SCAN_R18
SCAN_R17
SCAN_R16
SCAN_R15
SCAN_R14
SCAN_R13
GNDIO
SCAN_R12
SCAN_R11

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
PIN ASSIGNMENT 6
Table 3-1. Pin Descriptions
Pin # Pin Name IO Type Driving Capability Description
1GNDIO GND Ground
2VHV 5VPower Supply 5V input
3VCC33 Regulator 3.3V Output
4WAKUPKYN INPUT, PULL UP ACPI wakeup key
5SHUTDKYN INPUT, PULL UP ACPI shutdown key
6SCAN_M2 INPUT,OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
(dedicated for
mm/shortcut keys)
7SCAN_M1 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
(dedicated for
mm/shortcut keys)
8SCAN_M0 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
(dedicated for
mm/shortcut keys)
9SCAN_R18 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
10 SCAN_R17 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
11 SCAN_R16 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
12 SCAN_R15 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
13 SCAN_R14 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
14 SCAN_R13 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
15 SCAN_R12 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
16 SCAN_R11 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
17 SCAN_R10 INPUT,PULL UP,PULL DOWN
16mA, 50KOhm Row/Scan Line
18 SCAN_R9
INPUT,PULL UP,PULL DOWN
16mA, 50KOhm Row/Scan Line
19 SCAN_C8 INPUT,PULL UP 2.5K Ohm Column line
20 SCAN_C7 INPUT,PULL UP 2.5K Ohm Column line
21 SCAN_C6 INPUT,PULL UP 2.5K Ohm Column line
22 SCAN_C5 INPUT,PULL UP 2.5K Ohm Column line
23 SCAN_C4 INPUT,PULL UP 2.5K Ohm Column line
24 SCAN_C3 INPUT,PULL UP 2.5K Ohm Column line
25 SCAN_C2 INPUT,PULL UP 2.5K Ohm Column line
26 SCAN_C1 INPUT,PULL UP 2.5K Ohm Column line
27 SCAN_R8 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
28 SCAN_R7 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
29 SCAN_R6 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
30 SCAN_R5 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
31 SCAN_R4 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
32 SCAN_R3 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
33 SCAN_R2 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
34 SCAN_R1 INPUT/OUTPUT,PULLDOWN
16mA, 50KOhm Row/Scan Line
35 BIN INPUT
Rotary encoder input ‘B’
36 VCC3K Kernel 3.3V Input +3V power supply
37 GNDK Kernel Ground Ground
38 AIN INPUT Rotary encoder input ‘A’
39 GANGPWRN OUTPUT 8mA Port 1 power/Gang power

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
PIN ASSIGNMENT 7
enable (gang mode)
40 DP2OVRCUR INPUT,PULL UP 50KOhm Port 2 over current–
low
active
41 DP2PWRUP OUTPUT 8mA Downstream port 2
power enable –low
active
42 DP1OVRCUR INPUT,PULL UP 50KOhm Port 1 over current–
low
active
43 LED1 OUTPUT 8mA Additional LED 1 –
low
active –open drain
44 LED2 OUTPUT 8mA Additional LED 2 –
low
active –open drain
45 NUM_LOCK OUTPUT 16mA Num lock LED –low
active –open drain
46 CAPSLOCK OUTPUT 16mA Cap Lock LED –low
active –open drain
47 DESCSELET0 INPUT
48 DESCSELET1 INPUT
49 DESCSELET2 INPUT
50 MODEKEYN INPUT Fn Key
51 USB2_DM INPUT/OUTPUT 16mA
USB downstream port 2
D-
52 USB2_DP INPUT/OUTPUT 16mA
USB downstream port 2
D+
53 USB1_DM INPUT/OUTPUT 16mA
USB downstream port 1
D-
54 USB1_DP INPUT/OUTPUT 16mA USB downst
ream port 1
D+
55 USB_DM INPUT/OUTPUT 16mA USB upstream D-
56 USB_DP INPUT/OUTPUT 16mA USB upstream D+
57 VCCAP Analog 3.3V Input Analog VCC
58 GNDAP Analog Ground Analog ground)
59 XTAL_2 OUTPUT 12MHz crystal output
60 XTAL_1 INPUT 12MHz Crystal input
61 RSTN INPUT Reset –low active
62 MUTEKEYN INPUT,PULL UP 50KOhm Mute key, low active
63 SLEEPKEYN INPUT,PULL UP 50KOhm ACPI
(Sleep/wakeup/power
down) –low active
64 SCROLL_LOCK OUTPUT 16mA Scroll_lock LED output–
low active –open drain

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
SYSTEM ARCHITECTURE AND REFERENCE DESIGN 9
4.0 System Architecture and
Reference Design
4.1 AT9322 R2 Block Diagram
AT9322 Block Diagram

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
SYSTEM ARCHITECTURE AND REFERENCE DESIGN 10
4.2 Sample Schematics
R10 15K
JP1
HEADER 10
1
2
3
4
5
6
7
8
9
10
VCC3.3
SCAN_R17
SCAN_R4
J2
RIGHT
GND
DM
DP
OUT_A
FGND
C29
0.1UF
U3
24C08 or compatible
1
2
3
4 5
6
7
8
A0
A1
A2
GND SDA
SCL
WP
VCC
C32
0.1UF
AT MICRO AT9322 A
AT9322 USB KEYBOARD-HUB CONTROLLER
A4
1 1
Title
Size Document Number Rev
Date: Sheet of
R14 470
R5 15K
SCAN_R10
SCAN_C6
SCAN_R14 VCC3.3
SCAN_R4
SCAN_C4
SCAN_R18
SCAN_R8
SCAN_R5
J1
1
2
3
4
5
VCC
DATA-
DATA+
GND
FGND1
SCAN_R9
C9
1UF
SCAN_R3
C24
39PF
F8
FB
F7
FB
VCC3.3
SCAN_R18
C20
150UF
SCAN_C7
R26 100K
SCAN_C4
SCAN_R10
D2
LED
C34
150UF
SCAN_R16
F2
FB
SCAN_C8
SCAN_R17
Y1
12MHZ C23
47P
C19
47P
R8
1M
R27 100K
VCC3.3
U1
AT9322
26
25
24
23
22
21
20
19
34
33
32
31
30
29
28
27
18
17
16
15
14
13
12
11
10
9
36
57
3
56
55
54
53
52
5164
46
45
60
59
61
39
37
58
48
47
8
7
6
2
42
40
41
38
35
63
62
43
44
1
50
49
4
5
SCAN_C1
SCAN_C2
SCAN_C3
SCAN_C4
SCAN_C5
SCAN_C6
SCAN_C7
SCAN_C8
SCAN_R1
SCAN_R2
SCAN_R3
SCAN_R4
SCAN_R5
SCAN_R6
SCAN_R7
SCAN_R8
SCAN_R9
SCAN_R10
SCAN_R11
SCAN_R12
SCAN_R13
SCAN_R14
SCAN_R15
SCAN_R16
SCAN_R17
SCAN_R18
VCC3K
VCCAP
VCC3.3
USB_DP
USB_DM
USB1_DP
USB1_DM
USB2_DP
USB2_DMSCR_LOCK#
CAP_LOCK#
NUM_LOCK#
XTAL_1
XTAL_2
RESET#
GANGPWRN
GNDK
GNDAP
E2P_DATA
E2P_CLK
SCAN_M0
SCAN_M1
SCAN_M2
VHV
DP1_OVRCUR#
DP2_OVRCUR#
DP2_PWR#
A_IN
B_IN
SLEEP#
MUTE#
LED1#
LED2#
GNDIO
MODEKEYN
NC
WAKUPKYN
SHUTDKYN
SCAN_R15
SCAN_R1
C25
0.1UF
R4 15K
R23 47K
SCAN_C1
SCAN_R14
SCAN_C8
SCAN_R2
SCAN_R5
R7 39
SCAN_R7
F1
FB
SCAN_R12
C20
0.1UF R6 15K
SCAN_C3
C11
0.1UF
D3LED
R11 39
VCC3.3
C21
0.1UF
SCAN_R13
R13 470
R25 470K
R17 39
C10
10UF
R1 39 R2
1.5K
SCAN_R1
C22
39PF
R15 470
VCC3.3
SCAN_C3
VCC
SCAN_R6
U2
2526 or compatible
1
2
3
4 5
6
7
8
ENA#
FLGA#
FLGB#
ENB# OUTB
GND
IN
OUTA
SCAN_R3
C15
47P
SCAN_R15
C17
47P
VCC
R9 39
SCAN_R7
C26
0.1UF
D4LED
J3
LEFT
GND
DM
DP
OUT_A
FGND
SCAN_R9
VCC3.3
JP2
HEADER 18
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Disclaimer: This schematic is for reference only.
AT Micro Corp. makes no warranty for the use of its
products and bears no responsibility for any error that
appear in this document. Specifications are subject to
change without notice.
F4
FB
R16 39
C33
0.1UF
SCAN_R6
F3
FB
SCAN_C1
SCAN_C5
SCAN_R13
VCC
SCAN_R8
SCAN_R11
C36
0.1U
SCAN_C7
R12 39
C31
0.1UF
VCC
VCC
C14
0.1UF
SCAN_C2
SCAN_C2 R3 39
C37
0.1U
SCAN_C6
SCAN_R12
SCAN_R16
SCAN_C5
SCAN_R2
SCAN_R11
R24 47K

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
SYSTEM ARCHITECTURE AND REFERENCE DESIGN 11
4.3. AT9322 R2 Keyboard Hub EEPROM Sample Value
Offset Hex value Description
00 00,07 Configuration Byte 1 bit 0 : Individual power.
Byte 1 bit 1 : Wakeup on any key.
Byte 1 bit 2 : Select SelfPower change by HID
feature.
Byte 1 bit 3 : Enable disconnect on power change.
Byte 1 bit 4 : Disable Hub(keyboard only).
Byte 1 bit 5 : Enable Volume Up/Down Keys
(Disable rotary encoder).
Byte 1 bit 6 : Enable Split Report(16bits -id3,8 -
id1)
Byte 1 bit 7 : Enable Port Error
02 B1,C3 LoByte : Pointer to Hub device descriptor 000h ROM address
HiByte : Xfer end address + 1
04 1C,35 LoByte : Pointer to Hub configuration descriptor 000h ROM
address
HiByte : Xfer end address + 1 (config+interface+endpoint)
06 C3,CC LoByte : Pointer to HUB Class descriptor (0x29) 000h ROM
address
HiByte : Xfer end address + 1
08 CC,DE LoByte : Pointer to Keyboard device descriptor 000hROM
address
HiByte : Xfer end address + 1
0A 35,57 LoByte : Pointer to Keyboard configuration descriptor
HiByte : Xfer end address + 1 000h ROM
address
(config+interface0+HID0+endpoint1+interface1+HID1+endpoint2)
0C47,50 LoByte : Pointer to Keyboard HID descriptor (0x21) Interface 0
HiByte : Xfer end address + 1 000h ROM
address
0E 70,B1 LoByte : Pointer to Keyboard Report descriptor (0x22) Interface 0
HiByte : Xfer end address + 1 000h ROM
address
10 60,69 LoByte : Pointer to Keyboard HID descriptor (0x21) Interface 1
HiByte : Xfer end address + 1 000h ROM
address
12 54,02 LoByte : Pointer to Keyboard Report descriptor (0x22) Interface 1
HiByte : Xfer end address + 1 start in 200h
ROM address, end in 300h ROM address
14 02,06 LoByte : Pointer to string descriptor (index 0) 300h ROM
address
HiByte : Xfer end address + 1
16 06,12 LoByte : Pointer to string descriptor (index 1) 300h ROM
address
HiByte : Xfer end address + 1
18 12,3A LoByte : Pointer to string descriptor (index 2) 300h ROM
address

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
SYSTEM ARCHITECTURE AND REFERENCE DESIGN 12
HiByte : Xfer end address + 1
1A 3A,42 LoByte : Pointer to string descriptor (index 3) 300h ROM
address
HiByte : Xfer end address + 1
1C 09,02,19,00,01,01,02,E0,32 Config Desc. 1 interface, self powered, remote wakeup, 100 mA
Total bytes returned : 0x19
25 09,04,00,00,01,09,00,00,02 Hub interface descriptor, interface 0. Class code 0x9, Sub Class 02
2E 07,05,81,03,01,00,FF Hub endpoint descriptor
35 09,02,22,00,01,01,02,E0,32 Keybrd Config Desc. 1 interfaces, Self powered, remote wakeup,
100 mA
Total bytes returned : 0x22
3E 09,04,00,00,01,03,01,01,02 Keyboard interface descriptor, interface 0. Class code 0x3.Boot
subclass
47 09,21,10,01,00,01,22,41,00 Keyboard HID 1.1 descriptor , Country code=00
50 07,05,81,03,08,00,0A Keyboard endpoint descriptor
57 09,04,01,00,01,03,00,00,02 Added Key interface descriptor, interface 1. Class code 0x3.
subclass 02, (KB 1 interface, Added key Not Used)
60 09,21,10,01,00,01,22,AE,00 Added Key HID 1.1 descriptor, Country code=00
69 07,05,82,03,04,00,FF Added Key endpoint descriptor
70 05,01,09,06,A1,01,05,07,
19,E0,29,E7,15,00,25,01,
75,01,95,08,81,02,95,01,
75,08,81,01,95,05,75,01,
05,08,19,01,29,05,91,02,
95,01,75,03,91,01,95,06,
75,08,15,00,26,FF,00,05,
07,19,00,2A,FF,00,81,00,
C0
Keyboard report descriptor
B1 12,01,10,01,09,00,00,08,
8F,05,13,92,01,00,01,02,
00,01
Hub device descriptor, version 1. 1, change VID,PID
Device version 1
12 Descriptor length
01 Device Descriptor
10 01 USB Version 1.1
09 Hub class
00 Sub-class
00 Device Protocol
08 Maximum packet size
VV VV Vender ID –Hub Vender ID (058F)
PP PP Product ID -Hub Product ID (9213)
01 00 Device release number
01 Index of Manufacturer string descriptor
02 Index of Product string descriptor
00 Index of serial number string descriptor –no serial number
01 Number of configuration
C3 09,29,03,0C,00,16,64,02,FF Hub class descriptor.
09 Descriptor length
29 Hub Descriptor
03 Number of downstream port –one keyboard and 2 external
ports
0C 00 Individual Over-current, compound device, gang power
switch
16 Power good wait time 16hx2 mS
64 Maximum current required (100 mA)
02 Port 1 is not removable
FF Port power control mask

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
SYSTEM ARCHITECTURE AND REFERENCE DESIGN 13
CC 12,01,10,01,00,00,00,08,
8F,05,72,94,01,00,01,02,
00,01
Keyboard device descriptor, version 1.1, change VID,PID
Device version 1
12 Descriptor length
01 Device Descriptor
10 01 USB Version 1.1
00 Class defined in interface descriptor
00 Sub-class
00 Device Protocol
08 Maximum packet size
VV VV Vender ID –Keyboard Vender ID (058F)
PP PP Product ID -Keyboard Product ID (9472)
01 00 Device release number
01 Index of Manufacturer string descriptor
02 Index of Product string descriptor
00 Index of serial number string descriptor –no serial number
01 Number of configuration
DE 00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
Spare bytes for expanding the Key report descriptor
100 39,2C,4E,3A,3B,3C,3D,3E,
3F,40,41,42,43,53,47,5F,
60,61,56,5C,5D,5E,57,59,
5A,5B,62,63,58,44,45,46,
34,35,4D,31,1D,1B,06,19,
05,11,10,36,37,38,4C,55,
24,25,26,27,2D,2E,2A,2B,
14,1A,08,15,17,1C,18,0C,
12,13,2F,30,28,51,04,16,
07,09,0A,0B,0D,0E,0F,33,
32,4A,52,4B,48,50,4F,49,
00,89,E0,E4,E8,E2,E6,54,
8B,E3,00,00,67,88,00,8A,
E1,87,00,00,E5,66,E7,65,
64,29,1E,1F,20,21,22,23,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
Keyboard Matrix 8x18
190 60,61,56,5C,5D,5E,57,59,
5A,5B,62,63,58,44,45,46,
34,35,4D,31,1D,1B,06,19,
05,11,62,36,63,54,4C,55,
5F,60,61,55,2D,2E,2A,2B,
14,1A,08,15,17,1C,5C,5D,
5E,56,2F,30,58,4E,04,16,
07,09,0A,0B,59,5A,5B,57,
32,4A,4B,4B,48,4A,4D,49,
00,89,E4,E4,E8,E2,E6,54,
8B,E3,00,00,67,88,00,8A,
E1,87,00,00,E5,66,E7,65,
64,29,1E,1F,20,21,22,23,
00,00,00,00,00,00,00,00,
Keyboard Matrix 8x14
200 00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00, Spare bytes for expanding the Added Key report descriptor

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
SYSTEM ARCHITECTURE AND REFERENCE DESIGN 14
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,
254 05,0C,09,01,A1,01,85,01,
09,E0,15,E8,25,18,75,07,
95,01,81,06,15,00,25,01,
75,01,09,E2,81,06,C0,05,
01,09,80,A1,01,85,02,19,
81,29,83,15,00,25,01,75,
01,95,03,81,06,75,05,95,
01,81,01,C0,05,0C,09,01,
A1,01,85,03,95,01,75,01,
15,00,25,01,0A,21,02,81,
06,0A,8A,01,81,06,09,B7,
81,06,09,CD,81,06,09,E9,
81,06,09,EA,81,06,0A,92,
01,81,06,0A,24,02,81,06,
0A,8A,01,81,06,0A,23,02,
81,06,0A,21,02,81,06,0A,
26,02,81,06,0A,27,02,81,
06,09,E2,81,06,09,00,81,
06,09,00,81,06,95,01,75,
08,81,01,05,08,09,19,75,
01,91,02,09,2A,91,02,95,
01,75,06,91,01,C0,
Added Key report descriptor
(KB 1 interface, Added key Not Used)
302 04,03,09,04 Lang ID array, (index 0), change string
306 0C,03,
41,00,4C,00,43,00,4F,00,52,00, Leng,Str_desc, (index 1) Manufacturer, A,L,C,O,R
312 28,03,
41,00,55,00,39,00,34,00,
33,00,32,00,20,00,4B,00,
65,00,79,00,62,00,6F,00,
61,00,72,00,64,00,20,00,
48,00,75,00,62,00,
Leng, Str_desc (index 2), change string
Product,
A,T,9,3,2,2, ,K,e,y,b,o,a,r,d, ,H,u,b
33A 08,03,31,00,32,00,33,00 Leng,Str_desc (Serial number, index 3), change string
1,2,3
342 00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
Spare bytes

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
SYSTEM ARCHITECTURE AND REFERENCE DESIGN 15
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,00,00,
00,00,00,00,00,00,

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
SYSTEM ARCHITECTURE AND REFERENCE DESIGN 16
4.4 Sample Key Matrix Layout Table
This table is a sample key matrix. The AT9322 R2 can also mask this matrix as default
without an external EEPROM.
Table 4-1. Sample AT9322 R2 Key Matrix
H1 H2 H3 H4 H5 H6 H7 H8
V1 ?Left
V2 Alt-Left Japan Alt-Right Japan
V3 Ctrl-Left Caps-Lock
Ctrl-Right rKorea-Right
V4 Korea-Left
Shift-Right
Japan Shift-Left
V5 ZABack-Space
`~ Enter Home ?4
Tab
V6 XS+= 1! ]} ?85Q
V7 F3 F5 Print-Screen
Pause F11 F9 F7 F1
V8 Esc F4 F12 Scroll-Lock
F10 F8 F6 F2
V9 MJ7& 6^ UK,< Y
V10 NH8* 5%IL.> T
V11 BG9( 4$ O;: ?/ R
V12 VF0) 3# P‘” Space-Bar E
V13 CD-_2@ [{ Pg Up 9 ?6W
V14 Page-Up Page-DN \(UK) | ?-*Pg Dn 3 Ins 0
V15 Home End \|?+/?2. Del
V16 Insert Del ???Num Lock End 1 Enter (Pad)
V17 ?Right
V18 <> Japan Japan Rev.Key Brazil

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
ELECTRICAL CHARACTERISTICS 17
5.0 Electrical Characteristics
5.1 Absolute Maximum Ratings
SYMBOL PARAMETER RATING UNITS
VCC Power Supply -0.3 to 6.0 V
VIN Input Voltage -0.3 to VCC+0.3 V
VOUT Output Voltage -0.3 to VCC+0.3 V
Vcc5 Power Supply for Dual
Oxide Cells -0.6 to 6.0 V
Vin5 Power Supply for Dual
Oxide Cells -0.3 to Vcc5 +0.3 V
VOUT Output Voltage -0.3 to Vcc5 +0.3 V
TSTG Storage Temperature -55 to 150 OC
5.2Recommended Operating Conditions
SYMBOL PARAMETER MIN TYP MAX UNITS
VCC Power Supply 3.0 3.3 3.6 V
VIN Input Voltage 0-VCC V
Commercial Power Supply
for Dual Oxide Cells 4.75 5.0 5.25 OC
Industrial Power Supply
for Dual Oxide Cells 4.5 5.0 5.5 V
VCC5
VIN5 Input Voltage 0-Vcc5 V
Commercial Junction
Operating Temperature 025 115 OC
TjIndustrial Junction
Operating Temperature -40 25 125 OC

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
ELECTRICAL CHARACTERISTICS 18
5.3General DC Characteristics
SYMBOL
PARAMETER CONDITIONS MIN TYP MAX UNITS
IIL Input leakage current no pull-up or pull-down
-11?A
IOZ Tri-state leakage current -11?A
CIN3 3.3 Input capacitance 2.8 ?F
COUT3 3.3 Output capacitance 2.7 4.9 ?F
CBID3 3.3V Bi-directional buffer
capacitance 2.7 4.9 ?F
CIN5 5V Input capacitance 2.7 5.6 ?F
COUT5 5V Output capacitance ?F
CBID5 5V Bi-directional buffer
capacitance 2.7 5.6 ?F
5.4 DC Electrical Characteristics for 5 volts operation
( Under Recommended Operating Conditions and VCC=4.5v ~ 5.25v , Tj= 0OC to +115OC )
SYMBOL
PARAMETER CONDITIONS MIN TYP MAX UNITS
VIL Input Low Voltage CMOS 0.3*VCC V
VIH Input High Voltage CMOS 0.7*VCC
V
VIL Input Low Voltage TTL 0.8 V
VIH Input High Voltage TTL 2.0 V
Vt-
Schmitt trigger negative
going threshold voltage CMOS 1.78 V
Vt+
Schmitt trigger positive
going threshold voltage
CMOS 3.20 V
Vt-
Schmitt trigger negative
going threshold voltage TTL 1.10 V
Vt+
Schmitt trigger positive
going threshold voltage
TTL 1.90 V
VOL Output low voltage IOL=2, 4, 8, 12, 16, 24 mA 0.4 V
VOH Output high voltage IOH=2, 4, 8, 12, 16, 24 mA 3.5 V
RIInput Pull-up/down
resistance VIL=0V or VIH=VCC 50 K?

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
ELECTRICAL CHARACTERISTICS 19
5.5 DC Electrical Characteristics for 3.3 volts operation
( Under Recommended Operating Conditions and VCC=3.0v ~ 3.6v , Tj = 0OC to +115OC)
SYMBOL PARAMETER CONDITIONS MIN TYP MAX
UNITS
VIL Input Low Voltage CMOS 0.3*VCC V
VIH Input High Voltage CMOS 0.7*VCC V
Vt-
Schmitt trigger negative going
threshold voltage CMOS 1.20 V
Vt+
Schmitt trigger positive going
threshold voltage CMOS 2.10 V
VOL Output low voltage IOH=2, 4, 8, 12, 16, 24 mA 0.4 V
VOH Output high voltage IOH=2, 4, 8, 12, 16, 24 mA 2.4 V
RIInput Pull-up/down resistance VIL=0V or VIH=VCC 75 K?
5.6 Crystal Oscillator Circuit Setup for Characterization
The following setup was used to measure the open loop voltage gain for crystal oscillator
circuits. The feedback resistor serves to bias the circuit at its quiescent operating point and
the AC coupling capacitor, Cs, is much larger than C1 and C2.

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
ELECTRICAL CHARACTERISTICS 20
5.7 USB Transceiver Characteristics
RECOMMENDED OPERATING CONDITIONS
LIMITS UNITSYMBOL PARAMETER CONDITIONS MIN MAX
VCC DC supply voltage 3.0 3.6 V
VIDC input voltage range 05.5 V
VI/O DC input range for I/Os 0VCC V
VODC output voltage range 0VCC V
TAMB Operating ambient temperature
range in free air See DC and AC characteristics for
individual device
070 °C
ABSOLUTE MAXIMUM RATINGS (Notes 1 and 2)
In accordance with the Absolute Maximum Rating System, Voltages are referenced to GND (Ground=0v)
LIMITS UNITSYMBOL PARAMETER CONDITIONS MIN MAX
VCC DC supply voltage -0.5 +6.5 V
IIK DC input diode current Vi<0 -50 mA
VIDC input voltage Note 3 -0.5 +5.5 V
VI/ODC input voltage range for I/Os -0.5 Vcc
+0.5 V
IOK DC output diode current Vo> Vcc or Vo<0 +/-50 mA
VODC output voltage Note 3 -0.5 Vcc
+0.5 V
IODC output source sink current
for VP/VM and RCV pins Vo=0 to Vcc +/-15 mA
IODC output source or sink
current for D+/D-pins Vo= 0 to Vcc +/-50 mA
ICC, IGND DC Vcc or GND current +/-100
mA
TSTO Storage temperature range -60 +150 °C
PTOT Power dissipation per package mW
NOTES:
1. Stresses beyond thoselisted may cause permanent damage to the device. These are stress ratings
only and functional operation of the device at these or any other conditions beyond those indicated
under "Recommended Operating Conditions" is not implied. Exposure to absolute maximum rated
conditions for extended periods may affect device reliability.
2. The performance capability of a high performance integrated circuit in conjunction with its thermal
environment can create junction temperatures which are detrimental to reliability. The maximum
junction temperature of this integrated circuit should not exceed 150°C.
3. The input and output voltage ratings may be exceeded if the input and output clamp current ratings
are observed.

ｗｗｗ．ｙｃ－ｄｚ．ｃｏｍ
ELECTRICAL CHARACTERISTICS 21
DC ELECTRICAL CHARACTERISTICS
Over recommended operating conditions. Voltages are referenced to GND (Ground=0V).
LIMITS
SYMBOL PARAMETER -400°C to +850°CUNIT
TEST CONDITIONS MIN TYP MAX
VHYS Hysteresis on inputs Vcc=3.0V to 3.6V (Note 3)
0.3 0.4 0.5 V
VIH HIGH level input Vcc=3.0V to 3.6V (Note 3)
1.5 2.0 V
VIL LOW level input Vcc=3.0V to 3.6V (Note 3)
0.8 1.1 V
RoH Output impedance (HIGH
state) Note 2 28 34 43 ohm
RoL Output impedance (LOW
state) Note 2 28 35 43 ohm
VOH HIGH level output
(Note 3) Vcc=3.0V Io=6mA Vcc=3.0V Io=4mA
Vcc=3.0V Io=100?A
2.2
2.4
2.8
2.7 V
VOL LOW level output
(Note 3) Vcc=3.0V Io=6mA Vcc=3.0V Io=4mA
Vcc=3.0V Io=100?A
0.3 0.7
0.4
0.2
V
IQ Quiescent supply current Vcc=3.6V VI=Vcc or GND
Io=0 330 600 ?A
Isup Supply current in suspend Vcc=3.6V VI=Vcc or GND
Io=0 70 ?A
IFS Active supply current (Full
Speed) Vcc=3.3V 914 mA
ILS Active supply current (Low
Speed) Vcc=3.3V 2mA
ILeak Imput leakage current Vcc=3.6V VI=5.5V or
GND, not for I/O Pins +/- 0.1 +/- 0.5 ?A
IOFF 3-state output OFF-state
current Vi=Vih or ViL; Vo=Vcc or GND +/-10
?A
NOTES:
1. All typical values are at Vcc=3.3V and Tamb=25°C.
2. This value includes an external resistor of 24 ohm +/-1%. See "Load D+ and D-" diagram for testing
details.
3. All signals except D+ and D-.
