ATMTECH SC41T-CODEC User manual

SC41T-CODEC
4K Scaler with Soft Codec
All Rights Reserved
Version: SC41T-CODEC_2017V1.0
User Manual

4K Scaler with Soft Codec
Preface
Read this user manual carefully before using the product. Pictures shown in this manual
is for reference only. Different models and specifications are subject to real product.
This manual is only for operation instruction only. The functions described in this version
are updated till August 7, 2017. In the constant effort to improve our product, we reserve
the right to make functions or parameters changes without notice or obligation. Please
refer to the dealers for the latest details.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. It has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a commercial
installation.
Operation of this equipment in a residential area is likely to cause interference, in which
case the user at their own expense will be required to take whatever measures may be
necessary to correct the interference.
Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.

4K Scaler with Soft Codec
SAFETY PRECAUTIONS
To insure the best from the product, please read all instructions carefully before using
the device. Save this manual for further reference.
Unpack the equipment carefully and save the original box and packing material for
possible future shipment.
Follow basic safety precautions to reduce the risk of fire, electrical shock and injury
to persons.
Do not dismantle the housing or modify the module. It may result in electrical shock
or burn.
Using supplies or parts not meeting the products’ specifications may cause damage,
deterioration or malfunction.
Refer all servicing to qualified service personnel.
To prevent fire or shock hazard, do not expose the unit to rain, moisture or install this
product near water.
Do not put any heavy items on the extension cable in case of extrusion.
Do not remove the housing of the device as opening or removing housing may
expose you to dangerous voltage or other hazards.
Install the device in a place with fine ventilation to avoid damage caused by
overheat.
Keep the module away from liquids.
Spillage into the housing may result in fire, electrical shock, or equipment damage. If
an object or liquid falls or spills on to the housing, unplug the module immediately.
Do not twist or pull by force ends of the optical cable. It can cause malfunction.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
Unplug the power cord when left unused for a long period of time.
Information on disposal for scrapped devices: do not burn or mix with general
household waste, please treat them as normal electrical wastes.

4K Scaler with Soft Codec
Contents
1. Introduction........................................................................................................................................ 1
1.1 Introduction to SC41T-CODEC.................................................................................................1
1.2 Feature.....................................................................................................................................1
1.3 Package List.............................................................................................................................2
2. Specification...................................................................................................................................... 3
2.1 Transmitter...............................................................................................................................3
2.2 Receiver...................................................................................................................................4
3. Panel Description............................................................................................................................... 5
3.1 Transmitter...............................................................................................................................5
3.1.1 Front Panel................................................................................................................... 5
3.1.2 Rear Panel................................................................................................................... 6
3.2 Receiver...................................................................................................................................7
3.2.1 Front Panel................................................................................................................... 7
3.2.2 Rear Panel................................................................................................................... 7
4. System Connection............................................................................................................................ 8
4.1 Usage Precaution.....................................................................................................................8
4.2 System Diagram.......................................................................................................................8
5. Button Control.................................................................................................................................... 9
5.1 Manual Switching .....................................................................................................................9
5.2 Auto Switching........................................................................................................................10
5.3 Volume Adjustment.................................................................................................................10
6. RS232 Control..................................................................................................................................11
6.1 RS232 Connection .................................................................................................................11
6.2 RS232 Control Software.........................................................................................................12
6.3 RS232 Command...................................................................................................................13
6.3.1 Source Switching.........................................................................................................13
6.3.2 AudioAdjustment.........................................................................................................13
6.3.3 Output Resolution........................................................................................................14
6.3.4 Auto Power-off Setup...................................................................................................15
6.3.5 CEC Command...........................................................................................................16
6.3.6 Relay Control ..............................................................................................................17
6.3.7 EDID Configuration......................................................................................................17
6.3.8 HDCP Compliance ......................................................................................................17
6.3.9 Device Setup...............................................................................................................17
7. OSD Control.....................................................................................................................................18
7.1 Picture....................................................................................................................................18
7.2 Setup .....................................................................................................................................19
8. GUI Control.......................................................................................................................................20
8.1 Control Menu..........................................................................................................................21
8.2 Configuration Menu................................................................................................................22
8.3 RS232 Control Menu..............................................................................................................24
8.4 Password Menu......................................................................................................................26
8.5 GUI Update............................................................................................................................26
9. Panel Drawing ..................................................................................................................................27
10. Troubleshooting & Maintenance......................................................................................................28
11. Customer Service ...........................................................................................................................29

4K Scaler with Soft Codec
1
1. Introduction
1.1 Introduction to SC41T-CODEC
This SC41T-CODEC is a conferencing system codec kit supporting resolutions up to
4K@30Hz 4:4:4 and HDCP 2.2. It includes Transmitter and Receiver, providing AV
switching, audio de-embedded, and USB extension, plus system control. All video,
audio, control, USB and Ethernet signals can be transmitted over a single CATx cable
up to 100m.
The kit provides four video inputs such as HDMI, VGAand DP. To simplify meeting room
device management, the kit offers LAN for Ethernet and USB ports for devices
extension, four on the transmitter and two on the receiver. It supports a variety of 2.0
USB devices like camera, microphone and keyboard as well as other HID devices.
It also allows users to control system functionality via WEB GUI, RS232 and CEC.
Additionally, users can control the rise and fall of projector screen over relay port.
This is an ideal solution for meeting spaces using PC-based conferencing system
codecs such as Skype@, WebEx@and GoToMeeting@, etc.
1.2 Feature
Supports resolution converting ranging from 720p to 4k x 2k @30Hz 4:4:4.
Provides a variety of interfaces to simplify room devices management.
Supports PCs, USB devices like keyboard, webcam, MIC for conference system.
Extends the transmission distance of USB signals.
Two type B USB for connection to host, four type A USB for HID devices like
webcam, mic and keyboard.
Supports video source auto-switching function.
HDBaseT technology extend Video,Audio, control command and Ethernet signal up
to 100m.
Ethernet can be imported from either Receiver or Transmitter, providing LAN
accessibility for users.
Audio can be de-embedded out from AUDIO OUTPUT.
Allows connected displays to be controlled via CEC commands or front panel
buttons.
Ensures EDID communication between sources and display.
Relay commands can be triggered to control relay devices such as projector.
The Receiver provides video input port for working with BYOD-W (sold separately).

4K Scaler with Soft Codec
2
1.3 Package List
Transmitter
1 x SC41T-CODEC-T Transmitter
2 x Mounting Ears with 4 Screws
4 x Plastic Cushions
1 x Power Adapter (24VDC,2.71A)
1 x RS232 Cable (3-pin phoenix connector to DB9)
Receiver
1 x SC41T-CODEC-R Receiver
2 x Mounting Ears with 2 Screws
4 x Plastic Cushions
1 x 5-pin Phoenix Connector
1 x 7-pin Phoenix Connector
1 x User Manual
Note: Please contact your distributor immediately if you found any damage or defect in
the components.

4K Scaler with Soft Codec
3
2. Specification
2.1 Transmitter
Video
Video Input
(2) HDMI; (1) DP; (1) VGA
Video Input Connector
(2) Female HDMI; (1) DisplayPort; (1) Female VGA
(15-pin)
Video Output
(1) HDMI; (1) HDBaseT
Video Output Connector
(1) Female HDMI; (1) RJ45
Output Resolution
Supports 3840x2160@30Hz, 1920x1080, 1280x720
Standards
Compliant with HDMI 1.4 & HDCP2.2
Audio
Audio Input
(1) AUDIO
Audio Input Connector
(1) 3.5mm Stereo jack
Audio Input Impedance
>10kΩ
Control Part
Control port
(2) PC, (2) DEVICE; (1) RS232; (1) TCP/IP; (1) LAN
Control Connector
(2) Type-B USB; (2) Type-A USB; (1)3-pin phoenix
connector; (2) RJ45
General
Transmission Distance
Up to 100m
Operation Temperature
0 ~ +40℃
Storage Temperature
-10 ~ +55℃
Relative Humidity
10% ~ 90%
External Power Supply
Input: AC 100~240V, 50/60Hz; Output: 24VDC 2.71A
System Power Consumption
40w (Max)
Dimension (W*H*D)
220mm x 44mm x 120mm
Net Weight
617g

4K Scaler with Soft Codec
4
2.2 Receiver
Video
Video Input
(1) HDBT; (1) HDMI
Video Input Connector
(1) RJ45; (1) Female HDMI
Video Output
(1) HDMI
Video Output Connector
(1) Female HDMI
Output Resolution
Supports 3840x2160@30Hz, 1920x1080, 1280x720
Standards
Compliant with HDMI 1.4 & HDCP2.2
Audio
Audio Output
(1) Stereo balanced L/R audio
Audio Output Connector
(1) 5-pin phoenix connector
Audio Output Impedance
70Ω
Frequency Response
20Hz~20K Hz
Stereo Channel Separation
>80dB @1KHz
Control Part
Control port
(2) DEVICE; (1) RS232; (2) RELAY; (1) LAN
Control Connector
(2) Type-A USB; (1) 3-pin phoenix connector;
(2) 2-pin phoenix connector; (1) RJ45
General
Transmission Distance
Up to100m
Operation Temperature
0 ~ +40℃
Storage Temperature
-10 ~ +55℃
Relative Humidity
10% ~ 90%
External Power Supply
Powered by Transmitter
System Power Consumption
40w (Max)
Dimension (W*H*D)
205mm x 21.5mm x 95mm
Net Weight
358g

4K Scaler with Soft Codec
5
3. Panel Description
3.1 Transmitter
3.1.1 Front Panel
①POWER LED: The LED illuminates red when power is applied, or orange when the
auto-switching mode is chosen.
②INPUT LED & SOURCE SELECTOR:
1-HDMI: The LED illuminates green when 1-HDMI input signal is chosen.
2-HDMI: The LED illuminates green when 2-HDMI input signal is chosen.
3-DP: The LED illuminates green when 3-DP input signal is chosen.
4-VGA: The LED illuminates green when 4-VGA input signal is chosen.
RX HDMI: The LED illuminates green when the HDMI input signal on Receiver is
chosen.
SOURCE SELECTOR: Press this button to select input source signal, or
long-press for 3 seconds or more to enable auto-switching mode.
For more details, please refer to the 5 Button Control.
③DISPLAY CONTROL: Press this button to turn on/off the displays, and then the
activity LED ON/OFF will illuminates green.
④RETURN: Return key for OSD.
⑤MENU/ENTER: Menu or Enter key for OSD.
⑥VOL-/MUTE: Press this button to turn down the audio output volume, or long-press
3 seconds or more to mute / Left key for OSD.
⑦RELAY 1: Press this button to raise projector screen. / Up key for OSD.
⑧RELAY 2: Press this button to lower projector screen. / Down key for OSD.
⑨VOL+: Press this button to turn up the audio output volume. / Right key for OSD.
RX HDMI SOURCE
AUTO/3s
1-HDMI 2-HDMI 4-VGA3-DP OFF DISPLAYON MENU
ENTER
RETURN
RELAY 1
VOL +
VOL -
MUTE/3s RELAY 2
1234568
7
9

4K Scaler with Soft Codec
6
3.1.2 Rear Panel
①INPUT:
VIDEO: 2 HDMI inputs, 1 DP input and 1 VGA input.
AUDIO: 1 VGA auxiliary audio input.
②OUTPUT
HDMI: HDMI video output port.
HDBT: Support PoC. Connect with HDBaseT Receiver to transmit AV signal, IR
or RS232 control signal.
③CONTROL
PC1&PC2: Two Type-B USB ports, only one can be used to connect with PC,
and the two priority: PC1>PC2.
DEVICE 1& DEVICE 2: Two Type-A USB ports, connect with USB HID devices.
RS232: Serial port, 3-pin phoenix connector, connect with a control device (such
as PC).
TCP/IP: RJ45 connector, connect with PC to control this system via web-based
GUI.
LAN: Ethernet port for extending network signal.
Note: Please notice warning signs. The LAN port can’t be connected with HDBT
port.
FIRMWARE: Type-A USB port for updating system firmware or loading
customized EDID data.
④DC 24V: DC barrel connector for connecting the included power adapter.
HDMI
DC 24VINPUT
1-HDMI 2-HDMI 3-DP 4-VGA HDBT
RS232
Tx Rx
PC 1 DEVICE 1 TCP/IP LAN
OUTPUT
FIRMWARE
CONTROL
PC 2 DEVICE 2
AUDIO
124
3

4K Scaler with Soft Codec
7
3.2 Receiver
3.2.1 Front Panel
①POWER LED: The LED illuminates red when power is applied.
②HDBT LED: The LED illuminates green when HDBT input signal present.
③HDMI LED: The LED illuminates green when HDMI input signal present.
④FIRMWARE: Type-A USB port for updating system firmware.
3.2.2 Rear Panel
①HDBT IN: Connect to the HDBT OUT port on Transmitter via CAT5e/6a/7 cable,
support PoC technology.
②HDMI IN: HDMI input port.
③HDMI OUT: HDMI output port.
④AUDIO OUT: Stereo balanced L/R audio output port.
⑤DEVICES: Two Type-A USB ports, connect with USB HID devices.
⑥RS232: Serial port, 3-pin phoenix connector, connect with the display device (such
as projector) needed to be control via RS232 commands.
⑦RELAY1 & RELAY2: Connect with relay device (such as projector screen).
⑧LAN: Ethernet port, work with the LAN port on Transmitter to extend network signal.
Note: Please notice warning signs. The LAN port can’t be connected with HDBT port.
FIRMWARE
HDBT HDMI
1234
HDBT IN HDMI IN HDMI OUT AUDIO OUT
L R
DEVICES
12
Tx Rx
CONTROL
Relay1 Relay2
LAN
123458
67

4K Scaler with Soft Codec
8
4. System Connection
4.1 Usage Precaution
Verify all components and accessories included before installation.
System should be installed in a clean environment with proper temperature and
humidity.
All of the power switches, plugs, sockets and power cords should be insulated and
safe.
All devices should be connected before power on.
4.2 System Diagram
DC 12 V
HDMI
DC 24 VINP UT
1-HDMI 2 -HDMI 3-DP 4-VGA HDBT
RS23 2
Tx Rx
PC 1 DEV ICE 1 TCP/ IP LAN
OUTPUT
FIRM WARE
CONTROL
PC 2 DEV ICE 2
AUDI O
DVD
MacBook
Laptop
PC
DEVICES
Tx Rx
CONT ROLHDB T IN HDM I IN HDMI O UT L+R OU T
Rela y1 Rel ay2
LAN
1 2
USB Microphone
Wireless Keyboard and Mouse
Central Control System Router Projector
Wireless BYODTV Speaker USB Camera
Video:
Audio:
RS232:
HDBaseT:
Ethernet:
USB:
Laptop

4K Scaler with Soft Codec
9
5. Button Control
Front panel buttons can be used for signal switching, OSD, volume adjusting.
5.1 Manual Switching
Press the SOURCE/AUTO button to select one input source for Transmitter, press again
to select next source, switching sequentially between 1-HDMI, 2-HDMI, 3-DP and
4-VGA. The corresponding LED illuminates green.
The Receiver also features one HDMI input port, if you need to output the source signal
via its HDMI output port. The following is an example.
LED Status
Description
Status 1
The 1-HDMI LED illuminates green,
other source LEDs are gone.
The 1-HDMI is selected as input
source. The input signal will be
transmitted to all video output ports
of Transmitter and Receiver.
Status 2
The 2-HDMI and RX HDMI LEDs
illuminate green, other source LEDs
are gone.
The 2-HDMI is selected as input
source for Transmitter. The input
signal will be transmitted to all
video output ports of Transmitter.
The HDMI input signal on
Receiver will be only transmitted
to the HDMI output port of
Receiver.
Follow the below steps to switch to the status 2 from status 1.
①Press the SOURCE/AUTO button once to select 2-HDMI, and then release this
button.
②Press the SOURCE/AUTO button continuously until the RX HDMI LED illuminates
green to select the HDMI input for Receiver.
RX HDMI SOURCE
AUTO/3s
1-HDMI 2-HDMI 4-VGA3-DP
RX HDMI SOURCE
AUTO/3s
1-HDMI 2-HDMI 4-VGA3-DP

4K Scaler with Soft Codec
10
5.2 Auto Switching
Long-press SOURCE/AUTO button for 3 seconds or more to enable auto-switching
mode, and the auto-switching mode abides by the following principles:
New input
Once detecting a new input signal, the Transmitter would switch to this new signal
automatically.
Once connecting a source device to the HDMI IN port of Receiver, the Receiver will
switch to this source to output HDMI signal via HDMI OUT port automatically.
Rebooting device
The Transmitter have the ability to save the last configuration before losing power. If
the last switching mode is auto-switching, once rebooted, the Transmitter will
automatically enter auto-switching mode, then detect all inputs and memorize their
connection status for future rebooting using. If the last displayed signal is still
available, the unit will output the signal. If not, the unit will detect all the input signals
with priority from 1-HDMI to 4-VGA. When detected the first signal, it will transfer to
output.
Signal removing
Once removing the current display signal, the Transmitter will detect all input signals
with priority from 1-HDMI to 4-VGA. It will transfer the signal firstly detected to be
available to output devices.
Note:
Auto-switching function works only when inputting new signal, removing a signal or
power rebooting.
The HDMI input source on Receive cannot be selected under auto-switching mode.
5.3 Volume Adjustment
The Receiver features audio output ports for connecting speaker or AV amplifier.
Press the VOL+ or VOL- button on Transmitter to turn up or turn down the volume.
Meantime, it sends CEC commands to the display to turn up or down the display
volume.

4K Scaler with Soft Codec
11
6. RS232 Control
As RS232 commands can be transmitted to Receiver from the Transmitter, so it is able
to control the Transmitter or the third-party device (such as projector) on Receiver from
local.
The baud rate support 2400, 4800, 9600(default), 19200, 38400, 57600 or 115200.
6.1 RS232 Connection
There are two RS232 control modes.
Control Transmitter
Control Display
HDMI
DC 24VINPUT
1-HDMI 2-HDMI 3-DP 4-VGA HDBT
RS232
Tx Rx
PC 1 DEVICE 1 TCP/IP LAN
OUTPUT
FIRMWARE
CONTROL
PC 2 DEVICE 2
AUDIO
PC
HDMI
DC 24 VINP UT
1-HDMI 2-HDMI 3-DP 4-VGA HDBT
RS232
Tx Rx
PC 1 DEV ICE 1 TCP /IP LAN
OUTPUT
FIRMWARE
CONTROL
PC 2 DEV ICE 2
AUDIO
DC 12 V
PC
DEVICES
Tx Rx
CON TROLHDB T IN HDMI IN HDMI OUT L+R OUT
Relay1 Relay2
LAN
1 2
Projector

4K Scaler with Soft Codec
12
6.2 RS232 Control Software
Installation/uninstallation
Installation Copy the control software file to the computer connected with the
Transmitter.
Uninstallation Delete all the control software files in corresponding file path.
Basic Settings
First to connect the Transmitter with all input devices and output devices needed, then
to connect it with a PC which is installed with RS232 control software. Double-click the
software icon to run this software. Here we take the software CommWatch.exe as
example. The icon is showed as below:
The interface of the control software is showed as below:
Parameter Configuration area
Monitoring area, indicates if the
command sent works.
Command Sending area

4K Scaler with Soft Codec
13
Please set the parameters of COM number, bound rate, data bit, stop bit and the parity
bit correctly, and then you are able to send command in Command Sending Area.
6.3 RS232 Command
Communication protocol: RS232 Communication Protocol
Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none
The end mark of command is “<CR><LF>”.
6.3.1 Source Switching
Command
Function
Feedback
SWIN H1
Switch to 1-HDMI input.
Switch to HDMI1
SWIN H2
Switch to 2-HDMI input.
Switch to HDMI2
SWIN DP
Switch to 3-DP input.
Switch to DP
SWIN VG
Switch to 4-VGA input.
Switch to VGA
SWIN
RXHDMI
Switch to RX HDMI input.
Switch to RX HDMI
AUTO 01
Enable auto-switching.
Auto Switching
AUTO 00
Enable manual-switching.
Manual Switching
?GET IN
Get the input source of Transmitter.
(HDMI1,HDMI2,DP,VGA)
TX Device Input: HDMI1
Get the input source of Receiver.
(HDMI,HDBT)
RX Device Input: HDMI
?GET AUTO
Get the switching mode.
Manual Switching/Auto
Switching
VGAA
Auto-adjust the input parameter (VGA
only).
VGA Input Auto
6.3.2 Audio Adjustment
Command
Function
Feedback
AUMT S1
Mute source audio.
Audio Mute Source:
Enable
AUMT S0
Unmute source audio.
Audio Mute Source:
Disable

4K Scaler with Soft Codec
14
Command
Function
Feedback
AUMT V1
Mute VGA auxiliary input audio.
Audio Mute VGA: Enable
AUMT V0
Unmute VGA auxiliary input audio.
Audio Mute VGA: Disable
?GET AUMT
Get the Source mute status.
Audio Mute Source:
Enable
Get the VGA auxiliary audio mute status.
Audio Mute VGA: Enable
VOLS AP
Turn up the source audio volume
(xx=00~60).
Source Volume: xx
VOLS AN
Turn down the source audio volume
(xx=00~60).
Source Volume: xx
VOLV AP
Turn up the VGA auxiliary audio volume
(xx=00~60).
VGA Volume: xx
VOLV AN
Turn down the VGA auxiliary audio
volume (xx=00~60).
VGA Volume: xx
VOLS xx
Set the source audio volume (xx=00~60).
Source Volume: xx
VOLV xx
Set the VGA auxiliary audio volume
(xx=00~60).
VGA Volume: xx
?GET VOL
Get the source audio volume (xx=00~60).
Source Volume: xx
Get the VGA auxiliary audio volume
(xx=00~60).
VGA Volume: xx
6.3.3 Output Resolution
The default output resolution is 3840x2160@30Hz. Below is a list of the output
resolutions the built-in scaler can output.
Command
Function
Feedback
TRES 01
Set the output resolution for Transmitter
to 3840x2160@30Hz.
TX Device Resolution:
3840x2160
TRES 02
Set the output resolution for Transmitter
to 1920X1080.
TX Device Resolution:
1920x1080
TRES 03
Set the output resolution for Transmitter
to 1280x720.
TX Device Resolution:
1280x720
RRES 01
Set the output resolution for Receiver to
3840x2160@30Hz.
RX Device Resolution:
3840x2160
RRES 02
Set the output resolution for Receiver to
RX Device Resolution:

4K Scaler with Soft Codec
15
Command
Function
Feedback
1920x1080.
1920x1080
RRES 03
Set the output resolution for Receiver to
1280x720.
RX Device Resolution:
1280x720
?GET RES
Get the output resolution for
Transmitter.
Tx Device Resolution:
1920x1080
Get the output resolution for Receiver.
Tx Device Resolution:
1920x1080
6.3.4 Auto Power-off Setup
Command
Function
Feedback
?GET TIME
Check the auto power-off mode.
Auto Switch Mode no
input to shutdown time:
Disable
Manual Switch Mode no
input to shutdown time:
Disable
TIME AD
Auto Switch Mode: Disable the auto
power-off function.
Auto Switch Mode no
input to shutdown time:
Disable
TIME A1
Auto Switch Mode: Set the auto power-off
time to 1 minute when No signal input.
Auto Switch Mode no
input to shutdown time: 1
minutes
TIME A2
Auto Switch Mode: Set the auto power-off
time to 2 minute when No signal input.
Auto Switch Mode no
input to shutdown time: 2
minutes
TIME A3
Auto Switch Mode: Set the auto power-off
time to 5 minute when No signal input.
Auto Switch Mode no
input to shutdown time: 5
minutes
TIME A4
Auto Switch Mode: Set the auto power-off
time to 10 minute when No signal input.
Auto Switch Mode no
input to shutdown time:
10 minutes
TIME MD
Manual Switch Mode: Disable auto
power-off time function.
Manual Switch Mode no
input to shutdown time:
Disable

4K Scaler with Soft Codec
16
Command
Function
Feedback
TIME M1
Manual Switch Mode: Set the power-off
time to 1 minute.
Manual Switch Mode no
input to shutdown time: 1
minutes
TIME M2
Manual Switch Mode: Set the power-off
time to 2 minute.
Manual Switch Mode no
input to shutdown time: 2
minutes
TIME M3
Manual Switch Mode: Set the power-off
time to 5 minute.
Manual Switch Mode no
input to shutdown time: 5
minutes
TIME M4
Manual Switch Mode: Set the power-off
time to 10 minute.
Manual Switch Mode no
input to shutdown time:
10 minutes
6.3.5 CEC Command
Command
Function
Feedback
CECS P0
Turn off the source device by using CEC
way.
CEC: Turn Source off
CECS P1
Turn on the source device by using CEC
way.
CEC: Turn Source on
CECD P0
Turn off the display device by using CEC
way.
CEC: Turn Display off
CECD P1
Turn on the display device by using CEC
way.
CEC: Turn Display on
