Atoms Labs AWS33R User manual

QUICK START GUIDE
PRODUCT OVERVIEW
INSTALLING YOUR DEVICES
A. Setting up your monitor
1. Insert the memory card and/or connect HDD device to USB port.
2. Twist on the antenna to the LEFT side of the console.
3. Connect the Ethernet cable from the BACK of the console to your router.
4. Connect the 12V power adaptor and power on the system.
5. Twist on the stand to the back of the console.
AntennaPower Botton
Internet
Router
Mobile Device
Connect system directly after the router. Do not
connect system to router through a hub or switcher.
Enable DHCP and UPnP on your router. TCP port
#6000 and #80 should be opened.
Reset Botton USB Port
Memory Card Slot
Power Jack
Note: Before using the memory card/ HDD
for recording video, you MUST format the
memory card/ HDD on the console.
KIT CONTENT
*Camera / Receiver Antenna *Camera Stand *Digital Wireless Outdoor
IR Camera
Ethernet Cable
x 1
Screw Pack (For Camera ) Camera / Receiver Adaptor
Camera power
adapter-5V/1.5A
x 1
HDNVR power
adapter-12V/2A
Digital Wireless Receiver
Console
x 1 Note: Keep distance between device minimum 1 meter.
Monitor
Router
1 M+ 1 M+
1 M+
1 M+
1 M+
*Quantity varied subject to conguration
Thumb Screw
B. Installing your camera
1. Secure the camera stand to a stable surface, celling or wall mount using three pcs screws.
2. Loosen the thumb screw of the camera stand and secure the camera body to the bracket.
3. Screw the antenna into rear of the camera.
4. Connect the supplied power adaptor to the camera and the power source. The RED LED
will light up which indicate the camera is ready for setup.
(1) (2) (3)
7’ LCD Monitor for HD System
AWS33R

SYSTEM OPERATION
Quick Select Menu
Display/Undisplay Menu
Enter Main Menu
QUAD Display Select
Smart-QUAD Display Select
Single Channel Record/
Stop Single Channel Record
All Channel Record/Stop
All Channel Record
Volume Control
Mute/Vol1
Vol2/Vol3
Main Menu
Main Menu
Camera Setup
Live View with Quad Display
Live View with Dynamic Display
Tap again to return
Turn CH2 oTap to turn on /o the camera Turn CH2/CH3 o
Tap one channel Live-view full screen
Tap again to returnTap one channel Show it at left side Live-view full screen
SETUP THE HDNVR
1. Tap to extend quick select menu.
2. Tap to enter main menu.
Pair the camera to HDNVR
If you have additional cameras disconnected with HDNVR , follow steps below to pair:
1. Tap the camera setup icon to access the camera pairing screen.
2. Select the Camera channel (Camera 1/2/3/4).
3. Tap the "Camera Pairing" icon.
4. Within 35 seconds, press and hold the pairing button on the back of the camera for
5 seconds. The Green Link LED will light up which indicate the camera is paired successfully.
Tap one quadrant to choose the current channel, and a red check will display.
HDNVR will display audio from the current selected channel.
1.Camera Setup: Pair camera, and video quality.
2.Recorder Setup: Setup recording settings such as
date, recorder type, and motion area.
3.Event list: Event video playback.
4.System Setup: Setup system time, powersaving
mode, and restore default system settings.
5.Storage Setup: Management storage.
1. Connect the device to your router, and make sure DHCP and UPnP service are enabled on
your router setting.
2. Power up and turn on HDNVR.
In the Live View mode, wait until logo turns or .
This means system is now ready for internet connection. The process takes around 30 seconds.
3. Download the "WDVR Cam" app and run the app on a phone or tablet.
Andrio For iOS For Android

APP INTRODUCTION
4. Add New Device
Andriod: Tap the "NEW" icon to add new device.
iOS: Tap the "+" icno to add new device.
5. Tap the “scan QR code” located on the rear of the device. Also you can enter the ID manually.
6. Enter the default password "123456". Give your remote access a name and tap "save"
to exit.
7. Change the default password:
For privacy matter, follow the steps below to change the security code on both device
and app.
Note: If you have not installed the app to scan the QR code, we suggest to download and install the
app “Barcode Scanner ” .
a. Device: 1. In the main menu section, tap storage setup
2. Tap network setting
3. Click DHCP then changes the password
4. Tap “OK” once you’re nished password modication
b. WDVR CAM APP
For Andriod
1. Go to the device list
2. Press and hold the device name, the menu will appear on the panel. Then tap “modify”.
3. Tap “update” once you’re nished password modication
xxxxxxxxxxxxxxx
xxxxxxxx
1
2
3
Main Menu
Camera Setup
1
2
3
3-1
4
Note:
HDNVR allows max 3 remote viewers to access the system at a time. The 4th connection will be rejected.
When a local user is operating setup menu. The remote user will be temporarily rejected to access
HDNVR until the local user leaves the setup menu.
HDNVR requires 1.5Mbps connection bandwidth per connection to receive best viewing quality/
streaming. It is suggested to set camera resolution and quality to "Low" in order to receive
streaming remote view if the bandwidth is below 1.5Mbps.
8. Tap the device from the list, then tap "play" to connect. It will take a few seconds to
access the remote video, depending on the network environment.
For iOS
1. Tap the ”+” icon to enter device list
2. Tap [Edit] button
3. Change default password
1
2
3
Add
new device
Add new device
/Device List
Remote Setting
Push Notication
Playback
Snapshot
Record ON/OFF
Device List Live View
Connect/
Disconnect Device
Andriod iOS
* Tap to connect HDNVR,
then tap the “more” icon
that setting menu will show up.

Products with CE Marking comply with EMC Directive
(2014/30/EU); Low Voltage Directive (2014/35/EU); RED
(2014/53/EU); ROHS Directive (2011/65/EU) issued by the
Commission of the European Community. Compliance
with these directives implies conformity to the following
European Norms:
EMC: EN 301 489
LVD: EN 60950
Radio: EN 300 328
If the camera system no longer functions or can no longer be repaired, it must be disposed of according to the valid statutory regulations.
Disposal of spent batteries/accumulators:
You are required by law (Battery Ordinance) to return all spent batteries and accumulators. Disposing of spent batteries/accumulators with
common household waste is prohibited! Batteries/accumulators that contain hazardous substances are marked with the symbols on the
side. These symbols indicate that it is prohibited to dispose of these batteries/accumulators in the household waste. The abbreviations for the
respective heavy metals are: Cd=cadmium, Hg=mercury, Pb=lead. You can return spent batteries and accumulators that can no longer be
charged to the designated collection points in your community, outlets or wherever batteries or accumulators are sold. Following these
instructions will allow you to fulll the legal requirements and contribute to the protection of our environment!
Push Notication
a. Enable/disable the push notication:
For Andriod
1. Go to more section to tap Push Notication.
2. Click/unclick to enable/disable the push notication.
3. Enter user name.
4. Tap ”OK” when you done.
For iOS
1. Tap icon.
2. Enable/disable the push notication.
3. Enter user name.
4. Tap ”Save” when you done.
12
3
4
1
2
3
4
For Andriod
1. Tap push notication setting
2. Setup interval time of the push
For iOS
1. Tap push setting
2. Setup interval time of the push
c. Time period:
This function allows you to setup "Do Not Disturb" time. You can setup when Push is to start
and end. Only during the time, you will receive the push.
d. List:
From list section, you can see which smart devices currently receive push from the system.
WDVR app allows max 8 devices to receive the push. You may remove all devices from the
push list by resetting the language.
FACTORY DEFAULT SETTING
1. Go to the system setting.
2. Reset the language.
3. The system will restore to factory default.
Note: Please change default security code and apply push service from smart devices after you reset the
language and system parameter to default.
b. interval
Go to the push notication setting to setup interval time of the push. There are four options
you can select how long you’ll receive the push.
Note: Your smart phone will receive the push immediately after rst triggered. After that the camera will
send the push according to interval time you setup. This function allows you to receive less push of one
serial event happened continuously in time.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation
