Gas-Fired Convection Oven
Operating Instructions

Before you begin, please read these instructions carefully to use
this product correctly, to make the product perform ideally, and to
avoid hazards.

- 1 -
Dear customers and users：
Thank you for purchasing our products. In order to be able to better use
this product, please read these instructions carefully before any operation,
and follow the guide, to avoid any unnecessary trouble during using.
Please keep this instruction manual in a safe place for convenient
reference and operation.
This instruction manual is subject to any change without further notice,
and the manufacturer reserves the right of final interpretation.
The appliance is designed for commercial purposes, not for
household use.
A statement instructing the purchaser to post in a prominent
location instructions to be followed in the event the user smells gas.
This information shall be obtained by consulting the local gas supplier.

- 2 -
Gas-Fired Convection Oven
The Installation, Operation and Maintenance Guide
Contents
1. Safety Protection……………………………………………………3
2. Brief Introduction……………………………………………………3
3. Manufacturer's Authority and Responsibility……………………3
4. Parameter Specifications……………………………………………4
5. Transport and Storage…………………………………………………6
6. Installation and Debugging…………………………………………6
7. Safety Notices and Precautions……………………………………12
8. Operating Instructions…………………………………………… 13
9. Cleaning and Maintenance …………………………………………18
10.Electrical Schematic……………………………………………22

- 3 -
1、Safety Protection
Please make sure that the operator is an authorized and licensed
technician before you allow him/her to install and operate the products.
Be sure to strictly follow this instruction guide during installation and
using. The manufacturer is not responsible for any dangers or accidents
caused by improper operation or maintenance.
Do not store flammable or explosive objects around the product.
Keep all flammable and explosive objects at a safe distance away from
the product for normal use.
Place the product in a reasonable position. Regarding related
matters of gas, customer should execute the requirements of local gas
supply sector;
If you smell a gas leak, turn off the gas valves immediately and call
the gas company;
The product should not be operated by those under 18 years of age,
or those with physical or mental disorders, or disabilities that lack the
necessary knowledge or experience unless with appropriate
instructions and sufficient safety.
2、Brief Instruction
Such product is the Gas-Fired Convection Oven manufactured by us. The
product is in novel design, reasonable structure, durable and easy to
operate and maintain. This product has a pulse autoignition function for
more convenient operation; a double-speed heat cycling method is
employed and the burner flow is controlled to make the temperature in the
oven uniform; accurate control of time and temperature. It is an ideal

- 4 -
cooking appliance in the industry of hotel, supermarket, western restaurant,
fast food restaurant and food.
3、Manufacture’s Authority and Responsibility
Banning of all or partial transformation to the products without the
manufacturer's explicit authorization.
Manufacturers refused to undertake responsibility to third parties
as
the following reasons:
Not follow this instruction guidance and warning in in using and
testing;
Not in accordance with the requirements of technical parameters
using
this product;
Incorrectly or irrationally using the product by untrained personnel;
Not obey the local law using this product;
Be repaired or changed by unauthorized technicians;
Use the spare parts or accessories provided by non-manufacturers;
Accidents caused by force majeure;
Not strictly comply with related guide of this instruction by any
reason.
4、Parameter Specifications
4.1、ATCO-513B（Single Oven）：

- 5 -
4.2、ATCO-513B（Double-Stacked Ovens）：

- 6 -

- 7 -
Information of Gas Supply and Electric:
The internal thread of product’s intake-tube is 3/4" NPT.
DO NOT EXCEED GAS PRESSURES GREATER THAN THE FOLLOWING:
（Table 1）
GAS PRESSURE
NATURAL GAS
PROPANE GAS
AT INLET
13.84 in.W.C./3.45kPa
13.84 in.W.C./3.45kPa
AT MANIFOLD
3.5 in.W.C./0.87kPa
10 in.W.C./2.49kPa
PER BURNER
23,000 BTU/HR
23,000 BTU/HR
PER OVEN
46,000 BTU/HR
46,000 BTU/HR
INJECTOR
43#(φ2.26mm)
54#(φ1.40mm)
VOLTS
115
AMPS
9.0
PH.
1
HZ.
60
5. Transport and Storage
In the process of transportation, handle carefully and keep upright to
prevent damage of the product packing. Wrapped equipment should not be
in open air for a long time, and shall be placed in a well-ventilated and
non-corrosive gases warehouse. When equipment needs temporary storage,
rainproof measures should be taken.
6. Installation and Debugging
Any erroneous installation, adjustment, refit, overhaul or
maintenance may cause property damage or personal injury. The work
shall be performed by authorized and licensed technicians, otherwise
the manufacturer has the right not to provide warranty service;
Only be installed in accordance with the local code. If no similar
standard, you should conform to the National Fuel Gas Code, ANSI
Z223.1/NFPA 54, the National Gas Installation Code, CSA-B149.1, or the

- 8 -
L.P. Gas Installation Code, CSA-B149.2 as applicable;
The installation of electrical wiring from the electricmeter, main control
box or service outlet to the electrical appliance. Qualified installation
personnel must be familiar with all precautions required and have complied
with all requirements of state and local authorities having jurisdiction. See:
National Electrical Code, ANSI/NFPA70.
The appliance individual shutoff valve must be disconnected from
the gas supply piping system during any pressure testing of that system
at test pressures in excess of 1/2psi (3.45kPa).
For an oven equipped with casters, the installation shall be made with a
connector that complies with the Standard for Connectors for Movable Gas
Appliances, ANSI Z21.69/CSA 6.16 and a quick-disconnect device that complies
with the Standard for Quick-Disconnect Devices for Use with Gas Fuel, ANSI
Z21.4/CSA6.9.When installing the oven with casters and quick-disconnect hose,
adequate means must be provided to limit the movement of the oven without
depending on the connector and the quick disconnect device or its associated
piping to limit the oven movement. Restraining means may be attached to the
vertical portion of the base frame in the rear of the oven.
Unpacking and Installation
Please dispose of all packaging materials and residues after unpacking;
Check the equipment. If it is damaged, please keep wrappers and
receipts which must be signed by the carrier representative (Driver), and
contact the carriers to pursue a claim within 15 days after receiving;
Be sure to install supporting legs before using, and do not tear up any
label or logo before normal using;
Please read these instructions carefully before installation and operation.

- 9 -
Please contact your local agent if you have any questions;
Such stove shall be installed on the horizontal, solid, anti-skidding and
incombustible floor, and at the water-proof working area with sufficient
light and far away from the children and customers;
The installation position is a well-ventilated place in accordance with the
local regulations;
The charbroiled must be installed under the matched cooking fume
exhauster according to the local regulations;
Important: Installation and ventilation laws, and codes are very
different, you should state and comply with all codes of the National
Fire Protection Association Inc when it comes to requirements for
installation of equipment;
Hoist the product using a forklift to some height, fix the supporting leg
to 3 corresponding holes of the baseplate using a φ8 flat gasket, φ8 spring
gasket and M8×25 screws and screw such screws with a spanner. If a castor
is installed, its screws shall be screwed into the corresponding hole of the
baseplate, as shown in Figure below.

-10 -
Mounting Stacking Bracket
1. Install 4 pcs 5" castors or short legs to the baseplate of the bottom oven, as described in
the previous section.
2. Put the oven on the upper layer to that on the lower layer and align the edges of all
ovens.
3. Dismantle two existing screws on the rear lower part of the oven on the upper layer
and dismantle one existing screw on the rear upper part of the oven on the lower layer.
4. Install the stacking bracket using the existing screws and those in the packaging bag.
5. Repeat the steps and install the second stacking bracket on the other side.
Mounting Flue Extension to Top Oven
1. Take out the flue out of the packaging box and insert its upper part from bottom to top
into the opening at the rear upper part of the oven on the upper layer.
2. Align the lower part of the flue with the opening of the baseplate at the rear lower part
of the oven on the upper layer.
3. Align the hole on the flue with that on the rear plate of the oven on the upper layer and
fix it on the rear plate with 6 screws.

-11-

-12 -
The area around the oven must be kept clear of combustible materials. A
minimum clearance must be maintained between the oven and any
combustible or non-combustible surface;
MINIMUM CLEARANCES
Combustible
Non-Combustible
RIGHT SIDE
1"
1"
LEFT SIDE
1"
1"
REAR
6
6
FLOOR
6"
6"
Do not put anything around the equipment, and on the counter top and
bottom, in order to avoid influencing combustion and air circulation;
This oven has been tested and certified for use on gas systems that do
not exceed 1/2 psi (3.45kPa) or pressure. If the piping system is tested at a
pressure higher than 1/2 psi (3.45kPa),this oven should be isolated from the
supply by disconnecting it. If the piping system is tested at a pressure lower
than or equal to 1/2 psi (3.45kPa),this oven should be isolated from the
supply by shutting off the manual shut off valve located on the front panel.
ELECTRICAL CONNECTIONS
Your oven is supplied for connection to a 115 volt, single phase
grounded circuit. The electric motor, oven lights, indicator lights and control
circuits are connected through a seven-foot electric supply cord found at
the rear of the oven.
Before making any connections to these units, check the rating plate to
assure that the voltage and phase of the oven is compatible with the electrical
supply. When installing, all ovens must be electrically grounded in accordance
with local codes, or in the absence of local codes, with the National Electrical

-13 -
Code, ANSI/NFPA70 (in Canada-CSA Std.C22.2).Wiring diagrams are located in
the control compartment area of the oven. Standard wiring schematics are also
provided with this manual.
WARNING：This appliance is equipped with a three-prong (grounding)
plug for your protection against shock hazard and should be plugged directly
into a properly grounder three-prong receptacle. DO NOT cut or otherwise
remove the grounding prong from this plug.
VENTILATION
Proper ventilation is very important for the proper function of your oven. A
good ventilation system will allow the oven to function properly as well as
remove unwanted vapors and products of combustion. Not venting the ovens
properly can result in unsatisfactory baking results as well as the possibility of
damaging your oven. To keep your warranty in force, a proper ventilation
system must be employed, either direct vented or under a canopy;
Warning! Use soap water or testing instrument to test whether
piping joint leaks or not before using, and forbid using an open flame to
test!
After installing completely, you should check gas supply pressure. Use
a pressure gauge which is equipped with liquid (such as U-type
pressure gauge, the minimum value is 0.1mbar) or a digital pressure
gauge to test. Steps are as following:
●After opening the door, loosen the four
screws that hold the lower panel, pull

-14 -
the panel out, and the pressure test
point is on the right.
●Remove needle type pressure joint screw
arbor (Fig.1), then slip rubber tube of
pressure gauge over needle type pressure
joint;
●Start the equipment in accordance with the
instructions, measuring gas supply pressure
(dynamic pressure) in the work state;
●Access to the equipment if measured data Figure 1
within the limits of Table 1, otherwise,
you will need to adjust gas pressure
regulating valve or contact gas supplier
to bargain;
●Unplug pressure gauge after you accomplish pressure testing, then
install needle type pressure joint screw arbor.
Important: must screw joint screw arbor, to prevent gas escape!
It’s very important to debug the new stove. Through the
comprehensive system test of equipment, we can ensure function and
safety performance of products. Discovering any potential problems
before use (such as equipment’s placement, ventilation, operation, etc),
can avoid costly losses.
7. Safety Notices and Precautions
Warning! For your safety, do not place petrol and other flammables
nearby. Please keep clean and free of flammables surroundings. (Read
ANSI Z83.14B, 1991 for reference)
Warning! Any erroneous installation, adjustment and refit may
cause property damage or personal injury and maintenance failure.
Read the instructions carefully before installation and using.
Warning! Operation instruction must be placed in a conspicuous
location. When customers smell gas in the process of using, should take
Needle type
pressure joint screw
arbor

-15 -
safety precautions immediately. Immediately turn off the main gas valve,
extinguish all heat and flames, and call 911. Safety information can be
obtained from your local gas suppliers.
When using this equipment, safety precautions should
always be followed, including the following:
External surface will still be scalding after being used. You must take
care when touching these positions;
Turn off the equipment as repairing, maintaining and cleaning;
If the equipment has any problems of equipment damage, gas piping
leaks, igniter or valves damage, or lose product accessories, do not operate,
and call for the service immediately;
The use of attachments not recommended or sold by the manufacturer
may cause fire, personal injury or even death;
Do not use out of doors;
Such appliance is used to bake the food and shall not be used for other
purposes;
The equipment does not contain any user-serviceable parts. Dealers or
technicians will repair it. Do not take apart any spare parts without
authorization;
Never change any other parts without authorization to this equipment,
otherwise, may cause hazards, and the manufacturer has the right not to
provide warranty service;
Steel cutting producers used to manufacture with sharp edges. The
manufacturer has dealt with these sharp edges during production, however,
we insist the operator take care when in contact with this piece of
equipment;
Always keep hands, hair and clothing away from heating source.
Wait the unit cools down before cleaning. Because the unit is too hot to
handle after using.
8. Operating Instructions
Do not use fan or air-conditioning blowing at the flame, in order to

-16 -
avoid extinguishing flame and cause safety accidents;
Install the matched cooking fume exhauster according to the local
regulations of char broiler;
Make sure to keep the natural air circulation in the kitchen.
The information in this section is intended for the use of qualified operating
personnel. Qualified Operating Personnel are those individuals who have
carefully read the information contained in this manual, are familiar with the
function of the oven and/or have had experience with operating the equipment
described. We recommend following these instructions to insure optimum
performance, long life and trouble-free service from your oven.
WARNING: The gas-fired Convection Ovens rely on electricity for
powering the ignition system and the fan. Do not attempt to operate during a
power failure.

-17 -
CONTROLLER PANEL
1.Light Switch: Turns oven lights on/off.
2.Fan Speed Switch:(Optional)- Sets fan
speed
to high or low.
3.Time Digital display: Displays time
remaining in the chosen cycle.
4.Time Adjustment buttons: Sets/Adjusts
count down timer for cook cycle.
5.Temperature Adjustment Buttons: Sets /
Adjusts cooking temperature.
6.Temperature Digital Display: Displays the
temperature inside the oven.
7.Pulse Fan Button: Enable/Disables the
Pulse Fan function.
8.Start/Stop Button: tarts/Stops the cooking

-18 -
Programming and Operating Instructions
Models with the controller enable the oven to cook food at a specified
temperature for a specified time period, than enter an optional hold mode,. The
hold mode holds food at a specified temperature for a specified period of time.
When the power switch is in the ON position the oven will be in one of two
modes:
1. Cook Mode : In this mode the oven operates at a specified temperature
and the fan runs continuously, unless the cycle option is selected. In cycle
mode the fan runs for 30 seconds and is off for 30 seconds. This cycle
continues during the specified cook time.
2. Hold Mode : In this mode the oven operates at a specified hold temperature,
however the fan only runs when the burners are on . If the fan mode switch is in
the COOL position the fan will run continuously in the Hold mode.
To Program Cook Mode do the following:
1. Turn the power switch ON. The power switch is located in the middle of the
Control Panel.
