ATV 200 User manual

BRIEF INTRODUCTION TO FOUR-WHEELED
CROSS-COUNTRY VEHICLE MODEL 200ATV
Four-wheeled cross -country vehicle, model 200ATV is a full road condition vehicle
whichcanbedrivenonevery kindsofroadconditionssuchassandbeach,grassland,forest,
village,construction site country road , This maintenance manual of four-wheeled vehicle
model200ATV(Hereafter calledcross-country vehicle for short) compiledbyChongqing
Industries Co., Ltd is specially provided for saler and technical staff of our Group. This
manualmainlyintroducethemaintenance,removingandrepairingmethodofcross-country
vehicle and provide some relative technology and performance data. Because this manual
can’t collect the whole content of cross-country vehicle, it can only help maintainer of our
groupandit’ssalerhaveabasicunderstandingonworkingprinciple,maintenanceprocedure
andrepairingtechnologyofcross-countryvehicle. If you don’t have this knowledge, when
repairingcross-countryvehicle,theconditionofimproperassemblinganddangeroccursafter
assemblingareeasily happened. Properoperationand maintenance aretheadvance of your
safelydriving cross-countryvehicle, italsocan reducethe troublesofcross-countryvehicle
andkeepthebestperformanceofit.Thespecification,performanceandexplanationstatedin
the manual are determined according to newly design of the vehicle, which are subject to
changeswithoutnotice.
Inthismanual,forspeciallyimportant requirement,thewordsof“Warning”“Caution”
arelabelled toprompt relativemaintainertoabideit.
Inthemanual
Caution
Showthatifthecontentof“Warning”isn’t obeyed,thedriver,maintainer,
checkerwillbeheavilyinjuried,evendead.
Showthat you mustbecareful topreventthe vehicle frombeingdamaged.
Warning
Maintenancemanualoffour-wheeledcross-countryvehiclemodel200ATV
Firstedition 2004
This manual is published by publishing factory. maintain the copyright of
publishing. Without permitted, publishing is prohibited.
