AUDAC MBK260 User manual
INSTALLATION MANUAL
35 MM STAND ADAPTER FOR KYRA SERIES COLUMN SPEAKERS
A
D
B
C
E
EXPLODE DRAWING
Install the speaker part (‘A’ - which is standard included with the KYRA6/12 series loudspeakers) at the provided
location on the rear side of the loudspeaker.
It can be assembled on dierent heights depending on the mounting possibilities and required installation
height. Fixation is done through inserting both supplied mounting screws (‘B’) into the pre-drilled and threaded
holes at the back of the speaker. Depending on the inclination direction (upward or downwards) this part can
be assembled in two directions.
The second part (‘C’) has to be tted over a 35 mm pole tting (such as a speaker stand). Assembling is done
through insertion of two bolts and nuts (‘D’ - included with the speaker). Tighten both bolts once the required
incline angle is set and x to the pole tting by tightening the thumb screw (‘E’).
NOTE: Part ‘A’ is standard included with KYRA6 and KYRA12 series column speakers. For use with KYRA24 series loudspeakers on a 35 mm
stand, this part has to be ordered individually with part number # AU02001012X
The WEEE marking indicates that this product
should not be disposed with regular household
waste at the end of its product life. This regulation
is created to protect both the environment and
human health.
This product is developed and manufactured with
high quality materials and components which can
be recycled and/or reused. Please dispose of this
product at your local collection point or recycling
center for electrical and electronic waste. Do this
to make sure that the product is recycled in an
environmental friendly way, and help to protect
the environment in which we all live.
INSTALLATION MANUAL
35 MM STAND ADAPTER FOR KYRA SERIES COLUMN SPEAKERS
•
IF THERE IS ANY DAMAGE TO THE CARTON BOX
OR THE UNIT ITSELF, INFORM YOUR VENDOR
IMMEDIATELY.
•
ALWAYS FOLLOW THE LOCAL REGULATIONS AND
REQUIREMENTS REGARDING INSTALLATION,
SUSPENSION AND CONNECTION OF THIS
LOUDSPEAKER. EVEN WHEN OTHERWISE SPECIFIED
IN THIS DOCUMENT.
• THE INSTALLATION OF THIS LOUDSPEAKER SHALL
BE DONE BY QUALIFIED PERSONNEL ONLY.
•
ALWAYS KEEP THESE INSTRUCTIONS FOR FUTURE
REFERENCE. NEVER THROW THEM AWAY
• ALWAYS HANDLE THIS UNIT WITH CARE
• CLEAN ONLY WITH DRY CLOTH
•
HEED ALL WARNINGS AND FOLLOW ALL
INSTRUCTIONS
•
NEVER EXPOSE THIS EQUIPMENT TO RAIN,
MOISTURE, ANY DRIPPING OR SPLASHING LIQUID.
•
DO NOT INSTALL THIS UNIT NEAR ANY HEAT
SOURCES SUCH AS RADIATORS OR OTHER
APPAR ATUS THAT PRODUCE HEAT
•
DO NOT PLACE THIS UNIT IN ENVIRONMENTS
WITH A HIGH LEVEL OF DUST, HEAT, MOISTURE OR
VIBRATION
• THIS UNIT IS DEVELOPED FOR INDOOR USE ONLY.
DO NOT USE IT OUTDOORS
•
ONLY USE ATTACHMENTS & ACCESSORIES SPECIFIED
BY THE MANUFACTURER.
•
ONLY INSTALL THE SPEAKER IN LOCATIONS THAT
CAN STRUCTURALLY SUPPORT THE WEIGHT OF THE
SPEAKER. IGNORING THIS CAN BRING THE SPEAKER
DOWN.
•
DO NOT USE ANY OTHER METHOD THAN SPECIFIED
TO MOUNT THE SPEAKER. IF EXTREME FORCE IS
APPLIED TO THE SPEAKER, IT COULD FALL DOWN
•
ATTACH A SAFETY WIRE TO THE SPEAKER WHEN
IT IS MOUNTED HIGH UP. ONLY USE INDUSTRY-
ACCEPTED RIGGING TOOLS AND METHODS
• CAREFULLY CHECK THE UNIT’S CONDITION AFTER
UNPACKING.
PRECAUTIONS
This product contains no user serviceable parts.
Refer all servicing to qualied service personnel. Do
not perform any servicing (unless you are qualied
to do so.)
CAUTION - SERVICING
This product conforms to all the essential
requirements and further relevant specications
described in following directives: 2011/65/EU
(RoHS2) and 1907/2006 (REACH)
EC DECLARATION OF CONFORMITY
WASTE OF ELECTRICAL AND ELECTRONIC EQUIPMENT
(WEEE)
