BVR-25™
Wall Mountable Component Video/Digital
Audio Receiver
T hank you for choosing an AudioControl Active- Balanced product for your video and audio distribu-
tion needs. You are installing one of the most innovative
custom installation products available. This unit will allow
you to receive video and audio signals over standard
Category 5 wiring by using the highest quality active
circuitry. Please note that these products are primarily
designed for installation by professional audio video com-
panies. Therefore if any part of this manual is not clear …
STOP WHAT YOU ARE DOING! Contact your nearest
audio video installation company or call us and we will
refer you to one. Plasma monitors, projectors and some
DVD players are too expensive to damage so don’t attempt
anything you are unfamiliar with.
Now sit back, grab yourself a cold beverage and take a
moment to read through this manual before you charge off
into the installation. Once you cut a hole in the wall, you
are committed.
ACTIVE-BALANCED SERIES
Installation and
Operation Manual
®For Those Who Consider Perfection Possible®

ACTIVE-BALANCED SERIES
®
ACTIVE-BALANCED SERIES
®
23
2
Balanced Video Series
Here are some of the cool features of your new BVR-25
balanced video and audio receiver:
• Allows Simple Distribution of Highest-Quality Com-
ponent Video and Digital Audio Signals up to 1000 feet
(305 meters)
• Designed to Work with AudioControl’s Balanced Video
Transmitters (i.e. BVD-20, BVH-20)
• Receives Signals via Standard Cat-5 Type Cabling
• High Video Bandwidth - Compatible with 480, 720, and
1080 Formats
• Accepts 12 Volt Power via Front Panel Jack or Through
Connection on Rear Panel
• Can also Receive Digital Audio or Composite Video
Signal
• Signal Sensing 12 Volt Output Trigger
• Standard EIA-568 RJ-45 Cat-5 Connection Jack
• Adjustable Image Compensation and Gain Circuits with
Calibration Indicator
• Five Year Warranty and
built in the USA
BVR-25 Specifications
All specifications are measured with supplied 110 VAC
to 12 VDC wall transformer. As technology advances,
AudioControl reserves the right to change our specifica-
tions, like our weather.
Video Channels Component
Video Bandwidth 150 MHz @ -3 dB
Component Video Connections RCA
Video Slew Rate 1500 V/uS
Balanced Video Input Impedance 100 ohms
Video Output Impedance 75 ohms
Audio Channels 1 (digital)
Balanced Digital Audio Input Impedance 100 ohms
Digital Audio Output Impedance 75 ohms
Digital Audio Connector RCA
Cable Connection RJ-45 EIA-568B Standard
Optimum Cat-5 Cable Run
Component video 1000’
HD (1080) 300’
Power supply 12 VDC
Power draw: 130 mA
Output trigger voltage: 12 volts at 100mA
Weight: 1 lb.
Physical dimensions: 4.5”H x 2.75” W x 1.75” D
Installation dimensions: Standard Single Gang Wall Box
Warranty 5 Years
©2006 All Rights Reserved

ACTIVE-BALANCED SERIES
®
ACTIVE-BALANCED SERIES
®
3
22
EIA-568 RJ-45 Pin Connection Diagram
Pair 1 White-Blue (W-BL) Video 4 – : Audio/Video
Blue (BL) Video 4 + : Audio/Video
Pair 2 White-Orange (W-O) Video 1 + : Component Y
Orange (O) Video 1 – : Component Y
Pair 3 White-Green (W-G) Video 2 + : Component PB
Green (G) Video 2 – : Component PB
Pair 4 White-Brown (W-BR) Video 3 + : Component PR
Brown (BR) Video 3 – : Component PR
The First Step In Your Installation Procedure
FILL OUT AND SEND IN THE WARRANTY CARD!
Also, save the invoice or sales slip as proof of purchase.
These actions will protect this investment and help prove
that such a handy piece of audio equipment was really
in the system. Insurance companies can have such little
imagination when you are trying to make a claim.
Before You Begin
For the best product performance and the lowest use of
painkillers, nothing is better than a well-planned profes-
sional system installation. Before you start pulling wires
and punching holes in the walls, sketch out a full layout of
the complete system. This will help plan the wire routing
and minimize the “gotchas” later on.

ACTIVE-BALANCED SERIES
®
ACTIVE-BALANCED SERIES
®
21
4
① Video Calibration
Indicator Light
② Video Signal Gain
Control
③ Image Compensation
Control
④ Power Light
A Quick Tour of the BVR-25
①
②
③
④
⑤
⑥
⑦
⑧
⑤ 12 volt trigger output
⑥ Component Video
Outputs
⑦ Digital Audio/Composite
Video Output
⑧ 12 VDC power input
Block Diagrams BVR-25

ACTIVE-BALANCED SERIES
®
ACTIVE-BALANCED SERIES
®
5
20
Repair Information
In the unlikely instance that you ever need to have your
AudioControl component repaired. Please contact our fac-
tory for return instructions. Repairs are handled quickly
at our factory. You are responsible for paying the freight
charges to our factory. If your unit is under warranty, we’ll
ship it back to you the same method that you sent it into
us. Please make certain that you include a note stating the
problem with the unit (you’d be surprised how many people
forget that) along with your name, return shipping address
and a daytime telephone number.
Our Repair Address is:
AudioControl
Attn: Service Department
22410 70th Avenue West
Mountlake Terrace, WA 98043 USA
Phone [phone]
⑨
⑩
⑨ 12 VDC Barrier Block Power Input
⑩ RJ-45 inputs/outputs
Termination Resistor Network
RJ-45 Remote Power (4th Pair) Jumpers
On other side of
assembly
Side view of BVR-25
+
–
PWR
AV
A/V

ACTIVE-BALANCED SERIES
®
ACTIVE-BALANCED SERIES
®
19
6
Installation Information
Mounting the BVR-25
The small size and low power draw of these units allow
them to be mounted in almost any dry, indoor location,
specifically a single gang J-box (not provided). Pick mount-
ing locations close to the audio or video components that
will be connected to the BVR-25. You will want to keep the
unbalanced audio and video signal cables as short as pos-
sible since they are much more susceptible to noise pickup
than the balanced Cat-5 cables. Just remember you need to
at least be able to reach the units with a small screwdriver
to make any final adjustments
Video Wiring
The BVR-25 has 4 high-bandwidth outputs that are ca-
pable of extending component video signals (3 connectors,
Y, PB, PR) plus a composite video signal on the remaining
RCA connector. As an option, you can use the fourth RCA
connector on your BVR-25 to transmit a digital audio sig-
nal. The following system drawings reflect just a few of the
potential systems:
owner, but you do need a copy of the original sales slip.
4. You cannot let anybody who isn’t: (A) the Audio-
Control factory or (B) somebody authorized in writing by
AudioControl to service your BVR-25. If anyone other than
(A) or (B) messes with your BVR-25, that voids your war-
ranty.
5. The warranty is also void if the serial number is altered
or removed, or if the BVR-25 has been used improperly.
Now that sounds like a big loophole, but here is all we
mean by it:
Unwarranted abuse is: (A) physical damage (don’t use
the BVR-25 to level out a bookcase); (B) improper connec-
tions (120 volts into the power jack can fry the poor thing);
(C) sadistic things. This is the best product we know how
to build, but if you mount it to the filter pump of a hot tub,
something will probably go wrong.
Assuming you conform to 1 through 5, and it really isn’t
all that hard to do, we get the option of fixing your old unit
or replacing it with a new one.
Legalese Section
This is the only warranty given by AudioControl. This
warranty gives you specific legal rights that vary from state
to state. Promises of how well your BVR-25 will perform
are not implied by this warranty. Other than what we have
covered in this warranty, we have no obligation, express or
implied. Also, we will not be obligated for direct or indirect
consequential damage to your system caused by hooking up
the AudioControl BVR-25.
Failure to send in a properly completed warranty card
negates any service claims.

ACTIVE-BALANCED SERIES
®
ACTIVE-BALANCED SERIES
®
7
18
And now, a word from the legal department...
CONDITIONAL FIVE YEAR WARRANTY
Custom electronics installations are an invisible element of
many modern homes. You don’t appreciate what they do for
you unless something goes wrong. AudioControl recognizes
this fact and engineers the most bulletproof components we
know how. We stand behind that quality, with a full FIVE
YEAR parts and labor factory warranty when our components
are installed by an authorized AudioControl dealer in the Unit-
ed Sates. Otherwise your warranty is one year. You will be
happy to know that our warranty returns are rigorously tracked
and very few of the units we build ever need to be repaired.
“Conditional” doesn’t mean anything ominous. The Federal
Trade Commission tells all manufacturers to use the term to
indicate that certain conditions have to be met before they’ll
honor the warranty. If you meet all of these conditions, we will
warrant all materials and workmanship on the BVR-25 for
FIVE YEARS from the date you bought it, and we will fix or
replace it, at our option, during that time.
Here are the conditional conditions:
1. A completed warranty card must be returned to us within
15 days after signing off on the BVR-25 installation.
2. A sales receipt is required for proof of purchase showing
when and from whom the unit was bought. We’re not the only
ones who require this, so it’s a good habit to get into with any
major purchase.
3. The BVR-25 must have originally been purchased from
or installed by an authorized AudioControl professional. This
warranty is transferable. You do not have to be the original
System 1: Basic system using BVD-20 sending unit and BVR-25 receiver
System 2: Theater processor sending component video to video projector/plasma via
BVD-20 and a BVR-25

ACTIVE-BALANCED SERIES
®
ACTIVE-BALANCED SERIES
®
17
8
System 3: Satellite receiver feeding a BVH-20 and distributed to multiple BVR-
25’s
2.Check the Cat-5 wire configurations. Use an RJ-45
cable tester.
“Picture is fuzzy or edgy.”
1.Adjust the Cable Compensation control on the BVR-
25. This compensates for the increased capacitance on
longer Cat-5 cable runs and sharpens the video image.
2.Confirm the cable length. It is important to note that
the BVR-25 was designed for cabling no longer than
1000’ for standard component video or 300’ for a High
Definition signal. Cat-6 wiring will give the longest,
best picture.
“There is hum in the audio signal.”
1.Verify that the Cat-5 cable is properly terminated on
both ends.
2.Make certain that the system is wired with CAT-5
twisted-pair cabling.
3.Make certain there are not any cuts, pinches, or sharp
twists in the wiring, allowing a conductor to short to
ground (i.e. shield, conduit, cold water pipe, plenum).
“No +12 volt output”
1. Measure output with voltmeter.
2.Confirm amperage required for automation system.
Install relay if necessary.
3.The video signal feeding the BVR-25 is too low or un-
calibrated. Re-adjust gain and calibration controls.

ACTIVE-BALANCED SERIES
®
ACTIVE-BALANCED SERIES
®
9
16
Troubleshooting
“No Picture or Sound.”
1.Make certain the Power light is on the BVR-25 and the
power is on for the sending unit (i.e. BVD-20 or
BVH-20).
2.Verify that the RJ-45 termination on both ends of the
Cat-5 is correct. We all know this is easy to get wrong.
Use an RJ-45 cable tester to verify.
3.Make certain the Cat-5 cable run does NOT go through
an Ethernet Router or hub. It is alright to run the signal
through a passive patch bay.
4. Make certain display or monitor is compatible with
format of choice, i.e. 480P; 1080i; etc.
“No Power Light.”
1. Confirm that you are using the proper 12 VDC for the
BVR-25 and that the outlet has power.
“Horizontal bars across the screen”
1.Check the power grounding of the display device, the
video processor, satellite dish, cable box, and all com-
ponents in the video signal path. They should all be
grounded back at the electrical panel, not locally.
2.Make sure that the CAT-5 wiring going into your BVR-
25 is not running parallel with any high voltage AC
systems.
“Video picture scrambled or colors incorrect”
1.Confirm that the “Y”, “PB”, and “PR” connections are
correct.
Power Wiring
The BVR-25 operates with a 110 VAC to 12 volt DC wall
plug transformer (provided) that is terminated with a 5mm
jack that will plug into the front panel. We have conve-
niently labeled this jack “+12VDC Input”. Please note that
the 12 volt supply transformer provided with the BVR-25
is different than the 24 volt supply that is used with some
other AudioControl balanced line products. Therefore, be
careful to not use the wrong power supply. Please note that the
striped wire is positive (+) and the solid wire is negative (-).
Optional Rear Power Connection
As an option you can power the BVR-25 via connection
to a barrier block on the rear panel instead of the 5mm jack
on the front panel which allows for a cleaner trim-out of
System 4: Video signal being fed into BVD-20 and routed to multiple BVR-25’s
via daisy chain wiring

ACTIVE-BALANCED SERIES
®
ACTIVE-BALANCED SERIES
®
15
10
your installation. When powering the BVR-25 from the
rear, it utilizes a 2-pin barrier block, which will require you
to cut off the 5mm pin connector from the provided power
supply and terminate the wires directly onto the terminals.
Please note that the striped wire is positive (+) and the solid
wire is negative (-).
Remote Powering the BVR-25 via CAT-5
The BVR-25 can also receive power over the 4th pair
of wires in a single CAT-5 cable (Blue and Blue/White)
provided you are NOT already sending an audio or video
signal over these wires. To use this option you will need to
move both Remote Power Jumpers from the “AV” position
to the “PWR” position. In addition you will need to pro-
vide 12 VDC power over the 4th pair of CAT-5 wires that
runs to the BVR-25, which usually requires stripping out
the wires from the main loom. If you are providing power
from over 100 feet it is recommended that you utilize a
larger power supply (15 VDC/500ma) to offset any power
loss from the long CAT-5. You can purchase these power
supplies from most electrical supply companies. Please
note that a switching power supply with a 3-wire AC plug
will not work correctly.
Grounding
The BVR-25, like all AudioControl balanced line prod-
ucts, is designed to offer maximum isolation from radiated
signals that can creep into the video signal path and make
your pictures look funny (we are not talking about “Ha
Ha”). By design the BVR-25 has high input impedance to
levels are correct. While this procedure will not replace a
high level ISF type video calibration, it is a good starting
point.
Image Compensation: The Image Compensation control
on the BVR-25 equalizes the video signal to counteract the
effect of wire capacitance. In most cases the COMPENSA-
TION control should be set the same as the GAIN control.
If the GAIN control is set to the “5 o’clock” position, the
COMPENSATION control should be set the same. If the
image still appears to be too soft or too edgy, further adjust-
ing can then be done.

ACTIVE-BALANCED SERIES
®
ACTIVE-BALANCED SERIES
®
11
14
Adjusting the Controls
Properly setting the controls
on your BVR-25 will always
give you the maximum per-
formance. Although the unit
does come “pre-set” from the
factory with many of the inter-
nal enhancements at optimum
levels, we have no way of
knowing the exact length of
cable that you will be using.
Therefore, we have provided
a few simple controls to assist
you in the optimization of the
system:
Gain: Simply, this control
on the BVR-25 adjusts the
output level or gain on all
four of the RCA connections. To help with this adjustment
process we have also provided a Calibration Indicator LED
that triggers when there is a peak “white” signal level of
1 volt. Typically GAIN calibration can be made by turn-
ing on the processor’s OSD function which will most often
display either white on a black background or vice versa.
An ideal signal for calibration is a fixed image that is 50%
white and 50% black such as a “needle” or “checkerboard”
pattern on that comes with many video test generators. Ad-
justing the gain control will raise or lower the white levels.
The Calibration LED illuminates when the white signal
ground which minimizes the ground loops that can appear
in a coax wired system. However it is recommended that
you always make sure the structure you are in is wired to
the National Electrical Code. The NEC standards require
all ground wires to run back to the main panel prior to ter-
mination. We now return you to your regularly scheduled
manual text…
Signal Wiring
The BVR-25 operates using standard unshielded twisted-
pair (UTP) Category 5 (or better) wiring. Good wiring
practices will minimize the chance of noise pickup.
Make certain that you do not run any 110-240 volt power
wiring near or parallel to the CAT-5 signal cables as they
could radiate noise into the signal wires. You may pick up
AC hum. Tests have shown however that you will not pick
up songs from the group AC/DC. The
BVR-25 uses 12 VDC power, which
will not radiate into the signal wires.
If you need to cross over a power
wire, try to do it at right angles. Keep
the signal wiring as far as possible
from any noise sources such as light-
ing power supplies fluorescent lights,
dimmers, actuators, motors, and small
children.
RJ-45 connector with wires

ACTIVE-BALANCED SERIES
®
ACTIVE-BALANCED SERIES
®
13
12
Cat-5 Wiring
The RJ-45 connections on the BVR-25 conform to the
EIA-568B standard. This is the same Cat-5 cable-wiring
standard that a typical computer network utilizes. You can
use any existing 10/100 Base-T network cabling and patch
bays in an installation as long as it does not run through a
router or hub. The Cat-5 wiring must run directly from the
BVD-20 / BVH-20 to the BVR-25. Do not split or “Y-off”
the video signal coming out of your BVD-20 into multiple
BVR-25s as the video signal will be compromised. Use
the BVH-20 to drive multiple BVR-25s or you can “daisy
chain” from one BVR-25 to another if necessary. See page
13 for more information.
Daisy Chaining Multiple BVR-25’s
The BVR-25 has the ability to receive video and audio
signals over CAT-5 and then route them on to five maxi-
mum BVR-25’s. This allows for wiring in a daisy chain
format rather than the star method. If you are using your
BVR-25 in this manner you need to remove the “termina-
tion resistor network” from the socket on the rear of the
BVR-25 that is routing the signal to another BVR-25. The
last BVR-25 in the signal path MUST have the “R37” resis-
tor network inserted for the system to function properly.
12 Volt Output Trigger
The BVR-25 is equipped with a unique signal sensing
circuit that allows it to output a constant 12 volts (100ma)
which can be used to trigger remote mounted projectors,
activate a lift, lower a screen or trigger other automation
products. The presence of any Component (Y) or Com-
posite video sync signal at the RJ-45 inputs to the BVR-25
produces a sustained +12VDC on the tip of the Video Trig-
ger Jack.
