Audio enhancement BEAM User manual

1
BEAM Front
BEAM
Quick Start Guide
Green Power LED
Microphone 1 LED
BEAM LED Status Indicators visible through the front grille
Inputs and Controls
Optional Wall Mount Attachment Points
Microphone 2 LED
XD Microphone LINK LED
Note: Green Power LED must be ON indicating
the BEAM is plugged into AC outlet
BEAM Rear
24 VDC
Power
External
Speaker
Page
Mute
Line Output w/
Volume Control
Equalizer
Low-Mid-High
WPA-03
WPA-03
Optional Accessory
Port
Line
Inputs
Side View
Back View
XD Link
Line Input
Volume Controls
RS-232 Connection
to XD Receiver

Install BEAM into Power Base
Line Input Connections for
Computer, Phone, Etc.
Assisted Listening (ALD)
Line Input Volume
Controls – Side Panel
• The BEAM Can be used vertically or horizontally in the power base
• Insert the BEAM
• Plug the power connection from base into back of the BEAM
• Connect the power base to an electrical outlet with provided power cable
www.AudioEnhancement.com • 800.383.9362
The BEAM has an audio output
connection and level control
designed to work with a student’s
personal assistive listening device
or to send audio feed to a camera
and other devices
2
Pairing Microphones to the BEAM
Check to see if your microphone is paired by turning on your Teacher/Lanyard
and Handheld Microphones (Teacher/Lanyard Mic: press PWR for 1 second;
Handheld Mic: flip TALK switch up). If the LED under the BATT indicator turns
green, the mic is paired. If the LED blinks another color (orange), then turn o
your microphones and use the following instructions to pair them to the BEAM.
Teacher/Lanyard Microphone Pairing
Turn mic o: press and hold PWR/MUTE until the green BATT light turns o.
Press and release the XD LINK button on the side of the BEAM.
Press and hold the PWR/MUTE and REC buttons simultaneously on the Teacher/
Lanyard Microphone until a beep is heard from the BEAM.
Handheld Microphone Pairing
Turn mic o: flip the TALK switch down. The green BATT
light will turn o.
Press and release the XD LINK button on the side of
the BEAM.
Press and hold the PWR/LINK button and TALK
pushbuttons simultaneously on the Handheld
Microphone until a beep is heard from the BEAM.
Teacher Mic Handheld Mic
DC-40884.01
