Audio Hungary Qualiton C200 User manual

Qualiton C200
User’s Manual

IMPORTANT SAFETY INSTRUCTIONS ................................5
MARKINGS ...............................................................................9
PREFACE .................................................................................. 10
BASIC INFORMATIONS ......................................................... 11
TECHNICAL ASSISTANCE AND SERVICE INFORMATION ..12
GENERAL SPECIFICATIONS................................................. 13
ELECTRICAL SPECIFICATIONS .......................................... 14
FRONT PANEL ........................................................................ 16
REAR PANEL............................................................................ 18
CONTENTS OF PACKAGE..................................................... 20
PLACEMENT ........................................................................... 21
INSTALLATION OF VACUUM TUBES .................................. 22
USING THIRD PARTY VACUUM TUBES ............................ 25
BLOCK DIAGRAM .................................................................. 26
CONNECTION DIAGRAM ...................................................... 27
CONNECTION DIAGRAM - STEREO MODE ....................... 28
CONNECTION DIAGRAM - MONOBLOCK MODE ............ 29
AC MAINS CONNECTION .................................................... 30
GOOD TO KNOW ....................................................................31
REMOTE CONTROL ..............................................................32
INSERTING / REPLACING BATTERY .................................33
REPLACEMENT OF FUSE .....................................................34
WASTE MANAGEMENT ........................................................35
CONTENTS

1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Improper installation may cause malfunction!
6. Do not use this apparatus near water.
7. Clean only with a dry cloth.
8. Do not block any ventilation openings since this
may lead to re. Install in accordance with the
manufacturer’s instructions.
9. Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including ampliers) that produce heat.
10. Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not t into
your outlet, consult an electrician for replacement of
the obsolete outlet.
11. Connect mains power supply cord only to a
mains socket outlet with a protective earthing
connection.
USER’S MANUAL 5
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ THEM BEFORE OPERATING THIS EQUIPMENT!

12. Be careful with appliance cables! Do not lead
them across sharp surfaces, do not clam them
together and do not leave them in a hanging
position.
Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
13. You must not operate the appliance with
damaged cables.
14. Before powering up your amplier, make sure
protective cover, ports, plugs and cables are checked
for intactness.
15. Only use attachments/accessories specied by
the manufacturer.
16. Use only with the cart, stand, tripod, bracket, or
table specied by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid
injury from tip‑over.
17. Unplug this apparatus during lightning storms or
when unused for long periods of time.
18. No user‑serviceable parts inside. Improper
repair may lead to loss of warranty! Refer servicing
to qualified service personnel.
QUALITON C2006
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ THEM BEFORE OPERATING THIS EQUIPMENT!

19. Servicing is required when the apparatus has
been damaged in any way, such as power supply
cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not
operate normally, or has been dropped.
20. You must not start up damaged or faulty
appliance. In case of any malfunction, unplug your
amplier immediately.
21. In case of a malfunction, the protective cover
must not be opened or removed.
22. Do not expose this equipment to dripping or
splashing and ensure that no objects lled with
liquids, such as vases, are placed on the equipment.
23. Do not touch the appliance or its mains cable
with wet hands.
24. In case of re, you must not use water to
extinguish the re, even if the amplier is switched
off.
25. The appliance may only be used by qualied
adults or children above 14 years of age if
supervised by a qualied adult.
26. Keep the appliance out of the reach of children.
27. Make sure your domestic animal does not lie or
sit on the top of the appliance.
28. If you do not use your amplier for a long time,
unplug the appliance carefully.
USER’S MANUAL 7
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ THEM BEFORE OPERATING THIS EQUIPMENT!

29. To completely disconnect this equipment from
the AC mains, disconnect the power supply cord
plug from the AC receptacle.
30. The mains plug of the power supply cord shall
remain readily operable.
31. Do not expose batteries to excessive heat such
as sunshine, re or the like.
32. WARNING! To reduce risk of fire or electrical
shock, do not expose this equipment to rain or
moisture.
33. CAUTION! To reduce the risk of electric shock,
do not remove cover.
QUALITON C2008
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ THEM BEFORE OPERATING THIS EQUIPMENT!

The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance
instructions in the literature accompanying the
appliance.
CAUTION: Hot Surface! Do Not Touch!
Protective cover of the product may become
hot when operating this product continuously.
The crossed-out wheeled bin is the European
Union symbol for indicating separate
collection for electrical and electronic equipment.
This product contains electrical and electronic
equipment which should be reused, recycled or
recovered and should not be disposed of with
unsorted regular waste. Please return the unit or
contact the authorised dealer from whom you
purchased this product for more information.
The product meets the relevant directives
and standards of the European Union.
Supplied with alternating current (AC).
115 V / 230 V Nominal supply voltage.
50 Hz / 60 Hz Nominal supply frequency.
USER’S MANUAL 9
MARKINGS

Before installing the Qualiton C200 preamplier,
please study this User’s Manual carefully!
Operating your preamplier in a manner it is
designed for, ensures you an utmost musical
experience and a reliable operation.
If you have any questions on our products or
services, please do not hesitate to contact us on our
website www.audiohungary.com
QUALITON C20010
PREFACE

For your convenience, please ll out
the following lines to facilitate any future
technical assistance and repair service:
Serial Number:
_______________________________
Date of purchase:
_______________________________
Dealer Name:
_______________________________
Vacuum tubes used:
_______________________________
_______________________________
_______________________________
USER’S MANUAL 11
BASIC INFORMATIONS

QUALITON C20012
TECHNICAL ASSISTANCE AND
SERVICE INFORMATION
If at any time you have any questions about your
Qualiton product, do not hesitate to contact your
local Qualiton dealer, who is at your disposal. If you
or your dealer need more help, you can receive
technical assistance at:
Audio-Hungary Ltd.
132 Derkovits Street
4400, Nyíregyháza, Hungary
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
If it becomes clear that your Qualiton product needs
service, you should still contact your local dealer
rst. You can also contact us directly for more
instructions at one of the contact details above.

Number of input ports
4 unbalanced line level inputs (LINE 1-4),
2 balanced line level inputs (BALANCED INPUTS 1-2),
1 PHONO level input (PHONO MM)
Number of output ports
2 unbalanced line level outputs (LINE; SUB),
1 balanced line level output (BALANCED OUTPUTS),
1 headphone output per channel
Tubes required 8 x ECC83/12AX7
Weight 10.4 kg
Dimensions 43 x 40 x 16 cm
USER’S MANUAL 13
GENERAL SPECIFICATIONS

QUALITON C20014
ELECTRICAL SPECIFICATIONS
Nominal output level - Line 4 V
Input sensitivity - Line 1 V, to nominal output level
Input sensitivity - Phono 5,7 mV, to nominal output level
Max. input signal - Line 10 V
Max. input signal - Phono 70 mV
Gain - Line +12 dB
Gain - Phono +57 dB
Total harmonic distortion - Line < 0.05%, (f = 1 kHz)
Total harmonic distortion - Phono < 0.1%, (f = 1 kHz)

Frequency response - Line 4 Hz - 300 kHz, (-1 dB)
Frequency response - Phono 20 Hz - 20 kHz, (-0.5 dB)
Input impedance - Line 10 kOhm
Input impedance - Phono 47 kOhm
Signal-to-noise ratio - Line > 100 dB
Signal-to-noise ratio - Phono > 70 dB
USER’S MANUAL 15
ELECTRICAL SPECIFICATIONS

QUALITON C20016
FRONT PANEL
12 3 4 5

1. STANDBY (RED) / ON (WHITE) switch
2. INPUT SELECTOR rotary switch allows selection
of preamplier channel used. From left to right:
PHONO, LINE 1, 2, 3 and 4, BALANCED INPUTS 1
and 2
3. INPUT LEDs indicating the selected input port.
From left to right: PHONO, LINE 1, 2, 3 and 4,
BALANCED INPUTS 1 and 2
4. VOLUME control allows adjustment of the stereo
listening level
5. HEADPHONE connection for dynamic
headphones
USER’S MANUAL 17
FRONT PANEL

QUALITON C20018
REAR PANEL
21 3 4 5 6 7 8 9
4

1. GND terminal accepts a ground wire from a
turntable
2. PHONO INPUT accepts signals from a moving
magnet phono cartridge
3. LINE 1, 2, 3 and 4 INPUTS accept high level
program source signals
4. BALANCED INPUTS 1 accept high level program
source signals.
5. BALANCED INPUTS 2 accept high level program
source signals.
6. BALANCED OUTPUTS - Connections for an
external power amplier
7. LINE OUTPUTS - Connections for an external
power amplier
8. SUBWOOFER OUTPUT - Connection for an active
subwoffer
9. IEC appliance AC INLET with main switch.
USER’S MANUAL 19
REAR PANEL

QUALITON C20020
CONTENTS OF PACKAGE
Once you have unpacked the entire contents of the
package, you can now check that you have received
all the accessories.
- 1 pc Qualiton C200
- 1 pc Remote Control
- 1 pc User’s Manual
- 8 pcs ECC83 or 12AX7 vacum tubes
- 1 pc Standard Mains Cable
- 1 pc Torx Wrench (TX10)

• Please read the following carefully to select a
correct location for your amplier.
• IMPORTANT! Due to the vacuum tube construction
of the amplifier, it may heat up during use. Thus,
choose a location for installation where the
appliance can be well ventilated.
• The ventilation holes of the amplier must not be
covered (by tablecloth, curtain, newspaper, book,
etc.). Impairing ventilation can lead to overheating
and irregular operation conditions.
• Do not stack multiple units on top of each other.
• Avoid relocating the appliance from a cold to a
warm environment. Sudden temperature changes
can lead to moisture condensation. Please wait until
moisture is evaporated before putting your amplier
into operation.
• The aforesaid applies to the very rst installation of
the amplier as well. Prior to the rst installation,
leave the amplier at its place of operation at least
for 2 hours. Once this time is over, the amplier can
be powered up, according to this guide.
• The appliance is designed for indoor use. Do not
operate it in wet, humid environment.
• Do not store any electrical device or object in a
perimeter of 200 millimetres around your amplier.
Do not use the appliance next to heating sources
and radiators. Keep it away from hot or dusty
environment and ame.
200mm 200mm
200mm
USER’S MANUAL 21
PLACEMENT

QUALITON C20022
INSTALLATION OF VACUUM TUBES
1. You have to remove the protective cover to
prepare for the insertion of the electron tubes. The
protective cover locks in place with relatively high
resistance, be careful not to scratch the device while
removing it. See the gure below.
2. Remove a tube from one of the boxes labeled
ECC83 and carefully place it in one of the positions
labeled ECC83 / 12AX7 on the amplier. Make sure
that the holes in the electron tube socket t the pins
of the electron tube correctly. See the gure below.
3. Repeat the previous step with the other ECC83
tubes.
4. Carefully put the protective cover back in place.
See the gure below.
