Audio Pro Image Series Image 12 Instruction manual

Tekniska data:
Typ:......................................Sluten låda
Bestyckning: (Skärmade)
Diskant:.............1” Super Tweeter
Bas:...................................4,5”
Delningsfrekvens:....................2.800Hz
Frekvensomfång:...............50-35.000Hz
Känslighet: (1W / 1M)....................87dB
Impedans:..............................4 ohm
Rek. förstärkareffekt:............10 - 100 W
Dimensioner:(BxHxDmm)....126x200x175
Technical data:
Enclosure:...........................Closed box
Drive units: (Shielded)
Tweeter:............1” Super Tweeter
Woofer:..............................4,5”
Crossover:..............................2.800Hz
Frequency range:..............50-35.000Hz
Sensitivity: (1W / 1M)....................87dB
Impedance:................................4 ohm
Amp. requirement:...............10 - 100 W
Dimensions:(WxHxD mm)...126x200x175
Placering:
See the enclosed Audio Pro instruction
manual for further information.
Se medföljande Audio Pro instruktions-
bok för ytterligare information.
Placement:
Audio Pro AB, Helsingborg, Sweden
Swedish/English
Image 12
Image 12 Technical data.pmd 2004-02-24, 15:591

Charactéristiques:
Type:.................Suspension acoustique
Haut-parleurs: (Avec blindage)
Tweeter:............1” Super Tweeter
Woofer:..............................4,5”
Fréquence de séparation:........2.800Hz
Réponse en fréquence:......50-35.000Hz
Sensibilité: (1W / 1M).....................87dB
Impédance:................................4 ohm
Puissance d’entrée:..............10 - 100 W
Dimensions:(LxHxP mm).....126x200x175
Ôå÷íéêÜ óôïé÷åßá:Ôå÷íéêÜ óôïé÷åßá:
Ôå÷íéêÜ óôïé÷åßá:Ôå÷íéêÜ óôïé÷åßá:
Ôå÷íéêÜ óôïé÷åßá:
Ôýðïò:..........................Êëåéóôü êïõôß
ÌåãÜöùíá: (ÈùñáêéóìÝíá)
Ôïõßôåñ:.........................Èüëïò 1"
Ãïýöåñ:..............................4,5"
Crossover:................................2.800Hz
Aðüêñéóç óõ÷íïôÞôùí:.......50-35.000Hz
Åõáéóèçóßá: (1W / 1M)...................87dB
Áíôßóôáóç..................................4 ïhm
Åíßó÷õóç:................................10-100W
ÄéáóôÜóåéò:(ÐxYxB)....126x200x175mm
Emplacement:
Ãéá ðåñéóóüôåñåò ëåðôïìÝñåéåò
áíáöåñèåßôå óôï åã÷åéñßäéï ïäçãéþí.
Se référer au mode d’emploi ci-joint.
ÔïðïèÝôçóç
Audio Pro AB, Helsingborg, Sweden
Français/Åëëçíéêá
Image 12
Image 12 Technical data.pmd 2004-02-24, 15:592

Technische gegevens:
Soort:........................................Gesloten kast
Speaker soort: (afgeschermd)
Tweeter:................1” Super Tweeter
Woofer:.......................................4,5”
Crossover:.......................................2.800Hz
Freq. Bereik:...........................50-35.000Hz
Gevoeligheid: (1W / 1M).....................87dB
Impedancy:..........................................4 ohm
Aanbevolen versterker vermogen: 10 - 100 W
Maten:(BxHxDmm):.............126x200x175
Plaatsing:
Weitere Informationen erhalten sie
aus der beiliegenden Audio Pro
Bedienungsanleitung.
Lees hiervoor de Audio Pro ge-
bruiksaanwijzing.
Aufstellung:
Audio Pro AB, Helsingborg, Sweden
Nederlands/Deutsch
Technische Daten:
Typ:........Geschlossene Lautsprecherbox
Bestückung: (Magnetisch abgeschirmt)
Hochtöner:...........1”Super Tweeter
Baß:.............................................4,5”
Übergangsfrequenz:.....................2.800Hz
Frequenzgang:......................50-35.000Hz
Schalldruck: (1W / 1M).......................87dB
Impedance:.........................................4 ohm
Empf. Verstärkerleistung:........10 - 100 W
Abmessungen:(WxHxDmm)..126x200x175
Image 12
Image 12 Technical data.pmd 2004-02-24, 15:593

Tekniset tiedot:
Kotelotyyppi:.................................Suljettu
Elementit: (Magneettisuojattu)
Diskantti:...........1"Super Diskantti
Basso:......................................4,5"
Jakotaajuus:.................................2.800Hz
Toistoalue:.............................50-35.000Hz
Herkkyys: (1W / 1M)..........................87dB
Impedanssi:.....................................4 ohm
Vahvistin suositus:.................10 - 100 W
Mitat:(L x K x S mm)..........126x200x175
Sijoitus:
Katso mukana oleva ohje.
Collocazione:
Audio Pro AB, Helsingborg, Sweden
Suomi/Italiano
Dati tecnici:
Tipo:........................................Cassa chiusa
Elementi: (schermati)
Tweeter:...............1” Super Tweeter
Woofer:.......................................4,5”
Crossover:........................................2.800Hz
Gamma di frequenze:.............50-35.000Hz
Sensibilita`: (1W / 1M).........................87dB
Impedenza:..........................................4 ohm
Potenza richiesta:......................10 - 100 W
Dimensioni: mm 126x200x175 (L x A x P)
Per ulteriori informazioni vedere
l’accluso manuale d’instruzione
Audio Pro.
Image 12
Image 12 Technical data.pmd 2004-02-24, 15:594

Ubicación:
Vea el manual de instrucciones Audio
Pro adjunto para obtener más
información.
Audio Pro AB, Helsingborg, Sweden
Datos técnicos:
Tipo:...........................................Caja cerrada
Altavoces
Tweeter:..........................Cúpula de 1”
Woofer:..........................................4,5 ”
Frecuencia de cruce:......................2.800Hz
Banda de frecuencias:.........50 – 35.000Hz
Sensibilidad: (1W / 1M).......................87dB
Impedancia: ........................................4 ohm
Requisitos de amplificador:.....10 – 100 W
Dimensiones:(AxAxP mm).....126x200x175
Español
Image 12
