Audioplex MMX 4056 IR TARGET PACKAGE User manual

MMX 4056 IR TARGET PACKAGE
Used as a remote receiver and processor
SPECIFICATIONS:
INSTALLATION:
Connector: Pigtails.
Mounting: Fits into most standard single electrical junction boxes.
Remotes: Will handle almost all standard remote controllers (Note: does NOT work
with B & O equipment, which requires a proprietary confirmation talk-back
function).
Range: 26 feet indoors, 15 to 20 feet in direct sunlight.
Acceptance angle: + or - 55 degrees off center.
Wire: Uses conventional unshielded "zip" or telephone wire.
Power: 12 VDC @ 500 mA (unregulated (equals 15 volts), Included with packages)
Your IRTarget is designed to act as a remote receiver and processor of infrared signals.
This sensor will receive signals from remote controllers and send these signals to a remote
repeater. This allows remote operation of any unit from the room where the IRTarget is located.
CAUTION: Take care to make sure that the IRTarget installation is NOT IN THE LINE OF
SIGHT OR REFLECTION with the repeater. If radiation from the repeater is picked up by this
sensor, a feedback situation is created which will result in instability and unreliable operation.
Undesirable reflection can occur off of light colored walls, windows, mirrors, and even shiny wood
finishes! Also note that the wiring of the unit varies, depending on the type of infrared equipment
that is being used (see back of this page for wiring diagrams). Please call if you have any questions
about your installation.
Any standard type of wire can be used. Shielded or coaxial cable is not usually required
unless the wire passes through some unusually high electrical interference regions.
Prepare the wire leads to and from the IRTarget by stripping about 1/4" of insulation from
each of the ends. Twist strands tightly together so that none stick out to cause a possible short
circuit. OBSERVE POLARITY! The sensor will not function if the wires are not in order.
WARRANTY
Your AUDIOPLEX TECHNOLOGY IRTarget is covered by a Lifetime warranty against
defects in workmanship and materials. Any defects will be remedied without charge for labor or
parts.
Damage incurred by shipping or accident is not considered to be a defect, and not covered
by this warranty. AUDIOPLEX TECHNOLOGY is not responsible for defective operation caused
by abuse or by modification or service by an unauthorized person or agency.
The unit must be properly installed and operated according to instructions for the
warranty to apply. Any necessary servicing must be done by AUDIOPLEX TECHNOLOGY. The
products must be returned expences prepaid, with written authorization from the company. The
unit must be shipped with the proof of purchase and in the original carton and packing material
to avoid damage.
TECHNOLOGY
INSTALLATION MANUAL
(Patent Pending)
2004 - 1/22/04
DX

WIRING DIAGRAMS
(NOTE: 12 volt power supply and IRBug/IRFlood are supplied with IRTarget packages only)
AUDIOPLEX TECHNOLOGY
404 GWH P.O. BOX 440
MELVIN VILLAGE, N.H. 03850
1-800-257-2077 IN N.H. 1-603-544-8601
FAX: [phone]
FOR INSTALLATIONS USING AUDIOPLEX TECHNOLOGY INFRARED EQUIPMENT
TM
NILES is a registered trademark of Niles Audio Corporation, Inc.
XANTECH is a registered trademark of Xantech Corporation.
2004 - 1/22/04
TEST
out to emitters
12 vdc system status(optional)
1/8" test input connector
UNREGULATED
12 vdc power supply
ROOM 2ROOM 3
T
S
G
V
T
V
S
G
T
V
S
G
T
V
S
G
T
V
S
G
T
V
S
G
ROOM 4ROOM 5ROOM 6
SYS-TAT(optional)
SIGNAL
GROUND
12 VDC
BLUE
YELLOW
BLACK
RED
OPTIONAL SYS-TAT
SIGNAL
GROUND (GD)
12-15V (B+)
IRStation (Back View)
IRStation (Front View)
In-wall version shown, chassis version also available
Using IRStation / IRZ-1/ Niles / Xantech Connector Blocks
TM
DX
GD GD
IRBug/IRFlood or Emitter Plate
(up to 8 emitters in parallel)
UNREGULATED
12 VDC POWER
SUPPLY
OPTIONAL
12 VDC SYS-TAT
POWER SUPPLY TO
SWITCHED OUTLET
BLACK GROUND (GD)
YELLOW SIGNAL
WHITE STRIPED
RED 12-15V (B+)
BLUE SYS-TAT (Optional)
Termination Block
IR-TB SS
V
G
S
T
V
G
S
T
Using IRTarget Direct Wired to Emitters (no connector device)
MMX 4056
IRTarget
MMX 4056
IRTarget
