This unit is designed for installation in cars, trucks, and vans with an existing radio opening. In many cases, a
specialinstallationkitwillberequiredtomounttheradio to the dashboard. Thesekitsareavailableatelectronics
supply stores and car stereo specialist shops. Always check the kit application before purchasing to make sure the
kitworks withyour vehicle.If youneed akit butcannot findit available,call ourtoll-free “HELP”line at 1-800-645-4994.
UNIVERSAL INSTALLATION PROCEDURE USING MOUNTING SLEEVE
1. Slide the mounting sleeve off of the chassis. If it is locked into position, use the removal tools (supplied)
to disengage it.
2. Checkthedashboardopeningsizebyslidingthemountingsleeveintoit. Iftheopeningisnotlargeenough,carefully
cut or file as necessary until the sleeve easily slides into the opening. Do not force the sleeve into the opening
or cause it to bend or bow. Check that there will be sufficient space behind the dashboard for the radio chassis.
3. Locate the series of bend tabs along the top, bottom, and sides of the mounting sleeve. With the sleeve
fully inserted into the dashboard opening, bend as many of the tabs outward as necessary so that the
sleeve is firmly secured to the dashboard.
4. Place the radio in front of the dashboard opening so that the wiring can be brought through the mounting
sleeve. Follow the wiring diagram carefully and make certain all connections of the wiring harness are
secureand insulated with wire nuts or electrical tapeto insure proper operation of the unit. Aftercompleting
the wiring connections, turn the unit on to confirm operation (ignition switch must be “on”). If unit does not
operate, re-check all wiring until problem is corrected.
NOTE: AdjustAM antenna trimmer NOW. Referto label on rightside ofchassis foradjustment instructions.
Onceproperoperationisachieved,turnofftheignitionswitchandproceedwithfinal mounting ofthechassis.
5. Carefully slide the radio into the mounting sleeve making sure it is right-side-up until it is fully seated and
the spring clips lock it into place.
6. Attach one end of the perforated support strap (supplied) to the screw stud on the rear of the chassis using
the hex nut provided. Fasten the other end of the perforated strap to a secure part of the dashboard either
above or below the radio using the screw provided. Bend the strap to position it as necessary.
CAUTION: The rear of the radio must be supported with the strap to prevent damage to the dashboard
from the weight of the radio or improper operation due to vibration.
7. Test radio operation by referring to the Operating Instructions.
INSTALLATION USING KITS
1. If your vehicle requires the use of an installation kit to mount this radio, follow the instructions included with
the installation kit to attach the radio to the mounting plate supplied with the kit.
2. Wire and test the radio as described in Step 4 above.
3. Install the radio/mounting plate assembly to the sub-dashboard according to the instructions of the installation kit.
4. Attach the support strap to the radio and dashboard as described in Step 6 above.
5. Replace the dashboard trim panel.
ISO INSTALLATION PROCEDURE
This unit has threaded holes in the chassis side panels which may be used with the original factory mounting
brackets of some Toyota, Nissan, Mitsubishi, Isuzu, Hyundai and Honda vehicles to mount the radio to the
dashboard. Please consult with your local car stereo specialist shop for assistance on this type of installation.
1. Remove the existing factory radio from its dashboard or center console mounting. Save all hardware and
brackets as they will be used to mount the new radio.
2. Carefully un-snap the plastic frame from the front of the new radio chassis. Remove and discard the frame.
3. Remove the factory mounting brackets and hardware from the existing radio and attach them to the new radio.
CAUTION: DO NOT EXCEED M5 X 6 MM MAXIMUM SCREW SIZE.
LONGER SCREWS MAY TOUCH AND DAMAGE COMPONENTS INSIDE THE CHASSIS.
4. Wire the new radio to the vehicle as per step 4 above.
5. Mount the new radio assembly to the dashboard or center console using the reverse procedure of step 1.

128-5807B
3 of 44
INSTINST INSTINST
INSTALLALL
ALLALL
ALLAA
AA
ATT
TT
TION INSTRUCION INSTRUC
ION INSTRUCION INSTRUC
ION INSTRUCTT
TT
TIONSIONS
IONSIONS
IONS
22
22
2
8:30AM - 7PM
9AM - 5PM
CENTRAL EASTERN
6:30AM - 5PM
7AM - 3PM
MOUNTAIN
5:30AM - 4PM
6AM - 2PM
PACIFIC
MON. - FRI.
SATURDAY
DAY
TT
TT
TOLL-FREE INSTOLL-FREE INST
OLL-FREE INSTOLL-FREE INST
OLL-FREE INSTALLALL
ALLALL
ALLAA
AA
ATT
TT
TION ASSISTION ASSIST
ION ASSISTION ASSIST
ION ASSISTAA
AA
ANCENCE
NCENCE
NCE
The installation and wiring connections for this unit are so simple, we doubt you'll need our help, but, if you
do, we're here to help you. Just call our toll-free telephone assistance line at 1-800-645-4994 during the days
and hours shown (U.S.A. and Canada only).
7:30AM - 6PM
8AM - 4PM
NUT (5MM) EXISTING DASH OPENING
FILE EDGES TO FIT IF NECESSARY - DO NOT OVERFILE
NOTE: IF DASH IS SOLID, USE REAR SIDE (WITHOUT THE LIP) OF
MOUNTINGSLEEVEASATEMPLATE&CUT OPENING
UNIVERSAL INSTALLATION USING MOUNTING SLEEVEUNIVERSAL INSTALLATION USING MOUNTING SLEEVE
UNIVERSAL INSTALLATION USING MOUNTING SLEEVEUNIVERSAL INSTALLATION USING MOUNTING SLEEVE
UNIVERSAL INSTALLATION USING MOUNTING SLEEVE
REMOVE THE PLASTIC FRAME FROM THE FRONT OF THE
CHASSIS BY CAREFULLY UN-SNAPPING IT.
TYPICAL INSTALLATION
ISO INSTALLATIONISO INSTALLATION
ISO INSTALLATIONISO INSTALLATION
ISO INSTALLATION
20° MAX.
FRONT PANEL
CAUTION:
FORPROPEROPERATIONOFTHE CDPLAYER,THECHASSIS MUST BE
MOUNTED WITHIN 20° OF HORIZONTAL. MAKESURETHEUNITIS
MOUNTED WITHIN THIS LIMITATION.
SIDE VIEW
OF
CHASSIS
UN-SNAP ON LEFT AND
RIGHT SIDES
MAXIMUM
SCREW SIZE
M5 x 6
MAXIMUM
SCREW SIZE
M5 x 6
PERFORATED STRAP
MOUNTING SLEEVE
PLASTIC FRAME FACTORY MOUNTING
BRACKETS
BEND BOTTOM
TABS DOWNWARD
BEND TOP
TABS UPWARD
RADIO
SCREW STUD
NOTE: PLASTIC FRAME MUST BE REMOVED (UN-SNAP ON LEFT
AND RIGHT SIDES) TO USE REMOVAL TOOLS.
REMOVAL TOOLS
FASTEN THIS END TO SECURE
PART OF DASHBOARD.
DRILL HOLE IF NECESSARY.
FASTEN THIS END TO SCREW
STUD ON REAR OF CHASSIS
SCREW
(5MM)

128-5807B
4 of 44
BLACK
ANTENNASOCKET
ON REAR OF RADIO
POSITIVE (+) TERMINAL
12 VOLT BATTERY
CARBATTERY
METAL PART OF DASH
(DRILL HOLE IF
NECESSARY)
SCREW
RADIO
SEE PAGE 4 FOR
SPEAKER WIRING
ANTENNA AUTOMATIC
ANTENNA
CAR
FUSEBLOCK
IMPORTANT
THEBLUEWIRECANBEUSED
TO REMOTELY ACTIVATE AN
AUTOMATICANTENNAORAN
EXTERNAL AMPLIFIER (SEE
ANTENNA OR AMPLIFIER
MANUAL)
BLUE (0.5 AMP FUSE)
"RADIO" OR
"ACCESSORY" FUSE
EXISTING
ANTENNA
CABLE
RED (0.5 AMP FUSE)
IMPORTANT
THISWIREMUSTBECONNECTED
AS SHOWN OR RADIO WILL NOT
OPERATE PROPERLY
YELLOW (5 AMP FUSE)
RADIO WIRING
RR
RR
RAA
AA
ADIO WIRINGDIO WIRING
DIO WIRINGDIO WIRING
DIO WIRING
REFER TO PAGE 4 FOR SPEAKER WIRING
33
33
3

128-5807B
5 of 44
SPESPE
SPESPE
SPEAA
AA
AKK
KK
KER WIRINGER WIRING
ER WIRINGER WIRING
ER WIRING
44
44
4
SPEAKER WIRINGSPEAKER WIRING
SPEAKER WIRINGSPEAKER WIRING
SPEAKER WIRING
REFER TO PAGE 3
FOR RADIO WIRING
RCAJACKS
LINEOUT
FOR USE WITH
OPTIONAL
EXTERNAL
AMPLIFIERS
RED=RIGHTREAR
WHITE=LEFTREAR
WHITEw/BLACK STRIPE
WHITE
LEFTFRONT SPEAKER RIGHT FRONTSPEAKER
LEFTREAR SPEAKER RIGHTREARSPEAKER
GREEN
GRAYw/BLACK STRIPE
9-PINPLUGS
GREENw/BLACK STRIPE
WARNING!
lTHE AMPLIFIERS IN THIS RADIO ARE ONLY DESIGNED FOR USE WITH 4 SPEAKERS.
lNEVER COMBINE (BRIDGE) OUTPUTS FOR USE WITH 2 SPEAKERS.
lNEVER GROUND NEGATIVE SPEAKER LEADS TO CHASSIS GROUND.
lFAILURE TO WIRE EXACTLY AS SHOWN BELOW MAY CAUSE ELECTRICAL
VIOLETw/BLACK STRIPE
RADIO
8:30am - 7:00pm Eastern
9:00am - 5:00pm Eastern
Monday - Friday
Saturday
1-800-645-49941-800-645-4994
1-800-645-49941-800-645-4994
1-800-645-4994
HELP!
GRAY
VIOLET
4-PINPLUGS
SEE PAGE 3 FOR
RADIOWIRING
8-PIN DIN SOCKET FOR CONNECTION TO
OPTIONAL CD CHANGER
6
COMP AC T
DIN CABLE
(SUPPLIED WITH
CD CHANGER).
OPTIONAL
CD CHANGER
NOTE:
CHECK WITH YOUR RAMPAGE/AUDIOVOX CAR
STEREO SPECIALIST OR CALL 1-800-645-4994 FOR
RECOMMENDATIONS OF THE MODELS THAT WILL
WORK WITH YOUR RADIO.
